Title: TELECOMMUNICATIONS


1
TELECOMMUNICATIONS
  • Dr. Hugh Blanton
  • ENTC 4307/ENTC 5307

2
(No Transcript)
3
Phase-Locked Loops
  • A phase-locked loop (PLL) uses a feedback control
    circuit to allow a voltage-controlled oscillator
    to precisely track the phase of a stable
    reference oscillator, with the important feature
    that the output oscillator can be made to run at
    a multiple of the reference oscillator frequency.

4
  • Phase-locked loops are used
  • as FM demodulators,
  • in carrier recovery circuits, and
  • as frequency synthesizers for modulation and
    demodulation.
  • Phase-locked loops have very good frequency
    accuracy and phase noise characteristics, but
    suffer from the fact that settling times (between
    changes in frequency) can be long.

5
  • The basic circuit of a phase-locked loop consists
    of
  • a reference oscillator,
  • a phase detector
  • produces an output voltage proportional to the
    difference in phase of the inputs,
  • a loop amplifier and filter,
  • a voltage-controlled oscillator (VCO), and
  • operating at the desired output frequency
  • a frequency divider.

6
  • In operation, the output of the VCO is divided by
    N to match the frequency of the reference
    oscillator.
  • The phase detector produces a voltage
    proportional to the difference in phase of these
    two signals, and is used to make small
    corrections in the frequency of the VCO in order
    to align the phase of the VCO with that of the
    reference source.
  • The output of the phase-locked loop thus has a
    phase noise characteristic similar to that of the
    reference source, but operates at a higher
    frequency.
  • If a programmable frequency divider is used, it
    is possible to synthesize a large number of
    closely spaced frequencies with a relatively
    simple circuit.
  • This makes the phase-locked loop very useful for
    commercial wireless applications, especially
    those involving mu ltiple channels.

7
  • Phase-locked loops can be implemented in either
    digital or analog form, but we will only discuss
    analog PLLs because they are the only type
    capable of operating at RF and microwave
    frequencies.

8
  • There are several characteristics of phase-locked
    loops that are important in practice.
  • The capture range is the range of input frequency
    for which the loop can acquire locking.
  • The lock range is the input frequency range over
    which the loop will remain locked
  • this is typically larger than the capture range.
  • The settling time is the time required for the
    loop to lock on to a new frequency.

9
Practical Synthesizer Circuits
  • The AMPS cellular system requires a local
    oscillator in the 800 MHz band to receive one of
    several hundred voice channels having 30 kHz
    spacing.
  • Using a standard phase locked loop would require
    a reference source operating at 30 kHz and a VCO
    operating near 870 MHz, with a programmable
    divider providing a division ratio of more than
    24,000.
  • This would be impractical because of the large
    number of addresses required as well as the high
    frequency at which the divider would have to
    operate.

10
  • Instead, a phase-locked loop supplemented with a
    mixer and frequency multiplier is used

11
  • In this synthesizer the VCO operates at the
    frequency fo, which ranges from 217.5 to 222.5
    MHz.
  • The VCO output is frequency multiplied by four to
    achieve the desired synthesizer output in the
    range of 870 MHz.
  • Part of the VCO output is mixed with a fixed
    reference crystal oscillator at f1 228.02250
    MHz.
  • The filtered difference frequency of 6 to 11 MHz
    is low enough to be digitally divided with an
    inexpensive programmable counter.
  • The division ratio is selected with a 10-bit
    address to lie between 737 lt N lt 1402, according
    to the desired channel.

12
  • The output of the divider is compared to a stable
    7.5 kHz oscillator, f2 , and the phase error is
    used to control the VCO.
  • When the loop is in lock, the output frequency is
    fout 4(f1 ? f2).
  • Thus the output can be stepped in increments of 4
    f2 30 kHz.
  • The stability of the output is set by the
    stability of the reference sources f1 and f2.

13
  • If it is desired to produce an output frequency
    of fout 870.180 MHz. for example, then we solve
    the equation
  • 870.180 MHz 4(f1 ? N ? f2)
  • 4228.02250 ? N(0.0075)
  • This yields N 1397. which is the required
    setting of the programmable divider.

14
Phase Detectors
  • A phase detector provides an output voltage that
    is dependent on the phase difference between two
    input signals.
  • Two input signals of nominally the same frequency
    (wo), but different phases (q1 and q2), are
    applied to the input ports of a 90? hybrid
    coupler.

15
  • The output voltages developed across the mixer
    diodes can be written as

16
  • If we assume a square-law response for the mixer
    diodes, and retain only the quadratic terms, the
    diode currents can be written as
  • The negative sign of i2 accounts for the reversed
    diode polarity.

17
  • After combining the diode currents and low-pass
    filtering, the output voltage can be expressed as

18
  • This result shows that the output voltage of the
    phase detector is proportional to the sine of the
    difference in phase of the two input signals.
  • If this difference is small, then the sine
    function can he approximated by its argument, so
    that the phase detector output is proportional to
    the phase difference.
  • This is referred to as the linearized phase
    detector model.

19
  • The constant K, is the phase detector gain
    factor, and accounts for the diode square-law
    constants and current-to-voltage conversion.
  • It has dimensions of volts/radian.

20
Transfer Function for the Voltage-Controlled
Oscillator
  • We can assume that the VCO has an output
    frequency wo that is offset from its free-running
    frequency, wc,by an increment Dw
  • where the offset frequency is controlled by the
    control voltage vc applied to the VCO.
  • The constant Ko is the VCO gain factor, and has
    dimensions of HZ/V.

21
  • We define the phase of the offset frequency of
    the VCO as
  • Writing frequency as the time derivative of phase
    then gives

22
  • The integral yields the output phase in terms of
    the control voltage
  • The Laplace transform yields

23
  • Assume a reference input voltage given by
  • where qi is the phase of the input waveform.

24
  • The output voltage of VCO can be written as
  • where qo is the phase of the output waveform.
  • Note that the output frequency is N times the
    input (reference) frequency, due to the use of
    the frequency divider in the loop feedback path.

25
  • The phase detector output voltage can be
    expressed in the Laplace transform domain as

26
  • Since the divider divides the frequency by N, and
    phase is the derivative of frequency, the phase
    will also be divided by N.
  • So the relation between the feedback phase qf
    and the output phase, qo, is

27
  • The control voltage, Vc(s), applied to the VCO is

28
  • The transfer function is

29
(No Transcript)
30
(No Transcript)
31
  • The VCO control voltage is then found as
  • The loop phase error is

32
  • Consider a step change Dw in the frequency, so
    that the input voltage is
  • The input phase function is
  • where U(t) is the unit step function.

33
  • The Laplace transform is

34
First-Order Loop
  • First consider the simplest case of a PLL with no
    loop filter.
  • Then H(s) 1, and the VCO control voltage for a
    step change in frequency, reduces to
  • due to partial fraction expansion.

35
  • Since there is a maximum of one pole, the system
    is a first-order loop.
  • This result shows how the VCO control voltage
    varies in response to a step change in the input
    frequency.
  • At t 0, vc(t) 0.
  • The output frequency is w0 wc,the free-running
    VCO frequency.
  • In the limit as t??, the control voltage
    exponentially converges to

36
  • Then the output voltage of the VCO is, after
    locking, given by
  • which shows that the output frequency has tracked
    the input step in frequency, and is multiplied by
    N.

37
  • The time required for the output of the PLL to
    respond to the step change in input frequency is
    called the acquisition time.

38
(No Transcript)
39
(No Transcript)
