Geothermal Earth Energy

1
Geothermal Earth Energy
GEOTHERMIX Distribution Inc

• The Ideal Choice

2

• ..in fact, our home is right on top of a major
  source of energy our own backyard..

3

• The underground temperature stays relatively
  constant all year

4

• Geothermal systems circulate a water-based
  solution through a "loop" of small diameter,
  underground pipes

5
Types of Loops
Vertical Ground Closed Loops
Horizontal Ground Closed Loops
Open Loop System
6
Heating mode
7

• In winter, its much easier to capture heat from
  the soil at a moderate 50o F. than from the
  atmosphere when the air temperature is below
  zero.

8
Cooling mode
9

• In summer, the relatively cool ground absorbs a
  homes waste heat more readily than the warm
  outdoor air.

10

• Studies show that approximately 70 percent of the
  energy used in a Geothermal Heating and Cooling
  System is renewable energy from the ground.

11

• The remainder is clean, electrical energy which
  is employed to concentrate heat and transport it
  from one location to another.

12

• Geothermal systems are extremely energy efficient
  since they only need a comparably small amount of
  electricity to power the pump, compressor and
  fan.

13

• The energy efficiency of heating equipment can be
  compared by looking at the rated COP or
  Coefficient of Performance of the unit. COP is
  the ratio of energy output to energy input thus a
  higher COP rating indicates a more efficient
  unit.

14

• The COP of an electric furnace is 1, since each
  watt of electricity put into it produces the
  equivalent of 1 watt of heat energy out. The COP
  of a NORDIC unit is 3 or greater. Each watt the
  heat pump uses to run it's transferring mechanism
  enables it to draw 2 or more from the earth thus
  giving a total of 3 or more units out for every 1
  unit put in.

15

• When you use a geothermal comfort system you are
  choosing the highest quality, best-performing
  heating and cooling system available!

16
Safe and clean

• No flame, no flue, no odors, and no danger of
  fire or fumes. You can also benefit from less
  dust and better indoor air quality.

17
Environment

• The system emits no C02 which is considered a
  major contributor to environmental air pollution.
  This is Earths natural thermal energy, a
  renewable resource, that Mother Nature provides
  us.

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Comfortable

• The system provides precise distribution of
  warmer air in winter. Gone are the uneven
  temperatures experienced with ordinary furnaces.
  In summer you get central air conditioning with
  better dehumidification.

23
Reliability

• Microprocessor controls and state-of-the-are
  components allow smooth operation and years of
  low maintenance and service.

24
Quiet operation

• A super efficient compressor and soft-start,
  variable-speed fan make the system so quiet, that
  many people find themselves checking to make sure
  the systems is actually on.

25
Flexibility

• You get heating, central air conditioning and
  domestic hot water. Thats three systemsall from
  the same compact unit.

26
Attractive

• The completely self-contained unit is maintained
  indoors. There is no need for noisy, unsightly,
  outside condensing equipment.

27
Adaptability to comfort zoning

• Simple addition of a comfort zoning control allow
  the systems supply just the right amount of
  heating or cooling comfort to only the areas that
  require it.

Source Geothermal Heat Pump Consortium, Inc.
28
GEOTHERMIX Distribution Inc profile

• Company type
• Sales of HVAC systems, based on Renewable Energy
  technology

29
Company sector of activity

• Renewable Energy, Design and installation of
  geothermal solutions for residential, commercial
  and industrial applications.

30
Brief description of the Company

• GEOTHERMIX Distribution is a Canadian corporation
  offering Geothermal Heating and Cooling
  solutions for residential, commercial and
  industrial applications

31
Key services include

• Equipment distribution
• Project Planning, Management and Quality control
• Heat Load Calculations and Analysis
• Ground Loop Design
• Installation and Product training

32
We are also offering

• Education program for everyone who cares to learn
  about the benefits of using geothermal over
  electricity, gas and fuel based systems
• Our assistance to government and private
  organizations in establishing geothermal system
  installation standards

33
Target Partner

• We are looking for potential co-operation
  partners in our field of interest.
• It may be Governmental institutions, HVAC
  distributors and/ or contractors, able to carry
  tasks related to proper installation and support
  of geothermal heating and cooling system.
