Title: The Southern Ocean and Climate: What did we learn during WOCE?
1The Southern Ocean and ClimateWhat did we learn
during WOCE?
- Steve Rintoul
- CSIRO Marine Research and Antarctic CRC
- Australia
2Pre-WOCE view of the ACC/SO
- 2 circumpolar fronts
- wind-driven, in (flat-bottom) Sverdrup balance
- bottom form stress balances wind?
- Drake Passage transport 13413 Sv
- transport variability is barotropic
- no net meridional flow through Drake Passage gap
- poleward eddy heat flux in Drake Passage, SE NZ
- zonal circulation independent of meridional
circulation - water masses exported to lower latitudes, but
rates and mechanisms unknown
3Progress in the WOCE era
- remote sensing (SST, SSH)
- new instruments (e.g. ALACE floats)
- observations outside of Drake Passage
- improved model realism/resolution/diagnostics
- air-sea flux estimates from reanalyses
- advances in dynamical understanding
410,000 stations south of 25S since 1990
Orsi, 2002
5(No Transcript)
6(No Transcript)
7Oxygen on 27.4
8(No Transcript)
94-year mean SST gradient from ATSR reveals
multiple filaments and branches, which merge and
split.
Rintoul, Hughes and Olbers 2001
10Tracking ACC fronts using satellite altimetry
Careful comparison of hydrography and absolute
sea surface height maps shows each frontal branch
corresponds to a particular SSH contour. We can
use altimetry to track fronts, every 10 days
since 1992.
Sokolov and Rintoul, JMS, 2002
11- SAF 3 branches, merge near 140E, eddy-rich
downstream of change in orientation of SEIR. - PF 2 branches, separated by gt500 km at SR3,
merge after crossing ridge crest. - PF, SACCF strong equatorward deflection over
ridge. - Narrow meander envelopes near ridge.
12ACC Transport
Repeat sections show heat transport south
of Australia varies by 0.6 x 1015 W (relative
to 0?C). Variability is large (e.g. relative to
north-south heat flux in Indian
and Pacific.) Climate impact?
Rintoul and Sokolov, JGR, 2001
13Drake Passage transport 136?8.5 Sv
Cunningham et al., JGR, 2002
14(No Transcript)
15ACC transport ? 500 billion Lone Stars/sec
www.mylifeisbeer.com
16ACC transport in neutral density layers Australia
(SR3) color Drake Passage (SR1) black
Rintoul and Sokolov, 2001 Cunningham et al.,
JGR, 2002
17The tight relationship between temperature at 650
m and the baroclinic transport streamfunction
can be used to determine transport (above 2500
m) from temperature msmts. alone.
Rintoul, Sokolov and Church, JGR, 2002
18Net baroclinic transport time series from XBT
data (squares) and CTD data (diamonds)
19Net baroclinic transport south of Australia
(1993-2000)
Empirical relationship between surface
height and transport fn used to estimate
transport. Continuous record from altimeter
shows XBT time series is aliased.
Transport estimated from altimeter (thin line),
low-passed (thick blue line).
Rintoul, Sokolov, Church, 2002
20Streamwise average of absolute velocity of
Subantarctic Front Total transport 116 Sv
barotropic 16 Sv.
Phillips and Rintoul, JPO, 2002
21Eddy heat flux
Poleward eddy heat flux across SAF south of
Australia is larger than previously measured
elsewhere in the Southern Ocean.
Phillips and Rintoul, JPO, 2000
22Is the ACC in Sverdup balance?
ß?x ?pb ? ?H ??? ??F
Bottom pressure torque (color) barotropic
streamfn (black)
Rintoul, Hughes and Olbers 2001
23Steady, zonally-integrated momentum balance
-fV1 - ?'1p'1x ?o - R1
?1
Surface (includes Ekman)
-fV2 ?'1p'1x - ?'2p'2x - R2
?2
unblocked layer
?3
-fV3 ?'2p'2x - hpbx - R3
blocked layer
V net meridional volume flux ?o wind stress ?
layer thickness p pressure R Reynolds
stress divergence pb bottom pressure
24No interfacial form stress
V1 - ?o/f
Ekman transport in surface layer
V2 0
No transport in unblocked layer
V3 hpbx /f ?o/f
Deep geostrophic flow balances Ekman
? Overall balance of zonal momentum is between
wind stress and bottom form stress.
25Interfacial form stress ? 0
Adding the three equations and using fact
that mass is conserved (?(Vi) 0)
?o hpbx
? Again, overall balance of zonal momentum is
between wind stress and bottom form stress.
26Adiabatic flow (Vi 0)
?o ?'ip'ix hpbx
? Wind stress interfacial form stress
bottom form stress Note that
both standing and transient eddies contribute to
interfacial form stress.
27Diabatic flow (Vi ? 0)
Mixing and surface buoyancy fluxes drive mass
exchange between layers, so Vi net diapycnal
exchange ? 0.
