Title: System Design for Cognitive Radio Communications

1
System Design for Cognitive Radio Communications

2
Outline

3
Current State of Wireless

Wireless communication systems are evolving
substantially
New mobile radio systems aim at higher data rates
and a wide variety of applications
Higher capacity and performance required through
a more efficient use of limited resources
Two cutting edge solutions are UWB and cognitive
radio
UWB is considered to supplement Cognitive Radio

4
Cognitive Radio

Traditional system design allocates fixed amounts
of resources to the user
Adaptive design identifies the requirements of
the user, and then allocates just enough
resources
Introducing advanced attributes to the adaptive
design
Multi-dimensional awareness
Sensing
Learning
? Cognitive Radio

6
Opportunistic Spectrum Usage

Opportunistic Spectrum Usage
licensed bands can be utilized by secondary users
when they are not being used by their owners
leads to the most efficient exploitation of the
entire spectrum
The operation of unlicensed systems should not
affect the primary users

7
Spectrum Sensing

Cognitive radios periodically scan the spectrum
and detect the white bands
The target spectrum to be sensed should be
limited
The received signal can be sampled (after the
down-conversion) at or above the Nyquist rate and
can be processed digitally
The computational burden associated with spectrum
sensing
can be restricted to a reasonable level
? limited hardware complexity
The analog front-end required for a very wide
spectrum scan (wideband antenna, wideband
amplifiers and mixers), which have a rather high
cost, can be avoided
It can be prevented that a single type of
cognitive radio occupies the majority of the
bands that are open to opportunistic usage

8
Spectrum Sensing

Spectrum allocation for different types of
cognitive radios can be done by regulatory
agencies depending on
the intended range and
the throughput requirements
high data rate cognitive radios aiming at wide
range applications (like TV broadcast systems)
?wider target spectra at lower frequency bands
relatively low rate, short range communication
devices (like cordless phones)
?narrower bands at higher frequencies

9
Cooperation of Transmitter and Receiver

Both the transmitter and the receiver have
transmission
and reception capabilities
In order to match the results of the spectrum
sensing, each of them transmits the information
regarding the white spaces they have detected
The transmission of spectrum sensing results is
done via low power UWB signaling
Since UWB transmission will be underlay, it can
be done simultaneously with the real data
communication without affecting each other

10
Cooperation of Transmitter and Receiver

A low-complexity and low cost solution is OOK
based impulse radio UWB signaling using energy
detector receivers
Once both parties receive the spectrum sensing
information from the other party, they logically
AND the white spaces
Depending on these common white spaces, each
party designs a new pulse shape
what the receiving party uses as the template to
match the received pulse will be (almost) the
same as the transmitted pulse by the other party
? a successful matched filtering

11
Spectrum Shaping

Cognitive transceiver has to be able to
dynamically shape the spectrum of the transmitted
pulse to fill the spectrum opportunities
possible options
employing OFDM carriers as in the case of
UWB-OFDM
employing Prolate Spheroidal Wavelet Functions
(PSWF)
leakage from the opportunity bands to
the licensed systems in the adjacent bands
should be kept at a negligible level

12
Spectrum Shaping
13
Spectrum Shaping

16
Range of Cognitive Communications

In order to exchange the sensing information,
there should not be a gap between the sensing
ranges of both parties
the receiving sensitivity of both parties has an
important role in determining the range of
communication
We assume a rather high sensitivity around
-120dBm to -130dBm and free space propagation
? according to the Friis equation the range of
one-to-one cognitive communication is limited to
50m to 150m

17
Range of Cognitive Communications

18
Range of Cognitive Communications

A network of collaborating cognitive nodes may be
an effective solution
if the targeted range is wider than 50-150 m, or
if the cognitive devices are experiencing
shadowing (and are hardly able to detect the
primary users)
Consider a cognitive network whose nodes
communicate with each other using UWB to exchange
spectrum information

19
Range of Cognitive Communications

Looking at the BER expression for OOK modulated
UWB signals
it is seen that increasing Ns results in lower
BER, ? a very advantageous feature of UWB called
processing gain
By applying enough processing gain, farthest
nodes in a cognitive network can share the
spectrum sensing information

20
Range of Cognitive Communications

processing gain ? lowered throughput not a
limiting factor because a quite low data rate is
enough to transmit the spectrum sensing
information
By enabling all the nodes in a cognitive network
talk to each other via UWB, there is no need
to allocate a separate channel for sharing the
sensing information,
or to employ a centralized controller
The sensing information received from all the
other nodes in the network can be combined in
each node, and pulse design can be done
This way, the range of cognitive communications
can be extended to the coverage area of a
medium-sized network
