Hindi Parsing

1
Hindi Parsing

• Samar Husain
• LTRC, IIIT-Hyderabad,
• India.

2
Outline

• Introduction
• Grammatical framework
• Two stage parsing
• Evaluation
• Two stage constraint based parsing
• Integrated data driven parsing
• Two stage data driven parsing

3
Introduction

• Broad coverage parser for Hindi
• Very crucial
• MT systems, IE, co-reference resolution, etc.
• Attempt to make a hybrid parser
• Grammatical framework Dependency

4
Introduction

• Levels of analysis before parsing
• Morphological analysis (Morph Info.)
• Analysis in local context (POS tagging, Chunking,
  case markers/postpositions computation)
• We parse after the above processing is done.

5
Computational Paninian Grammar (CPG)

• Based on Paninis Grammar
• Inspired by inflectionally rich language
  (Sanskrit)
• A dependency based analysis (Bharati et al.
  1995a)
• Earlier parsing approaches for Hindi (Bharati et.
  al, 1993 1995b 2002)

6
CPG (The Basic Framework)

• Treats a sentence as a set of modifier-modified
  relations
• Sentence has a primary modified or the root
  (which is generally a verb)
• Gives us the framework to identify these
  relations
• Relations between noun constituent and verb
  called karaka
• karakas are syntactico-semantic in nature
• Syntactic cues help us in identifying the karakas

7
karta karma karaka

• The boy opened the lock
• k1 karta
• k2 karma
• karta, karma usually correspond to agent, theme
  respectively
• But not always
• karakas are direct participants in the activity
  denoted by the verb
• For complete list of dependency relations (Begum
  et al., 2008)

open
k1
k2
boy
lock
8
Hindi Parsing Approaches tried

• Two stage constraint based parsing
• Data driven parsing
• Integrated
• Two stage

9
Two stage parsing

• Basic idea
• There are two layers (stages)
• The 1st stage handles intra-clausal relations,
  and the 2nd stage handles inter-clausal
  relations,
• The output of each stage is a linguistically
  sound partial parse that becomes the input to the
  next layer

10
Stage 1

• Identify intra-clausal relations
• the argument structure of the verb,
• noun-noun genitive relation,
• infinitive-verb relation,
• infinitive-noun relation,
• adjective-noun,
• adverb-verb relations,
• nominal coordination, etc.

11
Stage 2

• Identify inter-clausal relations
• subordinating conjuncts,
• coordinating conjuncts,
• relative clauses, etc.

12
How do we do this?

• Introduce a dummy __ROOT__ node as the root of
  the dependency tree
• Helps in giving linguistically sound partial
  parses
• Keeps the tree connected
• Classify the dependency tags into two sets
• Tags that function within a clause,
• Tags that relate two clauses

13
An example

• mai ghar gayaa kyomki mai bimaar
  thaa
• I home went because I sick
  was
• I went home because I was sick

14
The parses
(a) 1st stage output, (b)
2nd stage final parse
15
2 stage parsing

• 1st stage
• All the clauses analyzed
• Analyzed clauses become children of __ROOT__
• Conjuncts become children of __ROOT__
• 2nd stage
• Does not modify the 1st stage analysis
• Identifies relations between 1st stage parsed
  sub-trees

16
Important linguistic cues that help Hindi parsing

• Nominal postpositions
• TAM classes
• Morphological features
• root of the lexical item, etc.
• POS/Chunk tags
• Agreement
• Minimal semantics
• Animate-inanimate
• Human-nonhuman

17
Nominal postpositions and TAM

• rAma ø mohana ko KilOnA xewA hE
• Ram Mohana DAT toy
  give
• Ram gives a toy to Mohana
• rAma ne mohana ko KilOnA xiyA
• Ram ERG Mohana DAT toy gave
• Ram gave Mohan a toy
• rAma ko mohana ko KilOnA xenA
  padZA
• Ram DAT Mohana DAT toy had
  to give
• Ram had to give Mohan a toy
• The TAM dictates the postposition that appears on
  the noun rAma
• Related concept in CPG
• Verb frames and transformation rules (Bharati et
  al., 1995)

18
Agreement

• rAma ø mohana ko KilOnA xewA hE
• Ram gives a toy to Mohana
• kaviwA ø mohana ko KilOnA xewI hE
• Kavita gives a toy to Mohana
• Verb agrees with rAma and kaviwA
• Agreement helps in identifying k1 and k2
• But there are some exceptions to this.

