BIST for Logic and Memory Resources in Virtex-4 FPGAs

1
BIST for Logic and Memory Resources in Virtex-4
FPGAs

• Sachin Dhingra, Daniel Milton, and Charles Stroud
• Electrical and Computer Engineering
• Auburn University

2
Outline of Presentation

• Overview of Virtex-4
• Architecture
• Operational Features
• Built-In Self-Test
• Architecture
• BIST for PLBs
• BIST for LUT-RAMs
• BIST for Block RAMs
• Experimental Results
• Test Time
• Memory Storage Requirements
• Summary

3
Xilinx Virtex-4 FPGAs

• Configuration memory 4.7M to 50.8M bits of RAM
• PLBs 1,536 to 22,272
• 4 LUTs/RAMs (4-input)
• 4 LUTs (4-input)
• 8 FF/latches
• Block RAMs 48 to 552 18K-bit dual-port RAMs
• Also operate as FIFOs
• DSP cores 32 to 512, each includes
• 18x18-bit multiplier
• 48-bit adder accumulator
• PowerPC processors 0 to 2
• Supports soft processor cores
• Can write read configuration memory

4
BIST for FPGAs

• Basic idea reprogram FPGA to test itself
• No area overhead or performance penalties
• Applicable to all levels of testing
• Application independent testing
• A generic test approach for a generic component
• Good diagnostic resolution
• Cost
• Memory to store BIST configurations
• Goal minimize number of configurations
• Download time to execute BIST configurations
• Goal minimize downloads and/or download time

5
BIST for PLBs

• Program PLBs as
• Test Pattern Generators (TPGs)
• Output Response Analyzers (ORAs)
• Logic blocks under test (BUTs)
• Two test sessions
• Row or column orientation
• Good for dynamic partial reconfiguration

6
Virtex-4 Logic BIST

• TPGs constructed from DSPs
• Accumulates constant 0x691
• Produces pseudo-exhaustive patterns
• Two TPGs per 4 rows of CLBs
• Each TPG drives alternating columns of BUTs
• ORAs in alternate columns
• 2 test sessions needed
• BUTs
• Logic slices need 10 configs
• Memory slices need 12 configs
• Not counting LUT RAMs
• Includes 2 for testing Shift Registers
• All slices test concurrently

7
Virtex-4 LUT RAM BIST

• TPGs constructed from
• DSPs used as counter
• Block RAM used as ROM
• Store March Y test patterns
• March DPR for dual-port
• Memory slice LUT RAMs
• 64x1 single-port
• 32x2 single-port
• 16x2 dual-port
• ORAs in logic slices
• Only 1 test session
• BIST structure
• Groups of 4 rows
• 2 TPGs per 4 rows
• Drive memory slices in those rows

8
BIST for Block RAMs DSPs

• Circular Comparison ORA
• Implemented in PLBs
• 1 ORA/core output
• Maximizes diagnostic resolution
• Two TPGs
• Implemented in PLBs
• Algorithms are a function of the BUT

9
March LR Test for RAMs

• Detects
• neighborhood pattern sensitivity faults
• intra-word coupling faults
• bridging faults
• Notation
• ? address downward
• ? address upward
• ? address either way
• w0 write 0
• r1 read 1
• Length of test 16N
• N number of address locations
• Word-oriented memory Background Data Sequences
  (BDS) to detect pattern sensitivity coupling
  faults
• BDS ?log2(K)?1, where K data width
• Length of test (167?log2(K)?)N

