Parsing

1
Parsing

• Compiler
• Baojian Hua
• bjhua_at_ustc.edu.cn

2
Front End
lexical analyzer
source code
tokens
abstract syntax tree
parser
semantic analyzer
IR
3
Parsing

• The parser translates the source program into
  abstract syntax trees
• Token sequence
• from the lexer
• abstract syntax trees
• check validity of programs
• cook compiler internal data structures for
  programs
• Must take account the program syntax

4
Conceptually
parser
token sequence
abstract syntax tree
language syntax
5
Syntax Context-free Grammar

• Context-free grammars are (often) given by BNF
  expressions (Backus-Naur Form)
• read Dragon sec 2.2
• More powerful than RE in theory
• Good for defining language syntax

6
Context-free Grammar (CFG)

• A CFG consists of 4 components
• a set of terminals (tokens) T
• a set of nonterminals N
• a set of production rules P
• s -gt t1 t2 tn
• with s?N, and t1, , tn ?(T?N)
• a unique start nonterminal S

7
Example

• // Recall the min-ML language in code3
• // (simplified)
• N decs, dec, exp
• T SEMICOLON, VAL, ID, ASSIGN, NUM
• S decs
• decs -gt dec SEMICOLON decs
• dec -gt VAL ID ASSIGN exp
• exp -gt ID
• NUM

8
Derivation

• A derivation
• Starts with the unique start nonterminal S
• repeatedly replacing a right-hand nonterminal s
  by the body of a production rule of the
  nonterminal s
• stop when right-hand are all terminals
• The final string consists of terminals only and
  is called a sentence (program)

9
Example

• decs -gt dec SEMICOLON decs
• dec -gt VAL ID ASSIGN exp
• exp -gt ID
• NUM

decs -gt (a choice)
derive me
val x 5 val y x
10
Example

• decs -gt dec SEMICOLON decs
• dec -gt VAL ID ASSIGN exp
• exp -gt ID
• NUM

decs -gt dec SEMICOLON decs -gt VAL ID ASSIGN
exp SEMICOLON decs -gt VAL ID ASSIGN NUM
SEMICOLON decs -gt VAL ID ASSIGN NUM
SEMICOLON dec SEMICOLON decs -gt
-gt VAL ID ASSIGN NUM SEMICOLON VAL
ID ASSIGN ID SEMICOLON decs
derive me
val x 5 val y x
11
Another Way to Derive the same Program

• decs -gt dec SEMICOLON decs
• dec -gt VAL ID ASSIGN exp
• exp -gt ID
• NUM

decs -gt dec SEMICOLON decs -gt dec SEMICOLON
dec SEMICOLON decs -gt
derive me
val x 5 val y x
12
Derivation

• For same string, there may exist many derivations
• left-most derivation
• right-most derivation
• Parsing is the problem of taking a string of
  terminals and figure out whether it could be
  derived from a CFG
• error-detection

13
Parse Trees

• Derivation can also be represented as trees
• useful to understand AST (discussed later)
• Idea
• each internal node is labeled with a non-terminal
• each leaf node is labeled with a terminal
• each use of a rule in a derivation explains how
  to generate children in the parse tree from the
  parents

14
Example

• decs -gt dec SEMICOLON decs
• dec -gt VAL ID ASSIGN exp
• exp -gt ID
• NUM

decs
SEMI
dec
decs
derive me
VAL

exp
dec
SEMI
decs
ID
val x 5 val y x
5
similar case
15
Different Derivations, same Tree
decs -gt dec SEMICOLON decs -gt VAL ID ASSIGN
exp SEMICOLON decs -gt
decs -gt dec SEMICOLON decs -gt dec SEMICOLON
dec SEMICOLON decs -gt
decs
SEMI
dec
decs
derive me
VAL

exp
dec
SEMI
decs
ID
val x 5 val y x
5
similar case
16
Parse Tree has Meaningspost-order traversal
decs -gt dec SEMICOLON decs -gt VAL ID ASSIGN
exp SEMICOLON decs -gt
decs -gt dec SEMICOLON decs -gt dec SEMICOLON
dec SEMICOLON decs -gt
decs
SEMI
dec
decs
derive me
VAL

exp
dec
SEMI
decs
ID
val x 5 val y x
5
similar case
17
Ambiguous Grammars

• A grammar is ambiguous if the same sequence of
  tokens can give rise to two or more different
  parse trees

