Cryptography and Privacy Preserving Operations Lecture 1

1
Cryptography and Privacy Preserving Operations
Lecture 1

• Lecturer Moni Naor
• Weizmann Institute of Science

2
What is Cryptography?
Traditionally how to maintain secrecy in
communication
Alice and Bob talk while Eve tries to listen
Bob
Alice
Eve
3
History of Cryptography

• Very ancient occupation
• Many interesting books and sources, especially
  about the Enigma
• David Kahn, The Codebreakers, 1967
• Gaj and Orlowski, Facts and Myths of Enigma
  Breaking Stereotypes, Eurocrypt 2003
• Not the subject of this course

4
Modern Times

• Up to the mid 70s - mostly classified military
  work
• Exception Shannon, Turing
• Since then - explosive growth
• Commercial applications
• Scientific work tight relationship with
  Computational Complexity Theory
• Major works Diffie-Hellman, Rivest, Shamir and
  Adleman (RSA)
• Recently - more involved models for more diverse
  tasks.
• How to maintain the secrecy, integrity and
  functionality in computer and communication
  system.

5
Cryptography and Complexity

• Complexity Theory -
• Study the resources needed to solve computational
  problems
• computer time, memory
• Identify problems that are infeasible to
  compute.

• Cryptography -
• Find ways to specify security requirements of
  systems
• Use the computational infeasibility of problems
  in order to obtain security.

The development of these two areas is tightly
connected! The interplay between these areas is
the subject of the course
6
Key Idea of Cryptography

• Use the intractability of some problems for the
  advantage of constructing secure system

7
Short Course Outline

• First part of this short course
• Alice and Bob want to cooperate
• Eve wants to interfere
• One-way functions,
• pseudo-random generators
• pseudo-random functions
• Encryption
• Second part
• Alice and bob do not quite trust each other
• Zero-knowledge protocols
• Secure function evaluation

8
Three Basic Issues in Cryptography

• Identification
• Authentication
• Encryption

9
Example Identification

• When the time is right, Alice wants to send an
  approve message to Bob.
• They want to prevent Eve from interfering
• Bob should be sure that Alice indeed approves

Alice
Bob
Eve
10
Rigorous Specification of Security

• To define security of a system must specify
• What constitute a failure of the system
• The power of the adversary
• computational
• access to the system
• what it means to break the system.

11
Specification of the Problem

• Alice and Bob communicate through a channel
• Bob has two external states N,Y
• Eve completely controls the channel
• Requirements
• If Alice wants to approve and Eve does not
  interfere Bob moves to state Y
• If Alice does not approve, then for any behavior
  from Eve, Bob stays in N
• If Alice wants to approve and Eve does interfere
  - no requirements from the external state

12
Can we guarantee the requirements?

• No when Alice wants to approve she sends (and
  receives) a finite set of bits on the channel.
  Eve can guess them.
• To the rescue - probability.
• Want that Eve will succeed with low probability.
• How low? Related to the string length that Alice
  sends

13
Example Identification
X
X
Alice
Bob
??
Eve
14
Suppose there is a setup period

• There is a setup where Alice and Bob can agree on
  a common secret
• Eve only controls the channel, does not see the
  internal state of Alice and Bob (only external
  state of Bob)
• Simple solution
• Alice and Bob choose a random string X ?R 0,1n
• When Alice wants to approve she sends X
• If Bob gets any symbols on channel compares to
  X
• If equal moves to Y
• If not equal moves permanently to N

15
Eves probability of success

• If Alice did not send X and Eve put some string
  X on the channel, then
• Bob moves to Y only if X X
• ProbXX 2-n
• Good news can make it a small as we wish
• What to do if Alice and Bob cannot agree on a
  uniformly generated string X?

16
Less than perfect random variables

• Suppose X is chosen according to some
  distribution Px over some set of symbols G
• What is Eves best strategy?
• What is her probability of success

17
(Shannon) Entropy

• Let X be random variable over alphabet G with
  distribution Px
• The (Shannon) entropy of X is
• H(X) - ? x ?G Px (x) log Px (x)
• Where we take 0 log 0 to be 0.
• Represents how much we can compress X

18
Examples

• If X0 (constant) then H(x) 0
• Only case where H(x) 0 is when x is constant
• All other cases H(x) gt0
• If X ? 0,1 and ProbX0 p and
  ProbX11-p, then
• H(X) -p log p (1-p) log (1-p) H(p)
• If X ? 0,1n and is uniformly distributed,
  then
• H(X) - ? x ? 0,1n 1/2n log 1/2n 2n/2n n
  n

19
Properties of Entropy

• Entropy is bounded H(X) log G with equality
  only if X is uniform over G

20
Does High Entropy Suffice for Identification?

• If Alice and bob agree on X ? 0,1n where X has
  high entropy (say H(X) n/2 ), what are Eves
  chances of cheating?
• Can be high say
• ProbX0n 1/2
• For any x? 10,1 n-1 ProbXx 1/2n
• Then H(X) n/21/2
• But Eve can cheat with probability at least ½ by
  guessing that X0n

21
Another Notion Min Entropy

• Let X be random variable over alphabet G with
  distribution Px
• The min entropy of X is
• Hmin(X) - log max x ?G Px (x)
• The min entropy represents the most likely value
  of X
• Property Hmin(X) H(X)
• Why?

22
High Min Entropy and Passwords

• Claim if Alice and Bob agree on such that
• Hmin(X) m, then the probability that Eve
  succeeds in cheating is at most 2-m
• Proof Make Eve deterministic, by picking her
  best choice, X x.
• ProbXx Px (x) max x ?G Px (x) 2
  Hmin(X) 2-m
• Conclusion passwords should be chosen to have
  high min-entropy!

23

• Good source on Information Theory
• T. Cover and J. A. Thomas, Elements of
  Information Theory

24
One-time vs. many times

• This was good for a single identification. What
  about many identification?
• Later

25
A different scenario now Charlie is involved

• Bob has no proof that Alice indeed identified
• If there are two possible verifiers, Bob and
  Charlie, they can each pretend to each other to
  be Alice
• Can each have there own string
• But, assume that they share the setup phase
• Whatever Bob knows Charlie know
• Relevant when they are many of possible verifiers!

