Lecture 7 Technical Analysis

1
Lecture 7Technical Analysis

• Economics 98 / 198
• Spring 2008

2
Current Events / News
Simulation Discussion
3
Lecture Content
4
Today

• Introduction to technical analysis
• Basics definitions
• Stock charts chart types
• Moving Averages
• Trends / Channels
• Support Resistance
• Volume

5
Technical Analysis? Huh?

• Dont get intimidated when you hear technical
  analysis
• Comes down to your supply and demand
• How is this different from fundamental analysis?
• Tries to make sense of market emotions by
  studying market actions

6
Chart Basics

• Technical Analysis Introduction to Stock Charts

7
Basic Terms

• Volatility
• Fluctuations
• 52-week high / low
• Price / trading range
• Open / closing price

8
Charts

• Maps price performance
• Sheds light on supply and demand
• investment roadmap
• Price / volume relationship important

9
Chart Types - Line Charts

• Most basic of all charts
• Just a line that connects the closing prices over
  a time frame
• No trading range

10
Chart Types Bar Chart

• Vertical line represents highs/lows of the day
• Horizontal line represents closing price
• Red down
• Blue/Black up

Daily High
Closing Price
Daily Low
Price Gap
11
Chart Types Candlestick Charts

• Vertical line represents the trading range
• Wide bar represents open and close
• White bar Up and closes above opening price
• Red Bar down
• Black bar up, but closes below the opening price

12
Chart Basics Time Scale

• Time Scale
• Dates along bottom of chart (varies from seconds
  to decades)
• Common Types intraday, daily, weekly, monthly
• Subtle differences between different time scales

13
Chart Basics Time Scale
Daily Chart
Weekly Chart
14
Volume

• Amount of shares that trade hands between seller
  and buyers
• Price movements more significant when volume is
  above average

15
Price and Volume
Average Volume
16
Trends are your Friends

• Trend general direction of stock
• Uptrend higher highs, higher lows

17
Sometimes, trends difficult to see
18
Trendlines

• Simply put, a line drawn connecting three lows to
  represent the overall trend
• Upward trendline represents support

19
Channels

• Two parallel trend lines that act as areas of
  support and resistance (more later)
• Any break through the channel is a break of the
  trend, otherwise the price should stay in range

20
SUPPORT / RESISTANCE

• Technical Analysis Introduction to Stock Charts

By Johns Wu thebulltrader.com
21
Chart Analysis Support

• Price at which BUYERS gt SELLERS consistently.
• Buyers who missed out on the first dip will be
  pressured to buy if price continues to respect
  the support.

22
AMZN Example of Supports
AMZN retraces from a monstrous rally to 60
AMZN stops tanking at 60. NOT A COINCIDENCE.
23
GOOG Support Psychology
510. MANNNN, I should have bought GOOG
!!
OK. Im not gonna miss out again. BUY _at_ 452
GOOG skyrockets from AWESOME earnings, but should
I buy it????
CAUTION Supports can breakdown.
24
Support Breakdowns

• SELL if support breaks down, because it
  signifies that BUYERS no longer overpower
  SELLERS.
• Breakdowns are a BEARISH SELL signal.

You should have sold here, at the BREAK DOWN.
25
Chart Analysis Resistance

• Price at which SELLERS overwhelm BUYERS
  consistently.
• When a stock makes a new high and then retraces,
  sellers who missed out _at_ the previous peak will
  feel pressured to sell when price climbs back to
  that level.

26
TM Resistance Psychology
Finally! 138. I better sell this time.
Should I sell?? Na, Ill take my chances.
I should have sold when TM was 138!!
27
Resistance Breakouts

• When price breaks out above resistance, it
  becomes a new support level. IMPORTANT
• Breakout signifies clear dominance of BUYERS.
  (good time to buy)
• This is a BULLISH BUY signal.
• My favorite trade setup.

28
TGT Resistance Breakout
BREAKOUT!!
RESISTANCE BECOMES SUPPORT
29
SHLD Breakout Trade
30
Moving Averages

• Technical Analysis Introduction to Stock Charts

31
Moving Averages (DMA or WMA)

• Most popular are 50-day and 200-day
• Shows the average price of the last days and
  plots it on a line
• Often acts as areas of support and/or resistance

32
WIRE Support _at_ 10 WMA
33
WIRE Support _at_ 10 WMA
34
CPA Support at 20 50 DMA
35
CPA Support at 20 50 DMA
20 DMA and 50 DMA becomes points of support for
this stock
36
So

• Charts are fundamental to technical analysis
• Important to understand what is shown on a chart
  and the information it conveys
• Chart patterns and bases to come

37
Tools for stock charts

• Technical Analysis Introduction to Stock Charts

38
Charting on StockCharts.com

• Getting comprehensive stock charts
• Type in the company symbol
• Once youre at the stock page, click on annotate
  to draw your own trendlines.
• From there, you will get lots of tools for
  analyzing stock charts

39
StockCharts.com
40
Annotating in StockCharts
41
Using Charts on Investors.com

• Log in using your username and password (you all
  have one as of now)
• Enter a symbol for the stock and then click on
  IBD Charts just below it
• There are links throughout the website that link
  to IBD charts
• Right clicking on the chart will give you
  important data for that day or week

42
Relative Strength Line
Moving averages
Volume
43
Homework / Reading

• Technical Analysis Introduction
• Investopedia Tutorial
• Link is on the download page of the website

44
Next Week

• Well be going over strategies using charts to
  buy stocks
• Timing market bottoms
• Identifying chart bases / patterns
• Timing your stock purchases (after youve done
  your research / stock screens)
• This is going to be the most technical /
  complicated part so make sure you understand the
  basics
