EEE493'20 Software Process Metrics

1
EEE493.20 Software Process Metrics
Royal Military College of Canada Electrical and
Computer Engineering

• Dr. Terry Shepard
• shepard_at_rmc.ca
• 1-613-541-6000 ext. 6031

Major JW Paul Jeff.Paul_at_rmc.ca 1-613-541-6000
ext. 6091
2
Why Software Metrics?

• Will they answer the question of how much
  software weighs?

3
(No Transcript)
4
Le kilogramme est l'unité de masse il est égal
à la masse du prototype international du
kilogramme.

• The reason why "kilogram" is the name of a base
  unit of the SI is an artefact of history.
• Louis XVI charged a group of savants to develop a
  new system of measurement. Their work laid the
  foundation for the "decimal metric system", which
  has evolved into the modern SI. The original idea
  of the king's commission (which included such
  notables as Lavoisier) was to create a unit of
  mass that would be known as the "grave". By
  definition it would be the mass of a litre of
  water at the ice point (i.e. essentially 1 kg).
  The definition was to be embodied in an artefact
  mass standard.
• After the Revolution, the new Republican
  government took over the idea of the metric
  system but made some significant changes. For
  example, since many mass measurements of the time
  concerned masses much smaller than the kilogram,
  they decided that the unit of mass should be the
  "gramme". However, since a one-gramme standard
  would have been difficult to use as well as to
  establish, they also decided that the new
  definition should be embodied in a one-kilogramme
  artefact. This artefact became known as the
  "kilogram of the archives". By 1875 the unit of
  mass had been redefined as the "kilogram",
  embodied by a new artefact whose mass was
  essentially the same as the kilogram of the
  archives.
• The decision of the Republican government may
  have been politically motivated after all, these
  were the same people who condemned Lavoisier to
  the guillotine. In any case, we are now stuck
  with the infelicity of a base unit whose name has
  a "prefix".

http//www1.bipm.org/fr/si/history-si/name_kg.html
5
http//encyclopedia.thefreedictionary.com/Kilogram
me

• The international prototype of the kilogram seems
  to have lost about 50 micrograms in the last 100
  years, and the reason for the loss is still
  unknown (reported in Der Spiegel, 2003 26). The
  observed variation in the prototype has
  intensified the search for a new definition of
  the kilogram. Although it is accurate to state
  that all other objects in the universe have
  gained 50 micrograms per kilogram, this
  perspective is counterintuitive and defeats the
  purpose of a standard unit of mass.

6
Measuring is hard

• Even old, widely used, well established metrics
• have a complicated history
• are still changing
• What is a metric?
• the type of property being measured?
• eg. lines of code
• the unit used to measure a property?
• eg. a standard for counting lines of code in Java
• the result of measuring a property?
• eg. the number of lines of code in a particular
  program
• In software, the term metric is used in all
  three senses
• most often in the first two senses

7
four scales of measurement

• The four scales are defined by three qualities
• magnitude, equal intervals, and zero
• Most basic is the nominal scale,
• represents only names
• has none of the three qualities.
• eg. a list of students, the set of names in a
  program
• Second is the ordinal scale
• has magnitude only
• values are ordered but arithmetic operations are
  pointless
• eg. house numbers on a street, ranking of
  software versions by market position
• Third is the interval scale
• possesses both magnitude and equal intervals
• values can be usefully added or subtracted
• eg. temperature in degrees F, ranking of software
  versions by date of release
• Fourth is the ratio scale.
• contains all three qualities
• values can be usefully multiplied or divided
• eg. temperature in degrees K, number of lines of
  code in a module

8
A helpful table
9
The following table shows the width and height of
ISO A and B paper formats, as well as the ISO C
envelope formats. The dimensions are in
millimeters
A8, A9, A10
10
The ISO paper size concept
.

• which scale is being used?
• why does software not use A0 size paper?
• all other branches of engineering do...

11
Is a process metricdifferent from a product
metric?

• What is the difference between them?

12
Product vs Process Metrics

• Product Metrics
• Measures of the product at any stage of
  development
• Complexity of the software design, size of the
  final program, number of pages of documentation
• Process Metrics
• Measures of the software development process
• Overall development time, type of methodology
  used, average level of experience of the
  programming staff

13
Properties of Process Metrics

• provide objective measures of
• project progress
• qualities of software products
• provide the means for estimating the cost and
  schedule to complete a project with desired
  levels of qualities
• accuracy improves over time
• each metric has two dimensions
• a static value
• a dynamic trend
• measuring change (trend) is the most important
  aspect of metrics for project management

process metrics provide reality checks
14
So, what do we measure for Software?
15
Does Software have weight?

• Software can exert very large forces
• Its weight depends on how it is represented
• paper, chips, circuit boards, chalk, CD, shrink
  wrap,
• Changing the software may not change its weight
• Is this useful or interesting?

