Modeling Component-based Software Systems with
UML 2.0
George T. Edwards Jaiganesh Balasubramanian Arvind
S. Krishna Vanderbilt University Nashville, TN
37203
2
Talk Outline

1. Introduction
2. UML 1.x History Shortcomings
3. UML 2.0 Specification, Design Goals and
   Enhancements
4. Case Study The UML 2.0 Structure Packages
5. Composite Structure
6. Example Collaboration Diagram
7. Component
8. Example Component Assembly
9. Deployment
10. Example Run-time Deployment

3
The Unified Modeling Language

• UML is a suite of object-oriented modeling
  packages that can be used to describe the
  structure and behavior of engineering systems.
• UML 1.0 was first standardized in 1996 to unify
  the Booch, Object Modeling Technique (OMT), and
  Object-Oriented Software Engineering (OOSE)
  methods.
• UML 1.x gained widespread acceptance as the
  standard way to describe software architecture.
• Over time, problems in the UML 1.x specification
  began to appear.
• Excessive size and complexity.
• Limited customizability.
• Some unused, poorly-defined elements.
• Inadequate support for components.

4
UML 2.0 Design Goals

• The UML 2.0 Request for Proposals laid out the
  following requirements
• Clarify the semantics of the generalization,
  dependency, and association relationships.
• Support encapsulation and scalability in
  behavioral modeling, especially for state
  machines and interactions.
• Remove restrictions on activity graph modeling
  due to the mapping to state machines.
• Add data flow modeling.
• Increase expressiveness of sequence diagrams.
• Enable the modeling of structural patterns, such
  as component-based development.

• The OMG has formulated an initiative called
  Model-Driven Architecture (MDA)
• A framework for a set of standards in support
  of a model-centered style of development
• Key characteristic of MDA
• The focus and principal products of software
  development are models.
• Key design goal for UML 2.0
• Improve the conceptual foundations of UML to
  provide better support for MDA.

5
UML 2.0 Specification

• UML 2.0 is divided into four sub-specifications.
• The infrastructure defines modeling primitives.
• The superstructure defines user-level packages.
• The diagram interchange allows the smooth
  exchange of UML-compliant models between software
  tools.
• The OCL description defines a formal language for
  constructing expressions on UML models.

The superstructure specification contains the
structure and behavior packages that nearly
everyone uses. The infrastructure specification
exists to simplify the overall UML hierarchy and
allow extensions.

6
UML 2.0 Structure Packages
The UML 2.0 Superstructure defines four packages
that successively depend on each other

• Class ? contains sub-packages that define the
  basic structural modeling concepts of UML,
  particularly classes and their relationships.
• Component ? contains artifacts for specifying
  software components, their interconnections and
  their implementations.
• Composite Structure ? allows representation of
  the internal structure of classes using
  containment and hierarchies.
• Deployment ? specifies a set of constructs that
  define the execution architecture of software
  systems.

7
Composite Structure Diagrams (1/3)

• Composite Structures are run-time instances of
  classes collaborating via connections.
• Why model Composite Structures?
• Allows representation of the internal structure
  of a class.
• Can represent run-time behavior of objects by
• specifying interconnections and collaborations
  between class instances.
• delegating operations to internally contained
  objects.

8
Composite Structure Diagrams (2/3)

• Composite Structure Diagrams extend the
  capabilities of Class Diagrams.
• Class Diagrams
• do not specify how internal parts are organized
  within a containing class.
• have no direct means of specifying how interfaces
  of internal parts interact with environment.

9
Composite Structure Diagrams (3/3)

• Modeling Elements
• Parts Connector ? models how internal
  instances are to be organized.
• Port ? defines an interaction point between a
  class and its environment or a class and its
  contents.
• Collaboration ? provides constructs for modeling
  roles played by connections.

10
Modeling Components (1/4)

• Components are highly flexible and reusable
  software modules.
• Have well-defined interfaces.
• Run on generic application servers.
• LOTS of other features that make them valuable
  software engineering artifacts.
• Why model components?
• Generate glue-code that wires components
  together.
• Configure component assemblies and underlying
  middleware.

11
Component Diagrams (2/4)

• UML 2.0 Components address the deficiencies of
  1.x Components
• UML 1.x components
• required syntax that did not scale well
• Diagrams with many components were difficult to
  understand, manage, and maintain.
• did not have the capability to precisely define
  interconnections and assemblies
• No ports for provided/required interfaces.
• No composition of component packages.

12
Component Diagrams (3/4)

• Modeling Elements
• Basic Component ? extends Structured Class.
• Packaging Component ? encapsulates other elements
  within a namespace.
• Both component types have two views
• External ? publicly visible properties and
  operations.
• Provided and required interfaces as ports.
• Wiring between components.
• Internal ? private properties and realizing
  classifiers.
• Delegation of port operations to contained class
  implementations.

13
Component Diagrams (4/4)

• Components interact with
• Interface ? specify the operations that the
  component implements as well as the operations
  that the component invokes.
• Class ? specify the internal operation
  implementations.
• Realization ? delegate interface operations to
  class implementations.
• Port ? specify the connection points between
  component interfaces.

14
Deployment Diagrams (1/2)

• The Deployment Package specifies the execution
  environment for component-based software systems.
• Comprises a set of constructs that can be used to
  represent the assignment of software artifacts to
  nodes.
• Why Model Deployments?
• Gain fine-grained control over the mapping of
  logical constructs, such as components, onto
  physical resources such as CPUs.
• Decouple platform-independent models from
  platform-specific models.

15
Deployment Diagrams (2/2)

• Modeling Elements
• Node ? represents hardware devices or software
  execution environments connected through
  communication paths to create networks of
  systems.
• Communication path ? an association between nodes
  through which they are able to exchange messages
  or signals.
• Artifact ? represents a concrete element in the
  physical world that is a result of a software
  development process.
• Deployment specification ? describes the
  configuration of artifacts deployed on the target
  nodes.

16
Concluding Remarks

• UML 2.0 represents the next generation of
  engineering system and business process modeling.
• New key features drive the evolutionary step
  towards the Model-driven Architecture.
• Support for component-based development.
• Interplay with CORBA Component Model.
• Assembly, configuration, and deployment modeling.
• Undoubtedly, engineers in all disciplines will
  become more and more dependent on standardized,
  semantically precise modeling paradigms.
• UML will continue to evolve as requirements and
  challenges arise.

17
