• SCADA

• Any way you want it
• The best of both worlds from Invensys

2
The two faces of SCADA

• Traditional SCADA for pipelines, power
  distribution or anything that spans great
  distances
• Typical
• Stand-Alone
• Networked
• Local control SCADA for plant or unit operations
  or any architecture that is within a defined
  boundary
• DCS
• PC based
• HMI / PLC

3
Only Invensys
delivering leading brand solutions, from the
production line to the bottom line.
4
Typical SCADA Platform
Programming/Engineering Stations UNIX or Microsoft
Enterprise PCs
Operator Stations Microsoft
WAN
Duel 100BaseT Ethernet
Communications Servers
Color Printer
B W Printer
Telecommunications Circuits (Multiple Protocols)
Web Interface Server
SCADA/History/Application Servers
RTU 50
RTU 50
OPTOnet
IED

• RTU 10

5
Stand Alone SCADA
HMI/SCADA Server
RS-232
Communications Network
RTU n
RTU 3
RTU 4
RTU 2
RTU 1
6
Networked SCADA
Report Printer
Alarm/Event Printer
Print Server
Print Server
SCADA Server Historical Archiving
Redundant Ethernet LAN 802.3
SCADA Server Data Acquisition
Data Concentrator
Modem Radio
Fiber Optic Converter
Modem Radio
Modem Radio
Modem Radio
Field Data Acquisition Local control
RTU 2
RTU 3
RTU 1
Serial Line
Serial Line
Serial Line
Fiber Optic Converter
Fiber Optic Converter
Fiber Optic Converter
Fiber Optic Cable
7
Plant Control (DCS world)
Corporate Network TCP/IP, DecNet, NFS, SNA,
X.25, OSI, Novell
Workstations
PCs
Computers
Fault Tolerant Process LAN (HSE 100MB Fiber)
Personal Workstation
Table-Top Workstation
Table-Top Workstation
Spectrum
PLC
Single Station Controllers
RTUs
Scales
Fault Tolerant Fieldbus
Fault Tolerant Fieldbus
Bar Code
Scanners
Etc...
8
Stand Alone HMI / PLC
HMI / MMI Operator Console
Programming Terminal
PLC processor
DIN Rail I/O
9
Networked HMI/PLC
Corporate Network TCP/IP, DecNet, NFS, SNA,
X.25, OSI, Novell
PCs
Server
Process LAN
Programming
Single Station Controllers
PLC
RTUs
Scales
Remote PC
Bar Code
Scanners
Etc...
I/O
I/O
10
Todays issues

• Distributed Control into the field
• Distributed Computing
• Distributed I/O into the field
• Services, Applications, Solutions
• Industry Standards
• Configurator tools
• Asset Management
• Performance guarantees ()
• Life Cycle Costs (scalability / migration /
  upgrades)
• Digital bus selection

11
