Chapter 5 Generic Programming

1
Chapter 5Generic Programming

• CS 260 Data Structures
• Indiana University Purdue University Fort Wayne

2
Generic Programming

• Chapter objectives
• What generic programming is
• Javas Object type and casting
• Wrapper classes
• Generic methods
• Generic classes
• Develop generic ArrayBag class
• Conversion of collection class to generic
  collection class
• Review the Java interface
• Develop a generalized iterator class

3
Generic Programming

• Instead of developing a separate collection class
  for each kind of element, it is advantageous to
  design a collection class for any kind of element
• Imagine the need for various kinds of bag classes
• IntArrayBag
• DoubleArrayBag
• StringArrayBag
• Etc.
• To work with a new kind of element, it is
  necessary to rewrite a bag class for the new kind
  of data

4
Generic Programming

• It would be better to write a bag class once and
  include a parameter that would establish the type
  of element at the time of instantiation
• We will see how to do this a little later using
  Java
• J2SE 5.0 has new features for implementing
  generic classes

5
Javas Object type

• Class String is a subclass of class Object
• A String object s is also an Object
• However, an Object obj may or may not be a String

Object

Throttle
Vector
String

Stack
6
Java casting
String s new String( Message ) Object
obj obj s // This is a widening conversion
(automatic in Java) s obj //
Compiler error s (String) obj
// This is a narrowing conversion

• A narrowing conversion requires an explicit
  typecast
• The narrowing conversion produces a runtime error
  if obj does not refer to a String object
• The compiler takes the programmers word for the
  validity of the explicit typecast
• The virtual machine checks the validity

7
Wrapper classes

• How can we have Object obj refer to a primitive
  value?
• Answer Use a wrapper class

int i 7 // i is a primitive
value Integer w new Integer( i ) //
Integer is the int wrapper class obj w
// Widening
conversion int j w.intValue( )
// Extracts the int value
7
anInteger
i w obj
7
8
Wrapper classes

• Wrapper classes were not convenient in earlier
  versions of Java
• The operator could not be used to combine
  objects
• To add w and w2, the following was needed
• J2SE 5.0 specifies automatic boxing and
  unboxing
• Automatic conversion between primitive and
  wrapper values
• The following now compile and execute properly

Integer w2 new Integer( 3 ) // Another int
wrapper w w w2
// Caused a compiler error
w new Integer( w.intValue() w2.intValue() )
Integer w 7 w w w2 int i w
9
Object methods and generic methods

• Consider the following method that returns an
  element from near the middle of the array
  parameter
• We would have to rewrite this method to work with
  an array of doubles or and array of characters

static Integer middle( Integer data ) if (
data.length 0 ) return null else
return data data.length/2
10
Object method example

• One possible solution
• However, certain programming errors cannot be
  caught at compile time
• If a is an array of Integer, then the compiler
  wont catch the following error

static Object middle( Object data ) if (
data.length 0 ) return null else
return data data.length/2
Character c (Character) middle( a ) -- this
does generate a runtime ClassCastException
11
Generic method example

• It is better to use the following generic method
• Here ltTgt represents a generic type parameter
• Generic type parameters always appear in angle
  brackets ltgt right before the return type in the
  header
• By convention, generic type parameters should be
  just a single capital letter

static ltTgt T middle( T data ) if (
data.length 0 ) return null else
return data data.length/2
12
Generic method example

• Note how the method header indicates to the
  compiler that the return type in this case is
  identical to the type of data in the array
  parameter
• Now, if c is a Character variable and a is an
  array of Integer, the compiler determines that
  the return type must be Character and detects the
  error
• Note No explicit casting to Character is needed

static ltTgt T middle( T data )
c middle( a )
c (Character) middle( a )
13
Generic method example

