Sparse Matrix Solvers on the GPU: Conjugate Gradients and Multigrid

1
Sparse Matrix Solvers on the GPU Conjugate
Gradients and Multigrid

• Jeffrey Bolz, Ian Farmer, Eitan Grinspun, Peter
  Schröder
• Caltech ASCI Center

2
Why Use the GPU?

• Semiconductor trends
• cost
• wires vs. compute
• Stanford streaming supercomputer
• Parallelism
• many functional units
• graphics is prime example
• Harvesting this power
• what application suitable?
• what abstractions useful?
• History
• massively parallel SIMD machines
• media processing

Chart courtesy Bill Dally
Imagine stream processor Bill Dally, Stanford
Connection Machine CM2 Thinking Machines
3
Contributions and Related Work

• Contributions
• numerical algorithms on GPU
• unstructured grids conjugate gradients
• regular grids multigrid
• what abstractions are needed?
• Numerical algorithms
• Goodnight et al. 2003 (MG)
• Hall et al. 2003 (cache)
• Harris et al. 2002 (FD sim.)
• Hillisland et al. 2003 (optimization)
• Krueger Westermann 2003 (NLA)
• Strzodka (PDEs)

4
Streaming Model
output record stream

• Abstract model
• Purcell, et al. 2002
• data structures streams
• algorithms kernels
• Concrete model
• render a rectangle
• data structures textures
• algorithms fragment programs

input record stream
globals
globals
5
Sparse Matrices Geometric Flow

• Ubiquitous in numerical computing
• discretization of PDEs animation
• finite elements, difference, volumes
• optimization, editing, etc., etc.
• Example here
• processing of surfaces
• Canonical non-linear problem
• mean curvature flow
• implicit time discretization
• solve sequence of SPD systems

6
Conjugate Gradients

• High level code
• inner loop
• matrix-vectormultiply
• sum-reduction
• scalar-vector MAD
• Inner product
• fragment-wise multiply
• followed by sum-reduction
• odd dimensions can be handled

7
yAx
Aj off-diagonal matrix elements
R pointers to segments
8
Row-Vector Product
X vector elements
J pointers to xj
R pointers to segments
Fragment program
Aj off-diagonal matrix elements
Ai diagonal matrix elements
9
Apply to All Pixels

• Two extremes
• one row at a time setup overhead
• all rows at once limited by worst row
• Middle ground
• organize batches of work
• How to arrange batches?
• order rows by non-zero entries
• optimal packing NP hard
• We choose fixed size rectangles
• fragment pipe is quantized
• simple experiments reveal best size
• 26 x 18 91 efficient
• wasted fragments on diagonal

10
Packing (Greedy)

9
9
8
8
8
8
8
7
7
15
13
13
7
7
7
7
7
7
7
7
6
5
5
4
12
12
11
10
9
9
non-zero entries per row
15
13
13
9
9
8
7
7
7
12
12
11
8
8
8
7
7
7
10
9
9
8
7
7
7
7
6
All this setup done once only at the beginning of
time. Depends only on mesh connectivity
11
Recomputing Matrix

• Matrix entries depend on surface
• must render into matrix
• two additional indirection textures
• previous and next

12
Results (NV30_at_500MHz)

• 37k elements
• matrix multiply
• 33 instructions, 120 per second
• only 13 flops
• latency limited
• reduction
• 7 inst/frag/pass, 3400 per second
• CG solve 20 per second

13
Regular Grids

• Poisson solver as example
• multigrid approach
• this time variables on pixel grid
• e.g. Navier-Stokes

after discretization solve Poisson eq. at each
time step
14
Poisson Equation

• Appears all over the place
• easy to discretize on regular grid
• matrix multiply isstencil application
• FD Laplace stencil
• Use iterative matrix solver
• just need application of stencil
• easy just like filtering
• incorporate geometry (Jacobian)
• variable coefficients

15
Multigrid

• Fine to coarse to fine cycle
• high freq. error removed quickly
• lower frequency error takes longer

Relax, Project, Interpolate
16
Computations and Storage Layout

• Lots of stencil applications
• matrix multiply 3x3 stencil
• projection 3x3 stencil
• interpolation 2x2(!)
• floor op in indexing
• Storage for matrices and DOFs
• variables in one texture
• matrices in 9(3x3) textures
• all textures packed
• exploit 4 channels
• domain decomp.
• padded boundary

17
Coarser Matrices

• Operator at coarser level
• needed for relaxation at all levels
• Triple matrix product
• work out terms and map to stencils
• exploit local support of stencils
• straightforward but t-e-d-i-o-u-s

18
Results (NV30_at_500MHz)

• 257x257 grid
• matrix multiply - 27 instructions
• 1370 per second
• interpolation 10 inst.
• projection 19 inst.
• Overall performance
• 257x257 at 80 fps!

19
Conclusions

• Enhancements
• global registers for reductions
• texture fetch with offset
• rectangular texture border
• scalar versus vector problems
• Where are we now?
• good streaming processor
• twice as fast as CPU implementation
• lots of room for improvement
• Scientific computing compiler
• better languages! Brook? C?
• manage layout in a buffer
