IBM DataPower PCI Solutions

1
IBM DataPowerPCI Solutions

• Steven Cawn
• WebSphere DataPower World Wide Sales leader
• scawn_at_us.ibm.com

2
What is PCI DSS?

• Payment Card Industry Data Security Standard (PCI
  DSS) is a global security program that was
  created to increase confidence in the payment
  card industry and reduce risks to PCI Members,
  Merchants, Service Providers and Consumers.

3
Payment Card Industry History
Defined by the Payment Card Industry Security
Standards Council, the standard was created to
increase controls around cardholder data to
reduce credit card fraud via its exposure.
Validation of compliance is done annually  by an
external Qualified Security Assessor (QSA) for
organizations handling large volumes of
transactions, or by Self-Assessment Questionnaire
(SAQ) for companies handling smaller volumes.

• Initial specifications adopted December 2004
• 1.1 Specifications adopted September 2006
• 1.2 Specifications adopted October 2008
• 1.2.1 specifications adopted August 2009
• 2.0 specifications adopted October 2010
• As of January 2011, every institution must abide
  by 2.0 specifications

4
To Whom Does PCI DSS Apply?

• All merchants service providers that store,
  process, use, or transmit cardholder data
• Retail (e-commerce brick mortar)
• Hospitality (restaurants, hotels, casinos)
• Convenience Stores (gas stations, fast food)
• Transportation (airlines, car rental, travel
  agencies)
• Financial Services (credit card processors,
  banks, insurance companies)
• Healthcare/Education (hospitals, universities)
• Government (where payment cards are accepted)

5
PCI DSS Requirements The Digital Dozen
Build and Maintain a Secure Network Build and Maintain a Secure Network
1. Install and maintain a firewall configuration to protect cardholder data
2. Do not use vendor-supplied defaults for system passwords and other security parameters
Protect Cardholder Data Protect Cardholder Data
3. Protect stored cardholder data
4. Encrypt transmission of cardholder data sent across open, public networks
Maintain a Vulnerability Management Program Maintain a Vulnerability Management Program
5. Use and regularly update anti-virus software
6. Develop and maintain secure systems and applications
Implement Strong Access Control Measures Implement Strong Access Control Measures
7. Restrict access to cardholder data by business need-to-know
8. Assign a unique ID to each person with computer access
9. Restrict physical access to cardholder data
Regularly Monitor and Test Networks Regularly Monitor and Test Networks
10. Track and monitor all access to network resources and cardholder data
11. Regularly test security systems and processes
Maintain an Information Security Policy Maintain an Information Security Policy
12. Maintain a policy that addresses information security Connected Entities and Contracts
PCI DSS Ver. 1.1
6
PCI Non-Compliance Consequences (Global)

• If non-compliant and a breach occurs
• Merchants/Service Providers have liability for
  the acquirer bank's losses, cost of the
  investigations, litigation costs and card
  re-issuance costs
• Fines per incident from Visa (against acquiring
  bank)
• Restrictions imposed by card companies
  (prohibiting future credit card processing)
• Repayment of losses may exceed the ability to pay
  and cause total failure of the organization
• Other potential consequences
• Damaged brand reputation
• Invasive media attention
• Loss of customers

7
Over to 1,800 worldwide installations and growing
Government

• Agencies and ministries
• Defense and security organizations
• Crown corporations

Banking

• 80 of top 100 Banks
• Numerous regional banks and credit unions
• SaaS providers, ASPs, regulators, etc.

Insurance

• Used by 95 of top global insurances firms
• SaaS providers, ASPs, regulators, etc.

Many, many, more

• Retailers
• Utilities, Power, Oil and Gas
• Airlines
• etc.

