MAEviz: Seismic Risk Assessment System

1
MAEviz Seismic Risk Assessment System

• October 31, 2008

2
Overview

• Scenario Emergency manager needs to determine
  short term shelter needs and longer term
  temporary housing after Magnitude 7.9 Earthquake
  in Shelby County Tennessee.
• Load Housing data and Freeways from Remote or
  Local Repositories
• Start from Dislocation Analysis and work
  backwards to create required inputs
• Damage Analysis with hazard uncertainty option
• Style View
• Result table with result columns highlighted
• Start from Dislocation analysis and work forward
  to Short Term Shelter Needs
• Highlight areas of large dislocation results
• Generate Shelter Supply requirements and display
  in report
• Run Temporary housing and report on housing
  assignments for displaced families

3
Create Scenario
Map View 2D or 3D maps
Scenario Data Maps, Tables, Fragility curves, etc.
Data Repositories Local File System, WebDAV,
PostGIS DB
4
Load Data Shelby county freeways
Loading Dataset Scenario view shows the dataset
loaded
Categorized Dataset Dataset are categorized in
the repositories
5
Load Data Building dataset (RES3)
Predefined Style The styles are predefined for
each dataset type
6
Execute Dislocation Analysis
Analysis User can choose an analysis among 50
analyses categorized
7
Execute Dislocation Analysis
Back Chaining User can create another analysis
which the analysis depends on
8
Execute Dislocation Analysis
Back Chaining New work flow is added
9
Execute Dislocation Analysis
View Maximized Each view can be maximized
Back Chaining New work flows are added
10
Dislocation Analysis Results
Layer Style User can customize the representation
of the layer
Map Legend Value classification is shown as map
legend
11
Dislocation Analysis Results
Tooltips Tooltip shows the description of column
and detailed value
Table View Results are displayed as table view
Highlighted Column The columns contained results
are highlighted
12
Short Term Shelter Needs Supplies
Whats next? What can the results of dislocation
feed into?
13
Short Term Shelter Needs Supplies
Whats next? MAEviz shows users possible next
analysis
14
Short Term Shelter Needs Supplies
Whats next? Short Term Shelter Needs Analysis is
added
15
Short Term Shelter Needs Supplies
Linking Views Selecting a row in the table
highlights the corresponding bridge on the map
16
Short Term Shelter Needs Supplies
Report MAEviz generates the report for shelter
needs and supplies (in PDF format)
Supplies for 1, 3, and 7 Day Planning
17
Temporary Housing Assignments
Temporary Housing Assignment Work Flow
18
Temporary Housing Assignments
Report Report of Housing Assignments includes
number of people assigned, capacity, address, etc.
19
Overview

• Decision makers of Shelby County need to exercise
  1,500,000 budget to retrofit highway bridges for
  preparing an earthquake (magnitude 7.9). They
  have six retrofit methods to be implemented and
  want to minimize the societal cost (which is
  measured via total system travel time (TSTT)).
  As a result, they need to know which bridge needs
  to be retrofitted with which method while
  minimizing TSTT under budget constraint.

20
Network-Based Seismic Retrofit (NBSR)
AnalysisSetting up the analysis
Input Parameter Form User interface for users to
enter input parameters the default values are
provided
NBSR Analysis Work Flow It shows the dependencies
and input parameters
21
Network-Based Seismic Retrofit (NBSR)
AnalysisResults Bridges selected for
retrofitting
Customized Layout Users can customized the
location and size of each view for their
convenience
Linking Views Selecting a row in the table
highlights the corresponding bridge on the map
22
Network-Based Seismic Retrofit (NBSR)
AnalysisResults Link Flow
2D 3D Map View 3D maps shows different
thickness of tube by link flow
Map Legend Map Legend shows the color
classification by link flow in 2D map
Linking Views Selecting a row in the table
highlights the corresponding link on the map
Table View Current table is sorted by link flow
(result columns are highlighted)
23
Network-Based Seismic Retrofit (NBSR)
AnalysisResults Total System Travel Time
Chart View Various charts are provided to
visualize the results. Users can zoom into
detailed ranges of data.
Tooltips When users move the cursor over the bar,
it displays detailed information.
