Analysis of DNA methylation patterns at the CNG

1
Analysis of DNA methylation patterns at the CNG
Jörg Tost, Ph.D. Group Leader Epigenetics

• Paris, 12.5.2005

tost_at_cng.fr
2
DNA based variations
3
Biological significance of DNA methylation

• X inactivation
• Imprinting
• Essential for embryogenesis and development
• Genome integrity
• Association with transcriptional activity (in
  some cases)

4
DNA methylation in disease

• Cancer
• Complex disorders
• - Type 2 Diabetes
• Imprinting disorders
• - Beckwith-Wiedemann syndrome
• - Silver Russel syndrome
• - Prader-Willi syndrome
• - Angelman syndrome
• Neurodevelopmental disorders
• - Fragile X
• - ICF
• - Rett syndrome

5
Aberrant methylation pattern
6
but no black and white situation
7
Methylation acts as allele inactivating hit, but
is reversible
Balmain et al., Nature Genetics  33, 238 - 244
(2003)
8
Methods for DNA methylation analysis

• Global methylation levels
• In situ detection of methylated cytosines
• Methylation sensitive restriction endonucleases
• Bisulphite conversion

9
Bisulphite conversion of DNA
10
Matrix-assisted laser desorption/ionization
time-of-flight mass spectrometry(MALDI ToF MS)
3-hydroxypicolinic acid
This picture was kindly provided by Ole Brandt.
11
GOOD assay for the analysis and quantification
of DNA methylation patterns

• Freeze methylation status by treatment with
  sodium bisulphite

Tost et al., NAR, 2003, e50
12
High-throughput epigenotyping in the MHC
13
Tissue specific methylation patterns
Promoter BF
DAXX Exon 1
14
DNA methylation based clustering for GSTP1 in
breast cancer samples
Ronneberg, Tost et al., manuscript under revision
15
The Pyrosequencing technology
Pictures reproduced from the application note A
new light on DNA, A. Sylvan, 2000
16
Workflow for pyrosequencing based DNA methylation
analysis
17
Methylation profiles of the GSTP1 promoter in
cancerous prostate biopsies
Four sequencing primers analyse 15 out of 17 CpGs
within the amplified fragment
Tost et al., BioTechniques, 2003, e50
18
Serial pyrosequencing for quantitative DNA
methylation analysis

• Cost reduction
• Accellerates workflow
• Saves precious DNA resources

Tost et al., BioTechniques, 2006, June Issue
19
The IGF2/H19 locus
Picture taken from the website of the Biology
Department - University of Nevada, Reno
20
11p15.5
21
IGF2 variable methylation degree at consecutive
CpGs
a.Maternal Blood Cells (MBC, n17)
Methylation level ()
Methylation level ()
b. Early Term Placentas (ETP, n6)
0 2 4 6 8
10 12 14 16
18 20
0 2 4 6 8 10

Methylation level ()
Methylation level ()
0 2 4 6 8
10 12 14 16
18 20
0 2 4 6 8 10

c. Full Term Placentas (FTP, n16)
Methylation level ()
Methylation level ()
0 2 4 6 8
10 12 14 16
18 20
0 2 4 6 8 10
Position of analysed CpG
Position analysed CpG
22
Cancer DNA methylation projects at CNG

• Breast Cancer (Human)
• in collab. with Prof. Vessela Kristensen (Radium
  Hospital, Oslo, Norway) 450 samples, 15 genes,
  Status analysis of the first 96 samples
• Lung Cancer (Human)
• in collab. with Dr. Zdenko Herceg (IACR, Lyon,
  France) pilot study 96 samples, 4 genes, Status
  analysis of the samples
• Liver Cancer (Human)
• in collab. with Dr. Catherine Cavard and Dr.
  Benoit Terris (Cochin Hospital, Paris, France) 96
  samples, 11 genes, Status analysis of the
  samples
• Pancreatic Cancer (Mouse Model)
• in collab. with Dr. Chang Zhang (University of
  Lyon, France) 13 mice (5 organs of each), 6
  genes, Status first round finished, reproduction
  of results

23
hMlh1 methylation in microsatellite instable
colon cancers
DNA extracted from tumor
DNA extracted from normal adjacent tissue
24
Pyrosequencing based methylation assays developed
at CNG
Cancer assays
25
Pyrosequencing based methylation assays developed
at CNG
All assays
26
Pipeline for epigenetic analysis
27
Acknowledgments

• Centre National de Génotypage, Evry
• The Epigenetics Laboratory
• Hafida El abdalaoui
• Florence Busato
• Emelyne Dejeux
• Virginie Audard (Hopital Cochin)
• Ivo Gut
• Mark Lathrop
• Collaborators
• Jean-Michel Dupont (University Paris V, Hopital
  Cochin)
• Hélène Jammes, Daniel Vaiman (INSERM U709,
  Hopital Cochin, Paris)
• Catherine Cavard and Benoit Terris (Hopital
  Cochin, Paris)
• Vessela Kristensen (Radium Hospital Oslo, Norway)
• Zdenko Herceg (IACR, Lyon)
• Tim Frayling and Andrew Hattersley (Peninsular
  Medical School, Exeter, UK)
• Chang Zhang (University of Lyon)
