AIRCRAFT MAINTENANCE

1
AIRCRAFT MAINTENANCE
Section 5

• Documentation and Certification for Aircraft
  Maintenance

2
Documentation Standard
ATA Specification 100 (early digital data
specifications included)
Creation of ATA Specification 2100 (ATA 100
appendix deleted)
Evaluation started on merger with S1000D
specification
lt 1989
1989 - 1993
1994 - 1999
2000
2005
Digital Data Specifications (incl. SGML) become
Appendix of ATA 100

• Creation of ATA Specification 2200 (iSpec 2200)
  based on
• ATA 100
• ATA 2100

3
Documentation Standard
4
Documentation Standard ATA

• ATA Spec 100
• Air Transport Association of America (ATA)
  standardized the overall format of the
  maintenance manuals
• Each system or system type was assigned a chapter
  number. For example,
• - Hydraulic systems are in ATA Chapter 29
• - Radio equipment is ATA Chapter 23.

5
ATA Spec 100

• Format
• 52 11 02 401
• Example
• 52 Doors
• 52-11 Passenger Doors
• 52-11-02 Passenger Door Handle
• 52-11-02-401 R/l Procedure for Pax Door Handles

6
ATA Specification 100

• GROUP STRUCTURE
• 51 STRUCTURES52 DOORS53 FUSELAGE54 NACELLES /
  PYLONS55 STABILIZERS56 WINDOWS57 WINGS
• GROUP PROPELLER / ROTOR
• 60 STD.PRACTICES - PROP / ROTOR61 PROPELLERS
• GROUP POWER PLANT
• 70 STANDARD PRACTICES ENGINE71 POWER PLANT -
  GENERAL72 ENGINE73 ENGINE FUEL and CONTROL74
  IGNITION75 AIR76 ENGINE CONTROLS77 ENGINE
  INDICATING78 EXHAUST79 OIL80 STARTING81
  TURBINES82 WATER INJECTION83 ACCESSORY GEAR
  BOXES
• 91 CHARTS

• AIRFRAME GENERAL
• 05 TIME LIMITS MAINTENANCE CHECKS06 DIMENSIONS
  and AREAS07 LIFTING and SHORING08 LEVELING and
  WEIGHTING09 TOWING and TAXIING10 PARKING and
  MOORING11 PLACARDS12 SERVICING
• AIRFRAME SYSTEMS
• 20 STANDARD PRACTICES AIRFRAME21 AIR
  CONDITIONING22 AUTOPILOT23 COMMUNICATIONS24
  ELECTRIC POWER25 EQUIPMENT and FURNISHINGS26
  FIRE PROTECTION27 FLIGHT CONTROLS28 FUEL29
  HYDRAULIC POWER30 ICE and RAIN PROTECTION31
  INSTRUMENTS32 LANDING GEAR33 LIGHTS34
  NAVIGATION35 OXYGEN36 PNEUMATIC37 VACUUM38
  WATER / WASTE49 AIRBORNE AUXILIARY POWER

7
ATA Spec 100
8
Documentation for Aircraft Maintenance

• Manufacturers Documentation

9
Manufacturers Documentation

• Airplane maintenance manual AMM
• Storage and recovery documents SRD
• Fault isolation manual FIM
• Schematic diagram manual SDM
• Task cards TC
• Wiring diagram manual WDM
• Illustrated parts catalogs IPC
• Fault reporting manual FRM
• Component maintenance manual CMM
• Vendor manuals VM
• Structural repair manual SRM
• Maintenance planning data document MPD
• Master minimum equipment list MMEL
• Dispatch deviation guide DDG
• Configuration deviation list CDL
• Service bulletins SBs
• Service letters SLs
• Maintenance tips MT

Customized to Contain Customer Configuration
10
Manufacturers Documentation

• Aircraft Maintenance
• AMM Aircraft Maintenance Manual
• FIM Fault Isolation manual / TSM Trouble
  Shooting Manual
• SDM Schematic diagram manual / ASM Aircraft
  Schematic Manual

11
Manufacturers Documentation

• AMM Aircraft Maintenance Manual
• Basic information on the operation and
  maintenance of the aircraft and its on-board
  equipment.
• Description and operation of each system
• Basic maintenance and servicing actions
• Functional tests and operational tests
• Adjustments
• Replenishing of various fluids
• Other servicing tasks

12
Manufacturers DocumentationAircraft Maintenance

• AMM Aircraft Maintenance Manual (Sample)

13
Manufacturers DocumentationAircraft Maintenance

• AMM Aircraft Maintenance Manual (Sample)

14
Manufacturers DocumentationAircraft Maintenance
FIM Fault Isolation manual / TSM Trouble
Shooting Manual Fault isolation trees for
the purpose of pinpointing and fixing problems
15
Manufacturers DocumentationAircraft Maintenance

• SDM Schematic diagram manual /
• ASM Aircraft Schematic Manual
• Schematic diagrams of electrical, electronic,
  and hydraulic systems on the aircraft as well as
  logic diagrams contains the detailed information
  and identifies wiring harnesses, connectors, and
  interfacing equipment.