26
The new requirement

• If Alice wants to approve and Eve does not
  interfere Bob moves to state Y
• If Alice does not approve, then for any behavior
  from Eve and Charlie, Bob stays in N
• Similarly if Bob and Charlie are switched

Charlie
Alice
Bob
Eve
27
Can we achieve the requirements?

• Observation what Bob and Charlie received in
  the setup phase might as well be public
• Therefore can reduce to the previous scenario
  (with no setup)
• To the rescue - complexity
• Alice should be able to perform something that
  neither Bob nor Charlie (nor Eve) can do
• Must assume that the parties are not
  computationally all powerful!

28
Function and inversions

• We say that a function f is hard to invert if
  given yf(x) it is hard to find x such that
  yf(x)
• x need not be equal to x
• We will use f-1(y) to denote the set of preimages
  of y
• To discuss hard must specify a computational
  model
• Use two flavors
• Concrete
• Asymptotic

29
One-way functions - asymptotic

• A function f 0,1 ? 0,1 is called a
  one-way function, if
• f is a polynomial-time computable function
• Also polynomial relationship between input and
  output length
• for every probabilistic polynomial-time algorithm
  A, every positive polynomial p(.), and all
  sufficiently large ns
• ProbAf(x) ? f-1(f(x)) 1/p(n)
• Where x is chosen uniformly in 0,1n and the
  probability is also over the internal coin flips
  of A

30
One-way functions concrete version

• A function f0,1n ? 0,1n is called a (t,e)
  one-way function, if
• f is a polynomial-time computable function
  (independent of t)
• for every t-time algorithm A,
• ProbAf(x) ? f-1(f(x)) e
• Where x is chosen uniformly in 0,1n and the
  probability is also over the internal coin flips
  of A
• Can either think of t and e as being fixed or as
  t(n), e(n)

31
Complexity Theory and One-way Functions

• Claim if PNP then there are no one-way
  functions
• Proof for any one-way function
• f 0,1n ? 0,1n
• consider the language Lf
• Consisting of strings of the form y, b1, b2bk

• There is an x ? 0,1n such that yf(x) and
• The first k bits of x are b1, b2bk
• Lf is NP guess x and check
• If Lf is P then f is invertible in polynomial
  time
• Self reducibility

32
A few properties and questions concerning one-way
functions

• Major open problem connect the existence of
  one-way functions and the PNP? question
• If f is one-to-one it is a called a one-way
  permutation. In what complexity class does the
  problem of inverting one-way permutations reside?

• good exercise!
• If f is a one-way function, is f where f(x)
  is f(x) with the last bit chopped a one-way
  function?
• If f is a one-way function, is fL where fL(x)
  consists of the first half of the bits of f(x) a
  one-way function?
• good exercise!
• If f is a one way function is g(x) f(f(x))
  necessarily a one-way function?
• good exercise!

33
Solution to the password problem

• Assume that
• f 0,1n ? 0,1n is a (t,e) one-way function
• Adversarys run times is bounded by t
• Setup phase
• Alice chooses x?R 0,1n
• computes yf(x)
• Gives y to Bob and Charlie
• When Alice wants to approve she sends x
• If Bob gets any symbols on channel call them z
  compute f(z) and compares to y
• If equal moves to state Y
• If not equal moves permanently to state N

34
Eves and Charlies probability of success

• If Alice did not send x and Eve (Charlie) put
  some string x on the channel to Bob, then
• Bob moves to state Y only if f(x)yf(x)
• But we know that
• ProbAf(x) ? f-1(f(x)) e
• or else we can use Eve to break the
  one-way function
• Good news if e can be made as small as we wish,
  then we have a good scheme.
• Can be used for monitoring
• Similar to the Unix password scheme
• f(x) stored in login file
• DES used as the one-way function.

A
y
Eve
y
y
x
x
35
Reductions

• This is a simple example of a reduction
• Simulate Eves algorithm in order to break the
  one-way function
• Most reductions are much more involved

36
Cryptographic Reductions

• Show how to use an adversary for breaking
  primitive 1 in order to break primitive 2
• Important
• Run time how does T1 relate to T2
• Probability of success how does ?1 relate to ?2
• Access to the system 1 vs. 2

37
Are one-way functions essential to the two guards
password problem?

• Precise definition
• for every probabilistic polynomial-time algorithm
  A controlling Eve and Charlie
• every polynomial p(.),
• and all sufficiently large ns
• ProbBob moves Y Alice does not approve
  1/p(n)
• Recall observation what Bob and Charlie
  received in the setup phase might as well be
  public
• Claim can get rid of interaction
• given an interactive identification protocol
  possible to construct a noninteractive one. In
  new protocol
• Alice sends Bob the random bits Alice used to
  generate the setup information
• Bob simulates the conversation between Alice
  and Bob in original protocol and accepts only if
  simulated Bob accepts.
• Probability of cheating is the same

38
One-way functions are essential to the two guards
password problem

• Are we done? Given a noninteracive
  identification protocol want to define a one-way
  function
• Define function f(r) as the mapping that Alice
  does in the setup phase between her random bits r
  and the information y given to Bob and Charlie
• Problem the function f(r) is not necessarily
  one-way
• Can be unlikely ways to generate it. Can be
  exploited to invert.
• Example Alice chooses x, x? 0,1n if x 0n
  set yx o.w. set yf(x)
• The protocol is still secure, but with
  probability 1/2n not complete
• The resulting function f(x,x) is easy to invert

• given y ?0,1n set inverse as (y, 0n )

39
One-way functions are essential to the two guards
password problem

• However possible to estimate the probability
  that Bob accepts on a given string from Alice
• Second attempt define function f(r) as
• the mapping that Alice does in the setup phase
  between her random bits r and the information
  given to Bob and Charlie,
• plus a bit indicating that probability of Bob
  accepts given r is greater than 2/3
• Theorem the two guards password problem has a
  solution if and only if one-way functions exist

40
Examples of One-way functions

• Examples of hard problems
• Subset sum
• Discrete log
• Factoring (numbers, polynomials) into prime
  components
• How do we get a one-way function out of them?

