Observing System Monitoring Center OSMC

1
Observing System Monitoring Center (OSMC)

• NOAA Office of Climate Observation
• IOOS Global Systems Program

2
Observing System Monitoring Center

• Hosted by the NOAA Office of Climate Observation
  on behalf of the Joint WMO/IOC Technical
  Commission for Oceanography and Marine
  Meteorology (JCOMM).
• Web-based GIS tool designed for near-real-time
  monitoring of the Global Ocean Observing System
  -- the Global Component of IOOS.
• An observing system management tool
• Objectives
• Monitor the status of the globally distributed
  systems
• Report system statistics routinely and on demand
• Designed for the Global Component (international)
  with built-in capabilities extensible to the
  Coastal Component of IOOS.

3
Initial Global Ocean Observing System for Climate
Status against the GCOS Implementation Plan and
JCOMM targets
October 2006
56
Total in situ networks
57
100
42
81
81
43
66
48
21

• A total of 5635 platforms are
• maintained globally.
• 68 countries contributing.
• USA contribution -- 2963 platforms

4
Beta version of the OSMC is available for test
and evaluation.
5

• Sort by
• Platform type
• Variables being sampled
• Time frame
• Contributing Country

6
Drill down for platform metadata and real-time
data reports. Database operations at NOAA NDBC.
Hold data for 5 years. Updated daily. Data
source -- GTS via the GODAE server system at Navy
Monterey. Other web sources are being added.
7
LAS -- GIS specially designed for observing
system managers (by NOAA PMEL)
Viewer Options
ESRI -- commercial GIS tool
Google Earth -- open source GIS with great
graphics, fun for kids (and adults)
8
2094 Platforms reporting 40435 observations
yesterday
9
1252 Drifting Buoys reporting yesterday
10
385 Drifting Buoys reporting barometric pressure
11
18 Drifting Buoys reporting wind
12
396 Moored Buoys reporting yesterday
13
819 Ships reporting two days ago
Location security Ship observations are not
available for the most recent 48 hours.
14
2334 Argo Floats reporting during the past month
15
Japan had 352 Platforms reporting during the past
month
16
Canada had 155 Platforms reporting during the
past month
17
Australia had 123 Platforms reporting during the
past month
18
The United States had 1574 Platforms reporting
yesterday
19
Initial design for sorting by Platform

• Tide Gauge Stations
• o GLOSS
• o Climate Reference Stations
• o Real Time Reporting
• o Geocentrically Located
• o NWLON
• Drifting Buoys
• o High Seas Drifters
• o Barometer Drifters
• o Wind Drifters
• o Hurricane Drifters
• o Ice Buoys
• Moored Buoys
• o Weather Buoys
• o Tsunami Warning Stations
• o Tropical Moored Buoys
• o Climate Reference Stations
• o Ocean Carbon Stations
• o Ecosystem Monitoring Buoys

• Ships
• o Volunteer Observing Ships
• VOSClim
• Weather Obs
• Weather and Ocean Obs
• Ocean Carbon Obs
• o Dedicated Ships
• Ecosystem Monitoring
• Charting Surveys
• Climate Monitoring (SAMOS)
• Ocean Carbon Surveys
• Platform support
• Research
• Ocean Transport Stations
• o Moored arrays
• o Cable Measurements
• Shore and Bottom Stations
• o C-MAN Weather Stations
• o PORTS Systems

20
Observing System Monitoring Center

• Coastal real-time data from systems reported by
  NDBC are automatically included.
• OSMC extensions presently under development
• Tide gauge stations
• Tsunameters
• Ocean reference stations
• Future
• Map rubber banding and magnification for coastal
  regions
• Sorting by additional variables e.g., waves
• Entire suite of platforms

21
Test Version 2.00 beta www.jcommops.org/network
_status Feedback opa_at_jcommops.org
22
Thank You
