CHAPTER 7 Bone Tissue Tissues

1
CHAPTER 7Bone Tissue- Tissues Organs of the
Skeletal System- Histology of Osseous Tissue-
Bone Development- Physiology of Osseous
Tissue- Bone Disorders CHAPTER 8The Skeletal
System Introduction
2
Bone Tissue

• bone is osseous connective tissue
• Bone cells
• Collagen
• Calcium phosphate and other minerals made hard by
  the calcification process

3
A Bone

• A bone (like the femur) is an ORGAN made of
• Osseous tissue
• Blood
• Bone marrow
• Cartilage
• Adipose tissue
• Nervous tissue
• Fibrous connective tissue

4
The Skeletal system

• is the combination of all these tissues and
  includes the organs
• Bones
• Cartilage
• Ligaments

5
Skeletal system functions

• TABLE 7.1
• Support of the body
• Protection of the organs
• Movement of the body
• blood formation
• electrolyte balance of blood
• acid-base balance of blood
• detoxification of blood

6
Bones of the skeletal system

• Figure 8.1 and Table 8.1
• 206 bones in adult human
• But there are some variations

7
The skeletal system is divided into two main
parts

• Axial skeleton
• skull
• middle ear bones
• hyoid bone
• vertebral column
• rib cage
• sternum
• Appendicular skeleton
• upper (arms) lower (legs) extremities
• pectoral (chest) pelvic (hip) girdles

8
(No Transcript)
9
(No Transcript)
10
Shapes of Bones

• Long
• longer than they are wide
• act as levers for movements
• examples femur, radius, phalanges, etc.
• Short
• length is about equal to width
• examples carpals tarsals

11
A. The Shape of Bones (p. 229, Fig.
8.2) B. General Features of Bones (p. 229, Fig.
8.3) C. Elaborations of Bone Structure
(p. 231, Fig. 8.4, Table 8.3)
12
Shapes of Bones (cont).

• Flat
• form an enclosure protect
• examples cranium, scapulae
• Irregular
• none of the above
• examples vertebrae, certain skull bones

13
(No Transcript)
14
General features of bones

• Long Bone Anatomy
• osseous tissue
• Compact bone
• Spongy bone
• medullary cavity
• diaphysis
• epiphysis
• articular cartilage
• nutrient foramina

15
(No Transcript)
16
General features of bones

• Long Bone Anatomy
• osseous tissue
• Compact bone
• Spongy bone
• medullary cavity
• diaphysis
• epiphysis
• articular cartilage
• nutrient foramina

17
(No Transcript)
18

• Periosteum
• Covers bone
• Dense irregular CT
• And bone forming cells
• Perforating fibers
• collagen fibers connect bone and periosteum
• Some of these are continuous with connective
  tissue of tendons
• Endosteum
• Lines medullary cavity
• Reticular CT
• And bone-forming cells (osteogenic cells)

19

• Epiphyseal plate
• Made of hyaline cartilage
• Located between epiphysis diaphysis in children
  and teens
• Functions as a growth zone in long bones
• Disappears at age 18-20
• Adults have only epiphyseal line

20
(No Transcript)
21
Flat bone anatomy

• Notice how flat bones also have compact and
  spongy bone.
• They are just arranged differently
• Flat bones are often found in the skull

22
(No Transcript)
23
Bone have many dents, holes, rough spots, etc.

• elevations
• Depressions
• canals
• holes
• slits

24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Four types of bone cells
Bone as a tissue..

• osteogenic cells
• osteoblasts
• osteocytes
• osteoclasts

28
Osteogenic cells

• Location
• endosteum,
• inner layer of periosteum,
• central canals
• Function
• provide the source of new bone cells
• divide to form osteoblasts

29
(No Transcript)
30
Osteoblasts

• Locations
• Inner layer of endosteum and periosteum
• Functions
• Synthesize collagen
• Mineralize bone
• Form lacunae
• do not divide

31
(No Transcript)
32
Osteoblasts

• When osteoblasts become surrounded collagen and
  minerals (bone), they no longer produce more
  collagen.
• They are now called OSTEOCYTES

33
Osteocytes

• Remain connected to other osteocytes by gap
  junctions.
• Thru gap junctions, they pass along the need for
  more bone material to the surface osteoblasts
• Osteoblasts then can make more bone tissue.

34
(No Transcript)
35
(No Transcript)
36
Osteoclasts

• Function
• move minerals from bone into blood.
• dissolve matrix using acids enzymes
• Structure
• Large cells arising from white blood cells
• Monocytes (wbcs) fuse to form osteoclasts
• Howships lacunae depressions etched into bone
  surface by osteoclasts

37
(No Transcript)
38
What is bone matrix made of?
Bone as a tissue..

