How Computer Architecture Trends May Affect Future Distributed Systems

1
How Computer Architecture TrendsMay Affect
Future Distributed Systems

• Mark D. Hill
• Computer Sciences Department
• University of Wisconsin--Madison
• http//www.cs.wisc.edu/markhill
• PODC 00 Invited Talk

2
Three Questions

• What is a System Area Network (SAN)and how will
  it affect clusters?
• E.g., InfiniBand
• How fat will multiprocessor servers beand how to
  we build larger ones?
• E.g. Wisconsin Multifacets Multicast Timestamp
  Snooping
• Future of multiprocessor servers clusters?
• A merging of both?

3
Outline

• Motivation
• System Area Networks
• Designing Multiprocessor Servers
• Server Cluster Trends

4
Technology Push Moores Law

• What do following intervals have in common?
• Prehistory to 2000
• 2001 to 2002
• Answer Equal progress in absolute processor
  speed(and more doubling 2003-4, 2005-6, etc.)
• Consider salary doubling
• Corollary Cost halves every two years
• Jim Gray In a decade you can buy a computerfor
  less than its sales tax today

5
Application Pull

• Should use computers in currently wasteful ways
• Already computers in electric razors greeting
  cards
• New business models
• B2C, B2B, C2B, C2C
• Mass customization
• More proactive (beyond interactive) Tennenhouse
• Today P2C where PPerson CComputer
• More C2P mattress adjusts to save your back
• More C2C Agents surf the web for optimal deal
• More sensors (physical/logic worlds coupled)
• More hidden computers (c.f., electric motors)
• Furthermore, I am wrong

6
The Internet Iceberg

• Internet Components
• Clients -- mobile, wireless
• On Ramp -- LANs/DSL/Cable Modems
• WAN Backbone -- IPv6, massive BW
• and ...
• SERVICES
• Scale Storage
• Scale Bandwidth
• Scale Computation
• High Availability

7
Outline

• Motivation
• System Area Networks
• What is a SAN?
• InfiniBand
• Virtualizing I/O with Queue Pairs
• Predictions
• Designing Multiprocessor Servers
• Server Cluster Trends

8
Regarding Storage/Bandwidth

• Currently resides on I/O Bus (PCI)
• HW SW protocol stacks
• Must add hosts to add storage/bandwidth

bridge
i/o bus
i/o slot 0
i/o slot n-1
9
Want System Area Network (SAN)

• SAN vs. Local Area Nework (LAN)
• Higher bandwidth (10 Gbps)
• Lower latency (few microseconds or less)
• More limited size
• Other (e.g., single administrative domain, short
  distance)
• Examples Tandem Servernet Myricom Myrinet
• Emerging Standard InfiniBand
• www.inifinibandTA.org w/ spec 1.0 Summer 2000
• Compaq, Dell, HP, IBM, Intel, Microsoft, Sun,
  others
• 2.5 Gbits/s times 1, 4, or 12 wires

10
InfiniBand Model (from website)
target (disks)
TCA
11
Inifiniband Advantages

• Storage/Network made orthogonal from Computation
• Reduce hardware stack -- no i/o bridge
• Reduce software stack hardware support for
• Connected Reliable
• Connected Unreliable
• Datagram
• Reliable Datagram
• Raw Datagram
• Can eliminate system call for SAN use (next slide)

12
Virtualizing InfiniBand

• I/O traditionally virtualized with system call
• System enforces isolation
• System permits authorized sharing
• Memory virtualized
• System trap/call for setup
• Virtual memory hardware for common-case
  translation
• Infiniband exploits queue pairs (QPs) in memory
• C.f., Intel Virtual Interface Architecture
  (VIA)IEEE Micro, Mar/Apr 98
• Users issue sends, receives, remote DMA
  reads/writes

13
Queue Pair

• QP setup system call
• Connect with process
• Connect with remote QP(not shown here)
• QP placed in pinned virtual memory
• User directly access QP
• E.g., sends, receives remote DMA reads/writes

proc
Main Memory
dma-W4
dma-R3
send2
receive1
send1
receive2
HCA
14
InfiniBand, cont.