• choosing useful metrics for software is a hard
  problem
• there are too many choices
• we will let Walker (not Winston) Royce choose for
  us

16
Seven Core Process Metrics (Walker Royce)

• Management Indicators
• Work and Progress
• Budgeted Cost and Expenditures
• Staffing and Team Dynamics
• Quality Indicators
• Change Traffic and Stability
• Breakage and Modularity
• Rework and Adaptability
• MTBF and Maturity

17
M1 work and progress

• purpose
• iteration planning
• plan vs. actuals
• management indicator
• perspectives
• SLOC
• function points
• object points
• scenarios
• test cases
• Software Change Orders (SCOs)

18
Work and Progress
100
planned progress 40
Work Plan
current time
actual progress 25
progress
schedule variance 15
time
100
19
M2 - budgeted costs and expenditures

• purpose
• financial insight
• plans vs. actuals
• management indicator
• perspectives
• cost per month
• full-time staff per month
• of budget expended
• earned value calculations

20
Planned and Actual Cost ? Progress
actual progress?
Expenditure Plan
100
current time
planned cost 40
expenditure
actual cost 15
cost variance -25
time
100
21
Earned Value Example
The earned value at the current time is the
planned cost of the actual progress. The negative
cost variance represents an under-budget
situation.
100
planned cost 40
Expenditure Plan
current time
actual progress 25
Expenditure (planned and actual)
actual cost 15
schedule variance 15
cost variance -10
time
100
dangerous assumption actual progress of 25
equates to planned costs of 25?
22
M3 staffing and team dynamics

• purpose
• resource plan vs. actuals
• hiring rate
• attrition rate
• perspectives
• people per month added
• people per month leaving

23
Staffing and Team Dynamics
planned
actual
Staffing
the two charts dont correspond ???
24
M4 - change traffic and stability

• purpose
• iteration planning
• management indicator of schedule convergence
• perspectives
• SCOs opened versus SCOs closed
• by type (0,1,2,3,4)
• by release / subsystem / component

25
Change Traffic and Stability
Open SCOs
SCOs
Closed SCOs
time
does this graph represent stability?
26
M5 breakage and modularity

• purpose
• convergence
• software scrap
• quality indicator (maintainability)
• perspectives
• reworked SLOC per change
• by type (0,1,2,3,4)
• by release / subsystem / component

27
Breakage and Modularity
Healthy
Breakage ()
design changes
implementation changes
time
28
M6 rework and adaptability

• purpose
• convergence
• software rework
• quality indicator (maintainability)
• perspectives
• average hours per change
• by type (0,1,2,3,4)
• by release / subsystem / component

29
Rework and Adaptability
Rework (/change)
implementation changes
Sick
design changes
time
30
M7 MTBF and maturity

• purpose
• test coverage / adequacy
• robustness for use
• quality indicator (reliability)
• perspectives
• failure counts
• by release / subsystem / component
• test hours until failure (MTBF)
• by release / subsystem / component

31
MTBF and Maturity
MTBF (hours/failure)
Reliability Growth
time
32
MTBF and Maturity
MTBF (hours/failure)
Reliability Decay
time
33
Characteristics of Good metrics
34
Characteristics of Good Metrics

• meaningful to the customer, manager and performer
• demonstrates quantifiable (real) correlation
  between process changes and business performance
• everything boils down to (cost reduction,
  revenue growth and margin increase)
• objective and unambiguous
• displays trend
• natural by-product of the process
• supported by automation

35
Another View
http//www.armysoftwaremetrics.org/about/issues.as
p

• Army Software Management Issues Measures
• (6 Management Issues the 14 Army Metrics)
• In order to better assess the maturity of
  software products, DISC4 requires PMs to address
  six management issues.  The PMs can respond to
  this mandate by tracking the metrics that map to
  each of the issues. The six management issues and
  the metrics that may be collected to address each
  issue are listed below.  Remember that the
  requirement is not to use all 14 measures, but to
  adequately address these issues

36
ASMO - 6 Management Issues

• Schedule and progress regarding work completion
• cost, schedule, and development progress
• Growth and stability regarding delivery of the
  required capability
• requirements traceability, requirements
  stability, design stability, development
  progress, and complexity
• Funding and personnel resources regarding the
  work to be performed
• cost and manpower
• Product quality regarding the delivered products

• fault profiles, reliability, breadth of testing,
  complexity, and depth of testing
• Software development performance regarding the
  capabilities to meet program needs
• software engineering environment
• Technical adequacy regarding software reuse, Ada,
  and use of standard data elements
• computer resource utilization

37
ASMO - Army Metrics 1-7

• COST - tracks software expenditures (dollars
  spent vs. dollars allocated).
• SCHEDULE - tracks progress vs. schedule
  (event/deliverable progress).
• COMPUTER RESOURCE UTILIZATION - tracks planned
  vs. actual size (percent resource capacity
  used).
• SOFTWARE ENGINEERING ENVIRONMENT - rates the
  developer's environment (the developer's
  resources and software development process
  maturity).
• MANPOWER - indicates the developer's application
  of human resources to the development program and
  the developer's ability to maintain sufficient
  staffing to complete the project.
• DEVELOPMENT PROGRESS - indicates the degree of
  completeness of the software development effort.
  This metric can also be used to judge readiness
  to proceed to the next stage of software
  development.
• REQUIREMENTS TRACEABILITY - tracks requirements
  to code (percent requirements traced to design,
  code, and test cases).

38
ASMO - Army Metrics 8-14

• REQUIREMENTS STABILITY - tracks changes to
  requirements (user/developer requirements changes
  and their effects).
•
• COMPLEXITY - assesses code quality.
• BREADTH OF TESTING - tracks testing of
  requirements (percent functions/requirements
  demonstrated).
•
• DEPTH OF TESTING - tracks testing of code (degree
  of testing).
•
• FAULT PROFILES - tracks open vs. closed anomalies
  (total faults, total number of faults resolved,
  and the amount of time faults are open by
  priority).
• RELIABILITY - monitors potential downtime (the
  software's contribution to mission failure).
• DESIGN STABILITY - tracks design changes and
  effects (changes to design and percent design
  completion).

39
References

• Royce, Walker. Software Project Management,
  Addison-Wesley, 1998. Chapter 13.
• Software Metrics - Carnagie Mellon Institute
• http//www.sei.cmu.edu/publications/documents
  /cms/cm.012.html
• Army Software Metrics Office
• http//www.armysoftwaremetrics.org/about/issu
  es.asp