Easy problem
41
Subset Sum

• Subset sum problem given
• n numbers 0 a1, a2 ,, an 2m
• Target sum T
• Find subset S? 1,...,n ? i ?S ai,T
• (n,m)-subset sum assumption for uniformly chosen

• a1, a2 ,, an ?R0,2m -1 and S? 1,...,n
• For any probabilistic polynomial time algorithm,
  the probability of finding S? 1,...,n such
  that
• ? i ?S ai ? i ?S ai
• is negligible, where the probability is over the
  random choice of the ais, S and the inner coin
  flips of the algorithm
• Subset sum one-way function f0,1mnn ? 0,1m

• f(a1, a2 ,, an , b1, b2 ,, bn )
• (a1, a2 ,, an , ? i1n bi ai mod 2m )

42
Exercise

• Show a function f such that
• if f is polynomial time invertible on all
  inputs, then PNP
• f is not one-way

43
Discrete Log Problem

• Let G be a group and g an element in G.
• Let ygz and x the minimal non negative
• integer satisfying the equation.
• x is called the discrete log of y to base g.
• Example ygx mod p in the multiplicative group
  of Zp
• In general easy to exponentiate via repeated
  squaring
• Consider binary representation
• What about discrete log?
• If difficult, f(g,x) (g, gx ) is a one-way
  function

44
Integer Factoring

• Consider f(x,y) x y
• Easy to compute
• Is it one-way?
• No if f(x,y) is even can set inverse as
  (f(x,y)/2,2)
• If factoring a number into prime factors is hard
• Specifically given N P Q , the product of two
  random large (n-bit) primes, it is hard to factor
• Then somewhat hard there are a non-negligible
  fraction of such numbers 1/n2 from the
  density of primes
• Hence a weak one-way function
• Alternatively
• let g(r) be a function mapping random bits into
  random primes.
• The function f(r1,r2) g(r1) g(r2) is one-way

45
Weak One-way function

• A function f 0,1n ? 0,1n is called a weak
  one-way function, if
• f is a polynomial-time computable function
• There exists a polynomial p(), for every
  probabilistic polynomial-time algorithm A, and
  all sufficiently large ns
• ProbAf(x) ? f-1(f(x)) 1-1/p(n)
• Where x is chosen uniformly in 0,1n and the
  probability is also over the internal coin flips
  of A

46
Exercise weak exist if strong exists

• Show that if strong one-way functions exist, then
  there exists a a function which is a weak one-way
  function but not a strong one

47
What about the other direction?

• Given
• a function f that is guaranteed to be a weak
  one-way
• Let p(n) be such that ProbAf(x) ? f-1(f(x))
  1-1/p(n)
• can we construct a function g that is (strong)
  one-way?
• An instance of a hardness amplification problem
• Simple idea repetition. For some polynomial q(n)
  define
• g(x1, x2 ,, xq(n) )f(x1), f(x2), , f(xq(n))
• To invert g need to succeed in inverting f in all
  q(n) places
• If q(n) p2(n) seems unlikely (1-1/p(n))p2(n)
  e-p(n)
• But how to we show? Sequential repetition
  intuition not a proof.

48
Want Inverting g with low probability implies
inverting f with high probability

• Given a machine A that inverts g want a machine
  A
• operating in similar time bounds
• inverts f with high probability
• Idea given yf(x) plug it in some place in g and
  generate the rest of the locations at random
• z(y, f(x2), , f(xq(n)))
• Ask machine A to invert g at point z
• Probability of success should be at least
  (exactly) As Probability of inverting g at a
  random point
• Once is not enough
• How to amplify?
• Repeat while keeping y fixed
• Put y at random position (or sort the inputs to
  g )

49
Proof of Amplification for Repetition of Two

• Concentrate on repetition of two g(x1, x2
  )f(x1), f(x2)
• Goal show that the probability of inverting g is
  roughly squared the probability of inverting f
• just as would be sequentially
• Claim
• Let ?(n) be a function that for some
  p(n) satisfies
• 1/p(n) ?(n) 1-1/p(n)
• Let e(n) be any inverse polynomial
  function
• suppose that for every polynomial
  time A and sufficiently large n
• ProbAf(x) ? f-1(f(x)) ?(n)
• Then for every polynomial time B and
  sufficiently large n
• ProbBg(x1, x2 ) ? g-1(g(x1, x2 )) ?2(n)
  e(n)

50
Proof of Amplification for Two Repetition

• Suppose not, then given a better than ?2e
  algorithm B for inverting g construct the
  following
• B(y) Inversion algorithm for f
• Repeat t times
• Choose x at random and compute yf(x)
• Run B(y,y).
• Check the results
• If correct Halt with success
• Output failure

Inner loop
Helpful for constructive algorithm
51
Probability of Success

• Define
• Syf(x) ProbInner loop successful y gt ß
• Since the choices of the x are independent
• ProbB succeeds x?S gt 1-(1- ß)t
• Taking t n/ß means that when y?S almost surely
  A will invert it
• Hence want to show that Prob y?S gt ?(n)

52
The success of B

• Fix the random bits of B. Define
• P(y1, y2) B succeeds on (y1,y2)

• P P ? (y1,y2 ) y1,y2 ?S
• ? P ? (y1,y2 ) y1 ?S
• ? P ? (y1,y2 ) y2 ?S

y1
Well behaved part
y2
want to bound P by a square
P
53
S is the only success..

