Senior Design II: IKE

1
Senior Design II IKE
2
Infrared Keyless Entry

Final Presentation Senior Design II November
27, 2001 Mississippi State University Department
of Electrical and Computer Engineering
3
Abstract

• Design an interface to allow entry without keys.
• Radio Frequency Keyless Entry (RFKE) does not
  provide flexible interaction between automobiles
  and external communication devices.
• Infrared technology integrated with keyless entry
  will provide alternate access to automobile.
• Devices such as laptops and palm pilots with
  infrared ports will be able to access the system.

Senior Design II IKE
4
Motivation

• Allow alternate entry to automobile without keys.
• Give flexibility to access multiple components of
  car.
• Ability to program car components with IrDA
  software.

Senior Design II IKE
5
Infrared Keyless Entry System
Senior Design II IKE
6
Team
Adria Jones, Team Leader
Ray Smith
Kenny Reynolds
Dr. Ray Winton,Advisor
Senior Design II IKE
7
Design Task Breakdown

• Kenny Reynolds
• Digital Signal Encoding / Decoding
• Micro-controller Interface
• Adria Jones
• Transmitter / Receiver Amplification
  Transmission
• Ray Smith
• IrDA Implementation

Senior Design II IKE
8
Key Components
Optical Signal Receiver
Handheld Ir Receiver
Decode
Amplification
Micro-Controller
Specified Function
Senior Design II IKE
9
Design Requirements
 1. Functionality The receiver unit will be able
to receive and decode encrypted signals sent from
a transmission device via infrared media. After
proper decryption, the unit will send a signal to
unlock the doors and/or perform some other
user-desired operation on another device of the
vehicle. 2. Unique Signal Keying The
transmitter will send unique encrypted infrared
signals to the receiver. The receiver unit will
be able to decrypt codes sent by the infrared
remote. The receiver will also be IrDA-1.1
compliant to be able to receive instructions from
a third party device, such as a laptop computer
or PDA. 3. Power Power to the receiver unit
will be delivered from the vehicle's battery.
The system will operate from 10 to 15 Volts DC
and consume no more than 100 mA of current. The
transmitting unit will operate on a 12V battery
and consume no more than 100 mA of current when
in operation.
Senior Design II IKE
10
Design Requirements
4. Physical Attributes The receiver unit
will be designed to be easily installed within a
properly equipped vehicle. The transmitter will
have simple buttons for the specified function of
the keyless entry system specified by the
user.  5. Affordability Components for both the
transmitter and receiver units will not exceed
35.
Senior Design II IKE
11
Serial Encoding / Decoding ICs

• Holtek HT-640 serial encoder and HT-648L
  decoder.
• Provide 10 data address lines and 8 control
  lines. (High, Low, Open)
• Built-in RC Oscillator allows for multiple
  transmission frequencies (0.15 kHz to 2.6 kHz).
• Codes supplied by PLD (PAL16L8)

Senior Design II IKE
12
Serial Encoding

• 10 control lines, 8 data lines
• Can be tied High, Low, or left open.
• 318 possible serial combinations.
• Code Scanning? At 10 scans/sec -gt 1.23 years
• Example Coding from PIC (f 100 kHz)
• A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 D1 D2
  D3 D4 D5 D6 D7 D8
• 0 1 0 1 1 0 1 0 0
  1 1 1 0 0 0 0 0
  1 1
• 0 1 0 1 1 0 1 0 0
  1 1 1 0 0 0 1 1
  0 0

13
Transmitter Circuit
Senior Design II IKE
14
Transmitter
Senior Design II IKE
15
Simulation/Results

Power Constraint 100 mA Actual 52mA Peak
16
Receiver Circuit
IrDA I/O
Output
Senior Design II IKE
17
Receiver Circuit
Senior Design II IKE
18
Finished Product
Senior Design II IKE
19
I/O Signals
Xmitter
Receiver
I/O signals at close range (1 foot).
Senior Design II IKE
20
I/O Signals
Xmitter
Receiver
I/O signals at close range (1 foot).
Senior Design II IKE
21
I/O Signals at Distance
Xmitter
Receiver
I/O word signals at distance (15 feet).
Senior Design II IKE
22
I/O Signals at Distance
Xmitter
Receiver
Senior Design II IKE
23
Ir Problems at Distance

• Ir input signals are shortened.
• HT648L Decoder chip requires bits slightly longer

• to match the operating transmission frequency
• of the system.
• Possible solution Tuning the attenuator box?

Senior Design II IKE
24
IrDA Access Program

Software interfaces through the PC into the
PC/PDAs IrDA hardware level.
25
Our Problems With IrDA

• Software -
• PC Interfacing Hardware Layer of IrDA protocol
• Microprocessor Code
• Cant pack enough decryption software into our
• Microprocessor to thwart random code scanners.
• Hardware
• Ambient daylight Ir causes severe transmission
• problems with IrDA.

Senior Design II IKE
26
Cost
DESIGN COMPONENTS COST
Serial Encoder 2.49
Serial Decoder 2.49
Microprocessor PIC 5.95
IR X-mitter LEDs 2 0.30
IR Receiver LEDs 2 0.30
IrDA Transceiver 3.10
Quad OpAmp 1.29
SPST Relays 2.18
Resistors Capacitors 1.00
Packaging 6.00
PCB Fabrication 3.00
Battery (12V Alkaline) 0.89
TOTAL DESIGN COST 28.99
Design Requirement 35
Senior Design II IKE
27
Demonstration
Senior Design II IKE
28
MetRequirements

Functionality Unique Signal
Keying Power Physical Attributes Affordability

29
Future Work

• Improve the Signal Range!
• Finish Debugging IrDA Software
• Package Logic Module into a Smaller Box

Senior Design II IKE
30
QUESTIONS?
Senior Design II IKE
31
References
1 "Technical Summary of "IrDA DATA" and "IrDA
CONTROL", http//www.irda.org/standards/standard
s.asp, Infrared Data Association, Walnut Creek,
California, 2000.   2 How Infrared Motion
Detector Components Work, http//glolab.com/pirpa
rts/infrared.html, Glolab Corporation, 2000
  3 Weiner, Seymour. Infrared Radiation,
Encyclopedia Americana, Vol. 15 . p.169.
Grolier Inc., 1994.   4 Knutson, Charles D.
Infrared Data Communications with IrDA. IrDA
Test and Interoperability Committee. Corvallis,
Oregon, 1998.
