TEMPORAL GIS

1
TEMPORAL GIS
Dr Francisco EscobarDept of Geospatial
ScienceRMIT University francisco.escobar_at_rmit.edu
.au
2
Overview

• Introduction
• About time
• Temporal dimension and GIS
• Time-based GIS models
• Time Geography and spatio-temporal regions
• Approaches for the integration of TG with GIS

3
Introduction

• Temporal variations are crucial in most GIS
  applications
• Versioning
• Dynamic phenomena
• Dynamic processes
• GIS search where? what? increasingly when?

4
Time is always present in Geographic DataTime
makes Cartographydifferent to Geometry
5
About time

• Scarce resource but endless
• Non stackable
• Non extendible
• Same pace for everyone
• Intersections on time related phenomena (what)
  that merge in a particular place (where) at a
  particular moment (when)

6
Temporal dimensions and GIS

• Understanding and digitising time
• Conceptualisation and modelling
• What kind of time?
• Lineal or cyclical time?
• Calendar and watches or subjective time?
• Absolute or relative time?

7
Temporal dimensions and GIS
Understanding and digitising time

• Should we register the changes or the successive
  states?
• What phenomena are considered relevant in a
  continuous time line?
• How to represent gradual changes?
• What distortions and imprecision are acceptable?

8
Temporal dimensions and GIS
Understanding and digitising time

• Three different approaches
• Time as a Z attribute DEM
• Region-to-entity layers.
• Monitoring changes implies comparisons between
  layers
• Space-time entity agents
• The interest resides on entities behaviour

9
Temporal dimensions and GIS

• Temporal registry of territorial changes
• At least implicitly all cartographic
  representation includes time
• A snapshot is not enough. To apprehend the
  dynamics interpolation is needed
• GIS made it possible to store historic records
  TGIS. But unable to answer questions on dynamism

10
Temporal dimensions and GIS

• Temporal registry of territorial changes
• Langrans 4 ways to understand and represent time
  in GIS
• Tetra-dimensional or hyper cube. Continuous
• Snapshots. Discrete. The only one available
• Only changes registered. Only applied to raster
• Spatio-temporal composition. State-map.

11
(No Transcript)
12
Tetra-dimensional or hypercube.Continuous
time-space
13
Temporal dimensions and GIS

• Spatio-temporal representation of autonomous
  entities agents
• System situated within and a part of an
  environment that senses that environment and acts
  on it, over time, in pursuit of its own agenda
  and so as to effect what it senses in the future

14
Unsolved problems

• Temporal data models
• Commercial GIS still in the slice stage
• Temporal resolution and scale
• Storage and longevity of temporal data
• Changes distribution and updates without
  compromising data integrity

15
Spatio-temporal accessibility and GIS

• Another way to consider time in GIS consists on
  accessibility analysis
• Location-allocation models
• Median Scheduling Problem

16
Time Budgets and Constraints
time
distance
17
Spatio-temporal accessibility and GIS

• Potential Path Space
• Potential Path Area

18
Minutes from red and green nodes we can spend at
different locations if departing from A and
arriving to B 120 minutes later
b
a
19
Limited accessibility with iso-chrones
(OSullivan et al, 2000)
20
Activity Diaries in GIS
2) Standardization and encoding ASCII files
21
Data sources

• Field work GPS/diaries
• Existing databases
• RACV
• Public transport timetables
• Emergency Services

22
Spatio-temporal accessibility and GIS

• http//divcom.otago.ac.nz/SIRC/GeoComp/GeoComp98/6
  8/gc_68a.htm

23
Time-Geography and the Spatio-Temporal Region

• Director presentation

24
Approaches for the integration of TG with GIS

• Accessibility
• School of Alcalá, Spain, Maria Salado
• School of Auckland, NZ, Otto Huisman
• Lifelines for health events
• NCGIA, David Mark
• Lifelines for individuals and events
• RMIT, Francisco Escobar

25
Potential Accessibility
26
Business hours within a distance
27
Dynamic segmentation

• It has the potential to provide the means for a
  time-GIS integration in a continuous manner
• Analogies with lifelines

In dynamic segmentation each element presents
different attributes in each of its different
sectors but it is kept as an undivided unit
28
(No Transcript)
29

• Temporal
• GIS

Time Geography
30
http//www.as.rmit.edu.au/courses/geospatial/timed
istance/
MM applied to TG and GIS
31
Types of animated mapping

• Types of changes (1)
• Shape

(Hayward, 1984)
32

• Types of changes (2)
• Location

33
t2
t1

• Types of changes (3)
• Rate

t2
t1
34

• Types of changes (4)
• Structure or texture

35

• Types of changes (5)
• Perspective (ArcView 3D Scene)

36

• Types of changes (6)
• Colour

37

• Types of changes (7)
• Size

38

• Types of changes (9)
• Scene

39

• Types of changes (10)
• Shot

40

• Types of changes (11)
• Theme

41
(No Transcript)
42
Potential

• Utilisation of existing databases
• Time and space applications
• LBS
• Criminology
• Service planning
• Marketing

43
Issues

• Privacy
• Static nature of GIS
• Limitations in multimedia software
• Data size

44
The future
