MultiProtocol Label Switching

1
MultiProtocol Label Switching

• Ron Bonica
• vBNS Engineering
• Worldcom
• May 15, 2000

2
MPLS Benefits

• Traffic Engineering
• Restoration (order seconds)
• Virtual Private Networks
• Reusable Technology
• MPLS signaling to configure optical cross connects

3
MPLS Non-Benefits

• Forwarding Speed
• Vendors demonstrating OC-192 line rate forwarding
  without MPLS
• Forwarding Simplicity
• Label lookup is simpler than longest match
• That isnt visible to customer
• Quality of Service
• No service contracts associated with an LSP

4
MPLS Concepts

• Label Switching Path (LSP)
• Label Switching Router (LSR)
• Ingress, Transit, Egress
• LSP Path Selection
• LSP Setup and Restoration
• Resource Reservation Protocol (RSVP)
• Label Distribution Protocol (LDP)

5
Label Switching Path

• Tunnel through a routing domain
• Ingress LSR makes IP routing decision
• Encapsulates datagram in MPLS header
• Label has local significance only
• Forwards datagram through LSP
• Transit LSRs forward based on MPLS header
• No L3 routing decision
• Label pushing and swapping
• Egress LSR pops MPLS label

6
Label Switching Path Disclaimers

• LSP does not appear as an interface to the
  ingress or egress router
• Ingress and egress routers do not exchange link
  state information across LSP
• For networks using PIM, multicast traffic does
  not traverse LSPs
• LSP does not preclude non-MPLS traffic from
  traversing interface via L3 forwarding

7
Label Switched Path
LSR1
LSR3
Switched
Label
Path
LSR2
LSR5
LSR4
LSR6
Ingress
Egress
LSR8
LSR7
8
Ingress Router Assigning Datagram to LSP

• By BGP next-hop
• Typical
• Not very granular
• Encourages creative uses of BGP next-hop
• By IP destination
• Administratively configured at ingress router
• By other IP header fields
• Various offerings from various vendors

9
Creative Uses for BGP Next-hop

• Egress LSR has two loopback addresses
• One LSP terminates at first loopback address
• Another LSP terminates at second loopback address
• Each loopback address is BGP next-hop for
  selected sub-networks
• Administratively configured at egress

10
LSP Path Setup

• Static
• Manually configured at each node
• Explicitly Routed LSP
• Signaled from ingress LSR
• Path strictly or loosely defined
• Constraint Based Shortest Path First
• Signaled from ingress LSR
• Link attributes and LSP constraints

11
ER-LSP Strict Definition
LSR1
LSR3
Switched
Label
Path
LSR2
LSR5
LSR4
LSR6
Ingress
Egress
LSR8
LSR7
12
ER-LSP Loose Definition
LSR1
LSR3
Switched
Label
Path
LSR2
LSR5
LSR4
LSR6
Ingress
Egress
LSR8
LSR7
13
Constraint Based Routing

• Links administratively assigned attributes
• Bandwidth, color
• Link attributes distributed by IGP
• TE extensions to OSPF and ISIS
• LSP routing constraints administratively defined
• Bandwidth, maximum hops, color
• LSR calculates routes that satisfies constraints

14
Constraint Based Routing
LSR1
LSR3
Switched
Label
Path
LSR2
LSR5
LSR4
LSR6
Ingress
Path
Label
Egress
Switched
LSR8
LSR7
15
LSP Setup Signaling

• Resource Reservation Protocol (RSVP)
• Distribute Information about paths and labels
• Label Distribution Protocol (LDP)
• Distribute information about paths, labels and
  Forwarding Equivalence Class mappings

16
LSP Setup RSVP

• RSVP messages propagated from ingress LSR to
  egress LSR
• Reverse of direction described in RFC 2205
• Soft state established at each intermediate node
• Represents LSRs behavior with regard to a
  incoming label on a specified interface
• Forwarding Interface
• Push, Pop, or Swap labels

17
RSVP Messages

• PATH
• Ingress to egress
• Integrity, label request and constraint objects
• RESV
• Egress to ingress
• Integrity, label and record objects
• TEAR
• Either direction
• Label object

18
LSP Setup LDP

• Protocol Between LDP Peers
• Discovery Messages
• UDP
• General (broadcast on segment)
• Targeted (can be multiple hops away, unicast)
• Session Control, Advertisement and Notification
  Messages
• TCP

