The New York Control Area (NYCA)

1
Session 4.

• The New York Control Area (NYCA)

Bob Waldele Manager Operations
Engineering Operations Reliability NYISO
2
Robert Waldele mini-bio

• 33 years with NYPP and NYISO (transmission
  planning, dispatcher training, operations
  engineering)
• BSEE(Comp. Sci., Power) Northwestern University
• Railfan/Photographer, Model Railroader (garden)
• Church Organist and Choir Director
• Rumored to have caused first Blackout (Nov. 9,
  1965) while still in high school
• Member of Operator Tools, Training, and EMS
  Performance Team of the NERC 2003 Blackout
  Investigation Task Force
• Active participant in numerous IEEE-PES, NPCC,
  NERC and EPRI study and support groups

3
Annie Liebovitz photographer

• Success didnt spoil me, Ive always been
  insufferable.

4
The New York Control Area (NYCA)

• Location of major facilities
• Generation
• Transmission system constraints
• The New York ISO
• Commercial responsibilities
• Normal operation responsibilities
• Emergency operation responsibilities
• Transmission interfaces (flowgates)
• Likely transmission constraints in NYCA
• Ties with neighboring systems
• OASIS

5
(No Transcript)
6
What does the NYISO do?

• The New York ISO
• Commercial responsibilities
• Administers the Tariffs
• Open Access Transmission Tariff (OATT)
• Market Services Tariff
• Agreements with Market Participants
• NYISO has operational responsibilities to insure
  the reliability of the NYCA and its
  interconnections

7
NYISO Markets

• Energy - in two separate markets
• Day-Ahead
• Real-Time
• 2 direct bid Ancillary Services
• Operating Reserve
• Regulation
• Generation Capacity - ICAP
• Cost Based Ancillary Services
• Congestion Protection - the TCC

8
More commercial information?

• We are not going to go into detail about the
  NYISO Market Operation
• NY Market Operation Course (NYMOC)
• Covers the aspects of dealing with the Market
  Information System (MIS), participating in the
  several ancillary service markets
• Go to www.nyiso.com for more information and
  schedule and registration

9
System Operations

• What does the NYISO do?
• Transmission system security (Reliability
  Coordinator)
• Control Area Operator (balancing authority)
• Outage Scheduling
• Planning (resource, transmission, load
  forecasting)
• Generator interaction with NYISO Control Area
  Operation

10
Overview of Control Area Operation
New York Control Area
11
Reliability Coordinators Responsibility
If we dont coordinate the collective security of
the interconnected power system, the whole
business can collapse like a house of cards. It
has happened, and its not pretty The Northeast
Blackout Nov. 9th 1965 (the grand-daddy of
them all until)
12
Other Notable Events

• July 1977 - New York City
• July 1989 - Province of Quebec
• January 1994 WSCC
• December 1994 WSCC
• July, August 1996 Pacific NW (3 times)
• January 1998 Montreal and Northern NY
• December 1998 San Francisco
• And who can forget
• August 14, 2003 Midwest and Northeast

13
Santayana

• those who refuse to learn from history are
  doomed to repeat it.

14
NYISOs RC Responsibilities

• Interaction with Generation Owners
• Interaction with Transmission Owners
• Transmission interfaces (flowgates)
• Likely transmission constraints in NYCA
• Ties with neighboring systems

15
Interaction with Generators

• Real-time security dispatch adjusts output of
  generators to respect system security constraints
• AGC adjusts generation to maintain area control
  error (ACE)
• Reserve pick-up adjusts generation following a
  contingency loss of resource

16
Load Following - RTS

• RTS dispatches generators with basepoints to meet
  the 5 minute projected load
• Primary control of generation based on
  availability, cost, capability limits, and
  response rates
• Maintain reserve requirements
• Adjusts generation to solve security constraints
• Calculates real time prices

17
Maintaining Interchange Schedules
18
Generation Dispatch to Follow the Load

• Day-ahead (SCUC) commits generation to load
  forecast and sufficient additional generation to
  meet reliability requirements (including reserve)
• Hour-ahead in-day in advance of real time
• Off dispatch units are scheduled by the hour
• Transactions are scheduled by the hour
• Additional generation needed resulting from
  forced outages, external schedule changes or
  forecast error
• 5-minute load following with on-dispatch units
  receiving 5-min. base points
• Six second AGC with on-control units receiving
  6-sec. base points respond to Area Control Error

19
SINGLE LARGEST SOURCE CONTINGENCY 1,200 MW
10 MIN SYNC
30 MIN
600 MW min
600 MW
10 MIN NON-SYNC
What is needed in addition to 10 min SYNC (600)
to total 1200 MW
10 MINUTE TOTAL 1,200 MW
RESERVE REQUIREMENT 1,800MW
20
NYISO Operating Reserve

• Consistent with NPCC Criteria and NYSRC
  Reliability rules, the NYCA must maintain
  sufficient operating reserve to withstand any
  loss of generation in the CA within design
  criteria
• NYCA Operating Reserve Requirement is 1 ½ times
  the largest contingency
• the largest source contingency is typically 1200
  MW
• Operating Reserve is maintained in three
  catagories
• Ten minute Synchronous Reserve
• Total ten minute reserve
• Total 30 minute reserve

