A Practical Introduction to TALx86

1
A Practical Introduction to TALx86

• CS342
• February 15, 2007
• Spencer Burdette

2
References

• Greg Morrisett, Karl Crary, Neal Glew, Dan
  Grossman, Richard Samuels, Frederick Smith, David
  Walker, Stephanie Weirich, and Steve Zdancewic
  TALx86 A realistic typed assembly language. In
  the 1999 ACM SIGPLAN Workshop on Compiler Support
  for System Software, pages 25-35, Atlanta, GA,
  USA, May 1999.
• Kedar N. Swadi and Andrew W. Appel. Typed Machine
  Language and its Semantics.
• Dan Grossman and Greg Morrisett.  Scalable
  Certification for Typed Assembly Language.  In
  the 2000 ACM SIGPLAN Workshop on Types in
  Compilation, Montreal, Canada, September 2000.
• Numerous Wikipedia articles http//www.wikipedia.
  org
• The Cornell TALx86 homepage http//www.cs.cornell
  .edu/talc/

3
Prerequisites

• Type theory notation and operations
• Various notations that formalize programming
  semantics
• Polymorphic lambda calculus
• First order predicate calculus
• Functional program languages that lend themselves
  to theorem proving
• ML, CAML, OCAML
• High Level Language polymorphism constructs
• ad-hoc, subtyping, parametric, etc.
• Assembler Operations and Optimizations
• x86, control-flow graphs, tail-call elimination,
  constant folding, etc.

S
S
R
R
4
Type Safety

• A looser interpretation than merely data type
  safety, (e.g. casting a long int to a char)
• A type error is defined as an attempt to perform
  an operation on some value that is not
  appropriate to its type.
• e.g. Setting the program counter to an address
  found in a local buffer (buffer overflow).
• Performing an arithmetic function on
  uninitialized data.
• Dereferencing a NULL pointer.

5
Type Safety (contd)

• Type safety is closely linked with memory safety.
• Allowing an arbitrary integer to be used as a
  pointer violates the principles of memory safety.
• Bounds checking of arrays is required for type
  safety.
• For the sake of simplicity, assume that most (if
  not all) types of programmatic flaws that have
  been discussed thus far in our class can be
  attributed to type violations.
• Type safety ultimately aims to provide strong
  guarantees about the runtime behavior of a
  system.
• Useful for proof-carrying or certified code
  deployment.

6
Type Safety Classifications (1 of 4)

• Static
• Early compile time (semantic analysis)
• Compiler complains of mismatched types in
  assignments and other expressions remedied using
  explicit casts.
• Late or post compile time (optimization time)
• Compiler (or a related tool) constructs data and
  control flow graphs and infers types of values
  from series of unifications and reductions.
  (Hindley-Milner type inference algorithm).

7
Type Safety Classifications (2 of 4)

• Dynamic
• Run-time environment assigns or infers types of
  variables during execution.
• Hybrid
• Polymorphic behavior of language requires
  annotation of certain variables that can not be
  resolved to a type during the static phase.

8
Type Safety Classifications (3 of 4)

• Nominative vs. Structural
• Nominative types must share the precise name to
  be compatible
• Structural types must describe values that
  share the same structure to be compatible.
• Weak vs. Strong
• Computer scientist experts agree that the weakly
  vs. strongly typed distinction is a grey area.
• Indications that a programming language is weakly
  typed
• Compiler inserts implicit type conversions on
  behalf of the programmer.
• Language allows programmer access to underlying
  bit patterns of data types, thus allowing them to
  bypass type checking.
• Data types can be cast or used directly for
  memory access.

9
Type Safety Classifications (4 of 4)

• The series of type classifications results in a
  matrix

Language Static/Dynamic Weak/Strong Nominative/Structural Safe?
assembly none strong structural no
C static weak nominative no
Java hybrid strong nominative yes
Javascript dynamic weak nominative yes
Lisp dynamic strong structural yes
ML static strong structural yes
10
What is TALx86?

• Typed Assembly Language for a subset of the Intel
  x86 ISA.
• Consists of a RISC-like assembly language and
  operational semantics for a simple abstract
  machine.
• A formal type system that captures the possible
  register, stack, and memory states of a program
  as well as their transitions.
• Rigorous proofs (well beyond the scope of this
  presentation, thankfully) have demonstrated that
  TAL enforces certain safety guarantees.

