Container Labeling Options Using rommelag

1
Container Labeling Options Using rommelag Blow
Fill Seal Technology

• PREPSENTED BY
• Mohammad Sadeghi
• V.P. RD
• Holopack International Corp.
• 1 Technology Circle
• Columbia, SC 29203
• Tel [phone]

2
Contents

1. General Overview of Blow Fill Seal Process
2. Container labeling
3. Pros and Cons
4. Examples

3
A. General Overview of Blow/Fill/Seal Process
4
The Process
5
BFS Process Steps

• The BFS cycle can be divided into the following
  steps
• Step 1 Parison Extrusion
• Step 2 Container molding
• Step 3 Container Filling
• Step 4 Container Sealing

6
Contents

1. General Overview of Blow Fill Seal Process
2. Container labeling
3. Pros and Cons
4. Examples

7
Labeling Options

1. Embossing
2. Paper label on tabs
3. Direct printing on tabs

8
a) Embossing- Engraved Molds

• A mirror image of information is engraved on the
  surface of a molds cavity.
• Small vacuum ports on the mold surface pull in
  the soft plastic embossing the container.

9
Engraved Mold
10
Engraved Mold
11
Embossing - Hot Stamp

• Hot Stamp embosses product information on each
  individual container tab after the container is
  sealed and ejected from the BFS machine

12
b) Paper Labels on Tabs

• The mold is designed with a tab, or flag on the
  tail or the cap.
• Tab is a solid surface providing space for paper
  labels

13
c) Direct Printing on Tabs

• Ink jet printing on tabs with barcodes, and
  product information

14
Contents

1. General Overview of Blow Fill Seal Process
2. Container labeling
3. Pros and Cons
4. Examples

15
a) Embossing
Pros Cons
No maintenance of label inventories Difficult to read on clear containers
Ensures 100 labeling of containers
Labels can not be removed
Ensure each unit is traceable
No leachables
16
a) Paper label on Tab
Pros Cons
Clearer to read Potential leaching of label adhesive into solution
Greatly reduces potential leaching into the solution
17
c) Direct printing on the Tab
Pros Cons
Clearer to read Potential leaching into solution
Eliminates potential leaching from paper labels
Greatly reduces potential leaching into the solution
Allows for barcode printing on line
18
Contents

1. General Overview of Blow Fill Seal Process
2. Container labeling
3. Pros and Cons
4. Examples

19
a) Embossed Labeling
20
a) Embossed labeling with coloration
21
b) Paper Label on Tab
22
c) Direct Printing on Tab
23
Conventional Labeling
24
Packaging With BFS
25
Packaging With BFS