21
Reserve Requirements

• NYISO instituted TO communicated
• Reserve Pick-up
• Payment based on following NYISO basepoints
• Energy dispatch based on economic selection, not
  necessarily units carrying reserve
• Performance penalties suspended
• Max Gen Pick-up
• Generation expected to produce at maximum
  capability reimbursed for energy produced no
  base points
• Performance penalties suspended.
• Selective Max Gen Pick-up
• Instituted on a zonal basis

22
Interaction with Transmission Owners

• Real-time security monitors loading of critical
  transmission facilities and paths
• NYISO coordinates facility switching for
  scheduled outages
• Coordinate response to emergency outages and/or
  contingency loss of facilities
• Coordinate EHV voltage profiles

23
Security Constraints

• Frequency
• Voltage
• Equipment Ratings
• System Constraints

24
Frequency

• Frequency is an indicator of the health of the
  interconnection
• Sudden changes in frequency are signals of
  things happening somewhere
• Slow changes/small deviations in frequency
  generally indicate load/generation trends
• Frequency is like the weather everybody talks
  about it

25
Security Constraints

• Frequency
• Voltage
• Equipment Ratings
• System Constraints

26
Voltage Control

• NYISO coordinates the voltage profile on the EHV
  transmission system
• NYISO requests for reactive support relayed by TO
  to generators
• Report AVR outages to the NYISO
• NYISO directs switching of EHV connected shunt
  capacitors and reactors
• Out of normal operation of transmission
  regulation devices (SVCs, etc.)

27
Security Constraints

• Frequency
• Voltage
• Equipment Ratings
• System Constraints

28
Ratings of Facilities

• Transmission equipment ratings
• Tie-line Rating Guide (NYSRC)
• Line conductor (size, configuration)
• Transformer ratings
• Load Interrupting Current ratings
• Breaker continuous (load) and interrupting
  (fault)
• CT, wavetrap, instrumentation ratings
• Bus conductor ampacity
• Generator capability and response rates
• Voltage ratings/limits - high and low

29
Ratings of Transmission Facilities

• Transmission equipment ratings
• Tie-line Rating Guide (NYSRC)
• Transmission line conductor
• Terminal equipment and bus section
• Ratings of jointly owned facilities
• Rating authority real-time updates
• Transformers
• Self-cooled, forced cooled
• Tap-changing capability

30
Generator Equipment Ratings

• Generators required to perform periodic testing
  to demonstrate capability
• DMNC (seasonal) for real power for participation
  in the energy and ICAP
• Reactive capability testing (annual) for
  participation in the VSS Ancillary Service

31
Voltage Ratings/Limits

• NYISO Controlled/Secured Stations
• TD or EO Manual, App. A-3 lists stations that
  NYISO monitors and secures
• Owner sets the post-contingency high/low voltage
  limits based on equipment ratings
• NYISO establishes pre-contingency high/low
  voltage limits to secure
• Prevent violation of post-contingency limit
• Pre-contingency limits determined by through
  system studies and approved

32
Security Constraints

• Frequency
• Voltage
• Equipment Ratings
• System Constraints

33
Transmission System Constraints

• Thermal ratings
• Transient Stability Limits
• Station Voltage limits
• Voltage Constrained Transfers
• Locational Reserve requirements
• Local Reliability constraints

34
Transmission Interfaces

• Historically in NYCA we have used transmission
  interfaces to monitor and secure the system
• 6 internal interfaces
• Several have transient or voltage stability
  limits
• All are evaluated on a forecast seasonal basis
• 4 external interfaces (neighboring CAs)
• Monitor inter-Area schedules/transactions
• All are evaluated on a forecast seasonal basis

35
Moses-South
Central East
Dysinger East
West Central
Total East
UPNY-ConEd
NYC Cable
Total East
36
NYISO Operating Interfaces

• Cross-State Interfaces
• Dysinger-East
• West-Central
• Moses-South
• Central East
• Total East
• UPNY-ConEd
• Sprain Brook/Dunwoodie-South (NYC Cable)
• Inter-Area Interfaces
• NYISO-IMO
• NYISO-ISO-NE
• NYISO-PJM
• NYISO-HQTE

37
Transmission System Constraints

• Station voltage limits
• Actions to prevent violation of pre-contingency
  voltage limits may include curtailing power
  transfers in the vicinity of the constraint
• Other constraints
• Maintaining operating reserve requirement
• Locational Reserve requirements
• Local Reliability constraints
• Local reliability rules

38
Solving Transmission Constraints

• NYISO Real-time dispatch will adjust generation
  to solve security constraints
• Can solve thermal rating (projected
  post-contingency overload) constraint for
  individual facilities
• Can solve interface constraint for
• Transient Stability Limits
• Voltage Stability (Collapse) Limits

39
Are we there yet? Are we there yet?
40
Summary

• The foundation for maintaining Reliability comes
  from the adequacy and security of
• Frequency, Voltage, Reserve, Regulation, while
  respecting equipment and interface limits.
• The NYISO uses EMS applications to commit,
  schedule and dispatch generation, balance load to
  secure the system
• Security Constrained Unit Commitment (SCUC)
• Balancing Market Evaluation (BME)
• Security Constrained Dispatch (SCD) and Automatic
  Generation Control (BME)

41
Yogi Berra

• Why buy good luggage? You only use it when you
  travel.
• or
• When you come to a fork in the road, take it.