8
What are WebSphere DataPower Appliances?
Business Value The purpose of WebSphere
DataPower Appliances is to take the hard parts
of SOA deployments (service security,
integration, ESB, load distribution, etc.) that
are traditionally performed by software on
application servers, yet have nothing to do with
Business Logic, and move those hard parts into
highly efficient hardened configuration driven
devices in the network. By moving this
computationally intensive grunt work into the
network, your application servers regain cycles
to do what you pay for them to do Run Business
Logic
8
8
9
What are WebSphere DataPower Appliances?
Product Value Specialized purpose-built
hardened embedded network devices that take the
hard parts of SOA security and integration
traditionally requiring complex and costly
software systems and delivers them in a simple
uncrate, rack, configure and deploy platform.
Powerful and uniquely efficient message and file
oriented configuration-driven Security and
Integration platform with the extremely low
operational TCO of a true network device.
9
9
10
WebSphere DataPower - Use Cases
Internet
DMZ
Trusted Domain
Application
Business
1 B2B Partner Gateway
Application
2 Secure Gateway (Web Services, Web
Applications) 3 Intelligent Load
Distribution
4 Internal Security 5 Light Weight Integration 6
Web Service Management 7 Legacy Integration 8
Run time SOA Governance
Consumer
Mobile
System z
11
WebSphere DataPower and the PCI DSS Digital
Dozen
Complete solution

• WebSphere DataPower ideal solution for many
  requirements
• Build and Maintain a Secure Network
• Requirement 1 Install and maintain a firewall
  configuration to protect cardholder data
• Requirement 2 Do not use vendor-supplied
  defaults for system passwords and other security
  parameters
• Protect Cardholder Data
• Requirement 3 Protect stored cardholder data
• Requirement 4 Encrypt transmission of cardholder
  data across open, public networks
• Maintain a Vulnerability Management Program
• Requirement 5 Use and regularly update
  anti-virus software
• Requirement 6 Develop and maintain secure
  systems and applications
• Implement Strong Access Control Measures
• Requirement 7 Restrict access to cardholder data
  by business need-to-know
• Requirement 8 Assign a unique ID to each person
  with computer access
• Requirement 9 Restrict physical access to
  cardholder data

Part of solution
12
DataPower - Key Functions for PCI Compliance
Easy to Use Appliance Purpose-Built for SOA
Security
Req. 1

• Web Services (XML) - Filter on any content,
  metadata or network variables
• Web Application Firewall - HTTP Protocol
  Filtering, Threat Protection, Cookie Handling
• Data Validation - Approve incoming/outgoing Web
  traffic, Web Services, XML at wirespeed
• Field Level Security - WS-Security, encrypt
  sign individual fields, non-repudiation
• Encryption of transport layer - HTTP, HTTPS, SSL.
• Anti Virus Protection - messages and attachments
  checked for viruses integrates with corporate
  virus checking software through ICAP protocol
• XML Web Services Access Control/AAA - SAML,
  LDAP, RADIUS, etc
• Management Logging - manage track services,
  logging of all activities, audit.
• Security Policy Management - security policies
  universally understood by multiple software
  solutions, eases PCI certification process.
• Easy Configuration Management - WebGUI, CLI,
  IDE and Eclipse Configuration to address broad
  organizational needs (Architects, Developers,
  Network Operations, Security)

Req. 3,4
Req. 5
Req. 7,8,9
Req. 10
Req. 12
13
WebSphere DataPower Protecting Cardholder Data
Encrypted digitally signed Message ltCredit
Cardgt ltCustgtBrian P. Belllt/Custgt ltEncrypted CCNgt
ws389maz301lt/Encrypted CCNgt ltCredit
TypegtAMEXlt/Credit Typegt . lt/Credit Cardgt
Incoming Message data not encrypted ltCredit
Cardgt ltCustgtBrian P. Belllt/Custgt ltCreditCardNumber
gt 3732 955939 395500lt/CreditCardNumbergt ltCredit
TypegtAMEXlt/Credit Typegt . lt/Credit Cardgt
Encrypted XML data is delivered to the database
to the encrypted credit card for later use
Client sends credit card information to be stored
in the database though an supported protocol
Protocols HTTP/s, MQ, Tibco, JMS, FTPs, NFS, etc
Database
Direct DB Connect
Response message is sent confirming the insertion
of the encrypted credit card number into the
database
Response message is received confirming the
insertion of the encrypted credit card number
into the database
Key Functions Terminate SSL Defend against XML
threats Validate XML (schema) Authentication Autho
rization Audit/Transaction Logging Filter
data Encrypt/Decrypt message Digitally sign
message Mask back-end resources Route based on
content
Requirement 3 Protect stored cardholder
data. Requirement 4 Encrypt transmission of
cardholder data across open, public networks.
14
Access Control Credential Mapping
Requirement 7 Restrict access to cardholder data
by business need-to-know. Requirement 8 Assign a
unique ID to each person with computer access.