• Roadmap
• NGIO/FIO merger in 99
• Spec in 00
• Products in 03-10
• My Assessment
• PCI needs successor
• InfiniBand has the necessary features (but also
  many others)
• InifiniBand has considerable industry buy-in (but
  it is recent)
• Gigabit Ethernet will be only competitor
• Good name with backing from Cisco et al.
• But TCP/IP is a killer
• Infiniband for storage will be key

15
InfiniBand Research Issues

• Software Wide Open
• Industry will do local optimization(e.g., still
  have device driver virtualized with system calls)
• But what is the right way to do software?
• Is there a theoretical model for this software?
• Other SAN Issues
• A theoretical model of a service-providers site?
• How to trade performance and availability?
• Utility of broadcast or multicast support?
• Obtaining quasi-real-time performance?

16
Outline

• Motivation
• System Area Networks
• Designing Multiprocessor Servers
• How Fat?
• Coherence for Servers
• E.g., Multicast Snooping
• E.g., Timestamp Snooping
• Server Cluster Trends

17
How Fat Should Servers Be?

• Use
• PCs -- cheap but small
• Workgroup servers -- medium cost medium size
• Large servers -- premium cost size
• One answer yes

18
How Do We Build the Big Servers?

• (Industry knows how to build the small ones)
• A key problem is the memory system
• Memory Wall E.g., 100ns memory access 400
  instruction opportunities for 4-way 1GHz
  processor
• Use per-processor caches to reduce
• Effective Latency
• Effective Bandwidth Used
• But cache coherence problem ...

19
Coherence 101
4
4
r0lt-m100
r1lt-m100
m100lt-5
X 5
100 4
100 4
interconnection network
memory
memory
100 4
20
Broadcast Snooping
P2GETX
P2GETX
data
data
data
21
Broadcast Snooping

• Symmetric Multiprocessor (SMP)
• Most commercially-successful parallel computer
  architecture
• Performs well by finding data directly
• Scales poorly
• Improvements, e.g., Sun E10000
• Split address data transactions
• Split address data network (e.g., bus
  crossbar)
• Multiple address buses (e.g., four multiplexed by
  address)
• Address bus is broadcast tree (not shared wires)
• But
• Broadcast all address transactions (expensive)
• All processors must snoop all transactions

22
Directories
P2GETX P1GETX
P2GETX
data
data
data
23
Directories

• Directory Based Cache Coherence
• E.g., SGI/Cray Origin2000
• Allows arbitrary point-to-point interconnection
  network
• Scales up well
• But
• Cache-to-cache transfers common in demanding
  apps(55-62 sharing misses for OLTP Barroso
  ISCA 98)
• Many applications cant use 100s of processors
• Must also scale down well

24
Wisconsin Multifacet Big Picture

• Build Servers For Internet economy
• Moderate multiprocessor sizes 2-8 then 16-64,
  but not 1K
• Optimize for these workloads (e.g. cache-to-cache
  transfers)
• Key Tool Multiprocessor Prediction Speculation
• Make a guess... verify it later
• Uniprocessor predecessors branch set
  predictors
• Recent multiprocessor work Mukherjee/Hill
  ISCA98, Kaxiras/Goodman HPCA99 Lai/Falsafi
  ISCA99
• Multicast Snooping
• Timestamp Snooping

25
Comparison of Coherence Methods
Use prediction to improve on both?
26
Multicast Snooping

• On cache miss
• Predict "multicast mask" (e.g., bit vector of
  processors)
• Issue transaction on multicast address network
• Networks
• Address network that totally-orders address
  multicasts
• Separate point-to-point data network
• Processors snoop all incoming transactions
• If it's your own, it "occurs" now
• If another's, then invalidate and/or respond
• Simplified directory (at memory)
• Purpose Allows masks to be wrong (explained
  later)

27
Predicting Masks

• Performed at Requesting Processor
• Include owner (GETS/GETX) all sharers (GETX
  only)
• Exclude most other processors
• Techniques
• Many straightforward cases (e.g., stack,
  code,space-sharing)
• Many options (network load, PC, software,
  local/global)

predicted mask
Mask Predictor
block address
feedback
28
Implementing an Ordered Multicast Network

• Address Network
• Must create the illusion of total order of
  multicasts
• May deliver a multicast to destinations at
  different times
• Wish List
• High throughput for multicasts
• No centralized bottlenecks
• Low latency and cost ( pipelined broadcast tree)
• ...
• Sample Solutions
• Isotach Networks Reynolds et al., IEEE TPDS
  4/97
• Indirect Fat Tree ISCA 99
• Direct Torus

