FCI ST50 ,

1
???????? ?????????? FCI ST50 ??? ???????,
??????? ??????? ? ?????

• Economy Mass Flow Measurement Better Solution
  Than Orifice, Venturi, Vortex and All Thermal
  Supplier

2
ST50 Thermal Mass Flow Meters for Air, Compressed
Air and Nitrogen

• New, Small-Sized, Professional Grade Enclosure
• Dual Wiring Accesses
• Blind Transmitter or Digital Display Versions
• Easy-to-Order for Field Set-up or Full Factory
  Set-up
• DC or AC Power Versions
• Dual Analog Outputs and Optional Pulse Output
• ½ or ¾ NPT
• Choice of SS or Teflon Ferrule
• Choice of 6, 12 or 18 Length Element with
  Adjustable U
• 316SS Probe Element
• Unique Hast-C Tip

3
ST50 Series Flow Meters

• Differentiated to Be Best Value For Specific
  Industry and Application Segments
• Price Positioned to Take Share from Alternate,
  Non-Thermal Technologies
• Matched Features and Functions Used By Targets to
  Position Underneath Over-Featured/Over-Priced
  Thermal Guys (and take share from them!)
• Targeted to Wastewater Treatment and
  Industrial/Commercial Aeration Applications,
  Plant Compressor Air/Energy Management, and
  Simple Nitrogen Flow Metering

4
Model ST50 Flow Meter

• Designed for Air, Compressed Air and Nitrogen
  Application in Pipe Sizes 2 to 12
• Easy to Specify
• - Three Core Types Blind, w/Local Display,
  w/Remote Display
• - Three U Lengths 6, 12, 18
• - Standard Flow Ranges (0.75 400 SFPS)
• Robust Design, Industrial Ready, Easy to Install
• - Single Penetration, ½ or ¾ NPT
• SS and Teflon Ferrule Options
• - All Metal NEMA 4X Housing
• Removable Caps on Both Ends For Easy Wire-Up and
  Servicing
• - 316SS Element with HastC Tips

5
Model ST50 Flow Meter

• Dual Analog Outputs Standard, Pulse Output Option
• 4-20mA and 0-10V
• Dual analog out complies with de-facto spec
  common to wastewater treatment documents.
• Optional 0-1kHz Pulse Output for Total Flow
• Digital Display Optional
• 9999 count large LCD user scaleable
• to engineering units or as 0.0 to 100.0
• Choice of Built-in (integral) or remote
• Includes IR sensor part of
• PDA IR Comm Link

6
Model ST50 Flow Meter

• Exclusive, New Wireless IR link for Standard
  PDA Option
• - Read Measurements, Configure/Set-up, and
  Extract Service Codes from Common, Low Cost PDA
• - Great for Hard-to-Reach Installations
• (that have line-of-sight access from
  ordinary plant location)
• Saves Time and Cost
• Perform service checks without opening unit
• - For Use with Palm-OS based PDA
• Palm-OS is Most Common and Prevalent
• WIN-CE OS Future Development if Demand
  Warrants
• - Requires ST50 with Digital Display Option and
  Ordering of Software CD Accessory

7
ST50 Wireless IR Link CommunicationVia PDA with
Palm-OS

• FCI Exclusive, Unique Capability
• No Other Thermal Supplier Providing
• For Use With Any Palm-OS Based PDA
• Note WIN-CE Not Supported (yet)
• Optional Feature
• Requires ST50 Version with Digital Display
• Models ST50-3, ST50-4, ST50-5 or ST50-6
• Hardware is Included with these Models
• Requires Software Accessory Option
• CD, Instructions, Upgrade License, etc.
• Software Can Be Added/Shipped Separately Anytime
• Sales Opportunity just in case, order digital
  display version

Requires line of sight. Usable distance 10 (3m)
IrDA
8
ST50 PDA Communication Option
Set-Up Menus

• Features
• All FC88 Functions and more
• Logging Totalizer values
• with time stamps
• Calibration Downloads
• Walk-by Diagnostics
• Data Storage, 64mB - 512mB
• Website Upgradeable

9
ST50 PDA Communication Option

• Features
• Password protected calibration file downloads
• Stored/Download
• No more Hand coefficient entries

10
Three New, Accessory Digital Readouts Added to
Enhance Total Solution Sale

• Easy Way to Increase Sales Revenue (Your
  Commissions!) per Order and Increase Service to
  the Customer (Yes, theyll work with other
  FCI products, too)

DM15 - Panel Mount LED Type - AC Line Powered -
Accepts 4-20mA or 0-10V

• DM10
• - Loop-Powered LCD Type
• Drops into 4-20mA signal anywhere

• DM20
• - Pulse Input Totalizer, Miniature, Panel Mount,
  LCD
• 8-digit, Front Panel Reset Button
• Self-Powered by Battery (10 year life and its
  included)

11
Target Industries/Applications

• Municipal Wastewater Treatment Plants
• Aeration Basins
• Global Aeration Applications Diverging Two
  Directions
• Industrial Self-Treatment Wastewater Plants
• Food Processors
• Chemical Plants
• Pulp Paper Mills
• Aquaculture Farms, Ponds and Lakes
• Aeration System

• Plant Expansion and Maintenance Upgrades Focused
  on Meeting Existing Spec with Lowest Cost
  Solution
• Elevated Price Competition Among Thermal Mfgrs
• FCI Answer ST50

Increased Plant Automation Driving Requirement
for Sophisticated Communications/Bus
Protocols (e.g. ProfiBus, HART) FCI Answer
ST98
12
Target Industries/Applications

• Industrial Manufacturing
• - Air Intake and Exhaust Lines With Blowers,
  Dryers, Furnaces and Burners
• - Paint Booth Exhaust and Ventilation Lines
• Food Processing
• - Air Intake and Circulation For Dryers, Ovens,
  Roasters, Blender/Mixers, Vacuum Sealing Machines
• - Nitrogen to Freeze Driers
• Commercial/Large Building HVAC
• - Duct and Damper Control
• All Plants
• - Air Compressor Main Intakes
• - Compressor Distribution Line Leak Detection

13
But, When Should I RecommendST98B/ST98 for
Similar Applications?

• When Better Accuracy is Needed
• - ST98s 1 vs. ST50 2
• For Gas Applications Other Than Air, C-A or
  Nitrogen
• When Pipe Size is Greater than 12
• - ST50 limited to 12 maximum
• When More Readings Are Needed From Built-in
  Display
• - ST98 has fancier 2 line x 16 character type
  that will display both flow and total, with
  engineering units
• In Hazardous Location/When Approvals Are Required
• - ST98s have them, ST50 do not
• When Communications Protocols Required
• HART, Profi-Bus, etc.
• When Greater Security Against Contamination is
  Needed
• - ST98 All Welded Element vs. ST50 Press Fit
• When More Range Is Needed in Compressed Air
• - ST98 goes to 600 SFPS vs. ST50 to 400 SFPS