18
Example

• exp -gt num
• -gt id
• -gt exp exp
• -gt exp exp

exp -gt exp exp -gt 3 exp -gt 3 exp
exp -gt 3 4 exp -gt 3 4 5
derive me
exp -gt exp exp -gt exp exp exp -gt 3
exp exp -gt 3 4 exp -gt 3 4 5
345
19
Example
exp
exp

exp
3
exp

exp

• exp -gt num
• -gt id
• -gt exp exp
• -gt exp exp

4
5
exp -gt exp exp -gt 3 exp -gt 3 exp
exp -gt 3 4 exp -gt 3 4 5
exp
exp

exp
exp -gt exp exp -gt exp exp exp -gt 3
exp exp -gt 3 4 exp -gt 3 4 5
5
exp

exp
3
4
20
Ambiguous Grammars

• Problem compilers make use of parse trees to
  interpret the meaning of parsed programs
• different parse trees have different meanings
• eg 4 5 6 is not (4 5) 6
• languages with ambiguous grammars are DISASTROUS
  the meaning of programs isnt well-defined! You
  cant tell what your program might do!
• Solution rewrite grammar to equivalent forms

21
Eliminating ambiguity

• In programming language syntax, ambiguity often
  arises from missing operator precedence or
  associativity
• is of high precedence than
• both and are left-associative
• Why or why not?
• Rewrite grammar to take account of this

22
Example

• exp -gt num
• -gt id
• -gt exp exp
• -gt exp exp

exp -gt exp term -gt term term -gt term
factor -gt factor factor -gt num -gt id
Q is the right grammar ambiguous? Why or why not?
23
Parser

• A program to check whether a program is derivable
  from a given grammar
• expensive in general
• must be fast
• to compile a 2000k lines of kernel
• even for small application code
• Theorists have developed specialized kind of
  grammar which may be parsed efficiently
• LL(k) and LR(k)

24
Predictive parsing

• A.K.A Recursive descent parsing, top-down
  parsing
• simple to code by hand
• efficient
• can parse a large set of grammar
• Key idea
• one (recursive) function for each nonterminal
• one clause for each right-hand production rule

25
Example

• decs -gt dec SEMICOLON decs
• dec -gt VAL ID ASSIGN exp
• exp -gt ID
• NUM

( step 1 represent tokens ) datatype token
Val Id of string Num of int Assign
Semicolon Eof ( step 2 connect with lexer
) token current ref getToken () fun advance
() current getToken () fun eat (token t)
if !current t then advance () else
error (want , t, but got , !current)
26

• decs -gt dec SEMICOLON decs
• dec -gt VAL ID ASSIGN exp
• exp -gt ID
• NUM

( step 1 represent tokens ) datatype token
Val Id of string Num of int Assign Semi
Eof ( step 2 connect with lexer ) token
current ref getToken () fun advance ()
current getToken () fun eat (token t) (
step 3 build the parser ) fun parseDecs()
case !current of VAL gt parseDec () eat
(Semi) parseDecs () EOF gt () _ gt
error (want VAL or EOF) fun parseDec () fun
parseExp ()
27
Moral

• The key point in predicative parsing is to
  determine the production rule to use (recursive
  function to call)
• must know the start symbols of each rule
• start symbol must not overlap
• ex exp -gt NUM ID
• This motivates the idea of first and follow sets

28
Moral

• Current nonterminal is S, and the current input
  token is t
• if wk starts with t, then choose wk, or
• if wk derives empty string, and the string follow
  S starts with t
• First symbol sets of wi (1ltiltn) dont overlap
  to avoid backtracking

