Jake Brake Engine Brake

1
Jake Brake Engine Brake Features Benefits
2
Why an Engine Brake?
TODAYS VEHICLE CHALLENGES
THE JAKE BRAKE RETARDER SOLUTION

• Improved aerodynamics, heavier loads and higher
  speeds demand more use of the vehicle foundation
  brakes. Jake Brake retarder minimizes the use of
  foundation brakes and thus reduces the costs of
  brake maintenance, repairs and associated
  downtime.
• Jake Brake retarders help the driver maintain a
  safe higher average speed (or shorter trip
  times). Additionally, the vehicle is down for
  brake system maintenance or repairs less often.
• Foundation brakes fade when used excessively. A
  Jake Brake retarder reduces the use of foundation
  brakes on downhill grades as well as level land.
  Driver comfort and control translate to driver
  retention.
• Used truck guides document that a Jake Brake
  retarder-equipped vehicle will sell for a 1000
  premium. Fleets confirm that these vehicles sell
  faster.

• Maintenance Costs
• Productivity
• Safety
• Resale Time and Value

3
How An Engine Brake Works
Creating a power absorbing air compressor
4-stroke with engine brake As the piston
approaches top dead center (TDC) on the
compression stroke, the exhaust valve is opened,
exhausting high pressure air. Therefore, no
energy is returned to the piston in the expansion
stroke. This net loss of energy is called engine
retarding, made possible by a compression-release
brake (or engine brake).
Intake
Compression
Expansion
Exhaust
Release
4-stroke motoring sequence without engine brake
Intake
Compression
Expansion
Exhaust
4
What an Engine Brake does Enables faster
downhill control speed
Control Speed The constant speed at which a
vehicle can descend a given grade without the use
of the vehicle foundation brakes.
80,000 lbs. 6 Grade 13-speed trans.
(Actual results may vary due to specific engine
and vehicle configuration.)
5
What an Engine Brake does Reduces slowing
time/distances on flat land
Example Slowing from 55 MPH to 45 MPH
No Retarder
19.4 seconds
1,423 feet
10L Retarder
10.0 seconds
733 feet
14L Retarder
8.4 sec.
616 ft.
6
Why a Jake Brake Brand Engine Brake?

• Jacobs Vehicle Systems has 40 years of vehicle
  retarding expertise.
• Jacobs engineering staff and research
  development spending proportions are rivaled only
  by the aerospace industry.
• Jacobs Vehicle Systems is the vehicle retarding
  technological leader, demonstrated by product
  performance improvements of more than 20 since
  the early 1990s.
• Complete Jake Brake product line
• Jacobs Engine Brake for heavy duty engines
• Jacobs Exhaust Brake for medium duty engines
• Brakes available for every appropriate diesel
  engine/configuration
• Engineered in cooperation with engine
  manufacturers design team
• Interfaces with all vehicle functions (ECM, ABS,
  Cruise Control, Auto-shift transmission, etc.)
• Demonstrated to be among the most reliable and
  durable heavy truck components
• Parts, service warranty available through
  engine distributors and truck dealers nationwide.
• Over 2 Million Jacobs Engine Brakes sold
• Specified by name more than any other engine
  component.

7
Engineered For The Road Ahead
