Global View of the Lee Model code

1
Global View of the Lee Model code

• S H Saw
• INTI International University, Nilai, Malaysia

2
3 kJ Plasma Focus Designed for International
Collaboration
3
Design of the UNU/ICTP PFF- 3kJ Plasma Focus
System??
4
UNU/ICTP PFF- narrow trolley to fit ICTP lift???
5
The Code

• From beginning of that program it was realized
  that the laboratory work should be complemented
  by computer simulation.
• A 2-phase model was developed in 1984
• We are continually developing the model to its
  present form
• It now includes thermodynamics data so the code
  can be operated in H2, D2, D-T, N2, O2, He, Ne,
  Ar, Kr,Xe.
• We have used it to simulate a wide range of
  plasma focus devices from the sub-kJ PF400
  (Chile) , the small 3kJ UNU/ICTP PFF (Network
  countries), the NX2 3kJ Hi Rep focus (Singapore),
  medium size tens of kJ DPF78 Poseidon (Germany)
  to the MJ PF1000, the largest in the world.
• An Iranian Group has modified the model, calling
  it the Lee model, to simulate Filippov type
  plasma focus .

6
Philosophy of our Modelling

• Experimental based
• Utility prioritised
• To cover the whole process- from lift-off, to
  axial, to all the radial sub-phases and recently
  to post-focussed phase which is important for
  advanced materials deposition and damage
  simulation.

7
Priority of Basis

• Energy consistent for the total process and each
  part of the process
• Mass consistent
• Charge consistent
• Connected to the reality of experiments

8
Priority of Results

• Applicable to all PF machines, existing and
  hypothetical
• Current Waveform accuracy
• Dynamics in agreement with experiments
• Consistency of Energy distribution
• Realistic Yields of neutrons, SXR, other
  radiations Ions and Plasma Stream in
  conformity with experiments
• Widest Scaling of the yields
• Insightful definition of scaling properties
• Design of new devices e.g. Hi V C-S
• Design of new experiments

9
Philosophy, modelling, results and applications
of the Lee Model code
10
Numerical Experiments

• Range of activities using the code is so wide
• Not theoretical
• Not simulation
• The only correct description is
• Numerical Experiments

11
PF1000

• Lo nH Co uF b cm a cm z0 ro mW
• 33.5 1332 16 11.6 60 6.1
• fm fc fmr fcr
• 0.13 0.7 0.35 0.65
• Vo Po Mw A At/Molecular
• 27 3.5 4 1 2

12
Firing the PF1000
13
Fitting PF1000 27kV-adjusting model parameters
until computed current waveform matches measured
(after getting L0 correct)
14
PF1000 fitted results
15
PF1000 Yn Focus Pinch Properties as functions
of Pressure
16
Plasma Focus- Numerical Experiments leading
Technology

• Numerical Experiments- For any problem, plan
  matrix, perform experiments, get results-
  sometimes surprising, leading to new insights
• In this way, the Numerical Experiments have
  pointed the way for technology to follow

17
NE showing the way for experiments and technology

• PF1000 (largest PF in world) 1997 was planning
  to reduce static inductance so as to increase
  current and neutron yield Yn. They published
  their L0 as 20 nH
• Using their published current waveform and
  parameters we showed their L0 33 nH
• that their L0 was already at optimum
• that lowering their L0 would be a waste of
  effort and resources

18
New General Insight- For every PF there is a
minimum L0 below which yield no longer increase

• It was thought that the lower L0 is the better
  would be the current and the yield
• Our NE showed that on the contrary every PF
  system has a minimum L0 no point trying to go
  below that- very expensive and will not increase
  yield
• This was a surprising result- and changes one
  frontier area of plasma focus technology

19
Determination of Pinch Current- by fitting a
measured current trace with reliable neutron
yield to the computed current trace.

• by fitting a measured current trace with reliable
  neutron yield to the computed current trace.

20
Results from Numerical Experiments with PF1000
- For decreasing L0- from 100 nH to 5 nH

• As L0 was reduced from 100 to 35 nH - As
  expected
• Ipeak increased from 1.66 to 3.5 MA
• Ipinch also increased, from 0.96 to 1.05 MA
• Further reduction from 35 to 5 nH
• Ipeak continue to increase from 3.5 to 4.4 MA
• Ipinch decreasing slightly to - Unexpected
• ? 1.03 MA at 20 nH,
• ? 1.0 MA at10 nH, and
• ? 0.97 MA at 5 nH.
• Yn also had a maximum value of 3.2x1011 at 35 nH.

21
Pinch Current Limitation Effect - (1/3)

• L0 decreases? higher Ipeak ?bigger a ?longer zp
  ?bigger Lp
• L0 decreases ?shorter rise time? shorter zo?
  smaller La
• L0 decreases, Ipinch/Ipeak decreases

22
Pinch Current Limitation Effect - (2/3)

• L0 decreases, L-C interaction time of capacitor
  decreases
• L0 decreases, duration of current drop increases
  due to bigger a
• ?Capacitor bank is more and more coupled to the
  inductive energy transfer
• ?