• S -gt w1
• -gt w2
• -gt
• -gt wn

29
Nullable, First and Follow sets

• To use predicative parsing, we must compute
• Nullable nonterminals that derive empty string
• First(?) set of terminals that can begin any
  string derivable from ?
• Follow(X) set of terminals that can immediately
  follow any string derivable from nonterminal X
• Read Dragon sec 4.4.2 and Tiger sec 3.2
• Fixpoint algorithms

30
Nullable, First and Follow sets
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a

• Which symbol X, Y and Z can derive empty string?
• What terminals may the string derived from X, Y
  and Z begin with?
• What terminals may follow X, Y and Z?

31
Nullable

• If X can derive an empty string, iff
• base case
• X -gt
• inductive case
• X -gt Y1 Yn
• Y1, , Yn are n nonterminals and may all derive
  empty strings

32
Computing Nullable

• Nullable lt-
• while (F still change)
• for (each production X -gt a)
• switch (a)
• case ?
• Nullable ? X
• break
• case Y1 Yn
• if (Y1?Nullable Yn?Nullable)
• Nullable ? X
• break

33
Example Nullables
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Round 0 1 2
F
34
Example Nullables
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Round 0 1 2
F Y, X
35
Example Nullables
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Round 0 1 2
F Y, X Y, X
36
First(X)

• Set of terminals that X begins with
• X gt a
• Rules
• base case
• X -gt a
• First (X) ? a
• inductive case
• X -gt Y1 Y2 Yn
• First (X) ? First(Y1)
• if Y1?Nullable, First (X) ? First(Y2)
• if Y1,Y2 ?Nullable, First (X) ? First(Y3)

37
Computing First

• // Suppose Nullable has been computed
• First(X) lt- // for each X
• while (First still change)
• for (each production X -gt a)
• switch (a)
• case a
• First(X) ? a
• break
• case Y1 Yn
• First(X) ? First(Y1)
• if (Y1\not\in Nullable)
• break
• First(X) ? First(Y1)
• // Similar as above

38
Example First
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
Round 0 1 2 3
First(Z)
First(Y)
First(X)
39
Example First
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
Round 0 1 2 3
First(Z) d
First(Y) c
First(X) c, a
40
Example First
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
Round 0 1 2 3
First(Z) d d, c, a
First(Y) c c
First(X) c, a c, a
41
Example First
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
Round 0 1 2 3
First(Z) d d, c, a d, c, a
First(Y) c c c
First(X) c, a c, a c, a
42
Parsing with First
Z -gt d d -gt X Y Z a, c, d Y -gt c
c -gt X -gt Y c -gt a
a
Now consider this string d Suppose we choose
the production Z -gt X Y Z But we get stuck at X
-gt Y -gt a neither can accept d! Why?
First(Z) d, c, a
First(Y) c
First(X) c, a
Nullable X, Y
43
Follow(X)

• Set of terminals that may follow X
• S gt X a
• Rules
• Base case
• Follow (X)
• inductive case
• Y -gt ?1 X ?2
• Follow(X) ? Fisrt(?2)
• if ?2 is Nullable, Follow(X) ? Follow(Y)

44
Computing Follow(X)

• Follow(X) lt-
• while (Follow still change)
• for (each production Y -gt ?1 X ?2 )
• Follow(X) ? First (?2)
• if (?2 is Nullable)
• Follow(X) ? Follow (Y)

45
Example Follow
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
Round 0 1 2 3
First(Z) Follow(Z) d, c, a
First(Y) Follow(Y) c
First(X) Follow(X) c, a
46
Example Follow
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
Round 0 1 2 3
First(Z) Follow(Z) d, c, a
First(Y) Follow(Y) c d, c, a
First(X) Follow(X) c, a d, c, a
47
Example Follow
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
Round 0 1 2 3
First(Z) Follow(Z) d, c, a
First(Y) Follow(Y) c d, c, a d, c, a
First(X) Follow(X) c, a d, c, a d, c, a
48
Predicative Parsing Table

