CHEP 2000

1
CHEP 2000
Data Handling in KLOE I.Sfiligoi INFN LNF,
Frascati, Italy
2
The KLOE experiment
KS?p p - KL?p p - (CP not)

• at DAFNE ?-factory
• main goal
• CP violation study
• other interesting fields
• kaon form factors
• kaon rare decays
• radiative f decays

KS?p p - KL?3p 0?6g
3
KLOE Requirements

• Data acquisition (at full DAFNE luminosity)
• 1011 events per year acquired
• 50 MB/s sustained throughput
• Computing power
• ALL the events need to be reconstructed
• Storage requirements
• one petabyte of raw and reconstructed events
• hundreds of megabytes of related
  data(configurations, slow control data,
  calibration parameters, etc.)

4
KLOE computing environment

• Based on a set of medium-sized servers
• Connected using commercial switched networks
  (Fast Ethernet and Gigabit Ethernet)
• Heterogeneous environment, several platforms
• IBM AIX on PowerPC
• Sun Solaris on Sparc
• Compaq Tru64 Unix on Alpha
• HP-UX on PA-RISC

5
KLOE storage pool

• Different policies for different types of data
• raw and reconstructed events on tape libraries,
  with big disk pools for data caching
• related data managed by a disk based database
  system
• analysis output on disk pools

6
Disk pools

• Four categories of disk pools are present
• each data acquisition node in the farm has its
  own small disk pool
• computing nodes write their output to
  centralized, NFS mounted disk pools
• separate disk pools are used as a cache for the
  events on tape
• analysis output is written to its own, central
  AFS mounted disk pool

7
Tape library

• Several automated tape libraries supported(at
  the moment the 5500 slot tape library is
  partitioned between two tape servers)
• Accessed using commercial software
• IBM ADSM with the current tape library

8
KLOE software

• Three distinct categories
• DAQ (or online)
• reconstruction and analysis (or offline)
• Monte Carlo

ANSI C
FORTRAN inside A_C
FORTRAN
The interface to the Data Handling System must be
compatible with all of them
9
KLOE Data Handling System

• Composed of four elements
• Database System
• Archiving System
• Spy System
• KLOE Integrated Dataflow (KID)

10
KLOE Data Handling System

• A mix of commercial and custom software
• the dependency on commercial software is
  minimized by the layers of custom software

• commercial software carries on all the vital
  functions

• custom software mostly extends and coordinates
  the functionality of the commercial software

11
KLOE Data Handling System

• Based on a set of multi-threaded non-privileged
  daemons and related libraries
• Distributed across several nodes
• Communication by means of TCP/IP sockets on high
  ports

• bypasses TCP/IP filtering
• flexible, programming language and operating
  system independent
• no configuration needed on the client side

12
KLOE Data Handling System

• Composed of four elements
• Database System
• Archiving System
• Spy System
• KLOE Integrated Dataflow (KID)

13
Database System

• Two distinct database systems are used

• offline database system

based on HepDB data stored as ZEBRA banks

• online database system

based on a Relational DBMS data are
structured in fields
extended for distributed environments
14
Online Database System

• data stored in a Relational DBMS
• IBM DB2 Universal Database at the moment
• communication between the clients (user
  applications) and the RDBMS through a database
  daemon

15
Database Daemon

• The database daemon is the only link between the
  applications and the RDBMS
• if the RDBMS is changed in the future, only the
  database daemon will need to be changed
• Different kinds of commands are managed by the
  daemon
• general SQL commands
• KLOE specific commands

16
Database Daemon

• Different kinds of commands are managed by the
  daemon

• general SQL commands

• KLOE specific commands

17
Database Daemon

• The use of KLOE specific commands has several
  advantages
• additional checks and restrictions are possible
• data consistency management is centralized
• fast central caches can be implemented

• for example, the DAQ configuration cache reduces
  the typical access time from 4 to 0.1 s

18
A light version

• The RDBMS is used to ensure flexibility,
  reliability and performance
• Demanding in terms of computing resources and
  management effort
• stand-alone environments oftencannot afford it
• A RDBMS-independent version of the database
  daemon is under development