• But
• ProbBy1, y2 ? g-1(y1, y2) y1 ?S ß
• and similarly
• ProbBy1, y2 ? g-1(y1, y2) y2 ?S ß
• so
• Prob(y1, y2) ?P and y1,y2 ?S
• Prob(y1, y2) ?P - 2ß
• ?2 e - 2ß
• Setting ß e/3 we have
• Prob(y1, y2) ?P and y1,y2 ?S ?2 e/3

54
Contradiction

• But
• Prob(y1, y2) ?P and y1,y2 ?S
• Proby1 ?S Proby2 ?S
• Prob2y ?S
• So
• Proby ?S v(a2 e/3) gt a

55
The Encryption problem

• Alice would want to send a message m ? 0,1n
  to Bob
• Set-up phase is secret
• They want to prevent Eve from learning anything
  about the message

m
Alice
Bob
Eve
56
The encryption problem

• Relevant both in the shared key and in the public
  key setting
• Want to use many times
• Also add authentication
• Other disruptions by Eve

57
What does learn mean?

• If Eve has some knowledge of m should remain the
  same
• Probability of guessing m
• Min entropy of m
• Probability of guess whether m is m0 or m1
• Probability of computing some function f of m
• Ideally the message sent is a independent of the
  message m
• Implies all the above
• Shannon achievable only if the entropy of the
  shared secret is at least as large as the message
  m entropy
• If no special knowledge about m
• then m
• Achievable one-time pad.
• Let r?R 0,1n
• Think of r and m as elements in a group
• To encrypt m send rm
• To decrypt z send mz-r

58
Pseudo-random generators

• Would like to stretch a short secret (seed) into
  a long one
• The resulting long string should be usable in
  any case where a long string is needed
• In particular as a one-time pad
• Important notion Indistinguishability
• Two probability distributions that cannot be
  distinguished
• Statistical indistinguishability distances
  between probability distributions
• New notion computational indistinguishability

59
...References

• Books
• O. Goldreich, Foundations of Cryptography - a
  book in three volumes.
• Vol 1, Basic Tools, Cambridge, 2001
• Pseudo-randomness, zero-knowledge
• Vol 2, about to come out
• (Encryption, Secure Function Evaluation)
• Other volumes in www.wisdom.weizmann.ac.il/oded/b
  ooks.html
• M. Luby, Pseudorandomness and Cryptographic
  Applications, Princeton University Pres
• ,

60
References

• Web material/courses
• S. Goldwasser and M. Bellare, Lecture Notes on
  Cryptography,
• http//www-cse.ucsd.edu/mihir/papers/gb.html
• Wagner/Trevisan, Berkeley
• www.cs.berkeley.edu/daw/cs276
• Ivan Damgard and Ronald Cramer, Cryptologic
  Protocol Theory
• http//www.daimi.au.dk/ivan/CPT.html
• Salil Vadhan, Pseudorandomness
• http//www.courses.fas.harvard.edu/cs225/Lectures
  -2002/
• Naor, Foundations of Cryptography and Estonian
  Course
• www.wisdom.weizmann.ac.il/naor

61
Recap of Lecture 1

• Key idea of cryptography use computational
  intractability for your advantage
• One-way functions are necessary and sufficient to
  solve the two guard identification problem
• Notion of Reduction between cryptographic
  primitives
• Amplification of weak one-way functions
• Things are a bit more complex in the
  computational world (than in the information
  theoretic one)

62
Is there an ultimate one-way function?

• If f10,1 ? 0,1 and f20,1 ? 0,1 are
  guaranteed to
• Be polynomial time computable
• At least one of them is one-way.
• then can construct a function g0,1 ? 0,1
  which is one-way
• g(x1, x2 ) (f1(x1),f2 (x2 ))
• If an 5n2 time one-way function is guaranteed to
  exist, can construct an O(n2 log n) one-way
  function g
• Idea enumerate Turing Machine and make sure they
  run 5n2 steps
• g(x1, x2 ,, xlog (n) )M1(x1), M2(x2), , Mlog
  n(xlog (n))
• If a one-way function is guaranteed to exist,
  then there exists a 5n2 time one-way
• Idea concentrate on the prefix

1/p(n)
63
Conclusions

• Be careful what you wish for
• Problem with resulting one-way function
• Cannot learn about behavior on large inputs from
  small inputs
• Whole rational of considering asymptotic results
  is eroded
• Construction does not work for non-uniform
  one-way functions
• Encryption easy when you share very long strings
• Started with the notion of pseudo-randomness

64
The Encryption problem

• Alice would want to send a message m ? 0,1n
  to Bob
• Set-up phase is secret
• They want to prevent Eve from learning anything
  about the message

m
Alice
Bob
Eve
65
The encryption problem

• Relevant both in the shared key and in the public
  key setting
• Want to use many times
• Also add authentication
• Other disruptions by Eve

66
What does learn mean?

• If Eve has some knowledge of m should remain the
  same
• Probability of guessing m
• Min entropy of m
• Probability of guess whether m is m0 or m1
• Probability of computing some function f of m
• Ideally the message sent is a independent of the
  message m
• Implies all the above
• Shannon achievable only if the entropy of the
  shared secret is at least as large as the message
  m entropy
• If no special knowledge about m
• then m
• Achievable one-time pad.
• Let r?R 0,1n
• Think of r and m as elements in a group
• To encrypt m send rm
• To decrypt z send mz-r

67
Pseudo-random generators

• Would like to stretch a short secret (seed) into
  a long one
• The resulting long string should be usable in
  any case where a long string is needed
• In particular as a one-time pad
• Important notion Indistinguishability
• Two probability distributions that cannot be
  distinguished
• Statistical indistinguishability distances
  between probability distributions
• New notion computational indistinguishability

68
Computational Indistinguishability

• Definition two sequences of distributions Dn
  and Dn on 0,1n are computationally
  indistinguishable if
• for every polynomial p(n) and sufficiently large
  n, for every probabilistic polynomial time
  adversary A that receives input y ? 0,1n and
  tries to decide whether y was generated by Dn or
  Dn
• ProbA0 Dn - ProbA0 Dn lt
  1/p(n)
• Without restriction on probabilistic polynomial
  tests equivalent to variation distance being
  negligible
• ?ß ? 0,1n Prob Dn ß - Prob Dn ß lt
  1/p(n)

69
Pseudo-random generators

• Definition a function g0,1 ? 0,1 is said
  to be a (cryptographic) pseudo-random generator
  if
• It is polynomial time computable
• It stretches the input g(x)gtx
• denote by l(n) the length of the output on
  inputs of length n
• If the input is random the output is
  indistinguishable from random
• For any probabilistic polynomial time adversary A
  that receives input y of length l(n) and tries to
  decide whether y g(x) or is a random string from
  0,1l(n) for any polynomial p(n) and
  sufficiently large n
• ProbArand yg(x) - ProbArand y?R
  0,1l(n) lt 1/p(n)
• Important issues
• Why is the adversary bounded by polynomial time?
• Why is the indistinguishability not perfect?