16
Manufacturers DocumentationAircraft Maintenance

• SDM Schematic diagram manual /
• ASM Aircraft Schematic Manual

17

Manufacturers Documentation Engineering

• To develop Aircraft changes and to assist in
  trouble shooting / Repairs
• AWM (Aircraft Wiring Manual)
• AWL (Aircraft Wiring List)
• ELA (Electrical Load Analysis)
• SB (Service Bulletins)
• SL (Service Letters)
• MT (Maintenance Tip)
• SRM (Structural Repair Manual)
• WBM (Weight and Balance Manual)
• To prepare maintenance, To plan maintenance
• TEM Tool Equipment Manual
• MPD Maintenance Planning

18
Manufacturers DocumentationEngineering

• WDM Wiring diagram manual /
• AWM Aircraft Wiring Manual

• Complete run of wiring, including cable bundle
  numbers and routing, plug and connector numbers
  and locations, bulkheads, and other structural
  elements through which the wiring is routed

19
Manufacturers DocumentationEngineering

• SRM Structural Repair Manual

• Information needed to effect certain repairs of
  the aircraft structure.
• Repairs are simple and are approved by the FAA
  for operator completion.
• Other structural repairs must be done by the
  airframe manufacturer or some other FAA
  designated repair facility.

20
Manufacturers DocumentationEngineering/Planning

• MPD Maintenance Planning

• List of maintenance and servicing tasks to be
  performed on the aircraft.
• All items of the MRB report along with other
  information.
• Certification maintenance requirements (CMRs)
• Tasks, which were developed by the MSG process

21
Manufacturers Documentation Maintenance/Planning
/Stores

• To provision and identify spare parts
• IPC Illustrated parts Catalog

• Lists and location diagrams of all parts used on
  the aircraft model.
• Information on part numbers, vendors,
  interchangeability of parts

22
Manufacturers DocumentationOperations

• To operate in cockpit/cabin, To prepare the
  flight
• MMEL Master Minimum Equipment List
• CDL Configuration deviation list
• DDG Dispatch deviation guide

23

Manufacturers DocumentationOperations

• MMEL Master Minimum Equipment List

• Identified by the airframe manufacturer and
  approved by the FAA
• Identify the equipment which may be degraded or
  inoperative at dispatch of the aircraft.
• Airline's responsibility to develop their own
  manual tailored to their specific equipment. (MEL)

24
Manufacturers DocumentationOperations

• CDL Configuration deviation list
• DDG Dispatch deviation guide

Involves configuration of the aircraft
Information on panels, fairings, and similar
variations in configuration that can be
nonstandard at dispatch as long as it does not
affect the safety of flight.
To secure the aircraft and the system against
inadvertent operation when some of the MMEL items
are inoperative or degraded at dispatch require
actions
25
Manufacturers Documentation Maintenance/Engineer
ing/Planning

• Whenever the airframe manufacturer or the engine
  manufacturer have modifications or suggestions
  for improving maintenance and/or servicing, they
  will issue appropriate paperwork to the affected
  airlines.
• SB Service Bulletins
• SL Service Letter
• MT Maintenance Tip

A service bulletin (SB) is usually a modification
of a system that will provide improved safety or
operation of a system and includes a detailed
description of the work and parts required.
A service letter (SL) usually provides
information to improve maintenance actions
without equipment modification.
The maintenance tip is a suggestion for
maintenance personnel to assist in their work or
improve conditions.
26
FAAs Documentations
27
FAAs Documentations

• Federal aviation regulations FARs
• Advisory circulars ACs
• Airworthiness directives ADs
• Notice of proposed rule making NPRM

28
Authoritys Documentation

• FAR Federal aviation regulations
• FAR part 121 (14 CFR 121)/JAR 121 regulations
  relating to certification and operation of large,
  commercial aircraft
• FAR / JAR part 145 Maintenance Station
• FAR/JAR part 147 Formation Center of
  Maintenance Staff
• JAR part 66 Certifying Staff

29
FAAs Documentations

• Advisory circulars (ACs)
• An advisory circular is a document issued by the
  FAA to provide assistance to operators on meeting
  the requirements of various FARs.

