A High Step-Up DC to DC Converter Under Alternating Phase Shift Control for Fuel Cell Power System || 2015-2016 IEEE Power system Projects Training

1
A High Step-Up DC to DC Converter
UnderAlternating Phase Shift Control for Fuel
CellPower System

• Presented by
• IIS TECHNOLOGIES
• No 40, C-Block,First Floor,HIET Campus, North
  Parade Road,St.Thomas Mount, Chennai, Tamil Nadu
  600016.
• Landline044 4263 7391,mob9952077540.
• Emailinfo_at_iistechnologies.in,
• Webwww.iistechnologies.in

2
ABSTRACT

• This paper investigates a novel pulse width
  modulation (PWM) scheme for two-phase interleaved
  boost converter with voltage multiplier for fuel
  cell power system by combining alternating phase
  shift (APS) control and traditional interleaving
  PWM control.
• The APS control is used to reduce the voltage
  stress on switches in light load while the
  traditional interleaving control is used to keep
  better performance in heavy load.
• The boundary condition for swapping between APS
  and traditional interleaving PWM control is
  derived

3
CIRCUIT DIAGRAM
4
TOOLS AND SOFTWARE USED

• MP LAB
• ORCAD/PSPICE
• MATLAB/SIMULINK

5
OUTPUT

• HARDWARE
• SIMULATION

6
