File Consistency in a Parallel Environment

1
File Consistency in a Parallel Environment

• Kenin Coloma
• kcoloma_at_ece.northwestern.edu

2
Outline

• Data consistency in parallel file systems
• Consistency Semantics
• File caching effect
• Consistency in MPI-IO
• 2-phase collective IO in ROMIO (a popular MPI-IO
  implementation)
• Intuitive Solutions
• Persistent File Domains
• PFDs - concept
• PFDs - statically blocked assignment
• PFDs - statically striped assignment
• PFDs - dynamic assignment
• Performance Comparisons
• Conclusions Future Work

3
Consistency Semantics

• POSIX and UNIX sequential consistency
• Once a write has returned, the resulting file
  must be visible to all processors
• MPI-IO sequential consistency
• Once a write has returned, the resulting file
  must be visible only to processors in the same
  Communicator
• If the underlying file system does not support
  POSIX or UNIX consistency semantics, MPI-IO must
  enforce its sequential consistency semantics
  itself

4
Caching and Consistency

• The client-server model for file systems often
  relies on client-side caching for performance
  benefits
• Client-side caching reduces the amount of data
  that needs to be transferred from the server
• NFS is one such file system, and does not enforce
  POSIX or UNIX consistency semantics

5
Caching and Consistency

• A simple example using MPI and unix io on NFS - 4
  procs

user buffers
p0
Open Seek(0 byte_off)
p1
p2
Read(16 bytes) Barrier
p3
client-side file caches
p0
Seek(rank4 byte_off) Write(4 bytes) Barrier
p1
p2
p3
Seek(0 byte_off) Read(16 bytes) Close
6
2-phase Collective IO in ROMIO

• 2-phase I/O, proposed and designed in PASSION (by
  Prof. Choudhary) is widely used in parallel I/O
  optimizations.
• MPI-IO implementation in ROMIO uses 2-phase
  collective I/O
• Advantages of collective IO
• Awareness of access patterns (often
  non-contiguous) of all participating processes
• Means of coordinating participating processes to
  optimize overall IO performance

7
2-phase Collective IO in ROMIO

• 2-phase IO
• Communication
• IO
• Reduce the number of IO calls to IO servers as
  well as the number of IO requests generated at
  the server
• All the IO done is more localized than it would
  otherwise be

2-phase Collective Write
User buffers
Comm. buffers
IO buffers
File
8
2-phase Collective IO in ROMIO

• A simple example to exhibit the file consistency
  problems even with collective IO in ROMIO - 4
  procs

user buffers
p0
MPI_File_open
p1
MPI_File_read_all() whole file
p2
p3
client-side file caches
MPI_File_write_all() stripe 1st half
p0
p1
p2
MPI_File_read_all() whole file
p3
MPI_File_close
9
Intuitive Solutions

• The cause obsolete data cached in client-side
  system buffer
• Simple solutions
• Disabling client-side caching
• entails changes to system configuration
• lose performance benefits of caching
• Use file locking
• can serialize I/O
• not feasible on large scale parallel systems
• effectively disables client-side caching
• Explicitly flushing out the cached data is the
  simplest solution, such as on Cplant
• ioctl(fd, BLKBLSBUF)
• fsync(fd) ensure the write reside on disk
• also effectively disables client-side caching

10
File locking

• File locking can cause IO serialization even if
  accesses do not logically overlap
• This is evident in collective IO where file
  domains never overlap

p0
p1
11
fsync and ioctl

• On Cplant
• Flush before every read
• Fsync after every write
• Performance ramifications
• Could be invalidating perfectly good data

Open Seek(0 byte_off) Read(16 bytes) Barrier Seek(
rank4 byte_off) Write(4 bytes) Barrier Seek(0
byte_off) Read(16 bytes) Close
lt fsync(fd)
12
Persistent File Domains

• Similar to the file domains concept in ROMIOs
  collective IO routines
• Enforces MPI-IO consistency semantics while
  retaining client-side file caching
• Safe concurrent accesses
• 3 - assignment strategies
• Statically blocked assignment
• Statically striped assignment
• Dynamic (on-the-fly) assignment

13
Statically blocked assignment
fsync(fd-gtfd_sys) ioctl(fd-gtfd_sys, BLKFLSBUF)

• Client side caches are coherent before starting
• File domains are kept the same between collective
  IO calls
• Maintain file consistency -- each byte can only
  be accessed by one processor
• Avoids excessive fsync and ioctl

