Nortel WiMAX and Wireless MeshSolution
Experience for Wireless city

• Jay Huang, Ph.D.
• Vice President, Carrier Networks, Asia
• Nortel

3
Market Drivers

• Reduces Cost
• Flatter architectures reduce complexity
• All IP service delivery get rid of circuit
  switched
• Data will have to be cheaper to drive new
  services
• Kick Starts Economic Development
• Attract new businesses, residents and tourists
• Bridges the Digital Divide
• Allows disadvantaged citizens to economically
  access on-line government, education, health and
  social services
• Improves Security and Public Safety
• When integrated with digital surveillance cameras
  have reduced crime by more than 50

Broadband access will enable Chapleau to
connect, and compete, with other communities
throughout the world, positioning us as a center
for innovation and change." Earle Freeborn,
Mayor of the Township of Chapleau, Ontario
4
Addressable Markets

• Outdoor Campus Environments
• Extending WLAN coverage to outdoor campus
  environments
• Provide students and faculty with access to
  university resources while on campus
• Supplemental revenue for universities competing
  with cell-phone usage

• Government Municipalities, Rural Areas
• Downtown City WiFi Hot-Zones
• Public safety networks, Police, Fire, Video
  Surveillance
• Broadband solution to under serviced rural
  communities

• Industrial Venues
• Manufacturing, mining facilities, ports,
  warehouses
• RFID Sensor Transport

• WiMAX for Backhaul
• Backhaul for WMN and Cellular BTS

5
WiMAX and WMN Network Architecture
Wireless Mesh Serving Area
Service Management Center
Data Base(s)
Billing Server
Application Server(s)
Nortel Wireless Mesh APs
Partner SMC
Nortel Metro Optical Metro
City Data Center
Nortel Ethernet Switch
Internet
Nortel VPN Gateway
WiMAX for Mesh Network Backhaul
Application Servers
File Servers
Service Providers
Provider 1
Nortel Switched Firewall
Provider 2
Partner AC
Nortel Wireless 7250 Gateways
Nortel Communication Servers
Nortel WiMAX 1000 series portfolio
Provider n
WiMAX Serving Area
6
Applications
Improving Municipal Operations and Service
Delivery
Public Safety
Municipal Operations

• Inspections and code compliant
• Fleet/asset tracking
• Workflow automation
• Automated meter
• reading
• VoIP Services

• Video Surveillance
• Mobile VPN
• Emergency and crisis management
• Rapid first responder Interoperability

Internet Services
Fully Tested and Integrated

• Residential
• Business store front
• Wholesale to competing ISPs
• Advertisement
• Roaming surcharges

• Come see the applications in action!
• Dedicated integration and testing lab in Raleigh,
  NC

7
Automated Meter ReadingReducing Utility
Operational Expenses
Data Collector Unit

• Reduce OPEX (personnel, equipment, vehicles)
• Reduce in-field safety accidents
• Improve data accuracy reducing customer
  complaints
• Improve customer satisfaction (leak detection,
  accurate billing)

METER TRANSMISSION UNIT (MTU)
Mesh AP
Reduce cost per meter read from 2 to 0.10
CUSTOMER SUPPORT CENTER
8
Nortel Multimedia ApplicationsTake Your Office
Anywhere
IP Telephony
SIP Multimedia Applications
Self Service
3rd Party Apps
Real-Time Collaborative Applications
Contact Center
Nortel Soft/Hard Clients
Unified Messaging

• Office workers
• Mobile workers
• Tele-workers

3rd Party Clients
Presence
MultimediaDashboard
Improved Communications for Todays distributed
and Mobile Workforce
9
RFID and Sensor Applications
Improving Efficiency with Real-Time Status
Fleet tracking monitoring
Inventory management asset tracking
Yard management access
One architecture supports all RFID, location, and
sensor services in the municipality... providing
simplified management extensive scalability
10
Fleet Tracking and Monitoring
Improving the Return on Mobile Assets
Identification, location, time stamp, route
path, speed, vibration,
Optimize Fleet Operations
Municipal Wireless Mesh
Edge appliance with GPS, sensors WiFi
Mapping Software Corporate ERP fleet management
Sensor Network Manager Appliance with data
tracking policies
Customer savings of 4,500 per vehicle per year
via increased asset utilization, route
optimization, and fuel savings
11
City of Taipei 2006 Intelligent City of the
Year

