Crosscutting Issues: The R

1
(No Transcript)
2
Crosscutting Issues The Rôle of Compilers

• Architects must be aware of current compiler
  technology

3
Modern Compilers
E.g. procedure inlining, loop transformations
Register allocation
Machine dependent optimisations
4
Compiler Technology

• Multiple passes complicate matters
• E.g. common subexpression elimination must assume
  that a register will be allocated for the
  temporary value
• E.g. Procedure inlining before size is known
• Register allocation is critical
• Uses graph colouring techniques
• Requires at least 16 registers to be effective

5
Architectural Issues

• How are variables allocated and addressed?
• Stack local variables, scalars
• Global data area global variables, constants,
  arrays
• Heap dynamic objects, not scalars
• How many registers are needed?
• Integer 26 registers
• FP 20 registers

6
Aiding Compiler Writers

• Architectures should
• Be regular (orthogonal instruction set)
• Provide primitives, not solutions
• Simplify trade-offs among alternatives
• Not require run-time interpretation of data known
  at compile-time
• VAX CALLS

Keep it simple!
7
Compiler Support for Multimedia Instructions

• SIMD instructions act on multiple smaller data
  items in a large word
• Solutions, not primitives!
• Too few registers!
• Data types not found in programming languages!

Result Only used by low-level graphics libraries.
8
Multimedia Instructions

• These SIMD instructions act like a mini-vector
  architecture
• E.g. MMX in 64 bits
• 8 8-bit vectors
• 4 16-bit vectors
• 2 32-bit vectors
• SSE 128 bits
• Much more limited than genuine vector processors

9
Putting It All Together MIPS

• 64-bit load/store design
• RISC features
• GPR, load-store architecture
• Small, simple instruction set
• Designed for efficient pipelining (fixed length
  instructions)
• Efficient compiler target

10
MIPS

• 32 64-bit integer registers
• R0R31
• R0 fixed 0
• 32 64-bit or 32-bit floating point registers
• Supports paired single operations

11
MIPS Data Types

• Integer
• Bytes, 16-bit halfwords, 32-bit words, 64-bit
  double words
• Operations are all 64-bit
• Floating point
• 32-bit and 64-bit

12
MIPS Addressing Modes

• Only immediate and displacement
• 16-bit displacements/immediates
• Register-indirect set displacement 0
• 16-bit absolute use R0
• Byte addressable with 64-bit addresses
• Big-endian or little-endian
• Alignment required

13
MIPS Instructions

• Three instruction formats

14
MIPS Operations

• Load-store
• ALU operations
• Add, subtract, multiply, divide, and, or, xor,
  LUI (load upper immediate), shifts
• Control transfer
• Set conditions
• Branch (reg0, reg?0, reg1reg2, reg1?reg2),
  jump, jump-and-link (call)
• Conditional move
• Floating point
• Paired single operations
• Multiply-add (DSP)

15
MIPS Instruction Usage

• Integer applications
• Load, add, branch, store, or, compare
• FP applications
• Add (int), load (int), load, multiply, add, store

Figure 2.34.
16
Another View Trimedia Media Processor

• Embedded processor for multimedia applications
• E.g. set-top boxes (decoders, etc.) and TVs
• Very different architecture
• 128 32-bit registers (FP or int)
• Partitioned (SIMD) instructions
• 2s complement and saturating arithmetic
• VLIW architecture

17
Trimedia VLIW Approach

• Compiler can group up to five instructions for
  simultaneous execution
• Must be independent
• Use NOPs if there are insufficient independent
  instructions
• Large program size
• Trimedia uses memory compression
• Programs are 2-3 times larger than MIPS (even
  with compression)!

18
Fallacies and Pitfalls

• Pitfall Designing a high-level instruction set
  to support HLLs
• Seldom provide an exact match
• Often too general (VAX CALLS)

19
Fallacies and Pitfalls

• Fallacy There is such a thing as a typical
  program
• Programs vary very significantly
• Pitfall Designing an architecture to reduce code
  size without considering compilers
• Compilers have much greater impact on code size
• Start with densest compiled code

20
Fallacies and Pitfalls

• Pitfall Expecting good compiled performance for
  DSPs
• Hand-tuned assembler is faster and more compact
• Fallacy An architecture without flaws cannot be
  successful
• 80x86!
• Segments, accumulators, stack-based FP

21
Fallacies and Pitfalls

• Fallacy You can design a flawless architecture
• All designs have trade-offs
• VAX code size more important than easy decoding
• Early RISCs delayed branches
• Address space

22
2.15. Concluding Remarks

• 1960s Stack architectures
• Matched the compiler technology of the day
• 1970s CISC era
• Tried to support HLL features in hardware
• Today RISC era
• Simple, load-store architectures

23
Concluding Remarks

• Trends in the 1990s
• Move to 64 bits
• Conditional instructions
• Eliminating branches
• Optimisation of cache access (prefetch
  instructions)
• Support for multimedia
• Faster floating point

24
The Future

• Trend towards VLIW architectures
• Increased use of conditional execution
• Blending of general-purpose and DSP architectures
• Emulating 80x86 architecture