???z(?'ip'ix) ? 0
? Divergence of interfacial form stress drives
meridional flow in the unblocked layer. ?
Buoyancy forcing, eddy stresses, and meridional
flow are intimately linked to the zonal
momentum balance.
28What controls the transport of the ACC?
- Observations and a variety of models suggest ACC
transport is a function of - ?n (n 0-1?)
- ?? x ?
- buoyancy flux
- topographic interactions
- baroclinic instability / eddy fluxes
- (Gent, Tansley, D. Marshall, J. Marshall,
Karsten, Olbers, Rintoul, Sokolov, Gille,
Gnanadesikan, Hallberg, )
29Schmitz (1996)
30(No Transcript)
31Orsi et al., 1999
32CFC inventory 8 Sv AABW 21 Sv total input to
deep ocean
Orsi et al., JGR, 2002
33(No Transcript)
34SO Overturning
- By including the water mass transformations
driven by air-sea fluxes, we can quantify the
overturning circulation for the first time. - vigorous deep cell
- weak upwelling through the thermocline
- NADW global cell closed by DW ? IW conversion in
SO
3534
4
?2
eddy mass flux
52
46
Speer et al., 2000 Sloyan and Rintoul, JPO, 2001
36Models also suggest the NADW overturning cell is
closed by upwelling and water mass transformation
in the SO.
Döös and Coward (1997)
37Formation, circulation and consumption of
intermediate and thermocline waters.
11
10
4
25
30
13
8
8
Sloyan and Rintoul (2001)
38Upper branch of the global OTC
cold 6.5 Sv
warm 5.3 Sv
cool 3.1 Sv
Speich et al., GRL, 2001
39Intermediate depth waters in both hemispheres
have become fresher in recent decades.
Wong et al., 1999
40Climate models show similar response suggest
strongest ocean climate change signal in SO.
Banks et al., GRL, 2000
41Observations south of Australia show large
variability in mode water properties from
year-to-year, driven by changes in cross-frontal
Ekman transport (not air-sea fluxes).
Circles show T-S properties of SAMW south of
Tasmania size of dot is proportional to strength
of mode. Triangles and squares are data from 1968
and 1978.
Rintoul and England, JPO, 2002
42(No Transcript)
43Warming of the Southern Ocean
Gille, Science, 2002
44Warming of Weddell Sea Warm Deep Water
Warm Deep Water flowing into and out of the
Weddell Sea has warmed by about 0.3C since the
mid-1970s. (Robertson et al., 2002)
45Climate models suggest SO overturning will slow
down as a result of global warming.
Warming and freshening increases the high
latitude stratification, shutting down
AABW formation. Is this result realistic? Can we
observe the change in stratification?
Hirst (1999)
46The Southern Ocean is the largest
zonally-integrated sink of anthropogenic CO2.
Sabine et al., 2002
47Massom et al., 2001
48Southern Annular Mode/Antarctic Oscillation
Thompson and Solomon, Science, 2002
49Antarctic Circumpolar Wave
White and Peterson, 1996
50Air temperature
Sea ice extent
Antarctic Dipole Subtracting May composites for
El Nino and La Nina events reveals the impact of
ENSO on the Southern Ocean. Response consists of
a dipole with centres in the Atlantic and Pacific
sectors, driven by the PSA teleconnection. (Yuan,
2001).
SLP El Nino
SLP La Nina
51- Modes of variability
- local or remote forcing?
- ocean response?
- feedback?
- coupled?
- regional climate impact?
52New view of the ACC/SO
- multiple filaments, which split and merge
- bottom pressure torque important (i.e. not in
flat-bottom Sverdrup balance) - transport f (?, ?x?, buoyancy forcing,
topography) - zonal and meridional circulations intimately
linked - eddies carry mass and heat poleward across Drake
Passage gap - quantified rate and mechanisms of water mass
formation - water mass transformation in SO closes
overturning cells - observed change at all depths
- identified modes of variability
53Science questions
- Strength, variability and sensitivity of SO
overturning? - Dynamics and climate impact of SH atmosphere,
ocean, ice variability? - How much mixing takes place in the Southern
Ocean? - Does the SO gain or lose heat and freshwater?
- Impact of SO variability (low latitudes, regional
climate, global overturning)?
54Conclusions
- We have made remarkable progress in understanding
the Southern Ocean during the WOCE era. - The Southern Ocean strongly influences regional
and global climate, and is sensitive to change. - The prospects for further progress are good. We
can now identify specific hypotheses and design
observing systems and models to test them.
55(No Transcript)
56(No Transcript)
57A similar relationship can be used to determine
transport for satellite measurements of sea
surface height.
Relationship between surface dynamic height and
transport function, determined from the 6 CTD
sections.
58A test of how well baroclinic transport can be
estimated from altimeter data. Residuals are
typically small (less than 5 Sv). Demonstrates
most of altimeter signal is due to changes in
baroclinic structure above 2500 m.
