THERMOSTATIC MIXING VALVES

1
THERMOSTATIC MIXING VALVES

• A Division of the Reliance Worldwide Corporation

2
Water Temperature Control

• Reasons for the code change
• Product Development
• Cash Acme Heatguard Products
• Features and Benefits
• Troubleshooting
• Certifications and Standards

3
WHY WE NEED TEMPERATURE CONTROL
4
Injury caused by sudden temperature changes

• Sudden changes in temperature can lead to falls
• The elderly and those with limited mobility are
  at greatest risk
• 49C 5 minutes
• 54C 30 seconds
• 60C 1 second
• Working on graph w/ Celsius

5
SCALDING FACTS Bureau of Consumer Protection -
USA 5,000 Scalds/Year 100 Deaths/Year Cost
2.3 Billion in Hospitalization Mostly Children
- 4th Largest Cause of Hospitalization -
Least Recognized Elderly - Reduced
Sensitivity/Mobility - Thermal Shock
Accidents Trauma Long Painful Recovery (skin
grafts) Large Portion of Body Serious
Accidents/Death Lawsuits
6
LEGIONAIRE DISEASE -DISCOVERED 1976 Philadelphi
a Legionnaires Convention Pontiac Fever
Michigan 1968 -ORGANISM Legionella
Pneumophilia -RESERVOIRS WATER PH / Nutrients
/ Micro biota Present In The
Environment -AMPLIFIERS Condensers /
Humidifiers Water Heaters A/C
Units Cooling Towers All with Stagnant
Tepid Water -AIRBORNE THROUGH WATER
PARTICLES INFECTION FIGHTING CELLS IN THE
LUNGS -CENTER FOR DISEASE CONTROL ATLANTA
ESTIMATES 10,000 TO 15,000 CASES / YEAR 5 TO
10 FATAL!!!!
7
PREVENTION Remove Sediment Accumulation Avoid
Dead Legs Cold Water Below 25C Hot Water
Above 60C
Recommendations by ASHRAE / ASPE / AWT
8
Canadian Plumbing Code - AmendmentHot Water
Temperature

• 2.10.7 Maximum Temperature of Hot Water
• (1) Except as provided in Sentence (2), the
  maximum temperature of hot water supplied by
  fittings to fixtures in residential occupancy
  shall not exceed 49ºC.
• (2) Sentence (1) does not apply to hot water
  supplied to installed dishwashers or clothes
  washers.

9
Canadian Plumbing Code - AmendmentHot Water
Temperature

• How to comply
• Fit a master thermostatic mixing valve at the
  water heater to distribute at 49ºC throughout the
  whole house, or
• Fit a mixing valve at each outlet.
• Note Recommend always fit an automatic
  compensating shower valve at each shower fixture.

10
Product OriginBI METALLIC

• Electrolysis
• Scaling
• Corrosion
• Metal Fatigue
• Memory Loss
• Low Reliability

11
BELLOWS TYPE

• Liquid Filled Bellows
• Remote probe
• Complex
• Initial high cost
• High Maintenance
• Primarily Industrial control

12
ENCAPSULATED WAX TECHNOLOGY

• Simple
• Accurate
• Reliable
• Inexpensive
• Optimum means of water temperature control

13
APPLICATIONS

• -Automotive
• -N.A.S.A.
• -Industrial
• -Heating
• -Domestic Water
• Residential / Commercial / Institutional

14
How does a Cash Acme Thermostatic Mixing
Valve work?
15
Thermostatic Mixing Valve
16
(No Transcript)
17
Principle of Operation

• Designed to mix hot/cold water supplies and
  deliver water at a safe temperature.
• Controlled by an integrated thermostatic element
  that senses the inlet water temperature and adds
  cold water accordingly.
• Heatguard valves also offer a shutdown in case
  of cold water failure.

18
Applications

• Distribution (HG 110, 115) Allows water to be
  stored at a sterilizing temperature and delivered
  at a safe temperature.
• Point-Of-Use (HG 145, 160) Can be used in either
  large distribution systems or directly at the
  hand lavatory, bath, or other direct fixture.

19
Markets

• Heating Accurate, inexpensive valves for
  hydronic heating. High flow rates, low pressure
  loss, wide temperature range.
• Domestic/Potable Water Aid in the prevention of
  scalding and Legionnaires Disease. Heatguard
  TMVs distribute safe, tempered water to the
  outlet while providing washing machines and
  dishwashers with water at a higher temperature.

20
Valve Location

• The most common installation site is directly at
  the water heater.
• - less costly, protects entire system, easily
  serviced
• A valve may also be installed directly at the
  fixture, namely the HG 145 and 160 TMVs.
• - may be best solution to protecting individual
  fixtures
• Installation must follow local codes and
  requirements.

21
Valve Location Direct Installation
22
Valve Location Single Fixture
23
Servicing

• Valve function can easily be checked by measuring
  the water temperature at the outlet nearest to
  the valve.
• - If the temperature is the same as originally
  commissioned, the valve is working fine
• - If the temperature is different, it may
  be because of debris buildup. Disassemble and
  clean the valve.

24
Cash Acme Recommendation

• The installation of a Cash Acme Thermostatic
  Mixing Valve should comply with the local Codes,
  Standards, and Safe Practices.
• Our valves are certified under the applicable
  Industry Standards, and meet or exceed
  performance guidelines.