70
Pseudo-random generators

• Definition a function g0,1 ? 0,1 is said
  to be a (cryptographic) pseudo-random generator
  if
• It is polynomial time computable
• It stretches the input g(x)gtx
• denote by l(n) the length of the output on
  inputs of length n
• If the input (seed) is random, then the output is
  indistinguishable from random
• For any probabilistic polynomial time adversary A
  that receives input y of length l(n) and tries to
  decide whether y g(x) or is a random string from
  0,1l(n) for any polynomial p(n) and
  sufficiently large n
• ProbArand yg(x) - ProbArand y?R
  0,1l(n) lt 1/p(n)
• Want to use the output a pseudo-random generator
  whenever long random strings are used
• Especially encryption
• have not defined the desired properties yet.

Anyone who considers arithmetical methods of
producing random numbers is, of course, in a
state of sin.

J. von Neumann
71
Important issues

• Why is the adversary bounded by polynomial time?
• Why is the indistinguishability not perfect?

72
Construction of pseudo-random generators

• Idea given a one-way function there is a hard
  decision problem hidden there
• If balanced enough looks random
• Such a problem is a hardcore predicate
• Possibilities
• Last bit
• First bit
• Inner product

73
Hardcore Predicate

• Definition let f0,1 ? 0,1 be a function.
  We say that h0,1 ? 0,1 is a hardcore
  predicate for f if
• It is polynomial time computable
• For any probabilistic polynomial time adversary A
  that receives input yf(x) and tries to compute
  h(x) for any polynomial p(n) and sufficiently
  large n
• ProbA(y)h(x) -1/2 lt 1/p(n)
• where the probability is over the choice y and
  the random coins of A
• Sources of hardcoreness
• not enough information about x
• not of interest for generating pseudo-randomness
• enough information about x but hard to compute
  it

74
Exercises

• Assume one-way functions exist
• Show that the last bit/first bit are not
  necessarily hardcore predicates
• Generalization show that for any fixed function
  h0,1 ? 0,1 there is a one-way function
  f0,1 ? 0,1 such that h is not a hardcore
  predicate of f
• Show a one-way function f such that given yf(x)
  each input bit of x can be guessed with
  probability at least 3/4

75
Single bit expansion

• Let f0,1n ? 0,1n be a one-way permutation
• Let h0,1n ? 0,1 be a hardcore predicate for
  f
• Consider g0,1n ? 0,1n1 where
• g(x)(f(x), h(x))
• Claim g is a pseudo-random generator
• Proof can use a distinguisher for g to guess
  h(x)

f(x), h(x))
f(x), 1-h(x))
76
Hardcore Predicate With Public Information

• Definition let f0,1 ? 0,1 be a function.
  We say that h0,1 x 0,1 ? 0,1 is a
  hardcore predicate for f if
• h(x,r) is polynomial time computable
• For any probabilistic polynomial time adversary A
  that receives input yf(x) and public randomness
  r and tries to compute h(x,r) for any polynomial
  p(n) and sufficiently large n
• ProbA(y,r)h(x,r) -1/2 lt 1/p(n)
• where the probability is over the choice y of r
  and the random coins of A
• Alternative view can think of the public
  randomness as modifying the one-way function f
  f(x,r)f(x),r.

77
Example weak hardcore predicate

• Let h(x,i) xi
• I.e. h selects the ith bit of x
• For any one-way function f, no polynomial time
  algorithm A(y,i) can have probability of success
  better than 1-1/2n of computing h(x,i)
• Exercise let c0,1 ? 0,1 be a good error
  correcting code
• c(x) is O(x)
• distance between any two codewords c(x) and c(x)
  is a constant fraction of c(x)
• It is possible to correct in polynomial time
  errors in a constant fraction of c(x)
• Show that for h(x,i) c(x)i and any one-way
  function f, no polynomial time algorithm A(y,i)
  can have probability of success better than a
  constant of computing h(x,i)

78
Inner Product Hardcore bit

• The inner product bit choose r ?R 0,1n let
• h(x,r) r x ? xi ri mod 2
• Theorem Goldreich-Levin for any one-way
  function the inner product is a hardcore
  predicate
• Proof structure
• There are many xs for which A returns a correct
  answer on ½e of the r s
• take an algorithm A that guesses h(x,r) correctly
  with probability ½e over the rs and output a
  list of candidates for x
• No use of the y info
• Choose from the list the/an x such that f(x)y

The main step!
79
Why list?

• Cannot have a unique answer!
• Suppose A has two candidates x and x
• On query r it returns at random either r x
  or r x
• ProbA(y,r) r x ½ ½Probrx rx ¾

80
Warm-up (1)

• If A returns a correct answer on 1-1/2n of the r
  s
• Choose r1, r2, rn ?R 0,1n
• Run A(y,r1), A(y,r2), A(y,rn)
• Denote the response z1, z2, zn
• If r1, r2, rn are linearly independent then
• there is a unique x satisfying rix zi for all
  1 i n
• Probzi A(y,ri) rix 1-1/2n
• Therefore probability that all the zis are
  correct is at least ½
• Do we need complete independence of the ri s?
• one-wise independence is sufficient
• Can choose r ?R 0,1n and set ri rei
• ei 0i-110n-i
• All the ri s are linearly independent
• Each one is uniform in 0,1n