11
Without the Jargon

• TALx86 is a low-level target language, analogous
  to Java bytecode, that is intended to support a
  variety of statically typed, weak or strong
  source languages.
• Like any good intermediate language, TALx86 has
  been designed to support common assembly-level
  optimizations.
• The TALx86 project provides tools for the
  assembly, disassembly, and linking of TAL
  binaries.

12
Advantages over JVML

• Semantic errors have been uncovered in the JVML
  verifier.
• It has been suggested that if type-soundness
  theorems had been applied to the JVML during the
  design phase, more bugs would have been
  prevented.
• It is difficult to compile high-level languages
  other than Java to the JVML, since the
  instructions and types are specifically tailored
  to Java.
• JIT compilation is used to accelerate
  performance, however an error in the JIT compiler
  can introduce a security hole, since JIT
  translation occurs after the verification step.

13
Diagram of Process
14
Explanation of Process

• Client receives packaged .tal files, similar to a
  .jar.
• Without access to or knowledge of the program
  source code or compiler, the TALx86 type verifier
  and link checker can be run.
• To prepare the code for execution, trusted
  modules are linked in for run time support, and
  memory management and array access and update
  macros are expanded.
• A somewhat optimized, type-safe native machine
  code binary is produced.

15
Type Annotation Classes

• Import and export interface information.
• Type constructor declarations, for new types and
  type abbreviations.
• Typing preconditions on code labels. Registers
  must have specific types before control may enter
  the associated code.
• Types on data labels, to specify type of a static
  data item.
• Typing coercions on instruction operands.
• Macro instructions, used to encapsulate small
  instruction sequences.

16
Crux of TALx86

• The most important feature of the type checker is
  3, the typing preconditions on code labels.
  General form of annotations
• Registers r1 through rn must contain types
  t1through tn before control is passed to the
  corresponding label.
• The bound type variables a1 an allow types on
  registers to be polymorphic, by treating them as
  abstract types.
• A set of kind of variables is supported,
  labeled with k, so only appropriate types are
  used to instantiate the bound type variables.

17
Reference code snippet

• / Calculate sum of first n natural numbers. /
• int i n1
• int s 0
• while (--i gt 0)
• s i
• Translated into TALx86 as (assumes n initially
  resides in ecx)
• mov eax, ecx i n
• inc eax i
• mov ebx, 0 s 0
• jmp test
• body eax B4, ebx B4
• add ebx, eax s i
• test eax B4, ebx B4
• dec eax --i
• cmp eax, 0 i gt 0
• jg body

18
An Actual Function

• int sum (int n)
• int i n1
• int s 0
• while (--i gt 0)
• s i
• return s
• Assume the caller places the return address in
  ebp and expects the return value in eax
• sum ecx B4, ebp eax B4
• mov eax, ecx i n
• inc eax i
• mov ebx, 0 s 0
• jmp test
• body eax B4, ebx B4, ebp eax B4
• add ebx, eax s i
• test eax B4, ebx B4, ebp eax B4
• dec eax --i

19
Problems with Previous Snippet

• Recall on the previous slide that the function
  sum() required the return address in ebp, the
  function parameter in ecx, and the return value
  in eax. Very ad-hoc approach, far from the
  standard calling convention.
• The standard C calling convention typically
  places arguments, return address, the old base
  pointer, local parameters, and possibly a return
  value on the stack.
• Values are not often passed among functions
  through registers.
• TALx86 is constructed so as to not be bound to a
  specific calling convention.

20
Stack Layout for a General Purpose Calling
Convention
esp
Caller (int p) char a Callee(a,
p) Callee(char a, int p) int i //
do stuff
Local variables of Callee
Old Base Pointer
Return Address
Parameters for Callee
Local variables of Caller
Old Base Pointer
Return Address
Parameters for Caller
ebp
21
TALx86 Stack Abstraction and Stack Datatypes

• Stack is defined as a list of types.
• s is a stack type
• se represents an empty stack
• ts a type that describes stacks where the top
  most element is of type t and the rest of the
  stack is described by s.
• Example
• eax B4B4B4se
• stack type with three elements, a return address
  expecting a B4 in eax, followed by two B4 values.
• esp can be bound to a stack type with the label
  sptr.

22
Revisiting our Reference Code

• int sum (int n)
• / Function body /
• The above code originally yielded the following
  TALx86 label
• sum ecx B4, ebp eax B4
• This represents a non-standard calling convention
• Using TALx86 stack abstractions and stack types,
  the sum() label can be rewritten as
• sum esp sptr eax B4B4se
• Read as Esp must contain a stack pointer that
  points to a section of code requiring a B4 in eax
  (i.e. the return address), followed by a B4.
• Spot a problem? The rewritten label does not
  allow for arbitrary stack depths.

