1
Johannes Deelstra Agricultural University,
Wageningen, The Netherlands Jordforsk
2
Modelling in monitored catchments
Experiences from case studies in Norway
SOIL/SOILN_NO in the Skuterud catchment SOILNDB
in the Mørdre catchment
3
Location of catchments in the JOVÅ-programme
North pole
president Bush
Volvo
EU, y/n
4
The Skuterud catchment
In operation since 1993
Land use Area ( ha) Agricultural area
272 forest area 129 Bogs 10 roads,
farms 13 Housing area 25 Total
area 449
5
The Mørdre catchment
In operation since 1991
Land use Area (ha) Agricultural area
444 Forest 192 Bogs
27 Housing area, roads, etc 18 Sum
681
6
Measurement programme in JOVÅ-catchments
Discharge measurement Water sampling and
analysis(TDS, Ntot, Ptot)
runoff(mm) N,P,SS loss (ha-1)
7
Measurement programme in JOVÅ-catchments (contd)

• Collection of information on farming practices
• type of crop
• fertiliser application
• yield
• sowing/harvesting dates
• type/date of soil tillage

In addition soil mapping, profile
descriptions additional determinations of soil
physical parameters
8
Simulation Skuterud
The Soil model

• water and heat transport in the vertical profile

• daily meteorological data and soil physical
  parameters, initial values
• numerous switches to set

SOILN_NO, Norwegian version of the Swedish SOILN
model
- includes major nitrogen and carbon processes -
many inputs from SOIL - nitrogen application
including the dates of application, type of
crops, sowing and harvesting dates, crop yield
ploughing dates - MATLAB
NITROGEN LEACHING FROM THE ROOT-ZONE TO TILE
DRAINAGE/GROUNDWATER.
9
Skuterud
Simulation for each farmer field
Simulations No measures With measures Optimal
fertiliser application Catch crops Irrigation
10
Nitrogen runoffno measures
Skuterud
11
Optimal fertiliser application
Skuterud
Nitrogen loss with optimal fertiliser application
12
Catchcrops
Skuterud
Nitrogen loss when catchcrops
13
Irrigation
Skuterud
Nitrogen loss when irrigation
14
Comparison of measures
Skuterud
Effects() Opt. fert. appl. 4.7 , Catchcrops
20, Irrigation 12
15
Nitrogen leaching maps
Skuterud
16
Mørdre - SOILNDBLarsson et al. (2001), SLU

• A shell in Visual Basic, coupling SOIL og
  SOILN(SLU)
• To quantify N-loss from agricultural areas

17
Input og parameterisering

• Input preperation through Excel into
  SOILNDB-database
• climatological data
• soilsdata
• farming practices (fert., soil prep., etc)
• Parameter setting
• through SOILNDB-database (possibility to change)
• through changing program-code

18
Soils

• soil physical parameters (pF, ksat, texture, org.
  matter)
• two alternative sources
• from soil database in SOILNDB (10 USDA jordarter
  og 7 Nordic soil types.
• own data

Farming practices
crop type, fertiliser, type and quantity soil
tillage, type, date
19
Simulation procedure Mørdre
Simulation for individual farmer fields (input
farmer information) for 2 ha units(input SSB)
20
Results runoff(mm)
21
Results nitrogen losses
22
Summary

• both models user friendly
• SOIL/SOILN_NO/SOILNDB, one dimensional -
  catchment?
• one dimensional model
• size of catchment(limits?)
• surface runoff?
• validation of modelling results
• against total catchment runoff justified?
• what about flow processes?
• how to deal with variability in catchments
• soil physical parameters,
• sowing/harvesting, fertiliser application