81
Warm-up (2)

• If A returns a correct answer on 3/4e of the r
  s
• Can amplify the probability of success!
• Given any r ? 0,1n Procedure A(y,r)
• Repeat for j1, 2,
• Choose r ?R 0,1n
• Run A(y,rr) and A(y,r), denote the sum of
  responses by zj
• Output the majority of the zjs
• Analysis
• Przj rx PrA(y,r)rx A(y,rr)(rr)x
  ½2e
• Does not work for ½e since success on r and
  rr is not independent
• Each one of the events zj rx is independent
  of the others
• Therefore by taking sufficiently many js can
  amplify to a value as close to 1 as we wish
• Need roughly 1/e2 examples
• Idea for improvement fix a few of the r

82
The real thing

• Choose r1, r2, rk ?R 0,1n
• Guess for j1, 2, k the value zj rjx
• Go over all 2k possibilities
• For all nonempty subsets S ?1,,k
• Let rS ? j? S rj
• The implied guess for zS ? j? S zj
• For each position xi
• for each S ?1,,k run A(y,ei-rS)
• output the majority value of zs A(y,ei-rS)
• Analysis
• Each one of the vectors ei-rS is uniformly
  distributed
• A(y,ei-rS) is correct with probability at least
  ½e
• Claim For every pair of nonempty subset S ?T
  ?1,,k
• the two vectors rS and rT are pair-wise
  independent
• Therefore variance is as in completely
  independent trials
• I is the number of correct A(y,ei-rS), VAR(I)
  2k(½e)
• Use Chebyshevs Inequality PrI-E(I)
  ?vVAR(I)1/?2
• Need 2k n/e2 to get the probability of error
  to 1/n
• So process is successful simultaneously for all
  positions xi,i?1,,n

S
T
83
Analysis

• Number of invocations of A
• 2k n (2k-1) poly(n, 1/e) n3/e4
• Size of resulting list of candidates for x
• for each guess of z1, z2, zk unique x
• 2k poly(n, 1/e) ) n/e2
• Conclusion single bit expansion of a one-way
  permutation is a pseudo-random generator

guesses
positions
subsets
84
Reducing the size of the list of candidates

• Idea bootstrap
• Given any r ? 0,1n Procedure A(y,r)
• Choose r1, r2, rk ?R 0,1n
• Guess for j1, 2, k the value zj rjx
• Go over all 2k possibilities
• For all nonempty subsets S ?1,,k
• Let rS ? j? S rj
• The implied guess for zS ? j? S zj
• for each S ?1,,k run A(y,r-rS)
• output the majority value of zs A(y,r-rS)
• For 2k 1/e2 the probability of error is, say,
  1/8
• Fix the same r1, r2, rk for subsequent
  executions
• They are good for 7/8 of the rs
• Run warm-up (2)
• Size of resulting list of candidates for x is
  1/e2

85
Application Diffie-Hellman

• The Diffie-Hellman assumption
• Let G be a group and g an element in G.
• Given g, agx and bgy it is hard to find cgxy
• for random x and y is probability of poly-time
  machine outputting gxy is negligible
• More accurately a sequence of groups
• Dont know how to verify given c whether it is
  equal to gxy
• Exercise show that under the DH Assumption
• Given agx , bgy and r ? 0,1n no polynomial
  time machine can guess r gxy with advantage
  1/poly
• for random x,y and r

86
Application if subset is one-way, then it is a
pseudo-random generator

• Subset sum problem given
• n numbers 0 a1, a2 ,, an 2m
• Target sum y
• Find subset S? 1,...,n ? i ?S ai,y
• Subset sum one-way function f0,1mnn ? 0,1m

• f(a1, a2 ,, an , x1, x2 ,, xn )
• (a1, a2 ,, an , ? i1n xi ai mod 2m )
• If mltn then we get out less bits then we put in.
• If mgtn then we get out more bits then we put in.
• Theorem if for mgtn subset sum is a one-way
  function, then it is also a pseudo-random
  generator

87
Subset Sum Generator

• Idea of proof use the distinguisher A to compute
  r x
• For simplicity do the computation mod P for
  large prime P
• Given r ? 0,1n and (a1, a2 ,, an ,y)
• Generate new problem(a1, a2 ,, an ,y)
• Choose c ?R ZP
• Let ai ai if ri0 and ai aic mod P if ri1
• Guess k ?R o,,n - the value of ? xi ri
• the number of locations where x and r are 1
• Let y yc k mod P
• Run the distinguisher A on (a1, a2 ,, an
  ,y)
• output what A says Xored with parity(k)
• Claim if k is correct, then (a1, a2 ,, an
  ,y) is ?R pseudo-random
• Claim for any incorrect k, (a1, a2 ,, an
  ,y) is ?R random
• y z (k-h)c mod P where z ? i1n xi ai mod
  P and h? xi ri
• Therefore probability to guess correctly r x is
  1/n(½e) (n-1)/n (½) ½e/n

ProbA0pseudo ½e
ProbA0random ½
pseudo-random
random
correct k
incorrect k
88
Interpretations of the Goldreich-Levin Theorem

• A tool for constructing pseudo-random generators
• The main part of the proof
• A mechanism for translating general confusion
  into randomness
• Diffie-Hellman example
• List decoding of Hadamard Codes
• works in the other direction as well (for any
  code with good list decoding)
• List decoding, as opposed to unique decoding,
  allows getting much closer to distance
• Explains unique decoding when prediction was
  3/4e
• Finding all linear functions agreeing with a
  function given in a black-box
• Learning all Fourier coefficients larger than e
• If the Fourier coefficients are concentrated on a
  small set can find them
• True for AC0 circuits
• Decision Trees

89
Composing PRGs
l1

• Composition
• Let
• g1 be a (l1, l2 )-pseudo-random generator
• g2 be a (l2, l3)-pseudo-random generator
• Consider g(x) g2(g1(x))
• Claim g is a (l1, l3 )-pseudo-random generator
• Proof consider three distributions on 0,1l3
• D1 y uniform in 0,1l3
• D2 yg(x) for x uniform in 0,1l1
• D3 yg2(z) for z uniform in 0,1l2
• By assumption there is a distinguisher A between
  D1 and D2
• A must either
• distinguish between D1 and D3 - can use A use
  to distinguish g2
• or
• distinguish between D2 and D3 - can use A use
  to distinguish g1

l2
l3
triangle inequality
90
Composing PRGs

• When composing
• a generator secure against advantage e1
• and a
• a generator secure against advantage e2
• we get security against advantage e1e2
• When composing the single bit expansion generator
  n times
• Loss in security is at most e/n
• Hybrid argument to prove that two distributions
  D and D are indistinguishable
• suggest a collection of distributions D D0, D1,
  Dk D such that
• If D and D can be distinguished, there is a
  pair Di and Di1 that can be distinguished.
• Difference e between D and D means e/k between
  some Di and Di1
• Use such a distinguisher to derive a contradiction

