By Rick Mercer with help from

1
A Hash Table and a little of Java's Collection
Framework

• By Rick Mercer with help from
• The Java Tutorial, The Collections Trail, by
  Joshua Block

2
Hash Tables Rick Mercer
3

Hash TablesAn implementation of a Map

• Outline
• Discuss what a hash method does
• translates a string key into an integer
• Discuss a few strategies for implementing a hash
  table
• linear probing
• quadratic probing
• separate chaining hashing

4
The Map ADT

• Map describes a type that stores a collection of
  elements that consists of a key and a value
• A Map associates (maps) a key the it's value
• The keys must be unique
• the values need not be unique

5
Hash Tables

• A Map is often implemented with a hash table
• Hash tables provide virtually direct access to
  objects based on a key (String or Integer)
• key could be your SID, your telephone number,
  social security number, account number,
• The direct access is made possible by converting
  a String or Integer key to an array index

6
Hashing

• A key such as "555-1234" results in an integer
  index from 0 to an array upper bound index
• Elements can be found, inserted, and removed
  using the integer index as an array index
• A hash table uses the same "address calculator"
  to (insert), get (find), and remove
• Could convert a String key to 4 like this
• "able" 97 98 108 101 404
• array index 404 array capacity

7
Hash Function

• Ideally, every key has a unique hash value
• Then the hash value could be used as an array
  index, however ....
• Cannot rely on every key "hashing" to a unique
  array index
• can get "close"
• need a way to handle "collisions"
• "abc" may hash to the same integer as "cba"

8
Hash function works something like this
Convert a String key into an integer that will be
in the range of 0 through the maximum capacity-1
Assume the array
capacity is 9997
hash(key)
AAAAAAAA
8482
1273
zzzzzzzz
hash(key)
Domain "!" .. "zzzzzzzz"
Range 0 ... 9996
9
Hash Function

• What if the ASCII value of individual chars of
  the string key added up to a number from ("A") 65
  to possibly 488 ("zzzz") 4 chars max
• If the array has size 309, mod the sum
• 390 TABLE_SIZE 81
• 394 TABLE_SIZE 85
• 404 TABLE_SIZE 95
• Keys converted to array indices could be

81 85 95
"abba" "abcd" "able"
10
A "too simple" hash function

• // Return an int in the range of 0..TABLE_SIZE-1
• public int hash(String key)
• int result 0
• int n key.length()
• for (int j 0 j lt n j)
• result key.charAt(j) // add up the chars
• return result TABLE_SIZE
• public static final int TABLE_SIZE 309
• public void testHashFunction()
• assertEquals(81, hash("abba"))
• assertEquals(81, hash("baab"))
• assertEquals(85, hash("abcd"))
• assertEquals(86, hash("abce"))
• assertEquals(308, hash("IKLT"))
• assertEquals(308, hash("KLMP"))

11
Collisions

• A good hash method
• executes quickly
• distributes keys equitably
• But you still have to handle collisions when two
  keys have the same hash value
• the hash method is not guaranteed to return a
  unique integer for each key
• example simple hash method with "baab" and
  "abba"
• There are several ways to handle collisions
• Consider separate chaining hashing

12
An Array of LinkedList Objects Implementation

• An array of linked lists

0
321
365
1
2
13
Insert is Easy

• public void put(String key, Comparable x)
• int pos hash(key)
• // Place the element in the correct list
• tablepos.add (x) // Is addFirst faster?
• public void display()
• for(int j 0 j lt TABLE_SIZE j)
• System.out.print(j ". ")
• // Print an entire linked list
• System.out.println(tablej)

14
Insert Six Objects

• MyHashTableltString, BankAccountgt h
• new MyHashTableltString,
  BankAccountgt()
• BankAccount a1 new BankAccount("abba",
  100.00)
• BankAccount a2 new BankAccount("abcd",
  200.00)
• BankAccount a3 new BankAccount("abce",
  300.00)
• BankAccount a4 new BankAccount("baab",
  400.00)
• BankAccount a5 new BankAccount("KLMP",
  500.00)
• BankAccount a6 new BankAccount("IKLT",
  600.00)
• // Insert BankAccount objects using ID as the
  key
• h.put(a1.getID(), a1)
• h.put(a2.getID(), a2)
• h.put(a3.getID(), a3)
• h.put(a4.getID(), a4)
• h.put(a5.getID(), a5)
• h.put(a6.getID(), a6)
• h.display()

15
A Better Hash methodFrom Mark Alan Weiss

• Java requires the key to overrode hashCode
• String and integer already do
• // Return an int in the range of 0..TABLE_SIZE-1
• public int hash(K key)
• return key.hashCode() TABLE_SIZE

16
The output when TABLE_SIZE10

• 0. abbaabba 100.00, baabbaab 400.00
• 1.
• 2.
• 3.
• 4. abcdabcd 200.00
• 5. abceabce 300.00
• 6.
• 7.
• 8. KLMPKLMP 500.00, IKLTIKLT 600.00
• 9.
• public void display()
• for (int j 0 j lt TABLE_SIZE j)
• System.out.print(j ". ")
• // Print an entire linked list
• System.out.println(tablej)