30
FAAs Documentations

• Airworthiness Directives (ADs)
• Issued by the FAA (Design Authority) to correct
  an unsafe condition that exists in a product
  (aircraft, aircraft engine, propeller, or
  appliance) and a condition that is likely to
  exist or develop in other, similar products.
• An AD, whose incorporation is mandatory, may be
  issued initially by the FAA or may be an action
  after the airframe manufacturer has issued a
  service bulletin (SB)
• AD will include
• (a) a description of the unsafe condition
• (b) the product to which the AD applies
• (c) the corrective action required
• (d) date of compliance
• (e) where to get additional information
• (f) information on alternative methods of
  compliance if applicable.

31
FAAAir Operators Documentation

• Air Operators Documentation

32
FAAAir Operators Documentation

• Operations specifications Ops Specs
• Technical policies and procedures manual TPPM
• Inspection manual IM
• Reliability program manual RPM
• Minimum equipment list MEL
• Task cards TC
• Engineering orders EOs

33
FAAAir Operators Documentation

• Operations specifications
• Written by the airline in accordance with strict
  FAA requirements and usually with the help of an
  FAA representative.
• Refers to numerous other documents to avoid
  duplication and details the airline's
  maintenance, inspection, and operations programs.
• Technical policies and procedures manual
• Primary document for the airline's ME operation
  and, with other documents supplied by the
  airframe manufacturer, serves as the FAA
  requirement for a maintenance manual per AC
  120-16D.
• Usually written by engineering, to ensure
  technical accuracy, from inputs supplied by
  management of the various ME organizations.
• Define exactly how all ME functions and
  activities will be carried out.

The TPPM is sometimes called the policies and
procedures manual (PPM), general maintenance
manual (GMM), or the maintenance organization
exposition (MOE)
34
Air Operators Documentation

• IM Inspection manual
• May be a separate document distributed primarily
  to QC personnel, or it can be a chapter in the
  TPPM (usual approach).
• Relate to all inspection activities within ME
• (a) mechanic inspection tasks from the MPD or the
  MRB report
• (b) QC inspector's tasks
• (c) special inspections (hard landings, bird
  strikes, etc.)
• (d) the airline's Required Inspection Item (RII)
  program
• (e) the paperwork, forms, and reports required to
  carry out these functions.

35
FAAAir Operators Documentation

• RPM Reliability program manual
• Airline's reliability program must be approved by
  the regulatory authority
• Minimum equipment list (MEL)
• Customize the MMEL for the operator particular
  airframe/engine configuration.
• The operator must carry copies of this MEL in
  each aircraft for flight crew reference.
• The applicable items in the DDG and the CDL
  should also be included with the MEL.
• Task cards
• To avoid unnecessary duplication of certain
  actions, and the unnecessary opening and closing
  of the same panels, then the operator write their
  own task cards to spell out exactly what to do
• Engineering orders (EO)
• Official paper work, issued by engineering and
  approved by QA
• Some airlines called simply a "Work Order."

36
What are some examples of RIIs?

• RII examples
• a. Installation, rigging, and adjustments of
  flight controls and surfaces.
• b. Installation and repair of major airframe or
  engine structural components.
• c. Installation of an aircraft engine,
  propeller, propeller blade, or rotor.
• d . Installation, repair, and calibration of
  certain avionics and navigational equipment.

37
Air Operators Documentation

• - What is an Air Operator ?
• Air operator or Aircraft operator means any
  person which provides the service of transport of
  goods or passengers by aircraft
• - What is an Air Operator Certificate?
• A Certificate authorizing as operator to carry
  out specified air transport operation.

38
AIR OPERATOR CERTIFICATION
39
Air Operators Documentation

• THE AIR OPERATOR CERTIFICATE - ICAO ANNEX 6,
• 4.2.1.1 An operator shall not engage in
  commercial air transport operations unless in
  possession of a valid air operator certificate or
  equivalent document issued by the State of the
  Operator.
• 4.2.1.2 The air operator certificate. shall
  authorize the operator to conduct commercial air
  transport operations in accordance with such
  conditions and limitations as may be specified.

40
FAAAir Operators Documentation

• 4.2.1.3 The issue of an AOC .by the State of
  the Operator shall be dependent upon the operator
  demonstrating an adequate organization, method of
  control and supervision of flight operations,
  training programme and maintenance arrangements
  consistent with the nature and extent of the
  operations specified

41
AOC-USA
42
AOC-UK
43
AOC-THAI
44
internationalAir Operators Documentation

• Air Operator Certificate-procedure
• The procedure for application and granting of an
  AOC is best organized in phases and will normally
  take following sequence
• 1. Pre-application phase
• 2. Formal application phase
• 3. Document evaluation phase
• 4. Demonstration and inspection phase
• 5. Certification phase
• (Reference ICAO Doc 8335-AN/879)

45
Air Operators Documentation

• ????????????????????????????????????
  ????????????????? 3 ??????????????
  ??????????????????????????????????????????????
  ??????????
• 1. ????????????????????????????????????????
  (????????) ???? ????????????????????????????????
  ???? ????????? (Airliner)
• 2. ???????????????????????????????????????????
  (???????????) ???????????????????????????????????
  ? ????????????? (Air Charter ???? Air Taxi)
• 3. ???????????????????????????????????????????
  (?????? ????????????) ????????????????????????????
  ??????????????????????? ??????????????????

