Cardiovascular System

1
Cardiovascular System
2
Cardiovascular System

• Functions
• pump saturated oxygenated blood into arterial
  system ? cells
• pump desaturated deoxygenated blood to lungs via
  veins for reoxygenation
• Heart size depends on persons size
• ? size of fist

3
(No Transcript)
4
(No Transcript)
5
Four Chambers

• Right atrium (deoxygenated bld)
• ?
• Right ventricle (to lungs)
• ?
• Left atrium (receives oxygenated blood)
• ?
• Left ventricle (to systemic circulation)

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
2 Types of Valves

• AV valves - mitral between LA LV
• - tricuspid between RA RV
• Prevents backflow during contraction - systole
• Semilunar valves - prevent backflow during
  relaxation of ventricles - diastole

10
Cardiovascular System

• Right left side of heart is divided by cardiac
  septum.

11
Cardiac Cycle

• Systole Diastole 1 heartbeat
• Systole - period when ventricles contract eject
  blood
• - mitral tricuspid close
• - S1 produced

12
Cardiac Cycle

• Diastole - ventricles in relaxed state
• - atria contract ? blood to ventricles
• - aortic pulmonary valve close
• - S2 produced

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Neck Vessels
18
Cardiovascular System

• under (N) circumstances impulse originates in
  S.A. node ? pacemaker
• (N) rate 60 - 100 bpm
• Dysrhythmias ? other cells also fire
• PAC ? abnormal firing in atrium
• PVC ? abnormal firing in ventricle

19
(No Transcript)
20
EKG

• Electrical activity recorded as specific waves.
• Records 2 Electrical Events
• 1. Depolarization - spread of impulse through
  heart
• 2. Repolarization - return of heart muscle to
  resting state.
• Sequence of R D ACTION POTENTIAL

21
EKG other terms

• Conductivity - cells ability to conduct
  transmit electrical impulse
• Contractility - ability of fibers to contract
• - ? contractility ? C.O.
• EKG
• P waves
• QRS complex
• ST segment

22
(No Transcript)
23
Factors Affecting Heart

• Exercise - ?
• Pain - ?
• Anxiety - ?
• Athletic fitness - ?
• Thyroxin - ?
• Epinephrine - ?
• ? temp - ?
• ? temp - ?

24
Blood Pressure

• Measure of pressure exerted by blood against
  walls of arteries.
• Systolic - pressure when heart contracts
• Diastolic - pressure with relaxation

25
Factors Affecting Blood Pressure

• Cardiac output - ? C.O. ? B/P
• - ? C.O. ? B/P
• Elasticity - ? with hardening ? B/P
• Blood viscosity - Polycythemia ? B/P
• - Anemia ?B/P

26
Factors Affecting Blood Pressure cont

• Age
• Weight
• Emotion
• Exercise

27
Assessment

• 1. History - major symptom, chest pain.
• P - exercise, straining, ?activity, emotional
• - rest, NTG, O2
• Q - crushing, heavy, dull, burning, pressure
• (own words)
• R - (L) Anterior chest
• - (R) arm, jaw, neck, shoulders

28
Assessment

• S - anorexia, N V
• - SOB, anxious, sweaty, dizzy
• T - constant, intermittent, sudden,
  insidious
• 2. SOB/Dyspnea - orthopnea
• 3. Palpitations - flutterings

29
Assessment

• 4. Sensation of skipped beats
• 5. Syncope - ? C.O. ? brain perfusion
• 6. Fatigue/weakness
• 7. Peripheral skin changes - edema - CHF
• tightness
• 8. Smoking - vasoconstriction
• 9. Weight gain

30
Assessment

• 10. Cough
• 11. Anxiety
• 12. Family history
• 13. Medications
• 14. Lifestyle
• 15. Post history

31
Physical Exam

• Cyanosis
• clubbing
• edema
• ? capillary refill
• pulse - rate, rhythm, strength
• pulse pressure - 120/80 pp - 40
• General appearance - distress, color, ? LOC
• Urinary output - ? kidney perfusion

32
Palpate Carotid artery
33
Abnormal Pulsations on Precordium
Base
Left Sternal Border
Apex
Apex
34
Congenital Heart Defects
35
Murmurs due to Vascular Defects
36
Murmurs due to valvular defects
37
Jugular Vein Pressure
38
Hepatojugular Reflex
39
Palpate Apical Impulse
40
Palpate Across Precordium
41
Auscultation

• S1, S2, S3, S4
• Look _at_ abnormal sounds
• Pericardial Friction Rub - coarse, scratchy
• Murmurs - rumbling, swishing
• - heard at valve area
• S3 ventricular wall compliance ?

42
Auscultatory Areas
43
Auscultate Heart Sounds
44
(No Transcript)
45
First and Second Heart sound
46
Auscultate Extra heart Sounds
47
Congestive Heart Failure
48
EKG readings

• Dysrhythmias indicate irregular pulse, chest
  pain, syncope, dyspnea
• Ventricular fibrillation (rapid bizarre
  pattern)
• palpate radial pulse - irregular ? possible
  atrial fibrillation
• Assess jugular vein pressure in semifowlers 45?

49
Diagnostic Tests

• Invasive
• Noninvasive
• 1. CXR - heart size
• - calcification of arteries, valves
• - position of heart

50
Diagnostic Tests

• 2. EKG - electrical activity
• - telemetry
• - dysrhythmias
• - drug therapy response Purpose of
• - response to activity telemetry
• detects pacemaker - pacemaker beats
• demand pacemaker - stimulates heart when
  rate drops below set level

51
Diagnostic Tests

• 3. Echocardiogram
• - high frequency sound waves through chest wall
• - Image on screen
• - returning signals recorded
• - look _at_ size, shape, motion
• - detect hypertrophy, pericardial effusion
  function of prosthetic valves.

52
Diagnostic Tests

• 4. Nuclear Medicine Testing
• - inject IV radioactive isotopes
• - uptake counted
• i.e. 1. Thallium scan - evaluates blood flow in
  different parts of heart
• - see old infarcts cold spots ?perfusion

53
Diagnostic Tests

• 4. Nuclear Medicine testing cont
• i.e. 2. Technetium Scan - taken up in area of MI
• - hot spots extent of damage
• - best 1 - 6 days

54
Diagnostic Tests

• Invasive
• 1. Cardiac catheterization
• 2. Biopsy
• 3. Pericardiocentesis - removal of fluid from
  pericardial sac.
• - see inflammation, tumor.

55
Diagnostic Tests

• Invasive cont
• 4. Stress test
• - detect etiology of chest pain
• - screen for CAD
• - functional capacity of heart after MI
• - drug therapy
• - identify dysrhymias by exercise

56
Diagnostic Tests

• Bloodwork
• - CBC - O2 capacity ? RBC, Hgb
• - WBC - ? MI (necrotic tissue)
• - ESR - Inflammation
• - Lytes - K
• - PT / PTT

57
Diagnostic Tests

• Bloodwork cont
• - Enzymes - CK - ? 6 hrs
• - peak 18 - 36 hrs
• - RTN 3 - 6 days
• - LD - ? 12 hrs
• - peak 48 - 72 hrs
• - RTN 10 - 14 days

58
Diagnostic Tests

• Bloodwork cont
• - Cholesterol / lipids
• - LDL - low density
• - HDL - high density ? carry lipids away
  from arteries.
