ASE101 Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables
Jeffrey Wong Consultant, Anton Ventures wongjtf_at_ao
l.com August 15-19, 2004
2
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Overview
• Limitations of other database performance
  monitoring approaches
• Limitations of this approach to database
  performance monitoring
• Typical uses for the real-time (RT) MDA database
  system
• Developmental timeline
• Architecture of the RT MDA database system
• Barrier synchronized time base and surrogate key
  equivalence
• Fast insertion mechanism for capturing MDA table
  output
• 2NF normalization and surrogate key substitution
  of foreign keys
• Stored procedure generation from specification
  files
• Restart of capture or archiving DML after
  deadlock victim termination
• Visualization of archived MDA performance data
• Visualization examples (3)
• Futures
• References
• Questions and answers

3
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Limitations of other database performance
  monitoring approaches
• Network Packet Sniffing Limited to
  request-response measurements. No information on
  Sybase internals efficiency
• Sampling via Separate Monitoring Process
  Separate process introduces latency effects. Can
  be highly invasive for short sampling periods
  (typically, anything less than 10 seconds). IPC
  (inter process communication) overheads can be
  significant. Typically, no synchronized time base
  for collected samples
• System Performance Report Typically, output is
  not in data-mining-friendly (i.e. tabular)
  format. Highly invasive for any sampling period
  less than two minutes
• Ad-hoc Measurements May not be monitoring the
  correct indicators. Very heavily dependent on the
  analysts skill level

4
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Limitations of this approach to database
  performance monitoring
• MDA Table Queries Hang at High CPU Utilization
  Levels This is a current limitation of the CIS
  proxy table mechanism upon which the MDA tables
  are based
• Specialized Resource Needs Ideally, both tempdb
  and the RT data capture database need to be on
  RAM disk, with the RT data capture database also
  requiring battery backup of its RAM disk. Next
  best would be configuring a named cache for
  tempdb and RAM disk hosting for the tempdb
  transaction log
• Lower Limit to Sampling Granularity Due to
  various technical considerations (including
  excessive resource utilization of CPU and disk),
  the current lower limit for the sampling
  periodicity is 5 seconds (c.f. MDA table minimum
  sampling periodicity of 1 second)
• Counter Wraparound Steady-state averaging
  technique was employed to estimate a counter
  value where that counter value had overflowed and
  wrapped around. This may or may not always be the
  correct technique to use

5
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Typical uses for the real-time (RT) MDA database
  system
• System Instability Root Cause Analysis The RT
  MDA database system was first deployed on a
  warm-standby replication reporting subsystem
  which had been experiencing intermittent
  stability issues. The two root causes of system
  instability were rapidly identified using this
  analysis system
• Capacity Planning and System Performance
  Monitoring Actual resource utilization of a
  business intelligence and data mining vendor
  application was quantified by the RT MDA database
  system, prior to its introduction on a 7x24 OLTP
  production system. The new application was
  subsequently monitored by the RT MDA database
  system to certify that it exhibited appropriate
  resource utilization in production
• System Performance Characterization System
  performance characteristics of 8 7x24 OLTP
  production systems are being collected by the RT
  MDA database system, prior to these 8 systems
  being consolidated on a 4 node cluster hardware
  system. The data collected by the RT MDA database
  system will be used to appropriately size and
  configure HA resource groups for that cluster

6
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Developmental Timeline
• April, 2003 Release of ASE 12.5.0.3 ESD 1 (MDA
  Tables release). Commenced private RD into MDA
  Tables functionality
• July, 2003 Commenced private development of RT
  MDA database system V1.0. This version of RT was
  single channel with a capture database and time
  base / surrogate key generator
• September, 2003 Deployment of RT MDA V1.0 to a
  production site (first commercial use). Commenced
  private development of RT MDA V1.1 Multi-channel
  for both capture and archiving databases, bit-map
  barrier synchronization for both capture and
  archiving, monitoring profiles, and
  capture/archiving stored procedure generation
  from specification templates
• January, 2004 Deployment of RT MDA V1.1 to a
  production site
• March, 2004 Commenced joint development of RT
  MDA V1.2 (visualization and capacity
  planning/system performance characterization)
• April, 2004 Deployment of RT MDA V1.2
  (visualization) to a production site
• June, 2004 Deployment of RT MDA V1.2 (capacity
  planning/system performance characterization) to
  a production site

7
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Architecture of the RT MDA database system

8
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Architecture of the RT MDA database system
  (continued)
• Transitions Description
• Transition A Parallel capture of MDA table data
  synchronized on a standardized time base / sample
  number identification pair
• Transitions B, C, D Capture stored procedures
  perform parallel inserts into the capture
  database. Tempdb is used to perform fast
  enumeration of capture data, such that for any
  capture data set, each row contains a
  monotonically increasing unique identifier. Each
  capture stored procedure schedules itself in a
  sleep-retry loop, if there is no data to process
• Transition E Parallel archiving and purge of
  captured MDA table data synchronized on user
  configured archiving and purging time intervals
• Transitions F, G, H, I Archive / purge stored
  procedures perform parallel inserts into the
  archive database when archiving, and parallel
  deletes into the capture and archive databases
  when purging. Tempdb is used to perform fast
  enumeration of filtered capture data, such that
  for any archive data set, each row contains a
  monotonically increasing unique identifier. Each
  archive / purge stored procedure schedules itself
  in a sleep-retry loop, if there is no data to
  process

