Safe and Responsible Biodiesel Production

1
Safe and Responsible Biodiesel Production

• Wilson College / Dickinson College
• Biodiesel Projects
• South Central PA

2
Our project

• Research the Best Practices for small scale
  biodiesel production
• Teach farmers to make fuel via a series of
  hands-on workshops
• Support 10 selected farmers with start-up funds
  and intensive follow-up training

3
Biodiesel Convert the fuel

• Reactants
• Vegetable Oil
• Methanol
• Lye catalyst
• Potassium or sodium
• Other inputs
• Energy (heat, mechanical)
• Labor

4
Biodiesel Convert the fuel

• Fatty acid methyl esters, AKA Biodiesel
• Crude glycerol byproduct
• Other products
• Wash water, bad veg oil

5
(No Transcript)
6
Straight Vegetable Oil optionConvert the vehicle

• Filtered vegetable oil is warmed using engine
  heat
• No added chemicals or money after initial
  investment
• One vehicle at a time

7
Biodiesel Process Steps
Heat oil to 130 degrees F
Determine recipe via chemical analysis
Collect used cooking oil and filter
React methanol and lye with hot oil
Allow gylcerol to settle, drain to storage
Recover methanol from fuel
Recover methanol from glycerol. Dispose of
glycerol appropriately
Wash and dry fuel
Filter fuel and use
8
SARE Project Teaching Farmers
9
Spoutwood Farm
10
New Morning Farm
11
One Straw Farm Appleseed Reactor
12
Dickinson College Biodiesel shop
13
Greensgrow Farm Project
14
Charlie Kolb 400 gallon reactor
15
Sankanac Farm CSA
16
Dry Tank Wilmer Newswanger
17
NMF Recommend SVO conversion
18

• Appleseed water heater based processor
• Closed system
• Affordable, effective
• 80 Gallon water heater
• 54 Gallon batches
• Plumbers delight methanol recovery condensor

19
Methanol recovery

• Regulatory compliance
• Simplify safe byproduct handling
• Save money energy

20
Secondary Containment
21
Talk to your fire chief

• Let them know what you are doing
• Ask for suggestions
• Work together to prevent accidents
• Tell your neighbors what you are up to

22
Glycerol If you recover methanol

• Compost
• Make soap
• Degreaser and floor cleaner
• Animal feed additive? (sweet, carbohydrate
  source)- watch pH
• Dust suppressant for roads and trails?
• Contact your local DEP office!

23
Glycerol composting research
24
Cover to reduce runoff
25
Glycerol, with methanol

• Contact your local DEP office
• Anaerobic (biogas) digester
• Industrial boilers/ kilns
• Landfill (ask permission from operator)
• We dont recommend burning at home. May create
  acrolein gas which is TOXIC

26
Wash water, on-farm

• Consult local DEP office
• Consider waterless alternatives
• Soap settling post-methanol recovery (GL1)
• Purolite bead filtration
• Constructed wetland for biofiltration
• Compost or dilute land application
• Far from any surface water or storm drain
• Watch for salt buildup
• Use a grease trap

27
Your Waste Water Treatment Plant will appreciate
a grease trap!
28
(No Transcript)
29
Gloves, goggles, dust mask
30
Signs and Labels!
31
Best Practices Manual

• www.wilson.edu/biodiesel
• steimanm_at_dickinson.edu
• How to information
• www.biodieselcommunity.org
• www.biodieselSMARTER.com
• www.b100supply.com
• www.utahbiodieselsupply.com