• Flexible organic portion
• collagen
• Glycosaminoglycans (GAGs)
• proteoglycans glycoproteins
• Hard inorganic portion
• hydroxyapatite
• calcium phosphate
• calcium carbonate
• Mg, K, Na, OH, F,

39
Osseous Tissue Matrix

• Bone without minerals bends too easily. (rickets)
• Bone without collagen breaks too easily. (brittle
  bone disease)

40
Histology of Compact Bone

• Osteon
• concentric lamellae, central canals, osteocytes
  in lacunae
• Blood vessels
• in central canals nourish bone remove wastes
• Perforating canals
• connect to central canals at right angles
• Nutrient flow
• central canals to inner and outer osteocytes
• Waste flow
• outer and inner osteocytes to central canal

41
(No Transcript)
42
Histology of compact bone (cont.)

• Canaliculi
• tiny channels in matrix containing cytoplasmic
  processes of osteocytes
• osteocytes joined by gap junctions in canaliculi

43
(No Transcript)
44
(No Transcript)
45
Histology of Spongy Bone

• trabeculae instead of osteons
• lattice of spines, rods, plates
• develop along lines of stress
• still lamellar, but no central canals
• bone marrow
• in space between trabeculae
• osteocytes are close to marrow blood supply

46
(No Transcript)
47
Bone Marrow

• soft tissue in
• medullary cavity of long bones
• between trabeculae of spongy bones
• and large central canals
• 3 kinds of marrow
• red
• yellow
• gelatinous

48
Red Marrow (myeloid tissue)

• In children
• found in most bones
• In adult
• in axial skeleton
• In proximal heads of femur humerus
• hemopoietic (makes blood cells)

49
Yellow Marrow

• adult
• in shafts of long bones
• arises from red marrow of childs bone
• contains fat
• no longer hemopoietic, but can revert

50
(No Transcript)
51
Glutinous Marrow

• in geriatric adults only
• reddish, jellylike tissue
• fat mostly gone

52
Formation of flat bonesIntramembranous
ossification

• intramembranous (within membrane)
• occurs in flat bones
• Some cranial bones
• ossification formation of bone

53
Intramembranous ossification(flatbones)

• During fetal development a CT sheet forms
• Blood vessels grow into the CT
• Osteogenic cells form
• Osteogenic cells become osteoblasts
• Osteoblasts make trabeculae
• osteoblasts become osteocytes
• trabeculae form spongy bone
• superficial trabeculae become calcified and
  condense (remodel) into compact bone

54
Osteoid Tissue soft collagenous tissue similar
to bone, except matrix has no minerals. When it
mineralizes, then its called bone tissue.
55
Long bone formationEndochondral ossification

• Endowithin
• Chondralcartilage

56
In fetal development

• Hyaline cartilage forms in the shape of bones
• Osteoblasts form on the surface, and make a bony
  covering around the cartilage
• chondrocytes in diaphysis multiply, grow larger,
  then die
• Calcium accumulates in matrix
• Spongy bone is formed

57
(No Transcript)
58
Primary Ossification Center

• Osteoclasts hollow out a marrow cavity
• Marrow forms for blood production

59
(No Transcript)
60
Secondary Ossification Center

• Secondary centers of bone formation form in both
  the epiphyses
• the epiphyses always retain spongy bone

61
Typical state of a long bone at birth
62
Metaphysis (growth plate)

• located between epiphysis and diaphysis)
• zone of reserve (resting) cartilage
• zone of cell proliferation -
• chondrocytes multiply, arrange into columns
• zone of hypertrophy
• Chondrocytes get larger
• zone of calcification
• Cartilage matrix starts to calcify
• zone of bone deposition
• Osteoblasts and osteoclasts (and osteogenic
  cells!) arrive
• SEE FIG 7.9

63
(No Transcript)
64
Bone growth in the metaphysis

• Resting cartilage cells lie next to epiphysis
• Cartilage cells closer to the diaphysis
  proliferate and form long columns
• These cells enlarge and push the reserve
  cartilage toward the bone ends, making the bone
  lengthen.
• Cartilage cells start to die, and bone cells
  invade the area.
• Bone cells make new bone material, strengthening
  the elongated bone.

65
(No Transcript)
66

• Green arrows Zone of Resting Cartilage
• Blue arrows Zone of Proliferation
• Black arrows Zone of Hypertrophy

67
Red arrows Zone of calcification White arrows
point to new bone Yellow arrows point to
calcified cartilage
68
(No Transcript)
69
BONE GROWTH

• Bones grow longer during childhood using the
  metaphysis.
• High levels of estrogen and testosterone increase
  bone lengthening during puberty
• Higher levels of estrogen and testosterone stop
  bone lengthening after puberty

70
Bone remodeling

• Osteoblasts are active throughout life
• Shape and contour changes occur on the surface of
  bone or in the cavities of bone
• Broken bones can mend
• Bones cannot lengthen after puberty

71

• Bone length is added by
• multiplication hypertrophy of chondrocytes
  interstitial growth
• Bone width and contours are added by
• Osteoblasts form new bone on the surface of an
  existing bone appositional growth

72
Achondroplastic dwarfism

• Is a genetic disorder where chondrocytes in the
  zones of cell proliferation and cell hypertrophy
  fail to multiply and enlarge during childhood.

