Protocols Progress with Current Work.

1
ProtocolsProgress with Current Work.
Richard Hughes-Jones The University of
Manchester www.hep.man.ac.uk/rich/ then
Talks
2
vlbi_udp UDP on the WAN

• iGrid2002 monolithic code
• Convert to use pthreads
• control
• Data input
• Data output
• Code branch for Simons file transfer tests
• Work on vlbi_recv
• Output thread polled for data in the ring buffer
  burned CPU
• Input thread signals output thread when there is
  work to do else wait on semaphore packet loss
  at high rate, variable thoughput
• Output thread uses sched_yield() when no work to
  do CPU used
• Add code for MarkV card and PCEVN interface
• Measure throughput, packet loss, re-ordering,
  1-way delay
• Multi-flow Network performance being set up
  Nov/Dec06

3
vlbi_udp B2B UDP Tests

• Kernel 2.6.9
• vlbi_recv sched_yield()
• Wait 12 us
• Stable throughput
• 999 Mbit/s variation less than 1 Mbit/s
• No packet loss
• Inter-packet time
• Processing time
• mean 0.1005 sigma 0.1438
• CPU load

• Cpu0 0.0 us, 0.0 sy, 0.0 ni, 99.7 id,
  0.3 wa, 0.0 hi, 0.0 si
• Cpu1 11.3 us, 88.7 sy, 0.0 ni, 0.0 id,
  0.0 wa, 0.0 hi, 0.0 si
• Cpu2 0.3 us, 0.0 sy, 0.0 ni, 99.3 id,
  0.3 wa, 0.0 hi, 0.0 si
• Cpu3 9.3 us, 15.6 sy, 0.0 ni, 37.5 id,
  0.0 wa, 1.3 hi, 36.2 si

4
vlbi_udp Multi-site Streams
Gbit link
Chalmers University of Technology, Gothenburg
Metsähovi
OnsalaSweden
Jodrell BankUK
Gbit link
TorunPoland
DedicatedGbit link
Dwingeloo DWDM link
MedicinaItaly
5
TCP tcpdelay How does TCP move CBR data?

• Want to examine how TCP moves Constant Bit Rate
  Data
• VLBI Application Protocol
• tcpdelay a test program
• instrumented TCP program emulates sending CBR
  Data.
• Records relative 1-way delay
• Web100 Record TCP Stack activity

6
TCP tcpdelay Visualising the Results
Stephen Kershaw

• If Throughput NOT limited by TCP buffer size /
  Cwnd maybe we can re-sync with CBR arrival
  times.
• Need to store CBR messages during the Cwind drop
  in the TCP buffer
• Then transmit Faster than the CBR rate to catch
  up

Arrival time
Message number / Time
7
TCP tcpdelay JB-Manc

• Message size 1448 Bytes
• Wait time 22 us
• Data Rate 525 Mbit/s
• Route JB-Man
• RTT 1 ms
• TCP buffer 2MB
• Drop 1 in 10,000 packets
• 2.5-3 ms increase in timefor about 2000
  messagesie 44 ms
• Classic Cwnd behaviour
• Cwnd dip corresponds to 1.2M bytes data
  Delayed (810 packets)
• Peak Throughput 620 Mbit/s

8
Arrival Times UKLight JB-JIVE-Manc
Presented at the Haystack Workshop

• Message size 1448 Bytes
• Wait time 22 us
• Data Rate 525 Mbit/s
• RouteJB-UKLight-JIVE-UKLight-Man
• RTT 27 ms
• TCP buffer 32M bytes
• BDP _at_512Mbit 1.8Mbyte
• Estimate catchup possible if loss lt 1 in 1.24M
• Data needed forJIVE-Manc 27msChicago-Manc 120
  ms
• Have 30 GBytes!!!

Stephen Kershaw
9
TCP TCP Stacks, Sharing, Reverse Traffic

• Delayed by Provision of UKLight link Manc -
  Starlight
• PC installed in Starlight and Manchester Sep06
• Udpmon tests Good
• Plateau 990 Mbit/s wire rate
• No packet Loss
• Same in both directions
• TCP studies Work Now in progress

10
DCCP The Application View

• Stephen Richard with help from Andrea
• Had problems with Fedora Core 6 using stable
  kernel 2.6.19-rc1
• DCCP data packets never reached the receiving
  TSAP !
• Verify with tcpdump
• Using 2.6.19-rc5-g73fd2531-dirty
• Ported udpmon to dccpmon
• Some system calls dont work
• dccpmon tests
• Plateau 990 Mbit/s wire rate
• No packet Loss
• Receive system crashed!
• Iperf tests
• 940Mbps, back-to-back
• Need more instrumentation in DCCP
• Eg a line in /proc/sys/snmp

11
10 Gigabit Ethernet Lab

• 10 Gigabit Test Lab now set up in Manchester
• Cisco 7600
• Cross Campus ? lt1ms
• Neterion NICs
• 4 Myricom 10 Gbit NICs delivery this week
• Chelsio being purchased
• Boston/Supermicro X7DBE PCs
• Two Dual Core Intel Xeon Woodcrest 5130 2 GHz
• PCI-e and PCI-X
• B2B performance so far
• SuperMicro X6DHE-G2
• Kernel (2.6.13) Driver dependent!
• One iperf TCP data stream 4 Gbit/s
• Two bi-directional iperf TCP data streams 3.8
  2.2 Gbit/s
• UDP Disappointing
• Installed Fedora Core5 Kernels 2.6.17 2.6.18
  (web100 packet drop) 2.6.19 on the Intel
  dual-core PCs

12
ESLEA-FABRIC4 Gbit flows over GÉANT

• Set up 4 Gigabit Lightpath Between GÉANT PoPs
• Collaboration with Dante
• GÉANT Development Network London Amsterdamand
  GÉANT Lightpath service CERN Poznan
• PCs in their PoPs with 10 Gigabit NICs
• VLBI Tests
• UDP Performance
• Throughput, jitter, packet loss, 1-way delay,
  stability
• Continuous (days) Data Flows VLBI_UDP and
• multi-Gigabit TCP performance with current
  kernels
• Experience for FPGA Ethernet packet systems
• Dante Interests
• multi-Gigabit TCP performance
• The effect of (Alcatel) buffer size on bursty TCP
  using BW limited Lightpaths

13
Options Using the GÉANT LightPaths

• Set up 4 Gigabit Lightpath Between GÉANT PoPs
• Collaboration with Dante
• PCs in Dante PoPs

• 10 Gigabit SDH backbone
• Alkatel 1678 MCC
• Node location
• Budapest
• Geneva
• Frankfurt
• Milan
• Paris
• Poznan
• Prague
• Vienna
• Can do traffic routingso make long rtt paths
• Ideal London Copenhagen

14
Network/PC Booking System

• Based on Meeting Room Booking System
• Divide into Links and End systems
• Hard work by Stephen Kershaw
• Tesing with VLBI

15