1. Client send request to App Server
2. Request carry client username Password
3. DataPower will authenticate client
4. DataPower will map credentials for unified
   communication with backend

Assuming all authentic users are authorized.
Otherwise TAM or similar must be used for
Authorization
15
DataPower Anti-Virus Protection

• Allows messages and attachments to be checked for
  viruses
• Integrates with corporate virus checking software
  through the ICAP protocol
• Anti-Virus Processing Actioneases configuration
  and use ofthis capability
• Includes pre-configured HostTypes (CLAM,
  Symantec, Trend, Webwasher) as well as
  customizability

16
Logging of Transactions
Requirement 10 Track and monitor all access to
network resources and cardholder data.

• DataPower can Log transactions passing through it
  to
• On-the-box File System
• Database
• Network File System
• MQ queues
• FTP Server
• DataPower could be integrated with monitoring
  software via
• SNMP protocol (not vendor specific)
• DataPower could integrate with Antivirus for
  attachments scanning

Requirement 5 Use and regularly update anti-virus
software
17
Protection against Open Web Application Security
Project (OWASP) Top 10 Attacks
 Top 10 Most Critical Web Application Security
Risks
18
Open Web Application Security Project Compliance
Provides Protection Against 100 Of OWASP Top
10 Risks
19
DataPower has deployments cross industry for PCI
Compliance

•


National Uniform Provider
Major Prepaid Wireless carrier
Large US based Insurance Provider
Telecommunication Provider in Australia
20
Summary Business Benefits

• Key Reusable Core IT Functionality Solves
  complex SOA IT service integration and security
  challenges in a secure, easy to consume and
  extremely low TCO network device
• Configuration Driven All enforced policies and
  mediations are configuration driven, not
  programmed. This significantly simplifies and
  reduces deployment requirements and cost
• Flexibility Secure, integrate, bridge and
  version applications without application
  modification
• Reduce Complexity Do work in the network as
  the data flows over the wire instead of on
  application servers, reducing infrastructure
  footprint and freeing up application servers to
  run more business logic
• Reduce Time to Market Dramatically decrease the
  time to deploy in your environment. Being a
  configuration-driven platform, most deployments
  are uncrate, rack, configure and deploy
• Reduce Risk Takes the grunt work out of SOA
  application security and integration allowing you
  to focus on building your business logic. In the
  network platform allows improved security and
  audit capabilities without application
  modification
• Lower TCO Its a network device. Customers own
  data has shown that DataPower appliances can be
  7X-8X less expensive to operate in the data
  center than software alternatives
• A New Approach These are not software
  pre-installed on servers. DataPower applies
  sophisticated embedded technology to solve
  complex IT challenges in new and novel ways

20
21
DataPower Product Family Highlights

• B2B Appliance XB62
• B2B Messaging (AS1/AS2/AS3/EDI)
• Trading Partner Profile Management
• B2B Transaction Viewer
• Support for HL7 and EDIfact Industry Pack

• Integration Appliance XI50B, XI50z, XI52
• Hardware ESB
• Any-to-Any Conversion at wire-speed
• Bridges multiple protocols
• Integrated message-level security
• Network Load Balancing

• Service Gateway XG45
• Enhanced Security Capabilities
• Centralized Policy Enforcement
• Fine-grained Authorization and Authentication
• Network Load Balancing

