Future Direction for Specs'

1
Future Direction for Specs.

• John DAngelo
• Federal Highway Administration
• AMAP 2006

2
Modified Binders Affect Performance

• Study same mix different binders.

PG 63-22 mod. no rutting
PG 67-22 unmod. 15mm rutting
3
Proposed MSCR TEST Protocol
Creep Stress
1
10
time
Creep Strain
time
4
High Temperature Binder Test

• New test criteria
• Perform multiple stress levels on the same sample
  at reduced number of cycles.
• Stress levels 25, 50, 100, 200, 400, 800, 1600,
  and 3200 Pa.
• Run 10 cycles at each stress level no rest
  periods
• Total cycles per test 80.

5
(No Transcript)
6
ALF and CR ranking
7
(No Transcript)
8
High Temperature Binder Criteria

• Study
• Refine the Multi-Stress Creep and Recovery Test
• Evaluate multiple binders
• Evaluate binder and mix properties to develop
  specification criteria.

9
Development of Standard Practice for Superpave
Plus Specifications

• Use of DSR in Place of ER and Ductility

10
Why Superpave Plus Specs.

• The existing specifications do not identify the
  performance characteristics of modified binders.
• The existing specifications do not have a
  criteria for fatigue or durability.
• Agencies look to other tests to identify
  modifiers
• Elastomeric polymer modifiers are desired

11
State DOTs Specifying Polymer PG (PG)
Ductility
ER
SB/SBS Required
ER
ER
PA
ER TT
ER
ER
ER
ER
ER
ER
ER FD
ER PA
ER
Ductility, TT ER
FD
TT DT
ER TT
ER
ER
ER
SB/SBS Required
ER
ER PA
ER-Elastic Recovery FD-Force Ductility TT-Toughnes
s Tenacity PA-Phase Angle
PA
FD ER
ER
PA
PG modifier
PG
12
Toughness Tenacity
13
Elastic Recovery
AC doesnt recover SB modified AC recovers
14
Problem Statement

• Provide Users with alternatives to the empirical
  Superpave Plus tests
• Elastic Recovery
• Ductility/ Force Ductility
• Toughness and Tenacity
• Approach Develop AASHTO/ASTM Standard Practice
  for Superpave Plus Specifications
• DSR
• Multiple Stress Creep Recovery

15
So What Do We Do? Use DSR Approach

• Use DSR
• Muti Stress Creep Recovery Test
• Two creep stress levels
• Ten cycles per stress level
• For Elastomeric modifiers Specify
• strain recovery gt 15 or 20
• Overall change between stress levels
• Run on the RTFOT
• Run on the same sample as RTFOT grading

16
Proposed MSCR TEST Protocol
3200 Pa
Creep Stress
100 Pa
1
10
time
Creep Strain
time
17
What criteria? recovered strain
(Peak Strain - recovered Strain)/Peak Strain
18
(No Transcript)
19
(No Transcript)
20
PG 64-34 1101 SBS 83 recovery 100Pa
21
PG 64-34 1101 SBS 21 recovery 3200Pa
22
70-22 3SBR 26 recovery 100Pa
23
70-22 3SBR 15 recovery 3200Pa
24
67-34 28 recovery 100Pa
25
67-34 9 recovery 3200Pa, 75 ER
26
Difference between low stress and high stress
shows how sensitive the formulation is to stress
Differential 9
Differential 66
Differential 59
Unknown
LDPE
EVA
27
Two 70-22s with SBS. Not all binders are the
same.
Differential 30
Differential 18
SBS
SBS
28
(No Transcript)
29
General relationship between ER and MSCR
Incompatible SBS
Special EVA
30
Findings to date

• The DSR MSCR percent strain recovery criterion
  can replace the FD, ER, or TT.

31
Future Steps

• Analyze available MSCR percent recovered strain
  data to finalize creep stress level and test
  protocol
• Where available, show relationships with existing
  ER, FD, Duct., and TT data

32
NCHRP 9-36 Improved Procedure for Laboratory
Aging of Asphalt Binders

• Improved procedure for short-term laboratory
  aging usable in a purchase specification such as
  AASHTO M320.
• Apply to neat and modified binders.
• Quantify binder volatility.
• Extend to long-term aging.
• Mimic PP2 mix aging.
• Advanced Asphalt Technologies (August 2005)

33
Original SAFT Apparatus (Glover)

• Aging Conditions
• 163C
• 30 minutes
• Atmospheric air
• 2 liters /minute

Heating Mantle
34
SAFT by COX
Vessel top fully enclosed
Sits on bench at convenient height
35
(4) Verification Study

• Mixtures with 12 binders
• Mixtures aged in laboratory
• Physical properties
• Binders aged with SAFT and RTFOT
• Physical properties
• Volatile collection and analysis
• Binder and mixture aging to be compared
• Comparison using Hirsch model
• Status
• Mixture work underway
• Binder aging to follow optimization study

36
Questions