91
Exercise

• Let Dn and Dn be two distributions that
  are
• Computationally indistinguishable
• Polynomial time samplable
• Suppose that y1, ym are all sampled according
  to Dn or all are sampled according to Dn
• Prove no probabilistic polynomial time machine
  can tell, given y1, ym, whether they were
  sampled from Dn or Dn

92
Existence of PRGs

• What we have proved
• Theorem if pseudo-random generators stretching
  by a single bit exist, then pseudo-random
  generators stretching by any polynomial factor
  exist
• Theorem if one-way permutations exist, then
  pseudo-random generators exist
• A harder theorem to prove
• Theorem HILL if one-way functions exist, then
  pseudo-random generators exist
• Exercise show that if pseudo-random generators
  exist, then one-way functions exist

93
Next-bit Test

• Definition a function g0,1 ? 0,1 is said
  to pass the next bit test if
• It is polynomial time computable
• It stretches the input g(x)gtx
• denote by l(n) the length of the output on
  inputs of length n
• If the input (seed) is random, then the output
  passes the next-bit test
• For any prefix 0 ilt l(n), for any probabilistic
  polynomial time adversary A that receives the
  first i bits of y g(x) and tries to guess the
  next bit, or any polynomial p(n) and sufficiently
  large n
• ProbA(yi,y2,, yi) yi1 1/2 lt 1/p(n)
• Theorem a function g0,1 ? 0,1 passes the
  next bit test if
• and only if it is a pseudo-random generator

94
Next-block Undpredictable

• Suppose that the function G maps a given a seed
  into a sequence of blocks
• let l(n) be the length of the number of blocks
  given a seed of length n
• If the input (seed) is random, then the output
  passes the next-block unpredicatability test
• For any prefix 0 ilt l(n), for any probabilistic
  polynomial time adversary A that receives the
  first i blocks of y g(x) and tries to guess the
  next block yi1, for any polynomial p(n) and
  sufficiently large n
• ProbA(y1,y2,, yi) yi1 lt 1/p(n)
• Exercise show how to convert a next-block
  unpredictable generator into a pseudo-random
  generator.

y1 y2, ,
95
Pseudo-Random Generatorsconcrete version

• Gn?0,1?m ??0,1?n
• A cryptographically strong pseudo-random sequence
  generator - if passes all polynomial time
  statistical tests
• (t,?)-pseudo-random - no test A running in time t
  can distinguish with advantage ?

96
Three Basic issues in cryptography

• Identification
• Authentication
• Encryption
• Solve in a shared key environment

A
B
S
S
97
Identification - Remote login using
pseudo-random sequence

• A and B share key S??0,1?k
• In order for A to identify itself to B
• Generate sequence Gn(S)
• For each identification session - send next block
  of Gn(S)

Gn(S)
98
Problems...

• More than two parties
• Malicious adversaries - add noise
• Coordinating the location block number
• Better approach Challenge-Response

99
Challenge-Response Protocol

• B selects a random location and sends to A
• A sends value at random location

A
B
Whats this?
100
Desired Properties

• Very long string - prevent repetitions
• Random access to the sequence
• Unpredictability - cannot guess the value at a
  random location
• even after seeing values at many parts of the
  string to the adversarys choice.
• Pseudo-randomness implies unpredictability
• Not the other way around for blocks

101
Authenticating Messages

• A wants to send message M??0,1?n to B
• B should be confident that A is indeed the sender
  of M
• One-time application
• S (a,b) -
• where a,b?R ?0,1?n
• To authenticate M supply aM? b
• Computation is done in GF2n

102
Problems and Solutions

• Problems - same as for identification
• If a very long random string available -
• can use for one-time authentication
• Works even if only random looking
• a,b

A
B
Use this!
103
Encryption of Messages

• A wants to send message M??0,1?n to B
• only B should be able to learn M
• One-time application
• S a
• where a?R ?0,1?n
• To encrypt M
• send a ? M

104
Encryption of Messages

• If a very long random looking string available -
• can use as in one-time encryption

A
B
Use this!
105
Pseudo-random Functions

• Concrete Treatment
• F ?0,1?k ? ?0,1?n ? ?0,1?m
• key Domain
  Range
• Denote Y FS (X)
• A family of functions Fk FS S??0,1?k ? is
  (t, ?, q)-pseudo-random if it is
• Efficiently computable - random access
• and...

106
(t,?,q)-pseudo-random

• The tester A that can choose adaptively
• X1 and get Y1 FS (X1)
• X2 and get Y2 FS (X2 )
• Xq and get Yq FS (Xq)
• Then A has to decide whether
• FS ?R Fk or
• FS ?R R n ? m ? F F ?0,1?n ? ?0,1?m ?

107
(t,?,q)-pseudo-random

• For a function F chosen at random from
• (1) Fk FS S??0,1?k ?
• (2) R n ? m ? F F ?0,1?n ? ?0,1?m ?
• For all t-time machines A that choose q
  locations and try to distinguish (1) from (2)
• ? Prob?A? 1 ? F?R Fk ?
• - Prob?A? 1 ? F?R R n ? m ? ? ? ?