29
Indirect Fat Tree ISCA 99
P D M
30
Indirect Fat Tree, cont.

• Basic Idea
• Processors send transactions up to roots
• Roots send transactions down with logical
  timestamp
• Switches stall transactions to keep in order
• Null transaction sent to avoid deadlock
• Assessment
• Viable high cross-section bandwidth
• Many "backplane" ASICs means higher cost
• Often stalls transactions
• Want
• Lower cost of direct connections
• Always delivery transactions as soon as possible
  (ASAP)
• Sacrifice some cross-section bandwidth

31
Direct 2-D Torus (work in progress)

• Features
• Each processor is switch
• Switches directly connected
• E.g., network of Compaq 21364
• Network order?
• Broadcasts unordered
• Snooping needs total order
• Solution
• Create order with logical timestampsinstead of
  network delivery order
• Called Timestamp Snooping ASPLOS 00

0
1
15
14
32
Timestamp Snooping

• Timestamp Snooping
• Snooping with order determined by logical
  timestamps
• Broadcast (not multicast) in ASPLOS 00
• Basic Idea
• Assign timestamp to coherence transactions at
  sender
• Broadcast transactions over unordered network
  ASAP
• Transaction carry timestamp (2 bits)
• Processors process transactions in timestamp
  order

33
Timestamp Snooping Issues

• More address bandwidth
• For 16-processors, 4-ary butterfly, 64-byte
  blocks
• Directory 38 372 more 240 more
• Timestamp Snooping 218 372 384 (lt 60
  more)
• Network must guarantee timestamps
• Assert future transactions will have greater
  timestamps(so processor can processor older
  transactions)
• Isotach Reynolds IEEE TPDS 4/97 more
  aggressively
• Other
• Priority queue at processor to order transactions
• Flow control and buffering issues

34
Initial Multifacet Results

• Multicast Snooping ISCA 99
• Ordered multicast of coherence transactions
• Find data directly from memory or caches
• Reduce bandwidth to permit some scaling
• 32-processor results show 2-6 destinations per
  multicast
• Timestamp Snooping ASPLOS 00
• Broadcast snooping with order determined by
  logical timestamps carried by coherence
  transactions
• No bus Allows arbitrary memory interconnects
• No directory or directory indirection
• 16-processor results show 25 faster for 25 more
  traffic

35
Selected Issues

• Multicast Snooping
• What program property are mask predictors
  exploiting?
• Why is there no good model of localityor the
  90-10 rule in general?
• How does one build multicast networks?
• What about fault tolerance?
• Timestamp Snooping
• What is an optimal network topology?
• What about buffering, deadlock, etc.?
• Implementing switches and priority queues?

36
Outline

• Motivation
• System Area Networks
• Designing Multiprocessor Servers
• Server Cluster Trends
• Out-of-box and highly-available servers
• High-performance communication for clusters

37
Multiprocessor Servers

• High-Performance Communication within box
• SMPs (e.g., Intel PentiumPro Quads)
• Directory-based (SGI Origin2000)
• Trend toward hierarchical out of box solutions
• Build bigger servers from smaller ones
• Intel Profusion, Sequent NUMA-Q, Sun WildFire
  (pictured)

38
Multiprocessor Servers, cont.

• Traditionally had poor error isolation
• Double-bit ECC error crashes everything
• Kernel error crashes everything
• Poor match for highly available Internet
  infrastructure
• Improve error isolation
• IBM 370 virtual machines
• Stanford HIVE cells

39
Clusters

• Traditionally
• Good error isolation
• Poor communication performance (especially
  latency)
• LANs are not optimized for clusters
• Enter Early SANs
• Berkeley NOW w/ Myricom Myrinet
• IBM SP w/ proprietary network
• What now with InfiniBand SAN (or alternatives)?

40
A Prediction

• Blurring of cluster server boundaries
• Clusters
• High communication performance
• Servers
• Better error isolation
• Multi-box solutions
• Use same hardware configure in the field
• Issues
• How do we model these hybrids?
• Should PODC SPAA also converge?

41
Three Questions

• What is a System Area Network (SAN)and how will
  it affect clusters?
• E.g., InfiniBand
• Make computation, storage, network orthogonal
• How fat will multiprocessor servers beand how to
  we build larger ones?
• Varying sizes for soft hard state
• E.g., Multicast Snooping Timestamp Snooping
• Future of multiprocessor servers clusters?
• Servers will support higher availability
  extra-box solutions
• Clusters will get server communication performance