9
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Architecture of the RT MDA database system
  (continued)
• Transitions Description (continued)
• Transitions J, K Time base trigger fires for
  each generated time base / sample number
  identification pair stored in the capture
  database, thereby ensuring that the time base
  history tables in the capture and archive
  databases are kept completely in sync
• Transition L Every day at 1 AM, a batch job is
  executed that encapsulates the previous days
  archive data into a set of time-stamped,
  time-series visualization tables and views
• Transitions M, N Data mining is performed on
  extracted time-series visualization data at the
  operations analysts convenience. Currently,
  unsophisticated visualization is carried out
  using Microsoft Excel (using its in-built
  charting module). It is intended in the future to
  extend the scope of the visualization to
  encompass other OLAP/BI tools (such as Impromptu)

10
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Barrier Synchronized Time Base and Surrogate Key
  Equivalence
• Barrier synchronization can handle up to 64
  parallel channels
• Most capture barrier synchronization is at one
  hierarchical level only, except for process
  monitoring which is at two hierarchical levels
  (this was done to enforce strict correlation
  between MDA process monitoring tables, albeit at
  the expense of introducing a one second time skew
  between sampling the process lookup table, and
  sampling the other process monitoring tables)
• The time base generation is also barrier
  synchronized, and is currently set for 15 second
  sampling intervals
• At the instant the current time base is
  synthesized, a monotonically increasing, unique
  surrogate key (identifier) is assigned to that
  time base. This surrogate key is the sample
  number for this particular parallel sampling
  activity
• Also at the instant the current time base is
  synthesized, it, along with the sample number,
  initial time base indicator and sampling
  interval, are written to the capture time base
  history table (NB This table forms the
  time-series frame of reference for the parallel
  capture activities of the RT MDA database system)

11
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Fast Insertion Mechanism for Capturing MDA Table
  Output
• The quantity of data output from MDA tables in a
  short period of time can be quite significant.
  For example, a trial deployment of RT MDA V1.0
  filled up 3 GB of disk in only one hour. There
  was only moderate activity on this target system,
  sampling intervals were 15 seconds, and only 4
  MDA tables were being monitored
• Consequently, the following techniques were
  employed to ensure that capture database table
  insertion was as fast as possible
• Most RT MDA tables are defined to use allpage
  locking, with SQL command retry used to recover
  from non-clustered index deadlocks
• All DML to the capture or archive databases is
  done through highly-optimized (TransactSQL)
  stored procedures
• Surrogate key updating of the control table is
  done once, at the end of the set insert composite
  transaction
• Minimally logged insert commands (select into)
  are used to insert data into the tempdb staging
  tables
• Set insert commands are used to insert the
  staging table rows into the respective capture
  database tables
• Tempdb has been configured on each database
  server that is being monitored, as having both a
  bound named data cache and a transaction log
  hosted on RAM disk

12
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• 2NF Normalization and Surrogate Key Substitution
  of Foreign Keys
• As discussed earlier, the volume of information
  that needs to be stored when building a database
  repository from sampled MDA table data, can be
  significant
• Hence, for V1.1 of the RT MDA database system, an
  archive database was introduced, along with a
  parallel time base synchronization mechanism
• This archive database contains 2NF versions of
  the data tables of the capture database, along
  with associated domain tables
• The domain tables contain the original column
  data as captured from the MDA tables, along with
  associated surrogate keys
• Part of the parallel archiving process involves
  substitution of the original MDA column data with
  the associated surrogate key. These surrogate
  keys now act as foreign keys for the 2NF data
  tables of the archive database
• The space savings accomplished by the above
  strategy are substantial. Currently, RT MDA V1.1
  can handle 7x24 capture and archiving with up to
  30 parallel channels on a 15 second cyclical
  sampling duration and a rotating 8 day archiving
  window with minimal invasiveness to the host OLTP
  system and with modest disk needs (3GB capture
  db, 6GB archive db)

13
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Stored Procedure Generation from Specification
  Files
• Given the performance and non-invasive
  requirements for the RT MDA database system, it
  is mandatory that the capture, archive,
  normalization and purge operations be performed
  via stored procedure executions
• However, the tedious and error-prone nature with
  manually encoding these stored procedures
  necessitated a more accurate and efficient
  process for generating these database objects
• Thus initially, the manual encoding process was
  performed for a representative MDA table, and for
  capture, archive, normalization and purge
  activities
• Then, the finished set of four stored procedures
  was parameterized and encoded as three perl
  template programs (NB archive and normalization
  activities were merged together)
• Three configuration files were then constructed,
  with each non-blank line of the files containing
  the parameter information for a particular stored
  procedure