19
LDP Modes

• Downstream Unsolicited
• Downstream On Demand

20
LDP Messages

• Discovery
• Hello
• Session Control
• Initialization
• Keep Alive
• Notification

21
LDP Messages (continued)

• Advertisement
• Address /Address Withdraw
• Label Request
• Label Abort Request
• Label Mapping / Withdraw / Release
• Label Mapping contains FEC/Label binding

22
Restoration Alternatives

• Fail-over to secondary path
• Setup in advance
• Physically diverse from primary
• Recalculate Path
• Signal back to source (slow)
• Circumvent failure (better)
• Fast Reroute (best)

23
Restoration Hot Standby
LSR1
LSR3
Primary
LSR2
LSR5
LSR4
LSR6
Ingress
Egress
Secondary
LSR8
LSR7
24
Restoration Signal to Source
Tear
LSR1
LSR3
Setup
X
LSR2
LSR5
LSR4
LSR6
Ingress
Egress
LSR8
LSR7
25
Restoration Circumvent Failure
LSR1
LSR3
Setup
X
LSR2
LSR5
LSR4
LSR6
Ingress
Egress
LSR8
LSR7
26
Restoration Time Hot Standby LSP Versus IGP
Reroute
MPLS1.25 Sec
OSPF1.25 Sec
x
R1
R2
Preferred Route or Primary LSP
MPLS1.5 Sec
x
OSPF3.25 Sec
Other Route or Standby LSP
R4
R3
Destination
27
Circuit Cross Connects

• Juniper proprietary
• Makes LSP look like ATM or Frame Relay PVC
• Associate ATM or frame relay UNI with endpoint of
  MPLS LSP
• All traffic from LSP is routed to UNI
• All traffic from UNI is routed to LSP

28
Circuit Cross Connects (continued)

• Endpoints must be like (ATM-ATM, Frame-Frame)
• AAL5 encapsulated IP over ATM
• AAL5 frame reassembled at ingress
• Ingress sends MPLS encapsulated AAL5 frame
  through network
• Egress breaks frame into cells and send through
  ATM UNI
• No ATM cell tax across backbone

29
What is Traffic Engineering

• Isnt that why we did MPLS in the first place?

30
Traffic Engineering

• Goals
• Meet customer SLAs
• Minimize expenditure required to meet SLAs
• Methods
• Direct traffic to devices that can provide
  required resources
• Divert traffic from devices that provide scarce
  resources, when required and possible.

31
Traffic Engineering Alternatives Before MPLS

• Layer 2 Traffic Engineering
• Full layer 2 mesh connects routers
• Two infrastructures to purchase and manage
• Same TE problems need to be solved at layer 2
  (e.g., path calculation, configuration
  management)
• Traffic Engineering using IGP metrics
• Control not sufficiently granular

32
TE Using IGP Granularity Problem
Using IGP metrics, steer traffic from R1 to R6
through R4. Also steer traffic from R2 to R6
through R5.
33
Traffic Engineering Methods

• Define edge-to-edge service requirements
• Bandwidth, delay, reliability
• Input from customer SLAs and performance data
• Catalogue link capabilities, network wide
• Calculate paths based on service requirements and
  link capabilities

34
Path Calculation Alternatives

• Off-line path calculation
• Model network and calculate paths off-line
• Transfer paths to routers (configure ER-LSP)
• On-line path calculation
• Configure routers with attributes of directly
  connected links
• IGP distributes link attributes with link state
  announcements
• Configure ingress router with LSP requirement
• Routers calculate path (distributed calculation)

35
Path Calculation Observations

• Path calculation is challenging
• On-line (distributed) path calculation is very
  challenging
• Order in which routers reserve resources becomes
  significant
• Distributed path calculation for large networks
  is very, very challenging

36
Difficult Paths to Calculate
600 mbps
200 mbps
37
Off-Line Path Calculation

• Pros
• Opportunity to review calculated paths before
  they go into the network

• Cons
• Configuration management effort
• Impractical to re-calculate for each potential
  link failure

38
On-Line Path Calculation

• Pros
• Reduced configuration management effort
• Automatic re-calculation after link failure, with
  information about which link failed

• Cons
• No opportunity to review calculated paths before
  they go into the network