19
Evaluation

• Two stage constraint based parser
• Data driven parsing
• Integrated
• 2 stage

20
Constraint based hybrid parsing

• Constraint satisfaction problem (Bharati et al.
  2008a)
• Hard constraints
• Rule based
• Soft constraints
• ML
• Selective resolution of demands
• Repair
• Partial Parses

21
(No Transcript)
22
Overall performance
UA L LA
CBP 86.1 65 63
CBP 90.1 76.9 75
MST 87.8 72.3 70.4
Malt 86.6 70.6 68.0
UA unlabeled attachments accuracy, L
labeled accuracy LA labeled attachment accuracy
23
Error analysis

• Reasons for low LA
• Less verb frames
• Some phenomena not covered
• Prioritization errors

24
Data driven parsing (Integrated)

• Tuning Malt and MST for Hyderabad dependency
  treebank (Bharati et al., 2008b)
• Experiments with different feature
• including minimal semantics and agreement

25
Experimental Setup

• Data
• 1800 sentences, average length of 19.85 words,
  6585 unique tokens.
• training set 1178 sentences
• development and test set 352 and 363 sentences

26
Experimental Setup

• Parsers
• Malt-version 1.0.1 (Nivre et al., 2007)
• arc eager
• SVM
• MST-version 0.4b (McDonald et al., 2005)
• Non-projective
• No. of highest scoring trees (k)5
• Extended feature set for both parsers

27
Consolidated results
28
Error analysis

• Reasons for low LA
• Difficulty in extracting relevant linguistic cues
• Agreement
• Similar contextual features Label bias
• Non-projectivity
• Lack of explicit cues
• Long distance dependencies
• Complex linguistic phenomena
• Less corpus size

29
Observations

• Features that proved crucial
• TAM (classes) and nominal postpositions
• Minimal semantics
• Animate-inanimate
• Human-nonhuman
• Agreement
• After making it visible

30
Data driven parsing 2 stage (Bharati et al.,
2009)

• MST parser
• Non-projective
• FEATS nominal and verbal inflections, morph
  info.
• Data
• 1492 sentences
• Training, development and testing 1200, 100 and
  192 respectively.

31
Modular parsing

• Intra-clausal and Inter-clausal separately
• Introduce a dummy __ROOT__
• Parse clauses in 1st stage
• Then parse relations between clauses in 2nd stage

32
Comparison with integrated parser
Details Accuracy Accuracy
Full (Stage1 Stage 2) LA 73.42
Full (Stage1 Stage 2) UA 92.22
Full (Stage1 Stage 2) L 75.33
Integrated LA 71.37
Integrated UA 90.60
Integrated L 73.35
There was 2.05, 1.62, 1.98 increase in LA, UA
and L respectively.
33
Evaluation
Details Accuracy Accuracy
Stage1 (Intra-clausal) LA 77.09
Stage1 (Intra-clausal) UA 92.73
Stage1 (Intra-clausal) L 78.70
Stage2 (Inter-clausal) LA 97.84
Stage2 (Inter-clausal) UA 99.67
Stage2 (Inter-clausal) L 98.00
34
Advantages

• Learning long distance dependencies becomes easy
• Stage 2 specifically learns them efficiently
• Few non-projective sentences
• Only intra-clausal ones remain
• Search space becomes local
• Handling complex sentences becomes easy

35
Error analysis

• Reasons for low LA (in 1st stage)
• Unavailability of explicit cues
• Combining modular parsing with minimal semantics
  should help
• Difficulty in learning complex cues
• Agreement
• Similar contextual features Label bias
• Less corpus size

36
References

• R. Begum, S. Husain, A. Dhwaj, D. Sharma, L. Bai,
  and R. Sangal. 2008. Dependency annotation scheme
  for Indian languages. In Proceedings of
  IJCNLP-2008.
• A. Bharati and R. Sangal. 1993. Parsing Free Word
  Order Languages in the Paninian Framework. Proc.
  of ACL93.
• A. Bharati, V. Chaitanya and R. Sangal. 1995a.
  Natural Language Processing A Paninian
  Perspective, Prentice-Hall of India, New Delhi.
• A. Bharati, A. Gupta and Rajeev Sangal. 1995b.
  Parsing with Nested Constraints. In Proceedings
  of 3rd NLP Pacific Rim Symposium. Seoul.
• A. Bharati, R. Sangal and T. P. Reddy. 2002. A
  Constraint Based Parser Using Integer Programming
  In Proc. of ICON-2002.
• A. Bharati, S. Husain, D. Sharma, and R. Sangal.
  2008a. A two-stage constraint based dependency
  parser for free word order languages. In
  Proceedings of the COLIPS IALP, Chiang Mai,
  Thailand.
• A. Bharati, S. Husain, B. Ambati, S. Jain, D.
  Sharma, and R. Sangal. 2008b. Two semantic
  features make all the difference in parsing
  accuracy. In Proceedings of the 6th ICON, Pune,
  India.
• A. Bharati, S. Husain, S. P. K. Gadde, B. Ambati,
  and R. Sangal. 2009. A modular cascaded partial
  parsing approach to complete parsing. In
  Submission.
• R. McDonald, F. Pereira, K. Ribarov, and J.
  Hajic. 2005. Non-projective dependency parsing
  using spanning tree algorithms. In Proc. of
  HLT/EMNLP, pp. 523530.
• J. Nivre, J. Hall, J. Nilsson, A. Chanev, G.
  Eryigit, S. Kübler, S. Marinov and E Marsi. 2007.
  MaltParser A language-independent system for
  data-driven dependency parsing. Natural Language
  Engineering, 13(2), 95-135.

37

• Thanks!!
