Program Checking

1
Program Checking

• Sampath Kannan
• University of Pennsylvania

2
Talk Outline

• Traditional software reliability paradigms.
• Program Checking
• Examples
• Extensions
• Spot checking
• Streams and stream checking
• Monitoring JAVA programs
• Future Directions

3
Traditional Approaches
Testing

• ad hoc or random test cases.
• Need to know answers to these cases.
• No mathematical guarantees.
• May look inside program.
• Done during design phase.

4
Verification

• Proves programs correct.
• Hard to do.
• Proofs not human-friendly.
• Looks inside programs.
• Done during design phase.

5
Program Checking BK95
I
O
6
Correct if P is correct on all inputs.
Buggy if P is wrong on input I.

Checkers outputs are as above with high
probability. Notion of correctness of P assumed
to be provided by some rigorous means.
7
Example Matrix Multiplication
Freivalds 79.
A, B
C
Checker
?
A(Bv) Cv
vector v
8
Example Graph Isomorphism
G
H
9
Yes, here is isomorphism
G, H
No
CheckerBK95
If Program says No

• Pick G or H at random.
• Permute to get graph K.
• Ask the program (G,K).
• If K obtained from G Expect Yes.
• If K obtained from H Expect No.
• Call program Buggy if it does not meet
  expectation.

10
Program Checking Paradigm

• Checking done at run-time
• Overhead to program.
• Errors detected as they happen.
• Environment errors also detected.
• Actual implementation is checked.
• Checkers are problem specific
• Checker design requires ingenuity.
• Not universal paradigm.
• Works against all programs for a problem.
• Dont need to look at inside of program.

11
Checking Correctness of Memory
BEGKN 94.
checker requests
Unreliable Memory
user requests
User
Can check using O(log N)-sized reliable memory
that an adversarial memory (RAM, Stack, Queue) of
size N is functioning correctly. Techniques
used Special classes of hash functions,
cryptographic primitives.
12
Problems/Areas with Checkers

• Linear Algebra
• Group Theory
• Arithmetic
• Number Theory
• Polynomial Algebra
• Computations with Real Numbers
• Sorting
• Data Structures
• Graph Problems
• Combinatorial Optimization

13
Summary of Part 1

• Program checking works on mathematically
  clean problems... but it takes a fair amount
• of effort to come up with a good checker.
• The definition requires the checker itself
• to be simpler (faster) than the program
  being checked, but this does not count the
• cost of additional calls to the program.

Challenge 1) Reduce Overhead 2) Design
checkers for more problems So that the technique
can be applied to systems w. low resources.
14
Spot-Checking
Question Can we settle for an approximate
notion of correctness in order to drastically
reduce overhead? Answer We can in some cases.
Using spot checks EKKRV 99
15
Spot Checking Sorting
A program for sorting is approximately correct
if (1 e) fraction of the output is in ascending
order and (1 - e) fraction of the output elements
are input elements. We want a spot-checker
that Says okay to correct output Says
Buggy to output that is not even
approximately correct. How do we design such a
spot-checker?

16

• Repeat O(1/e) times
• Pick random element x from input.
• Binary search for x in output.
• If (x not found) report Buggy
• Report okay.

Method works because All elements that are
successfully found by binary search form an
ascending sequence. We are verifying that there
is a large ascending sequence and that most
input elements are in output. Checker takes
O(log n) time!
17
Streams

• Deluge of time-dependent data... if we dont
  process
• it soon, it will become irrelevant! or it will
  be too late!
• Need to change both
• What we ask about the data.
• How we find the answer to our questions.
• Need good theoretical models to model the
  constraints under which we operate.

18
Model
FKSV 99.
0 1 0 0 1 0 1 1 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 0 1
1 1 1 1 0 1 0 1 0 1 1 0 1 1 0 1 0 1 1 0 1 1 1 0
could be a CISCO router with netflow software.
Processor
(size is small relative to stream size.)
Memory
19
Detecting Anomalies
0 1 0 0 1 0 1 1 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 0 1
1 1 1 1 0 1 0 1 0 1 1 0 1 1 0 1 0 1 1 0 1 1 1 0
Is this the output of a fair coin? Given streams
of data describing internet traffic flow is there
an anomalous day? Application to intrusion
detection? Can you stand on Times Square, watch
the NYSE ticker tape go by twice and decide
whether there was a big change in the stock
market in between?
20
Main Results on Streams
. . . (1, 3), (7, 12), (3, 6), (2, -1), (4, -5),
(7, 6), (8, 0), (1, -4), (9, 5), (3, -2), (5,
-10), (2, 6) . . .
What is the L1 distance between these two
functions? (i.e., )
Our solution Above distance can be
approximated arbitrarily closely using memory
that is only logarithmic in length of stream.
Stream computing will become increasingly
important as will the problem of verifying
properties of data streams.
21
Run-time Monitoring and Checking

• Sampath Kannan
• Moonjoo Kim
• Insup Lee
• Oleg Sokolsky
• Mahesh Viswanathan

22
Objectives

• Static analysis
• abstract model
• Dynamic behavior checking
• consistency between abstract model and
  implementation
• To provide a framework for automatic generation
  of monitors and checkers

23
Fundamental Issues

• How does a monitor gather information from a
  running system?
• How does the monitor relate to requirements?
• How do we integrate dynamic monitoring with
  static analysis?
• Can monitor be used to steer a system?
• What mathematical guarantees do monitors provide?

24
MAC Architecture
System Spec
Requirement Spec
Formal verification
Design
25
Design Issues

• Filter
• passive versus active
• when to take snapshot
• Event Handler
• mapping between concrete state and abstract event
• Checker
• inclusion based on trace, ready semantics,
  bisimulation
• Corrector
• how to provide feedback

26
Properties

• Safety
• e.g. The gate is always closed while a train is
  in crossing.
• Security
• e.g. detecting denial of service attack.
• Performance, Real-time
• e.g. QoS - does my car accelerate from 0-60 in 5
  secs?
• Resource usage
• e.g. 10 MB of memory.

27
Future Directions

• Run-time assurance of correctness is an
  attractive complement to static analysis.
• Traditional correctness paradigms are more able
  to deal with flow-of-control correctness, type
  checks and the like. The big gap is in
  ensuring correctness of mathematically
  sophisticated computation. Program checking
  fills this gap.
• As we begin to reason about large programs and
  large volumes of input and output we need
• non-traditional models (both in theory and
  practice) for talking about efficient
  computation.