• Generic methods may have any number of generic
  parameters
• Restrictions
• The generic data type inferred by the compiler
  must never be one of the primitive types
• Cannot call a constructor for a generic type
• May not create a new array of elements of the
  generic type

static ltS,T,Ugt T myMethod( S a, U target )
14
Generic classes

• Generic classes also involve generic type
  parameters
• As with generic methods, generic classes also
  refer to one or more underlying but unspecified
  data types
• The angle brackets must appear immediately after
  the class name

public class ArrayBagltEgt implements Cloneable
private E data private int
manyItems ???
15
Generic classes

• An application using a generic class must
  instantiate the class with an actual type
  substituted for the generic type parameter
• Then instance methods may be called as usual
• Automatic boxing and unboxing works as usual in
  the case of myIntBag

ArrayBagltIntegergt myIntBag new
ArrayBagltIntegergt() ArrayBagltStringgt myStringBag
new ArrayBagltStringgt()
myIntBag.add( 123 ) myStringBag.add( This is a
test )
16
Generic classes

• Generic classes provide the same compile-time
  type checking advantages as to generic methods
• Restrictions
• Types used for instantiation must not be any of
  the eight primitive types
• A constructor for the generic type may not be
  called
• Cannot create a new array of elements of the
  generic type

17
ArrayBag implementation issues

• See pp. 260-268 for a complete implementation of
  the generic ArrayBag class
• To overcome the restriction on no new array of
  E-type objects, typecasting is used in the
  constructor

public ArrayBag() final int
INITIAL_CAPACITY 10 manyItems 0
data (E ) new Object INITIAL_CAPACITY
18
ArrayBag implementation issues

• When ArrayBag instance methods involve ArrayBag
  parameters or an ArrayBag return type, specify
  the data type as ArrayBagltEgt
• This prevents a bag of elements of one type to be
  added to a bag of elements of a different type

public void addAll( ArrayBagltEgt addend ) ???
19
ArrayBag implementation issues

• When a generic collection tests ltEgt type elements
  for equality, it should use an equals method
  rather than the operator
• All classes that are part of Java have equals
  methods
• Including wrapper classes
• Set unused pointers to null
• For example, this should be done in the remove
  method
• Then garbage collection can recycle unused storage

20
Conversion of a collection class to a generic
class

• See pp. 258 259 for eight steps for converting
  a non-generic class to a generic class
• Update the name of the class by adding ltEgt
• Find all places where the type of the underlying
  element should be changed to E
• Change any static methods to generic static
  methods
• Dont create new E objects or arrays
• Replace any primitive equality test or !
  by calls to equals
• Decide if null is ever allowed as an element
• If so, then equals( ) cannot be applied to null
  elements
• Set unused reference variables to null
• Update all documentation

21
Implementing a generic Node class
public class NodeltEgt // private E
data private NodeltEgt link //
public Node( E initialData, NodeltEgt initialLink )
data initialData link
initialLink public void addNodeAftert(
E element ) link new NodeltEgt(
element, link )

• For more details, see Appendix E, pp. 764 - 771

22
Java interfaces

• Recall that Java defines interfaces
• An interface . . .
• is a list of related methods that may represent
  some standard behavior to included as part of a
  new class
• requires that the methods specified by the
  interface be implemented by any class that
  implements the interface
• Standard interfaces are well known
• If you know that a certain class implements a
  standard interface, then you can rely on the
  specified methods being available
• Format

public class MyClass implements SomeInterface

23
Generic interfaces

• A generic interface is like an ordinary
  interface, except the methods depend on one or
  more unspecified classes
• Example the IteratorltEgt generic interface
• Java 5.0 defines a generic interface called
  IteratorltEgt that depends on an unspecified class
  E
• Any class that implements the IteratorltEgt
  interface must be a generic class with its own
  generic type parameter E

24
Behavior of the IteratorltEgt interface

• Behavior of IteratorltEgt
• public boolean hasNext( )
• public E next( )
• public void remove( )
• Any class implementing the Iterator interface
  must implement these methods
• These methods are what are needed to iterate over
  a collection of E-type objects