25
Heatguard General Features

• Optional Integral check valves
• Dummy valves
• High flow rates
• Low pressure drop
• Anti scaling piston
• Pressure imbalance stability
• Dual mixing diverting
• Dummy installation valve
• Total package
• Distribution ASSE 1017
• Point of Use ASSE 1016
• End of Line ASSE 1062

26
Heatguard General Features

• Superior reliability
• Absolute temperature stability
• Robust low complexity construction
• Easily serviced
• Over 30 years of experience and 2 million valves
  sold annually

27
Heatguard 110-D

• Temperature Actuated Mixing Valve
• For domestic hot water distribution systems

28
Heatguard 110-D

• Temperature range of 35C - 49C
• Delivers water at a max temp. of 49C while
  allowing the water heater to be set at 60C or
  higher
• Listed by IAPMO (cUPC) and ASSE 1017

29
Heatguard 110-D Flow Rate
30
Heatguard 115-D

• Temperature Actuated Mixing Valve
• Larger valve with higher flow rates than the
  110-D

31
Heatguard 115-D

• Temperature range of 35C - 49C
• The 115-D features a 30 GPM flow rate at 45 PSI,
  making it suitable for large applications
• Listed by IAPMO (cUPC) and ASSE 1017

32
Heatguard 115-D Flow Rate
33
Heatguard 110-H, 115-H

• Temperature Actuated Mixing Valve
• For domestic heating applications

34
Heatguard 110-H, 115-H

• Temperature range of 35C - 60C
• Features a high flow rate that reduces pressure
  loss within the system
• Listed by cUPC and ASSE 1017

35
Heatguard 110-H Flow Rate
36
Heatguard 145Point of use device designed to
supply a single outlet.
37
Heatguard 145

• Temperature range of 35C - 46C
• Compact design for point-of-use applications
• Features flow rates as low as 0.5 GPM for stable
  operation
• Listed by cUPC and ASSE 1016-T

38
Heatguard 145 Flow Rate
39
Heatguard 160Delivers a constant mixed water
temperature to one or more outlets
40
Heatguard 160

• Temperature range of 35C - 46C
• Available with 4 in 1 service fittings which
  provide for an easier, more flexible installation
• Designed for outlets that require a high level of
  protection
• Listed by UPC, ASSE 1016, and CSA (B-125).

41
Heatguard 160 Flow Rate
42
Heatguard 160 4in1 Flow Rate
43
Masterguard Series
44
Masterguard

• 6 High Flow rate central mixers (810, 820, 830,
  840, 850, 860)
• Sizes ranging from ¾ to 2
• Flow rates up to 150 GPM
• Controlled temperature to 49C
• Installed at heat source
• Complete with 4 in 1 service fittings

45
Masterguard Flow Rate (810-860)
46
Heatguard Temperature Actuated Flow Reducer

• Fit most showers faucets, and baths
• Perfect for remodeling applications
• Install directly into the showerhead or tap

47
Heatguard Temperature Actuated Flow Reducer

• Maximum temperature of 85C
• Maximum operating pressure of 145 PSI
• Certified to UPC, IAPMO, CSA, and ASSE 1062

48
Heatguard Fittings

• Kits contain three fittings of the selected type
• Fitting kits include sweat, barb for PEX,
  compression, threaded (NPT), and CPVC
• All fittings kits have option of purchasing with
  check

49
Cash AcmeThermostatic Mixing ValvesProduct
Features

• ISO 9001 Manufacturing Standard
• Fully certified ASSE / IAPMO / CSA / State of
  Mass.
• 100 factory tested
• Accurate temperature delivery
• Shut down on cold water failure
• Adjustable and lockable / tamper resistant
• Set in factory
• Integral unions
• Variable connections
• sweat / compression / barb / threaded / CPVC / 4
  in 1

50
Troubleshooting
51
Troubleshooting Contd
52

• STANDARDS
• ASSE 1017 Thermostatic Control Valves
  Self-Activated For Primary Domestic Use
• Located At The Heat Source
• Minimize Fluctuating Pressure Differentials
• Monitor Mixed Water Temperature
• Final Temperature Control Required At Fixture
  Outlet
• Protects outlet on cold water failure

53
STANDARDS ASSE 1016 Thermostatic / Pressure
Balance Combination -T -P.B. Primary For
Showers / Tubs / Sinks Maintain Temp Within
3F (1.7C) Adjustable Maximum Setting Cold
Water Failure Tested
54
OTHER STANDARDS ASSE 1062 TAFR - End of
Line Reduce From To Less Than .25 GPM Within 5
Seconds Point Of Use Single Fixture ASSE 1066
Pressure Balance In Line Valves Individual
Fixtures Reduce From To Less Than .5 GPM
55
NEW STANDARDS

• ASSE 1069
• Thermostatic For Group Fixture
• Final Temperature Control
• (Mix 160 / Shower)
• ASSE 1070
• Thermostatic for a Single Fixture
• Final Control or tempered downstream
• (Mix 145)

56
STORE HIGHDISTRIBUTELOW
57
THANK YOUCash Acme Canada1120
Michèle-Bohec BlvdBlainville QC J7C 5N5
