Selective Soldering Machine Manufacture: The Aspects To Consider

1
Selective Soldering Machine Manufacture The
Aspects To Consider
2
Selective Soldering Machine Manufacture The
Aspects To Consider!

1. Size

2. Floor space
The very first one is related with the size of
the printed board circuit. You have to decide the
size that is needed for processing. If it is with
the single PCB, then you must consider whether it
will need to be in a panel of two or more.
The next thing to consider is the floor space.
You must check the availability. You must know
that some selective soldering machines can vary
from about one metre to several metres long
according to their configuration.
sasinno.com
3
3. Machine maintenance
The machine maintenance is also another important
aspect. These machines can be relatively low
maintenance, but if, you want to modify them in
any way or make them run automatically for a
whole production shift with no human
intervention, then you must consider the relative
factors.
4. Solder pots
You must check how many solder pots will be
needed. Also, you might also need to set the
machine up to have both leaded and lead-free
solder available. This can minimize the
changeover times between jobs.
sasinno.com
4
5. Solder nozzles
The type and the size of the solder nozzle should
also be considered. While one can change them
quickly and easily, limiting the options here
will improve throughput and cost.
6. Nitrogen supply
The process of selective soldering will require
nitrogen with a high level of purity. Depending
on the hours that the machine will be used, you
must think about the supply of nitrogen and keep
the back-up handy.
sasinno.com
5
8. Pre-heating
7. Flux
Lastly, a typical but competent system will
provide you top and bottom heating of the PCB
both before and after fluxing. But it also
depends on the PCB assembly one might have to
consider further heating later.
Most of the systems will typically offer fluxing
at the start of the process however, if it's a
long soldering process then you might need to
consider fluxing again but at the later stage.
If you want a perfect and competent soldering
system where you can get all these facilities
then just visit us at sasinno.com your most
trusted selective soldering machine manufacturer.
With more than 10 years soldering process
experience, we understand your requirement.