22
Additional Information

• WebSphere DataPower home page
• http//www-01.ibm.com/software/integration/datapow
  er
• WebSphere DataPower Information Center (online
  help)
• http//pic.dhe.ibm.com/infocenter/wsdatap/v5r0m0/i
  ndex.jsp
• developerWorks
• http//www.ibm.com/developerworks/websphere/zones/
  businessintegration/dp.html
• WebSphere Education
• http//www.ibm.com/software/websphere/education/
• IBM Software Services for WebSphere
• http//www.ibm.com/developerworks/websphere/servic
  es/
• IBM WebSphere DataPower SOA Appliance Handbook
• http//www.ibmpressbooks.com/bookstore/product.asp
  ?isbn9780137148196
• DataPower SOA Appliance Customer Forum
• http//www.ibm.com/developerworks/forums/forum.jsp
  a?forumID1198

23
Additional Information

• Global WebSphere Community
• http//www.websphereusergroup.org/datapower
• Technotes
• http//www.ibm.com/search/csass/search?qsnspel
  angenfiltercollectionstgsysx,dblue,ic,pubs,dev
  rel1prodU692969C82819Q63
• DataPower Redbooks
• http//www.redbooks.ibm.com/cgi-bin/searchsite.cgi
  ?querydatapower
• DataPower on YouTube
• http//www.youtube.com/watch?vLRy0twFpmUQ
• zEnterprise and PCI-DSS compliance
• http//www.businesswire.com/news/home/201003080066
  57/en/atsec-Publishes-Payment-Card-Industry-Compli
  ance-Large
• Certification Whitepaper regarding PCI Compliance
• http//www.atsec.com/downloads/white-papers/PCI_Co
  mpliance_for_LCS.pdf
• DataPower OWASP White Paper
• ftp//submit.boulder.ibm.com/sales/ssi/ecm/en/wsw1
  4196usen/WSW14196USEN.PDF

24

Thank You
25
OWASP DataPower Compliance Details
26
Threat A1- Injection

• Threat description
• Injection flaws, such as SQL, Command shell, or
  LDAP injection, occur when untrusted data is sent
  to an interpreter as part of a command or query.
  The attackers hostile data can trick the
  interpreter into executing unintended commands,
  or accessing unauthorized data.
• DataPower mitigation
• Data type checking for invalid input
• XML Threat protection setting for XPath injection

• SQL injection filter configuration rejects SQL
  injections
• Regular-expression filters used as a catch-all
  for shell injections, LDAP calls, PHP code, or
  any other programming language

27
Threat A2 - Cross-Site Scripting (XSS)

• Threat description
• XSS flaws occur whenever an application takes
  untrusted data and sends it to a web browser
  without proper validation and escaping. XSS
  allows attackers to execute scripts in the
  victims browser which can hijack user sessions,
  deface web sites, or redirect the user to
  malicious sites.
• DataPower mitigation
• Native XSS filter configuration for rejecting
  incoming/outgoing traffic that contains XSS
  content

28
Threat A3 - Broken Authentication and Session
Management

• Threat description
• Application functions related to authentication
  and session management are often not implemented
  correctly, allowing attackers to compromise
  passwords, keys, session tokens, or exploit other
  implementation flaws to assume other users
  identities.
• DataPower mitigation
• Broad security standards support, i.e.
  WS-Security, XACML, SAML, SSL/TLS
• Out-of-the-box integration with many
  industry-leading PDP solutions, such as Tivoli
  Access Manager, Active Directory, LDAP,
  SiteMinder, etc.
• Centralized platform for Security governance
• Tools for configurable AAA and Crypto processing,
  as well as key protection

29
Threat A4 - Insecure Direct Object References

• Threat description
• A direct object reference occurs when a developer
  exposes a reference to an internal implementation
  object, such as a file, directory, or database
  key. Without an access control check or other
  protection, attackers can manipulate these
  references to access unauthorized data.
• DataPower mitigation
• Enforces security decisions based on properly
  classified users authorized to specific resources
  and actions in a policy.
• Transforms and exposes indirect object
  identifiers that are mapped to direct object
  identifiers at the application, such as
  references to a SSN or an Account number.