23
Supporting Common Calling Conventions (Take 3)

• TALx86 supports stack polymorphism in order to
  abstract portions of the stack.
• Rewrite as
• sum esp sptr eax B4, esp sptr
  B4rB4r
• In order to enter the code associated with the
  sum label
• esp must be a stack pointer that points to a
  section of code.
• The code pointed to by sptr must require
• eax to hold a B4
• esp to hold a stack pointer that contains a B4
  (essentially, an address)
• Following that address, there can be some other
  stuff, r.
• Following the return address, our sums stack
  must contain a B4 (the input value n), and some
  other stuff r.

24
Dynamic Memory

• TALx86 provides an assembly level macro for heap
  allocation of data, malloc.
• malloc allocates memory and inserts a pointer to
  the newly allocated space in eax.
• Proper initialization of dynamic memory is
  critical to type-safety, so a variance is added
  to each field.
• e.g. B4u, B4r, B4w, B4rw
• Field variances are tracked.
• Uninitialized data can be written, but not read.

25
Dynamic Memory (contd)

• Simple Example
• malloc 4, ltB4gt
• mov eax0, 3
• After the first instruction, the verifier assigns
  eax the type B4u, a pointer to an
  uninitialized B4.
• After the second instruction, the type of eax
  becomes
• B4rw, a pointer to a readable and writeable
  B4.
• Naturally, these types can be used as constraints
  for basic block labels.

26
Arrays

• Array sizes and indices cannot always be
  determined statically, however a type safe
  language must guarantee that any index lies
  between 0 and the physical size of the array.
• TALx86 introduces macros to handle array
  subscripting and updating asub, aupd,
  respectively.
• Two type constructors are also provided
• S(s), where s some constant or an abstract
  value, a.
• array(s, tv)
• s a type expression representing the size of
  the array.
• t type of element.
• v variance (one of u, r, w, or rw)

27
Array Example

• Simple Example
• Increment each element of a 5 integer array.
• lab eax array(5, B4rw), ebx S(5)
• mov ecx, 2
• put eaxecx into edx, array size in ebx, B4
  size is 4
• asub edx, eax, 4, ecx, ebx
• inc edx
• put edx into eaxecx, array size in ebx, B4
  size is 4
• aupd eax, 4, ecx, edx, ebx
• Clearly only works for arrays of size 5. Here
  comes the abstract notation
• Sint.eax array(s, B4rw), ebx S(s)

28
Link Verification

• Link Verifier
• Ensures that xxx.tal make valid assumptions about
  the files and types they share with other modules
  using the corresponding xxx_i.tali and xxx_e.tali
  files.
• In addition to verifying that there are no
  missing or multiple symbol definitions, the
  TALx86 linker checks that the files agree on the
  types of shared values.

29
Type Verification

• Type Verification
• Using the given annotations, performs type
  verification using a type inference algorithm
• Algorithm succeeds if a set of values can be
  generated that preserve the label preconditions
  while progressing through each of the possible
  states.
• If the algorithm get stuck, the code is not
  type safe.
• Optimization methods are performed (constant
  folding, common subexpression reduction,
  tail-call elimination, etc.) to collapse code
  size and minimize runtime overhead.
• Anything that is proven to be known at assembly
  time is flattened. Run time checks are preserved
  elsewhere.

30
Benefits

• Language design has been supported by rigorously
  proven type-soundness theorems.
• Target language is intended to be more generic
  than JVML, thus allowing a wider range of source
  languages to compile toward it.
• Ideally, assembly-level optimizations will yield
  higher performance than JVML.

31
Limitations

• Although the researchers claim that a type-unsafe
  source language (such as C) can be compiled to
  TALx86, the restrictions of the target language
  contradict this claim.
• TALx86 specifically forbids pointer arithmetic,
  the address operator, and pointer casts, since
  compiling these features safely would impose a
  significant performance penalty. (As weve
  witnessed in previous discussions!)
• Memory management type variance (u, r, w, rw)
  tracking does not support aliasing.
• No floating point handling.
• Essentially, only a subset of higher level source
  language capabilities are provided, and they are
  only mapped to a subset of the x86 ISA.

32
Discussion

• THANK YOU
