ROBOTS IN RADIO-ACTIVE ENVIRONMENTS

1
ROBOTS IN RADIOACTIVE ENVIRONMENTS
2
INTRODUCTION

• In a critical place such as a nuclear power plant
  , where the manual work is quite difficult the
  application of robots are really worth
  mentioning.
• Robots are used to prevent exposure of humans to
  radiations in Nuclear Power plants

3
CONCEPT

• Websters dictionary definition
• An automatic device that performs functions
  ordinarily described to human beings
• Robotic Institute of America definition
• It is a reprogrammable multifunctional
  manipulator designed to move materials, parts,
  tools etc through variable programmed motion of
  the performance of a variety of tasks

4
CONTENTS

• Minimize human exposure
• Maintenance activities
• Steam Generators
• Tele-operation platform
• End effectors
• Remove fallen objects in
• primary circuit nozzle
• PWR reactor vessel

5
MINIMIZE HUMAN EXPOSURE

• Risk of contamination which is accidental
• Irradiation affects operators work areas
• Professional workers are few in number and
  require years of experience
• International laws exist which limit the max
  exposure rate of workers
• Reduce working time and increase maintenance cost

6
PREVENTIVE MAINTENANCE AND UNFORSEEN INCIDENTS

• Periodic maintenance require
• Careful preparation
• Safety
• Well known working environment
• Prepared using a full scale mockup
• For telerobotics there is
• Geometric model of the remote site
• Mission is programmed
• Operates in supervision mode

7
WHAT IS THE NEED OF ROBOTS IN STEAM GENERATORS ?

• Steam Generators use U bent tubes. U bent tubes
  in WSG made using inconel alloy
• to ensure High thermal efficiency of heat
  exchanger
• Multiple stresses
• Mechanical and thermal loading vibrations
  corrosion
• Maintenance jobs during plant refueling are
  complex
• Water cleaning, nozzle dam insertion etc.

8
ROSA in proximity to the nozzle dam,
positioning gripper to remove it
ROSA NOZZLE DAM INSERTION

• Remote user interface
• Control six axis arm

9
Arm base is attached to tube sheets by means
of four hydraulic cam locks

• Arm is equipped with a remote quick
  connector to facilitate the assembly and
  disassembly of such tools

10
JUMPER EXECUTING THE TASK
11
TELEOPERATION PLATFORM

• New platform developed using Hewlett Packard UX
  operating system
• Local area network connects with teleoperation
  platform with robot control unit
• Graphic models of arm, loader, tube sheet
  channel head was developed using ROBCAD

12
The Sequence of observation made by the operator
when robot is loaded at tube sheet of SG

• Critical Needs careful programming
• Arm should be manually inserted in the channel
  head through a narrow man way

13

• One inside the RQC is attached to a loader
• Hence the cinematic tree is inverted

• Operator moves the loader
• Arm should perform a predefined motion scheme

14

• After last motion the arm base should be
• perfectly aligned with the tube sheet

• Operator moves the base until the camlocks
  are inside the anchor tubes and expand them

15
END EFFECTORS

• Develop tools that could operate on tube sheets
  of SG
• Operations include
• Detecting wrong tubes
• Canceling wrong tubes
• Recovering them
• Drilling plugs
• Placing the nozzle dams

16
ELECTRO DISINTEGRATION MACHINE

• To disintegrate foreign elements located in
  the tubesheet

17
PARTS OF EDM

• Remote Quick Connector (RQC) to attach to robot
  end, a fixed platform where vision are installed

18
CONTD.

• Potentiometer for alignment with the tubesheet
  Camlocks for anchoring to it
• Commands are provided to fit activate EDH, to
  fit intensity and voltage parameters and to load
  and unload the tool

19
REMOVAL OF FALLEN OBJECTS IN PRIMARY CKT NOZZLE

• Objects may fall inside primary nozzle during
  maintenance operation, if dam not installed
• Necessary to develop special tools.
• Tools are handled by jumpers from channel head
  nozzle so accumulated doses are high

20
INSPECTION RETRIEVING VEHICLE

• It is highly robust fail safe.

21
REMOVAL OF FALLEN OBJECTS INSIDE PWR VESSEL

• Parts of tools may fall inside vessel during
  refuelling because of human error

22

• Teleoperated and robotized
• system for maintenance
• operation in nuclear
• powerplant vessels
• (TRON) is a four joint of
• robotised pole

• Used to retrieve fallen objects
• from the PWR reactor vessel
• It comprises jointed pole, end
• effectors computer vision
• navigation system

23
APPLICATIONS

• STEAM GENERATORS
• Primary tube inspection maintenance.
• Channel head cleaning .
• Nozzle dam insertion.
• REACTOR CAVITY
• Fuel transfer channel cleaning underwater
  inspection.
• REACTOR VESSEL
• Underwater inspection repair.
• Foreign fallen object removal.

24
CONCLUSION

• With improving technology growing
• perception of the need to keep human
• workers away from high radiation areas,
• more competitive robotic systems are
• increasingly becoming available

25