30
Threat A5 - Cross-Site Request Forgery (CSRF)

• Threat description
• A CSRF attack forces a logged-on victims browser
  to send a forged HTTP request, including the
  victims session cookie and any other
  automatically included authentication
  information, to a vulnerable web application.
  This allows the attacker to force the victims
  browser to generate requests the vulnerable
  application thinks are legitimate requests from
  the victim.
• DataPower mitigation
• Provides several building blocks to prevent such
  attacks
• Creation, or checking Nonce values
• Generation, or validation Digital Signatures on
  each request
• Creation, or confirmation for Hash values
• Injection, or parsing of secondary session
  cookies present in hidden HTTP fields

31
Threat A6 - Security Misconfiguration

• Threat description
• Security misconfiguration can happen at any level
  of an application stack, including the platform,
  web server, application server, framework, and
  custom code. The system could be completely
  compromised without one knowing it. Causing all
  data to be stolen, or modified slowly over time.
• DataPowers mitigation
• DataPower can't solve this problem alone, but it
  can significantly reduce the scope of what must
  be configured, or programmed
• By pulling security policies and functions away
  from application servers and centralizing them on
  DataPower, the chance of security
  misconfiguration is reduced because the number of
  systems that contain security processing code is
  also reduced.
• Additionally, centralizing corporate wide
  security policies on a common gateway means that
  services that trust the gateway are all
  configured to share a consistent security policy
  among them.

32
Threat A7 - Insecure Cryptographic Storage

• Threat description
• Many web applications do not properly protect
  sensitive data, such as credit cards, SSNs, and
  authentication credentials, with appropriate
  encryption or hashing. Attackers may steal or
  modify such weakly protected data to conduct
  identity theft, credit card fraud, or other
  crimes
• DataPower mitigation
• Standards based cryptographic processing, such as
  encryption and hash operations
• Secured key material stored in the encrypted part
  of the file system
• Encrypts sensitive data and stores it in a
  database. Providing authorized applications to
  access confidential data through DataPower in
  essence functioning as a Data-as-a-Service (DaaS)
  provider

33
Threat A8 - Failure to Restrict URL Access

• Threat description
• Many web applications check URL access rights
  before rendering protected links and buttons.
  However, applications need to perform similar
  access control checks each time these pages are
  accessed, or attackers will be able to forge URLs
  to access these hidden pages anyway.
• DataPower mitigation
• Leverage DataPowers explicit white-list policy
  model using Matching rules
• Enforces per-request authentication and
  resource-based authorization based on the AAA
  framework
• URL-Rewrites to hide the original URL of the
  backend application

34
Threat A9 - Insufficient Transport Layer
Protection

• Threat description
• Applications frequently fail to authenticate,
  encrypt, and protect the confidentiality and
  integrity of sensitive network traffic. When they
  do, they sometimes support weak algorithms, use
  expired or invalid certificates, or do not use
  them correctly.
• DataPower mitigation
• SSL Proxy configuration secures traffic using
  SSL/TLS
• Strong SSL Cipher suite is available and enabled
  by default
• Clients can be trusted using mutual
  authentication
• CRL and OCSP support ensures certificates are
  valid and trusted
• The key material is stored securely in an
  encrypted portion of the flash memory

35
Threat A10 - Invalid Redirects and Forwards

• Threat description
• Web applications frequently redirect and forward
  users to other pages and websites, and use
  untrusted data to determine the destination
  pages. Without proper validation, attackers can
  redirect victims to phishing or malware sites, or
  use forwards to access unauthorized pages.
• DataPower mitigation
• Applications not expecting Re-directs can be
  configured to reject HTTP 302
• HTTP Front-side handler, User-Agent and URL
  Re-write configurations can be used to flag and
  reject these requests as potential threats