19
A light version

• A RDBMS-independent version of the database
  daemon is under development
• limited to KLOE specific and the most frequently
  used SQL commands
• based on use of flat files containing a small
  portion of the data

• not suitable for production environment,but
  enough for home use

20
KLOE Data Handling System

• Composed of four elements
• Database System
• Archiving System
• Spy System
• KLOE Integrated Dataflow (KID)

21
KLOE Archiving System

• Expected event data managed by KLOE
• 1 PB
• Tape libraries needed
• data storage and retrieval non trivial
• random access to data very inefficient
• Disk-based intermediate buffers used

22
KLOE Archiving System

• Two types of intermediate buffers
• DAQ, offline and Monte Carlo output are
  structured as YBOS files and written on their
  disk output areas
• event data needed by offline as input are read
  from the archiving system disk-cache

23
KLOE Archiving System

• Data needs to be migrated
• from output areas to the tape library
• as soon as possible(taking into account also
  efficiency concerns)
• from the tape library to the disk cache
• when an application needs it(or even better, a
  bit earlier)
• Migration is totally automated and transparent to
  the applications

24
KLOE Archiving System

• The Archiving System is made of four components
• storage managers
• disk space managers
• output areas
• cache areas
• archival director
• cache manager
• Communication by means of TCP/IP sockets
• Coordinated by the online database

archADSM spacekeeper filekeeper archiver retrieve
25
Storage Managers

• One for each logical tape library
• Allows
• queries about tape library content
• file archival
• file retrieval
• Transaction oriented(if the underlying tape
  library software supports it)

26
Storage Managers

• The only link between the tape library and the
  rest of the system
• interface independent of the underlying archiving
  software
• IBM ADSM is used with the current tape library
• if other products is used in the future, only a
  specific storage manager will need to be developed

27
Disk Space Managers

• One for each disk pool
• Create and delete files
• unused files get deleted to make space for new
  ones

28
Archival Director

• Fully automated
• Works in polling mode
• from time to time looks for files ready to be
  archived
• starts archiving only when enough data is
  available
• Files are ordered and grouped to minimize the
  expected retrieve time
• Several groups of files can be archived in
  parallel

29
Cache Manager

• User driven
• when a file is needed, the application asks the
  cache manager where it is located
• a retrieve is performed by the manager if needed
• Several requests can be issued at the same time
• the manager reorders them internally to minimize
  the tape mounts
• Communication by means of TCP/IP sockets

30
KLOE Archival System
archiver
Tape Library
Tape Library
...
n
archADSM
archADSM
. . .
m
spacekeeper
spacekeeper
Disk Pool
Disk Pool
DB
. . .
filekeeper
k
filekeeper
Disk Pool
Disk Pool
retrieve
NFS mount
local file system
TCP/IP socket
TCP/IP socket
31
KLOE Data Handling System

• Composed of four elements
• Database System
• Archiving System
• Spy System
• KLOE Integrated Dataflow (KID)

32
Spy System

• KLOE data acquisition software allows the event
  data to be read-out before they get written to
  disk
• The mechanism that reads those data is called Spy
• Based on use of shared memory buffers
• DAQ processes are piped using this mechanism
• the spy system reads data from the buffers
  without interfering with the DAQ

33
KLOE Data Handling System

• Composed of four elements
• Database System
• Archiving System
• Spy System
• KLOE Integrated Dataflow (KID)

34
KLOE Integrated Dataflow (KID)

• Integration library
• database accesses and retrieve operations hidden
• Offers a single point of access to all the
  services
• URI-based selection

35
Management effort

• The entire system is managed by only a few
  people
• 3 people (2 full time) are engaged in KLOE
  computing system management (including storage)
• 1 person is engaged in the development and
  management of the online database and the
  archiving system
• 2 people spend few percent of their time for the
  maintenance of the offline database

36
CHEP 2000
Data Handling in KLOE I.Sfiligoi INFN LNF,
Frascati, Italy