25
The Lister class

• We develop a generalized iterator class named
  Lister
• Lister will implement the IteratorltEgt interface
• Objects of type Lister will be external iterators
  that iterate over collections built with linked
  lists
• An external iterator maintains its own copy of
  the cursor
• The constructor initializes Lister instance
  variable current to the head of a linked list
• The collection itself doesnt need a cursor
  variable

26
The Lister class

• An external iterator allows multiple iterations
  to occur over some collection object
  simultaneously
• Perhaps you have nested loops
• Each loop needs to separately iterate over the
  collection
• Just define as many iterator objects as you need
• The Lister class we will develop works with
  generic linked lists built out of generic Nodes

27
The Lister class

• ADT invariant of the Lister class
• The instance variable current is the head
  reference for the linked list that
• contains the elements that have not yet been
  provided by the next method
• If there are no more elements to provide, then
  current is the null reference

import java.util.Iterator import
java.util.NoSuchElementException public class
ListerltEgt implements IteratorltEgt //
private NodeltEgt current // current is a
cursor for the linked list of a collection
// public Lister( NodeltEgt head )
current head public boolean hasNext(
) return ( current ! null )

28
The Lister class
// Returns the next element and advances the
cursor to the subsequent element public E
next( ) E answer if ( ! hasNext( )
) throw new NoSuchElementException( "The
Lister is empty ) answer
current.getData( ) current
current.getLink( ) return answer
// // We dont want the remove method, but we
have to implement something public void
remove( ) throw new UnsupportedOperationEx
ception( "Lister has no remove method )
// end class Iterator
29
Using the Lister class

• We still need to tie the Lister instance variable
  current to a node in the linked list
• Suppose we have a generic LinkedBagltEgt class
• Like IntLinkedBag but elements are of class E
• However, suppose LinkedBagltEgt implements the
  IteratorltEgt interface and eliminates the internal
  iterator
• We will place int values in the LinkedBag in
  wrappers
• See Appendix F in the text, pages 772 777
• A special method needs to be added to LinkedBag
  to attach the external iterator to the linked
  list within the LinkedBag
• This method is iterator( )

public ListerltEgt iterator( ) return new
ListerltEgt( head )
30
Using the Lister class

• Now we can iterate over LinkedBagltIntegergt

LinkedBagltIntegergt b new LinkedBagltIntegergt(
) ListerltIntegergt list int sum 0 b.add( new
Integer( 11 ) ) b.add( new Integer( 7 )
// Iterate over the bag and add up all the
ints list b.iterator( )
// this attaches lis to bs linked list while (
list.hasNext( ) ) sum sum list.next( )
//automatic unboxing is used
31
Using the Lister class

• Java 5.0 has an enhanced for loop that can be
  used with any class that implements the
  IterableltEgt interface

// Iterate over the bag and add up all the
ints list b.iterator( )
// this attaches lis to bs linked list for (
Integer next list ) sum sum next
//automatic unboxing is used
32
The Java CollectionltEgt interface

• Generic Java collection classes may implement the
  generic CollectionltEgt interface
• Behavior of CollectionltEgt classes
• Some Java classes implementing this interface

add equals removeAll addAll hashCode retainAll
clear isEmpty size contains iterator toArray co
ntainsAll remove
Vector Set List ArrayList SortedList HashSet
33
The Java TreeMapltK,Vgt class

• A map is a collection class in which key-value
  pairs may be added
• A pair can be retrieved or removed by specifying
  just its key
• Java has a Map interface that requires behavior
  needed by maps
• The generic TreeMapltK,Vgt class . . .
• Implements the Map interface
• Has two generic type parameters
• K for the type of keys
• V for the type of values
• The keys must come from a class that implements
  the generic ComparableltKgt interface
• This allows keys to be compared as follows
  key1.compareTo( key2 )

34
The Java TreeMapltK,Vgt class

• Some behavior of the TreeMapltK,Vgt class
• public void clear( )
• public boolean containsKey( K key )
• public V get( K key )
• public SetltKgt keySet( )
• public V put( K key, V value )
• public int size( )