March Y ?(w0) ?(r0,w1,r1) ?(r1,w0,r0) ?(r0)
March LR w/o BDS ?(w0) ?(r0, w1) ?(r1,w0,r0,r0, w1) ?(r1,w0) ?(r0,w1,r1,r1,w0) ?(r0)
March LR with BDS ?(w00) ?(r00, w11) ?(r11,w00,r00,r00, w11) ?(r11,w00) ?(r00,w11,r11,r11,w00) ?(r00,w01,w10,r10) ?(r10,w01,r01) ?(r01)
10
Virtex II Block RAM BIST
BIST config Test Algorithm BDS Address Locations (A) Data Width Clock Cycles TPG Slices ORA Slices
1 March LR No 16K 1 2x14xA 62 N?D?2
2 March LR No 8K 2 2x14xA 62 N?D?2
3 March LR No 4K 4 2x14xA 64 N?D?2
4 March LR No 2K 9 2x14xA 64 N?D?2
5 March LR No 1K 18 2x14xA 68 N?D?2
6 March LR Yes 512 36 58xA 174 N?D?2
7 March s2pf No 512 36 14xA 64 N?D?2
8 March d2pf No 512 36 9xA 113 N?D?2
N of block RAMs D of data bits Total
clock cycles 829,952
Includes testing programmable controls Active
level of reset, clock enable, write enable Active
edge of clock Includes testing programmable write
modes Write-first, Read-first, No-change
11
Virtex-4 Block RAM BIST
BIST Configuration Test Algorithm Address Locations (A) Data Width (D) Clock Cycles
1 March LR w/ BDS 512 36 58A
2 MATS 8K 2 25A
3 MATS 16K 1 25A
4 March s2pf 512 36 14A
5 March d2pf 512 36 9A
6 FIFO 4K 4 6A
7 FIFO 2K 9 6A
8 FIFO 1K 18 6A
9 FIFO 512 36 6A
10 FIFO ECC 512 64 3A
Total clock cycles 334,848 . TPG slice count 608 ORA slice count 72N where N block RAMs Total clock cycles 334,848 . TPG slice count 608 ORA slice count 72N where N block RAMs Total clock cycles 334,848 . TPG slice count 608 ORA slice count 72N where N block RAMs Total clock cycles 334,848 . TPG slice count 608 ORA slice count 72N where N block RAMs Total clock cycles 334,848 . TPG slice count 608 ORA slice count 72N where N block RAMs
Configurations 1-5 in one BIST download Configurat
ions 6-10 in another download Generic TPG for
each download
12
Virtex-4 Block RAM BIST

• FIFOs
• Test full and empty flags
• Test almost flags (full and empty) via dynamic
  partial reconfiguration during BIST configuration
• Significant reduction in number of downloads
• ECC RAM
• Problem detecting faults in FT circuit
• Solution initialize RAM with Hamming errors
• Detect faults in bit error detection/correction
  circuit status outputs during full read cycle
  of RAM BIST
• Detect faults in Hamming code generation circuit
  during full write then read cycle of RAM BIST

13
Reducing Test Time

• Orient BIST architecture to configuration memory
• Keep routing constant between configurations
• Downloading BIST configurations
• Partial reconfiguration
• Frame Data Register
• Allows multiple frame writes with same data
• Reduces frames written for configurations
• Optimize ordering of BIST configurations
• Retrieving BIST results
• Partial configuration memory readback
• Dynamic partial reconfiguration
• Read BIST results after set of BIST
  configurations
• Slight loss of diagnostic resolution

14
Reducing Test Time
Partial Mem RB
Partial Reconfig
Full Mem RB
Full Config
Download Technique
ORA Results Retrieval Technique
15
Reducing Test Time contd
Partial Mem RB
Partial Reconfig
Full Mem RB
Full Config
Download Technique
ORA Results Retrieval Technique
16
Summary

• Virtex-4s large size and specialized cores pose
  challenges for developing efficient tests
• BIST Techniques
• Partial Reconfiguration
• Regular Test Structures
• New architectural operational features of
  Virtex-4 improve the efficiency of BIST
• BIST Results
• Test time improvements
• Over 12X improvement in Virtex-4 compared to 5X
  for Virtex
• Memory storage reduction
• 5X improvement for Virtex-4, 3X for Virtex
