Telecommunications Engineering Topic 2: Modulation and FDMA

1
Telecommunications EngineeringTopic 2
Modulation and FDMA

• James K Beard, Ph.D.
• [phone]
• jkbeard_at_temple.edu
• http//astro.temple.edu/jkbeard/

2
Topics

• Homework
• Amplitude Modulation
• BPSK
• QPSK
• Summary
• Assignment
• References

3
Modulation

• Text section 3.2
• Defined as encoding data onto a carrier
• Transmitter signal
• Single frequency, or carrier, without modulation
• Spectrum about carrier frequency with modulation

4
Modulation Issues

• Spectrum
• Bandwidth of transmitted spectrum and bit rate
  are related
• Efficiency is a function of the modulation
• Multiple access
• Enables more than one user per channel
• Modulation concept is integrated with multiple
  access concept

5
Linear and Nonlinear Modulation

• Linear
• Sum of two modulated transmitters is same as
  modulation from sum of signals
• Multiplying input by a constant results in the
  output of the modulator scaled by that constant
• Nonlinear when either condition does not hold

6
Analog and Digital Modulation

• Analog modulation
• Signal is time-continuous
• Transmitted spectrum is, in general, a continuous
  spectrum
• Digital modulation
• Signal is discontinuous bit stream
• Transmitted spectrum falls off as 1/f or 1/f2

7
Amplitude and Angle Modulation

• Amplitude modulation
• The transmit signal is the carrier multiplied by
  a linear function of the signal
• The phase of the transmitted signal is constant
• Angle modulation
• The phase or frequency of the carrier is varied
  in the modulation process
• The amplitude of the transmitted signal is
  constant

8
Amplitude Modulation

• Text Section 3.3.1
• Definition
• Transmitted signal is product of
• Carrier signal unmodulated transmitter signal
• Data signal plus offset
• Offset is to make signal factor nonnegative
• Transmitted signal components
• Carrier from offset
• Sum and difference signals from data

9
BPSK

• Text section 3.3.2
• BPSK Binary Phase-Shift Keying
• Modulation is phase inversions
• Spectrum is splattered quite a bit
• Spectral lines separated by bit rate frequency
• Shape of spectral lines follows sinc function
• The sinc function spectrum
• Parameterized for pi/2 increments
• Result is 1/f envelope on lines

10
QPSK

• Text section 3.3.3
• QPSK Quadraphase-Shift Keying
• Similar to BPSK except four phases instead of two
• Variation Offset QPSK, or OQPSK
• Phase transitions confined to pi/4
• Elimination of pi/2 phase shifts improves
  spectrum
• Offset is related to mapping of code to waveform
• Chip rate doubles to implement code-waveform
  mapping

11
Spectral Efficiency

• Spectral efficiency means
• High percentage of signal spectrum in band
• Better pulse shape reproduction in receivers
• More accurate decoding at a given SNR
• Less crosstalk and cross-interference
• Higher spectral efficiency
• The first goal of the waveform designer
• Gains in efficiency with little added complexity

12
Improved Spectral Efficiency

• Baseline is square pulse
• Sinc function spectrum
• Rolloff is 1/f
• First cut is raised cosine
• Square spectrum with cosine transition
• Pulse is inverse Fourier transform
• Root raised cosine
• Square root of raised cosine in transmitter and
  receiver
• Transmitted pulse is inverse Fourier transform of
  square root of spectrum

13
Raised-Cosine Spectra
14
Raised-Cosine Pulses
15
Root Raised-Cosine Spectra
16
Root Raised-Cosine Pulses
17
RRC for (0,1,1,0,0)
18
Topics

• Continuous-phase modulation minimum shift
  keying (MSK)
• Power spectra of MSK signal
• Gaussian-filtered MSK
• Frequency division multiple access (FDMA)

19
Continuous-Phase Modulation

• Also called Minimum Shift Keying
• FSK with phase continuity between pulses
• Allows rolloff of 1/f4 as opposed to 1/f
• Define the difference in the number of cycles
  between the two frequencies over a pulse time as
  the deviation ratio h

20
Special Values of h

• When h is pi
• Phase is the same at the end of each pulse
• Starting phase is the same every time
• When h is pi/2
• Minimum for good spectral efficiency
• Starting phase can walk pi/2 per pulse
• Back to same phase every two pulses

21
Power Spectra of MSK Signal

• Fourier transform of signal shows 1/f4 rolloff

22
Gaussian-Filtered MSK

• Gaussian shape
• Represents a parabola on a dB plot
• Good first-order fit to many single-lobe curves
• Simple filters
• Main lobe of beam pattern
• Simple to work with
• Produces pulse as it would be transmitted
• Some spreading in time
• Good performance

23
Frequency Division Multiple Access

• FDMA
• Closely-spaced frequency channels in transmission
  band
• Cross-channel modulation controlled
• Waveform design
• Guard band

24
Summary

• Modulation
• Puts signal data on a carrier for transmission
• Linear or nonlinear
• Amplitude or angle
• Spectral efficiency
• Simple RC and RRC show first cut
• Gains are apparent using first principles
• MPSK provides good channel efficiency
• FDMA provides good multiplexing alternative

25
Assignment

• Read Text 3.4.1, 3.7.3-3.7.5, 3.8
• Read Bit Error Rate (BER), section 3.12

26
Bit Error Rates

• Examined here for simple receivers
• BPSK, QPSK, MSK, etc.
• No pulse shaping filters
• Purpose is to show
• Differences between fundamental modulation types
• The effect of the channel

27
High SNR Bit Error Rate
General equations in Table 3.4 p. 159
28
AWGN Bit Error Rates
29
High SNR AWGN Bit Error Rates
30
Rayleigh Fading Bit Error Rates
31
BER Conclusions

• AWGN BER
• BPSK/QPSK/MSK provide best performance
• Others are close enough to be useful
• Select best spectral control for best achievable
  BER
• Fading
• Low SNR area of fading pdf drives BER
• Significant variable fading forces high BER
• Houston, we have a problem

32
Study Problems and Reading Assignments

• Study examples and problems
• Problem 3.30, p. 177, Adjacent channel
  interference
• Problem 3.35 p. 178, look at part (a) part (b)
  was done in class
• Problem 3.36 p. 178, an intermediate difficulty
  problem in bit error rate using MSK
• Reading assignments
• Review Sections 4.1, 4.2 (EE300 material)
• Read Sections 4.3, 4.4

33
Okumrua-Hata Empirical Model

• Chapter 2, Theme Example 1, p. 82
• Equation for propagation loss in urban
  environments
• Example of empirical model
• Look at measured data
• Estimate form that measurement variations might
  take
• Do RMS fits of different equations to the data
• Select the ones that seem to work best

34
Parameters

• Range, valid from 1 km to 20 km
• Base station height, valid from 30 m to 200 m
• Receiver height, valid from 1 m to 10 m
• Operating frequency, valid from 150 MHz to 1 GHz

35
Forms of equations

• Base equation is
• Fit is to A, B, C
• Note that B is 10 times the propagation exponent

36
Results
37
Practice Quiz

• What are the three layers and their functions?
• Problem 2.22 p. 81, Link Budget
• Example 2.21 p. 83, Base Station Antenna Height
  using Okumrua-Hata model
• Problem 3.17 p. 173