• Investment Drivers
• Support Tawains Mobile City Vision
• Support Taipeis large population with innovative
  new broadband technologies
• Solution
• Wireless Mesh Network Solution
• Aptilo Subscriber Management Solution
• Full Turnkey Services
• Results
• High-speed wireless services in Mass Rapid
  Transportation stations, selected commercial
  buildings and other key locations across the city

• Innovative applications such as E-Bus, and
  M-Medicine
• Support for 272 sq Km, 2.65M people, 10,000 APs

"With powerful business models for government
applications, enterprises, and wireless and
wireline service providers, Nortel's Wireless
Mesh Network solution enables delivery of secure
wireless broadband services that can provide a
cost-effective method for extending wireless LAN
coverage more broadly into business and end-user
markets." C.S. Lin, Chairman of Qware, Chief
Executive Officer of President Group
12
Golden Telecom MoscowEuropes Largest Wireless
Mesh Network

• Investment Drivers
• Expansion of its broadband access network through
  Wi-Fi capabilities in 2006
• Indoor and outdoor coverage to extend to 3.9M
  residents
• Solution
• Wireless Mesh Networking
• Full Turnkey Services
• Results
• VOIP/Internet Access via Aport Search engine,
  location services
• 7,500 APs phased in approach
• Commercial launched in Mar 1st 2007

13
Marshalltown Iowa Kick-Starting Economic
Development

• Investment Drivers
• Differentiate community, attract new business
  investment, retain current businesses and
  residents.
• Ubiquitous mobility services to city
  departments, business and residents
• Solution Wireless Mesh Network Solution
• Results
• First Wi-Fi city network in the State of Iowa
• Lower capital outlay than large-scale fiber
• Citizens, city workers, businesses and visitors
  gain seamless access and roaming
• Ready for public safety applications, eg. for
  emergency response workers and video surveillance
  purposes, local hospital applications

14
SAB/NetagoCanadas First Commercial WiMAX
Deployment

• Investment Drivers
• Bring wireless broadband to underserved, rural
  communities in Southeastern Alberta
• Solution
• Fixed 802.16d solution in 3.5GHz spectrum
• Collaborative project Public and Private
  Enterprise
• Results
• Wireless broadband access to residences and
  business
• Internet, email, multimedia apps, VoIP, digital
  video surveillance and remote telemetry
• Coverage of 8000 sq. miles (21,000 sq. km)

15
WiMAX 16d and WMN Deployments
Strong Ongoing Customer and Partner Deployments

• City of Taipei - Taiwan
• Southern city of Kaohsiung -Taiwan
• National Police Agency, Ministry of Interior -
  Taiwan
• CMCC Hebei _ PRC
• Jinan University - PRC
• TianJin TEDA PRC
• ShenZhen Foxcomm campus - PRC
• Seowon University Korea
• Vex-Telemar - Brazil
• BHP Billiton - Suriname
• Verizon Puerto Rico
• Super Group South Africa
• Simbiti Gulf Estate South Africa
• Chapleau - Canada
• Annapolis, Maryland

• University of Arkansas
• National Taiwan University
• Edith Cowan University, Australia
• Data Ventures, Inc / Ronco - USA
• MIT
• NASA Return to Flight mission
• SCANA, Riverbanks Zoo South Carolina
• Marshalltown, Iowa
• SimplySurf - Dunrobin
• Chapleau Rural Deployment
• City of Richardson, Texas
• Royal Ottawa Hospital
• Boracay Island, beach resort Philippines
• Tsukuba University - Japan
• ..and more

16
The Nortel Difference

• Cost-effective method for extending WLAN coverage
  more broadly into business and end user markets.
• Secure platform for WLAN access and is highly
  flexible in terms of capacity, coverage, and
  availability.
• End-to-End solution w/ fully tested and
  integrated application suites Campus,
  Municipality, Hotspot, Industrial and backhaul
  deployments.