14
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Stored Procedure Generation from Specification
  Files (continued)
• The above mentioned perl programs were next run
  with the respective configuration files, thereby
  producing the deployment source code for the RT
  MDA database system stored procedures
• Installation and unit testing of the generated
  stored procedures was then carried out on a
  development system
• Finally, the tested stored procedures were
  deployed on target production database servers
  and carefully monitored for possible malfunction

15
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Restart of Capture or Archiving DML After
  Deadlock Victim Termination
• Given that most tables in the RT MDA capture
  database are of allpage locking (for performance
  reasons), the inclusion of deadlock retry logic
  is mandatory due to the distinct possibility of
  non-clustered index deadlocks occurring during
  normal operation
• Initial implementation involved using a C or
  sybperl program per channel to re-submit the RT
  MDA stored procedure for execution automatically
  upon detection of the deadlock. However, this
  approach was abandoned due to logistic reasons
  (i.e. installing system software on multiple
  production systems requires significant
  commitment from outside groups for any large
  organization)
• Current implementation involves a perl program
  per channel performing re-submittal of a shell
  script for execution automatically upon detection
  of the deadlock. The shell script in turn calls
  up the RT MDA stored procedure via isql
• Future plans involve adapting Jean-Paul Martins
  asemon-logger Java program to provide the same
  functionality that was initially implemented to
  handle the non-clustered deadlock issue

16
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Visualization of Archived MDA Performance Data
• Current methodology is simply applying Microsoft
  Excels charting module to RT MDA archive data
  extracted using custom visualization views
• Major limitation of this approach is that there
  is no easy way to prevent the charting module
  from auto scaling the chart axes (especially the
  Y-axis), thus distorting the relevancy of the
  visualization
• Advantages of this approach include easy
  auto-filtering of column data, easy chart type
  composition, and fast charting performance (when
  the chart data is taken from a flat file rather
  than dynamically through a database connection)
• A recent discovery has been the existence of
  Jean-Paul Martins asemon Java GUI program for
  display of MDA table data in a tabular format.
  Consequently, the current focus for visualization
  has been temporarily shifted to adaptation of
  this program to access RT MDA capture and archive
  databases (rather than further development of the
  Microsoft Excel approach)
• Three visualization examples have been included
  in this presentation to show the effectiveness of
  the Microsoft Excel approach to date

17
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Visualization Example 1 (disk activity)

18
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Visualization Example 2 (engine activity)

19
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Visualization Example 3 (buffer pool activity)

20
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Visualization Example 3 (buffer pool activity,
  continued)

21
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Futures (in no particular order)
• Adaptation of the RT MDA database system to
  utilize other data mining/BI GUI tools (such as
  Impromptu)
• Adaptation of Jean-Paul Martins asemon Java GUI
  program to visualize data contained in both the
  RT MDA capture and archive databases
• Adaptation of Jean-Paul Martins asemon-logger
  Java program to utilize the barrier
  synchronization and capture/archive stored
  procedures of the RT MDA database system
• Implementation of missing value simulation and
  time axis normalization in the RT MDA archive
  database
• Design and implementation of event notification
  triggers in the RT MDA capture database. It is
  intended to integrate these notification triggers
  into the resource group failover mechanism of a
  well-known hardware vendors cluster computing
  system
• Integration of Replication Server into the RT MDA
  database, so that the RT MDA archive,
  normalization and purge operations can be handled
  by DSI invocation of custom function strings
• Integration of Replication Server 12.5
  performance counters into the RT MDA database
  system

22
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• References
• Whats new in ASE 12.5.0.3 Sybase Incorporated
  (the original reference for MDA Tables
  functionality)
• http//www.sypron.nl (Rob Verschoors Web site
  more information of MDA Tables setup and usage)
• http//www.sybase.com/developer/codexchange
  (source code for Jean-Paul Martins asemon and
  David Owens sybmon Java GUI monitoring programs
  are available at this Web site)
• Tips, Tricks Recipes for Sybase ASE Rob
  Verschoor (where some components of the fast
  insertion mechanism for MDA table data capture
  were initially discussed)
• Predictive Data Mining, A Practical Guide
  Sholom M. Weiss, Nitin Indurkhya (background
  information on data mining techniques)
• Data Mining and Statistical Analysis Using SQL
  Robert P. Trueblood, John N. Lovett, Jr. (data
  mining statistical analysis queries using
  Transact-SQL)

23
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables

• Questions and Answers
• We have 10 minutes for QA. Please feel free to
  ask. Thank you
• I will defer the difficult questions for when the
  10 minute period has expired (your schedule
  permitting)
• Any questions that I cannot answer I will try to
  do so later via email, time permitting. Please be
  so kind as to leave me your email address in this
  case
• My email address is wongjtf_at_aol.com. If you still
  have questions regarding this presentation,
  kindly send me a note and I will respond as soon
  as I can. Thanks

24
Building a Real-Time Database Performance
Repository Using the Sybase MDA Tables
Jeffrey Wong Consultant, Anton Ventures wongjtf_at_ao
l.com August 17, 2004