17
Array of LinkedLists

• import java.util.LinkedList
• public class MyHashTableltK, Vgt
• private final static int TABLE_SIZE 10
• private LinkedList table
• private class HashNode
• private K key
• private V data
• private HashNode(K key, V data)
• this.key key
• this.data data
• _at_Override
• public String toString()
• return key.toString() ""
  data.toString()

18
LinkedList is Java Collection class, available to
all

• public MyHashTable()
• table new LinkedListTABLE_SIZE
• for (int j 0 j lt TABLE_SIZE j)
• tablej new LinkedList()
• // return an int in the range of 0..TABLE_SIZE-1
• public int hash(K key)
• return key.hashCode() TABLE_SIZE
• public void put(K key, V x)
• HashNode hn new HashNode(key, x)
• int pos hash(key)
• tablepos.add(hn)

19
Collection Framework

• Java's collection framework is a unified
  architecture for representing and manipulating
  collections. It has
• Interfaces abstract data types representing
  collections
• Implementations concrete implementations of the
  collection interfaces
• Algorithms methods that perform useful
  computations, such as searching and sorting
• These algorithms are said to be polymorphic the
  same method can be used on different
  implementations

20
Interfaces

• An interface describes a set of methods
• no constructors or instance variables
• Interfaces must be implemented by classes
• 646 java classes implement gt 1 interfaces (02)
• 2 or more classes implement an interface
• Classes guaranteed to have the same methods
• Objects can be treated as the same type
• Can use different algorithms / instance variables

21
Collection interfaces
Queue
22
Implementations

• A collection class
• implements an ADT as a Java class
• implements all methods of the interface
• selects appropriate instance variables
• can be instantiated
• Java provides several implementations (classes)
• ArrayList, LinkedList, HashMap, HashSet, Stack,
  TreeMap, TreeSet
• Some of this will be on the quiz

23
Algorithms

• Java has polymorphic algorithms to provide
  functionality for different types of collections
• Sorting (e.g. sort)
• Shuffling (e.g. shuffle)
• Routine Data Manipulation (e.g. reverse, addAll)
• Searching (e.g. binarySearch)
• Composition (e.g. frequency)
• Finding Extreme Values (e.g. max)

24
Map and SortedMap

• The Map interface defines as get, put, contains,
  keySet, values, and entrySet
• TreeMap implements Map
• put, get, remove O(log n)
• HashMap implements Map
• put, get, remove O(1)
• SortedMap extends Map by adding
• SortedMapltK,Vgt subMap(K fromKey,
  K toKey) SortedMapltK,Vgt
  tailMap(K fromKey)
• K lastKey() K firstKey()

25
Set and SortedSet

• The Set interface
• add, addAll, remove, size, but no get!
• Some implementations
• TreeSet values stored in order, O(log n)
• HashSet values in a hash table, no order, O(1)
• SortedSet extends Set by adding methods
  SortedSetltEgt tailSet(E fromElement) E
  first()
• SortedSetltEgt headSet(E fromElement) E
  last()
• SortedSetltEgt subSet(E fromElement,
  E toElement)

26
2 SortedMap methods

• TreeMapltString, BankAccountgt c
• new TreeMapltString, BankAccountgt()
• c.put("M", new BankAccount("Michel", 111.11))
• c.put("G", new BankAccount("George", 222.22))
• c.put("S", new BankAccount("Sam", 333.33))
• c.put("P", new BankAccount("Pei", 444.44))
• c.put("C", new BankAccount("Casey", 555.55))
• assertEquals("C", c.firstKey())
• assertEquals("S", c.lastKey())
• // Get the set of keys in the Map
• Set s c.keySet()
• assertEquals("C, G, M, P, S", s.toString())

27
Sorted keys?

• TreeSet keySet returns a sorted set
• HashMap keySet returns keys in chaotic order
• A HashMap converts the key into an integer that
  represents an array index
• The key/value mapping is added to the list in
  that location
• There can be several keys that "hash" to the same
  array index so search the small list O(1)

28
HashMap keys not in order

• Change TreeMap to HashMap and the keys are not in
  order
• HashMapltString, BankAccountgt c
• new HashMapltString, BankAccountgt()
• c.put("M", new BankAccount("Michel", 111.11))
• // 3 puts not shown
• c.put("C", new BankAccount("Casey", 555.55))
• SetltStringgt s c.keySet()
• System.out.println(s.toString())
• Output
• S, M, C, P, G

29
Iterators

• Iterators provide a general way to traverse all
  elements in a collection
• ArrayListltStringgt list new
  ArrayListltStringgt()
• list.add("1-FiRsT")
• list.add("2-SeCoND")
• list.add("3-ThIrD")
• IteratorltStringgt itr list.iterator()
• while (itr.hasNext())
• System.out.println(itr.next().toLowerCase())


Output 1-first 2-second 3-third
30
Enhanced for Loop

• The for loop has been enhanced to iterate over
  collections
• General form
• for (Type element collection)
• element is the next thing visited each
  iteration
• for (String key s)
• System.out.println(key " ")

31
Map methods

• Map objects do not have an iterator
• However, methods do exist that return a set
• // What is returned?
• SetltStringgt s tm.keySet()
• IteratorltStringgt itr s.iterator()

32
Algorithms

• See the Java API for the Collections class
• play with sort, binarySearch, reverse, shuffle
• your choice, or what's relevant for final project
• Use Java's API to examine the Collections methods
• shuffle
• binarySearch