108
Equivalent/Non-Equivalent Definitions

• Instead of next bit test for X??X1,X2 ,?, Xq?
  chosen by A, decide whether given Y is
• Y FS (X) or
• Y?R?0,1?m
• Adaptive vs. Non-adaptive
• Unpredictability vs. pseudo-randomness
• A pseudo-random sequence generator g?0,1?m
  ??0,1?n
• a pseudo-random function on small domain ?0,1?log
  n??0,1? with key in ?0,1?m

109
Application to the basic issues in cryptography

• Solution using a shared key S
• Identification
• B to A X ?R ?0,1?n
• A to B Y FS (X)
• A verifies
• Authentication
• A to B Y FS (M)
• replay attack
• Encryption
• A chooses X?R ?0,1?n
• A to B ltX , Y FS (X) ? M gt

110
Goal

• Construct an ensemble Fk k?L ? such that
• for any tk, 1/?k, qk k?L ? polynomial in k,
  for all but finitely many ks
• Fk is a (tk, ?k, qk )-pseudo-random family

111
Construction

• Construction via Expansion
• Expand n or m
• Direct constructions

112
Effects of Concatenation

• Given l Functions F1 , F2 ,?, Fl decide whether
  they are
• l random and independent functions
• OR
• FS1 , FS2 ,?, FSl for S1,S2 ,?, Sl ?R?0,1?k
• Claim If Fk FS S??0,1?k ? is
  (t,?,q)-pseudo-random
• cannot distinguish two cases
• using q queries
• in time tt - l?q
• with advantage better than l??

113
Proof Hybrid Argument

• i0 FS1 , FS2 ,?, FSl p0
• i R1, R2 , ? , Ri-1,FSi , FSi1 ,?, FSl
  pi
• il R1, R2 , ? , Rl
  pl
• ? pl - p0 ?? ? ? ? i ?pi1 - pi ?? ?/l

114
...Hybrid Argument

• Can use this i to distinguish whether
• FS ?R Fk or FS ?R R n ? m
• Generate FSi1 ,?, FSl
• Answer queries to first i-1 functions at random
  (consistently)
• Answer query to FSi , using (black box) input
• Answer queries to functions i1 through l with
  FSi1 ,?, FSl
• Running time of test - t ? l?q

115
Doubling the domain

• Suppose F(n) ?0,1?k ? ?0,1?n ? ?0,1?m which
  is (t,?,q)-p.r.
• Want F(n1) ?0,1?k ? ?0,1?n1 ? ?0,1?m
  which is (t,?,q)-p.r.
• Use G ?0,1?k ? ?0,1?2k which is (t ,?) p.r
• G(S) ? G0(S) G1(S)
• Let FS (n1)(bx) ? FGb(s) (n)(x)

116
Claim

• If G is (t?q,?1)-p.r and F(n) is (t?2q,?2,q)-p.r,
  then F(n1) is (t,?1 ?2 ?2,q)-p.r
• Proof three distributions
• (1) F(n1)
• (2) FS0 (n) , FS1 (n) for independent S0, S1
• (3) Random

D? ?1 ?2 ?2
117
...Proof

• Given that (1) and (3) can be distinguished with
  advantage ?1 ?2 ?2 , then either
• (1) and (2) with advantage ?1
• G can be distinguished with advantage ?1
• or
• (2) and (3) with advantage 2 ?2
• F(n) can be distinguished with advantage ?2
• Running time of test - t ? q

118
Getting from G to F(n)

• Idea Use recursive construction
• FS (n)(bnbn-1 ?b1)
• ? FGb1(s) (n-1)(bn-1bn-2 ?b1)
• ? Gbn(Gbn-1 ( ? Gb1(S)) ?)
• Each evaluation of FS (n)(x) n invocations of G

119
Tree Description
S
G1(S)
G0(S)
G0(G0(S))
Each leaf corresponds to an X. Label on leaf
value of pseudo-random function
G1(G0(G0(S)))
120
Security claim

• If G is (t ?qn ,?) p.r,
• then F(n) is (t, ? ? n?q??,q) p.r
• Proof Hybrid argument by levels
• Di
• truly random labels for nodes at level i.
• Pseudo-random from i down
• Each Di - a collection of q functions
• ? i ?pi1 - pi ?? ?/n? q??

121
Hybrid
?S
i
S1
S0
Di
G0(S0)
n-i
G1(G0(S0))
122
Proof of Security

• Can use this i to distinguish concatenation of q
  sequence generators G from random.
• The concatenation is (t,q?) p.r
• Therefore the construction is (t,?,q) p.r

123
Disadvantages

• Expensive - n invocations of G
• Sequential
• Deterioration of ?
• But does the job!
• From any pseudo-random sequence generator
  construct a pseudo-random function.
• Theorem one-way functions exist if and only if
  pseud-random functions exist.

124
Applications of Pseudo-random Functions

• Learning Theory - lower bounds
• Cannot PAC learn any class containing
  pseudo-random function
• Complexity Theory - impossibility of natural
  proofs for separating classes.
• Any setting where huge shared random string is
  useful
• Caveat what happens when the seed is made
  public?

125
References

• Blum-Micali SIAM J. Computing 1984
• Yao
• Blum, Blum, Shub SIAM J. Computing, 1988
• Goldreich, Goldwasser and Micali J. of the ACM,
  1986

126
...References

• Books
• O. Goldreich, Foundations of Cryptography - a
  book in three volumes.
• Vol 1, Basic Tools, Cambridge, 2001
• Pseudo-randomness, zero-knowledge
• Vol 2, about to come out
• (Encryption, Secure Function Evaluation)
• Other volumes in www.wisdom.weizmann.ac.il/oded/b
  ooks.html
• M. Luby, Pseudorandomness and Cryptographic
  Applications, Princeton University Pres
• ,

127
References

• Web material/courses
• S. Goldwasser and M. Bellare, Lecture Notes on
  Cryptography,
• http//www-cse.ucsd.edu/mihir/papers/gb.html
• Wagner/Trevisan, Berkeley
• www.cs.berkeley.edu/daw/cs276
• Ivan Damgard and Ronald Cramer, Cryptologic
  Protocol Theory
• http//www.daimi.au.dk/ivan/CPT.html
• Salil Vadhan, Pseudorandomness
• http//www.courses.fas.harvard.edu/cs225/Lectures
  -2002/
• Naor, Foundations of Cryptography and Estonian
  Course
• www.wisdom.weizmann.ac.il/naor
