9 Tips to Consider when Buying Selective Soldering Machine China

1
Presented by sasinno
2
9 Tips to Consider when Buying Selective
Soldering Machine China
There are several benefits from investing in this
type of machine, there are also several
considerations to make before purchasing. In this
post, we will look at nine points that require
further thought to make sure you select the right
selective soldering machine for your products.
3
SIZE
What PCB sizes do you need to process? Along with
a single PCB, you also need to consider whether
it will be in a panel of two or more to make
production more cost-effective and efficient.
FLOOR SPACE
How much floor space do you have available?
Selective soldering machines China can vary from
1 meter to several meters long, depending on the
configuration of the machine.
4
MACHINE MAINTENANCE
Selective soldering machines come with fairly low
maintenance. However, if you wish the machines to
run automatically for a complete production shift
without any human intervention, then this might
be a consideration.
SOLDER POTS
How many solder pots do you require? For example,
you might require the machine to have both
lead-free and leaded solder available, to reduce
changeover times between jobs.
5
SOLDER NOZZLES
What size and type of solder nozzle you might
require? While these are fast and easy to change
over, restricting the number of options here will
increase throughput and cost.
FLUX
PRE-HEATING
A typical system may provide bottom and top
heating of the PCB before soldering and after
fluxing. Depending on the PCB assembly, you might
need to consider further heating at a later
stage.
Machines usually offer fluxing at the beginning
of the process. If it is a long soldering
process, you might need to consider fluxing again
at the later stage.
6
PCB ASSEMBLY HANDLING
Machines can be loaded and unloaded manually, or
designed to be in-line. For longer, automated
runs adding board stackers at the input and
output stages might be efficient.
CONFIGURATION
Do you want to change the machines configuration
in future? For example, do you want to add
further solder stations, fluxing, or pre-heating?
If so, a modular system might be more efficient
than an all-in-one solution.