73
(No Transcript)
74
mineral deposition

• When calcium and phosphate concentrations reach a
  critical point in tissues, they crystalize onto
  collagen fibers. The first hydroxyapetite
  crystals encourage more crystals to form.
• Minerals plus collagen equals bone tissue.

75
Mineral resorption -- process of dissolving bone

• Calcium and phosphate from bone can be released
  back to blood for use in other areas.
• Osteoclasts use Hydrochloric acid and acid
  phosphatase to dissolve bone

76
mineral resorption

• Is often caused by physical stress
• example braces on teeth
• osteoclasts resorb minerals on one side of tooth
  socket (zone of higher pressure)
• osteoblasts deposit minerals on opposite side
  (zone of reduced pressure)
• Osteocytes can detect stress on bones

77
calcium phosphate homeostasis

• bone is a reservoir for these minerals
• 99 of body Calcium is in bone
• 90 of body Phosphate is in bone
• Phosphate is important for
• Calcium is needed for
• Muscle contraction, nerve, conduction, blood
  clotting

• DNA, RNA, ATP, phospholipid synthesis

78
calcium phosphate homeostasis

• hypocalcemia
• Deficiency of blood calcium
• leads to tetany and spasms of muscle
• carpopedal spasm
• Laryngospasm
• death

79
(No Transcript)
80
calcium phosphate homeostasis

• hypercalcemia
• an excess of blood calcium
• leads to depression of nervous system
• muscle weakness
• emotional upset
• cardiac arrest

81
Hormonal homeostasis of calcium

• calcitonin
• a hormone secreted by thyroid
• lowers blood calcium levels
• osteoclasts are inhibited
• osteoblasts are stimulated

82
Hormonal homeostasis of calcium

• parathyroid hormone
• released by parathyroid glands
• raises blood calcium levels by
• Stimulating osteoclasts
• Promotes calcium reabsorption at kidney
• promotes vitamin D synthesis and allowing vitamin
  D to raise blood calcium
• Inhibits collagen synthesis by osteoblasts,
  inhibiting deposition of calcium in bone

83
Vitamin D or calcitriol

• considered a hormone
• made by combined actions of sun, skin, liver,
  kidneys
• Promotes intestinal absorption of calcium and
  phosphorous
• Prevents rickets, osteomalacia

84
How vitamin D is made

• Keratinocytes contain 7-dehydrocholesterol
• Sunlight converts 7-dehydrocholesterol into
  previtamin D3 and then vitamin D3
• Transport proteins carry vitamin D3 to blood
• Vitamin D3 travels to liver and is converted into
  calcidiol
• Calcidiol travels to kidney and changed to
  calcitriol (active vitamin D).

85
(No Transcript)
86
Other hormones

• Growth hormone
• Thyroid hormone
• Insulin
• Estrogen
• Testosterone

87
Bone Disorders

• Fractures
• Rickets
• Osteomalacia
• Osteogenesis imperfecta (brittle bone disease)
• Osteoporosis
• Osteomyelitis
• Bone cancers

88
Fractures -- types

• Closed
• Open
• Complete
• Incomplete
• Greenstick
• Hairline
• Comminuted
• Displaced

89
(No Transcript)
90
Special fractures

• Colles distal end of radius
• Common in older women (assoc w/ osteoporosis)
• Pott distal end of tibia, fibula, both
• Common sports injury
• Epiphyseal fractures - in children
• Can affect ability for that bone to continue
  growing

91
(No Transcript)
92
(No Transcript)
93
Healing of fractures

• Hematoma formation
• Blood vessels of bone and periosteum disrupted
  bleeding clot formation
• Granulation tissue formation
• Soft fibrous tissue - fibroblasts first repair
  cells to arrive in area local osteogenic cells
  start dividing osteoclasts, osteoblasts invade
  from periosteum and endosteum
• Soft callus formation
• Fibroblasts deposit collagen osteogenic cells
  differentiate into chondroblasts- produce
  fibrocartilage
• Hard callus formation
• Other osteogenic cells differentiate into
  osteoblasts - form boney collar
• Remodeling - over about 3 to 4 months

94
(No Transcript)
95
(No Transcript)
96
(No Transcript)
97
Osteoporosis

• Most common bone disease
• Bones lose mass - both organic matrix and mineral
• Highest incidence in elderly white and asian
  women african americans and hispanics also
  susceptible
• Increased frequency of fractures ( about 40 of
  50 year old women will fracture a bone during
  their remaining lifetime)
• Greatest risk in post-menopausal women
• Estrogen stimulates osteoblasts
• Also occurs in amenorrheal younger women
• Boniva, Fosamax - new treatment

98
osteoporosis

• What types of treatments would you suggest?
• You have all the resources you want!