46
Air Operation License ????????????????????????
????????????????
47
ThaiAir Operators Documentation

• ????????????????????? (AOC Manuals)
• ??????????????????? (Flight Operation Manual -
  FOM)
• ?????????????????? (Aircraft Flight Manual - AFM)
• ?????????????????????????????? (Flight Attendant
  Manual)
• ???????????????????????? (Flight Operation
  Officer or Dispatcher)
• ???????????????????????????????? (Minimum
  Equipment List MEL)
• ??????????????????? (Route Manual)
• ????????????? (Training Manual)
• ?????????????????? (Dangerous Good Manual DGM)
• ??????????????????????????????? (Emergency
  Manual)

48
ThaiAir Operators Documentation

• ????????????????????? (Quality Assurance Manual
  QAM)
• ???????????????????????????????????????? (Safety
  Management System Manual - SMS)
• ???????????????????????????? (Security Program
  Manual SPM)
• ??????????????????????? ???????? (Weight and
  Balance Manual WBM)
• ?????????????????????? (Ground Handling Manual
  GHM)
• ???????????????????????? (General Maintenance
  Manual GMM)
• ???????????????????????????? (Maintenance Program
  or Maintenance Schedule - MPD)

49
AirOperatorCertificate ?????????????????????
????????
50
Operations Specifications (Ops. Spec.)
51
Certificate of Registration???????????????????
(????????)
52
Documentation for Aircraft Registration?????????
?????????????????

• - ?????????????????????????? ???????????????????
• - ?????????????????????????????????
  ???????????????????
• - ????????????????????????????????????????????
  (De-registration)
• - ???????????????????????????????????? (Export
  Certificate of Airworthiness)

53
Certificate of Airworthiness?????????????????
????
54
Documentation for Aircraft Airworthiness
Certificate????????????????????????????????

• - ?????????????????? ???????????????????????????
• (Type Certificate and Type Certificate Data
  Sheet)
• - ??????????????????????????????????????
• (Previous Certificate of Airworthiness)
• - ?????? ???????????????????????????????????????
  ??????
• (?) ???????????? (Aircraft Flight Manual -
  AFM)
• (?) ??????????????????????? (Aircraft
  Maintenance Manual - AMM)
• (?) ????????????????? (Overhaul Manual)

55
Documentation for Aircraft Airworthiness
Certificate????????????????????????????????

• (?) ??????????????????????????????????????
  (Illustrated Part Manual - IPM/IPC)
• (?) ?????????????? (Flight Operation Manual -
  FOM)
• (?) ????????????????????? (Wiring Diagrams
  Manual - WDM)
• (?) ????????????????? ???????? (Weight and
  Balance Manual)
• (?) ????????????????? (Service Bulletin)
• (?) ???????????????????? (Maintenance Planning
  Data Maintenance Review Board Report
  MPD/MRB)
• (?) ???????????????????????????????????
  (Master Minimum Equipment List - MMEL)

56
Documentation for Aircraft Airworthiness
Certificate????????????????????????????????

• 3.6 ?????????????????????????????? (Weight and
  Balance Report)
• 3.7 ?????????????????????????? (Compass Swing
  Data)
• 3.8 ?????????????????????????????????????????????
  ????????????????? ??? (Export Certificate of
  Airworthiness)
• 3.9 ?????????????????????? ?????????????????
  (Aircraft Data) ??????????? (Engine Data) ?????
  (Propeller Data) ??????????? ?????????????????????
  ????? (Auxiliary Power Unit Data) (?????)
  ??????????????? ???????? (Component Data)

57
Documentation for Aircraft Airworthiness
Certificate????????????????????????????????

• 3.10 ???????????????????????????????????????????
  ???? (Aircraft History Logbook) ???????????
  (Engine History Logbooks) ????? (Propeller
  History Logbooks) ????????????????? ??????????????
  ?????? (?????) (Auxiliary Power Unit History
  Logbook)
• 3.11 ???????????????????????????????????????????
  ?????????????????? ???????? (Insurance
  Certificate)
• 3.12 ???????????????????????????????????????????

• ___________

58
Insurance
59
Radio Station License
60
(No Transcript)