Effect is more pronounced at lower L0
23
Pinch Current Limitation Effect - (3/3)

• A combination of two complex effects
• Interplay of various inductances
• Increasing coupling of C0 to the inductive
  energetic processes as L0 is reduced
• Leads to this Limitation Effect
• Two basic circuit rules lead to such complex
  interplay of factors which was not foreseen
  revealed only by extensive numerical experiments

24
Neutron yield scaling laws and neutron saturation
problem

• One of most exciting properties of plasma focus
  is
• Early experiments show YnE02
• Prospect was raised in those early research years
  that, breakeven could be attained at several tens
  of MJ .
• However quickly shown that as E0 approaches 1 MJ,
  a neutron saturation effect was observed Yn does
  not increase as much as expected, as E0 was
  progressively raised towards 1 MJ.
• Question Is there a fundamental reason for Yn

25
Global Scaling LawScaling deterioration observed
in numerical experiments (small black crosses)
compared to measurements on various machines
(larger coloured crosses) Neutron saturation is
more aptly portrayed as a scaling
deterioration-Conclusion of IPFS-INTI UC research

• S Lee S H Saw, J Fusion Energy, 27 292-295
  (2008)
• S Lee, Plasma Phys. Control. Fusion, 50 (2008)
  105005
• S H Saw S Lee.. Nuclear Renewable Energy
  Sources Ankara, Turkey, 28 29 Sepr 2009.
• S Lee Appl Phys Lett 95, 151503 (2009)
• Cause Due to constant dynamic resistance
  relative to decreasing generator impedance

26
Scaling for large Plasma Focus

• Targets
• IFMIF (International fusion materials irradiation
  facility)-level fusion wall materials testing
• (a major test facility for the international
  programme to build a fusion reactor)

27
Fusion Wall materials testing at the mid-level of
IFMIF 1015 D-T neutrons per shot, 1 Hz, 1 year
for 0.1-1 dpa- Gribkov

• IPFS numerical Experiments

28
Fast capacitor bank 10x PF1000-Fully modelled-
1.5x1015 D-T neutrons per shot

• Operating Parameters 35kV, 14 Torr D-T
• Bank Parameters L033.5nH, C013320uF, r00.19mW

• E08.2 MJ
• Tube Parameters b35.1 cm, a25.3 cm z0220cm
• Ipeak7.3 MA, Ipinch3.0 MA
• Model parameters 0.13, 0.65, 0.35, 0.65

29
Ongoing IPFS numerical experiments of Multi-MJ
Plasma Focus
30
50 kV modelled- 1.2x1015 D-T neutrons per shot

• Operating Parameters 50kV, 40 Torr D-T
• Bank Parameters L033.5nH, C02000uF, r00.45mW
• E02.5 MJ
• Tube Parameters b20.9 cm, a15 cm z070cm
• Ipeak6.7 MA, Ipinch2.8 MA
• Model parameters 0.14, 0.7, 0.35, 0.7
• Improved performance going from 35 kV to 50 kV

31
IFMIF-scale device

• Numerical Experiments suggests the possibility of
  scaling the PF up to IFMIF mid-scale with a
  PF1000-like device at 50kV and 2.5 MJ at pinch
  current of 2.8MA

32
Scaling further- possibilities

• 1. Increase E0, however note scaling
  deteriorated already below YnE0
• 2. Increase voltage, at 50 kV beam energy 150kV
  already past fusion x-section peak further
  increase in voltage, x-section decreases, so
  gain is marginal
• Need technological advancement to increase
  current per unit E0 and per unit V0.
• We next extrapolate from point of view of Ipinch

33
Scaling Plasma Focus from Ipinch using present
predominantly beam-target in Lee Model code
34
SXR Scaling Laws

• First systematic studies in the world done in
  neon as a collaborative effort of IPFS, INTI IU
  CPR and NIE Plasma Radiation Lab
• Scaling laws extended to Argon by AECS

35
Special characteristics of SXR-for applications

• Not penetrating for example neon SXR only
  penetrates microns of most surfaces
• Energy carried by the radiation is delivered at
  surface
• Suitable for lithography and micro-machining
• At low intensity - applications for surface
  sterilisation or treatment of food
• at high levels of energy intensity, Surface
  hammering effect, production of ultra-strong
  shock waves to punch through backing material

36
Compression- and Yield- Enhancement methods

• Suitable design optimize compression
• Role of high voltage
• Role of special circuits e.g current-steps
• Role of radiative cooling and collapse

37
Latest development

• Modelling
• Ion beam fluence
• Post focus axial shock waves
• Plasma streams
• Anode sputtered material

38
Ion beam post-pinch plasma stream
calculationsSome preliminary Results- INTI
IU-IAEA collaboration
39
6. Developing the most powerful training and
research system for the dawning of the Fusion Age.

• Integrate
• 6a the proven most effective hardware system
  of the UNU/ICTP PFF with
• 6b the proven most effective numerical
  experiment system Lee Model code
• with emphasis on dynamics, radiation and
  materials applications.

40
Into the fusion era Plasma focus for
training/Research

• (a) Experimental facility TRPF
• 1 kJ focus 10 kV 20 uF 80 nH
• Measurements
• current, voltage sufficient to deduce dynamics
  and estimate temperatures
• Fibre-optics, pin diodes magnetic probes
  directly measure speeds, ns imaging
• SXR spectrometry, neutron counters TOF, ion
  collectors for radiation particle measurements
• Simple materials processing experiments

41
Into the fusion era Plasma focus for research
training

• (b) Numerical Experiments code
• To complement TRPF
• Computes dynamics and energy distributions
• Plasma pinch evolution, size and life time
• Post focus Ion Beam, plasma stream and anode
  sputtered material
• Connection with reality through fitting computed
  current to measured current trace
• Behaviour of plasma focus and yields as functions
  of pressure, gases, storage energies, circuit
  currents and pinch currents.
• Carry out above experiments with any plasma
  focus.
• Optimization of planned plasma focus

42
(a) The proven most effective 3 kJ PF system
The trolley based UNU/ICTP PFF 3 kJ plasma focus
training and research system will be updated as
a 1 kJ system
43
(b) The proven most effective and comprehensive
Model code

• Firmly grounded in Physics
• Connected to reality
• From birth to death of the PF
• Useful and comprehensive outputs
• Diagnostic reference-many properties, design,
  scaling scaling laws, insights innovations

44
(b) Philosophy, modelling, results and
applications of the Lee Model code