MPI_File_open MPI_File_set_size MPI_File_read_all
MPI_File_write_all MPI_File_read_all MPI_File_clos
e
File size could be useful in creating file
domains Create file domains
Delete file domains
fsync(fd-gtfd_sys) ioctl(fd-gtfd_sys, BLKFLSBUF)
Compute Nodes
ENFS Servers File Domains
14
Statically blocked assignment

• Statically Blocked Assignment
• Based on equal division of whole file
• Least complexity least amount of changes to
  ROMIO
• ADIOI_Calc_aggregator() - just a calculation,
  based on
• File size
• Number of processes

15
Statically blocked assignment

• A Key Structure - ADIOI_Access
• struct
• ADIO_Offset offsets
• int lens
• MPI_Aint mem_ptrs
• int file_domains
• int count

my_reqsnprocs others_reqsnprocs
16
Statically blocked assignment
MPI_File_open MPI_File_set_size MPI_File_read_all
MPI_File_close
17
Statically blocked assignment
MPI_File_open MPI_File_set_size MPI_File_read_all
MPI_File_close
18
Statically blocked assignment
MPI_File_open MPI_File_set_size MPI_File_read_all
MPI_File_close
19
Statically blocked assignment
MPI_File_open MPI_File_set_size MPI_File_read_all
MPI_File_close
20
Statically blocked assignment
user buffers

• Drawback
• File inconsistency comes about when there are
  multiple IO calls often to different regions of
  the file rather than the whole file
• The previous point means that this assignment
  scheme will not be efficient unless accesses are
  rather large portions of file (3/4 of the file
  size)

p0
p1
p2
p3
client-side file caches
p0
p1
p2
p3
21
Statically striped assignment

• Statically Striped Assignment
• Based on a striping block size parameter passed
  to ROMIO through file system hints mechanism
• Somewhat more complex than statically blocked
  assignments
• Processes can own multiple file domains
• More end cases
• ADIOI_Calc_Aggregator() - still just a
  calculation, based on
• Striping block size
• Number of processes

22
Statically striped assignment
MPI_File_open MPI_File_set_size MPI_File_read_all
MPI_File_close
23
Statically striped assignment
buf_idx1

• One significant change due to processes having
  multiple file domains and communication
• Mapping communicated data to or from the user
  buffer

p0
p1
buf_idx1
p0
p1
p0
p1
24
Statically striped assignment
MPI_File_open MPI_File_set_size MPI_File_read_all
MPI_File_close
25
Statically striped assignment
26
Statically striped assignment
27
Statically striped assignment
user buffers

• Opportunity to match stripe size to access
  pattern
• Should work particularly well if the aggregate
  access regions for each IO call are fairly
  consistent nprocsstripe size
• This becomes less significant if the stripe size
  is greater than the data sieve buffer (dflt 4MB)

p0
p1
p2
p3
client-side file caches
p0
p1
p2
p3
28
Dynamically assigned

• Static approaches cannot autonomously adapt to
  actual file access patterns
• 2 approaches
• Incremental book keeping approach
• reassignment
• Most complex of the three
• Multiple file domains
• With respect to the file layout, file domains are
  irregular
• Assignment a definitive assignment policy must be
  established

p0
p1
p2
p3
p2
p3
p0
p1
write_all 1
write_all 2
29
Dynamically assigned

• ADIOI_Calc_aggregator will become a search
  function
• Augment ADIOI_Access
• Struct
• ADIO_Offset offsets
• int lens
• int count
• Data structure pointers (e.g. b tree)

30
Performance Comparisons
MPI_File_Open MPI_File_set_size() Loop
(iter) MPI_File_Read_all MPI_File_Write_all MPI_
File_close
Factors Collective Buffer Size (4MB) Stripe
Size in Application Available cache Aggregate
Access File size (Static Block) No. procs
31
Conclusions Future Work

• File consistency can be realized without locking
  or any changes to system configuration
• Except for the statically block assigned method,
  all the methods tested resulted in similar
  results
• The exact conditions under which each solution
  will perform best still need to be determined
  through further experimentation
• The Dynamic approach to persistent file domains
  is still unimplemented and is still under design
  considerations
• Reassignment vs. book keeping
• Specifics of each policy also need to be worked
  out

32
Data sieving in ROMIO
Read case

• Quick overview of data sieving
• Data sieving is best suited for small densely
  distributed non-contiguous accesses

User buffer
Data sieve buffer
File