• With Nullables, First(), and Follow(), we can
  make a parsing table P(N,T)
• each entry contains a set of productions

t1 t2 t3 t4
(EOF) N1 ri N2
rk N3 rj
49
Predicative Parsing Table

• For each rule X -gt ?
• for each a?First(?), add X -gt ? to P(X, a)
• if X is nullable, add X -gt ? to P(X, b) for each
  b ? Follow (X)
• all other entries are error

t1 t2 t3 t4
(EOF) N1 r1 N2
rk N3 ri
50
Example Predicative Parsing Table
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
a c d
Z Z-gtX Y Z Z-gtX Y Z Z-gtd Z-gtX Y Z
Y Y-gt Y-gtc Y-gt Y-gt
X X-gtY X-gta X-gtY X-gtY
First(X) Follow(X) c, a c, d, a
First(Y) Follow(Y) c c, d, a
First(Z) Follow(Z) d, c, a
51
Example Predicative Parsing Table
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
a c d
Z Z-gtX Y Z Z-gtX Y Z Z-gtd Z-gtX Y Z
Y Y-gt Y-gtc Y-gt Y-gt
X X-gtY X-gta X-gtY X-gtY
First(X) Follow(X) c, a c, d, a
First(Y) Follow(Y) c c, d, a
First(Z) Follow(Z) d, c, a
52
LL(1)

• A context-free grammar is called LL(1) if it can
  be parsed this way
• Left-to-right parsing
• Leftmost derivation
• 1 token lookahead
• This means that in the predicative parsing table,
  there is at most one production in every entry

53
Speeding up set Construction

• All these sets (Nullable, First, Follow) can be
  computed simultaneously
• see Tiger algorithm 3.13
• Order the computation
• Whats the optimal order to compute these set?

54
Example Speeding up set Construction
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
Round 0 1 2 3
First(Z)
First(Y)
First(X)
Q1 Whats reasonable order here?
Q2 How to set this order?
55
Directed Graph Model
Z -gt d -gt X Y Z Y -gt c -gt X -gt Y -gt a
Nullable X, Y
d, c, a
c
Y
Z
Q1 Whats reasonable order here?
X
c, a
Q2 How to set this order?
Order Y X Z
56
Reverse Topological Sort

• Quasi-topological sort the directed graph
• Quasi topo-sort general directed graph is
  impossible
• also known as reverse depth-first ordering
• Reverse information (First) flows from
  successors to predecessors
• Refer to your favorite algorithm book

57
Problem

• LL(1) can only be used with grammars in which
  every production rules for a nonterminal start
  with different terminals
• Unfortunately, many grammars dont have this
  perfect property

58
Example

• exp -gt num
• -gt id
• -gt exp exp
• -gt exp exp

exp -gt exp term -gt term term -gt term
factor -gt factor factor -gt num -gt id
Q is the right grammar LL(1)? Why or why not?
59
Solutions

• Left-recursion elimination
• Left-factoring
• Read
• dragon sec4.3.2, 4.3.3, 4.3.4
• tiger sec3.2

60
Example
exp -gt term exp exp -gt term exp -gt
term -gt factor term term-gt factor term
-gt factor -gt num -gt id
exp -gt exp term -gt term term -gt term
factor -gt factor factor -gt num -gt id
Q is the right grammar LL(1)? are those two
grammars equivalent?
61
LL(k)

• LL(1) can be further generalized to LL(k)
• Left-to-right parsing
• Leftmost derivation
• k token lookahead
• Q table size? other problems with this approach?

62
Summary

• Context-free grammar is a math tool for
  specifying language syntax
• and others
• Writing parsers for general grammar is hard and
  costly
• LL(k) and LR(k)
• LL(1) grammars can be implemented efficiently
• table-driven algorithms (again!)
