Title: shanmu


1
NUCLEIC ACID
2
NUCLEIC ACID
  • Nucleic acids are biological macromolecules
  • They are members of a family of biopolymers
    essential for life, and include DNA and RNA
  • nucleic acids function in encoding, transmitting
    and expressing genetic information.
  • Nucleic acids were first discovered by Friedrich
    Miescher in 1871.

3
Molecular composition
  • Each nucleotide consists of three components a
    purine or pyrimidine nucleobase, a pentose sugar,
    and a phosphate group.
  • The sugars and phosphates are connected to
    phosphodiester linkages

4
DNA RNA
5
(No Transcript)
6
(No Transcript)
7
Pirimidine and Purine bases
  • Pyrimidine and Purine are heterocyclic aromatic
    organic compound
  • Pirimidine basesCytosin,Urasil and Thymine
  • Purine basesAdinine and guanine

8
Adininine
  • Adenine (a purine derivative) 9H-purin-6-amine
  • A chemical component of DNA and RNA.
  • The shape of adenine is complementary to either
    thymine in DNA or uracil in RNA.

9
Guanine
  • Guanine (a purine derivative)
  • found in DNA and RNA
  • guanine is only paired with cytosine.
  • 2-amino-6-hydroxypurine

10
Cytosine
  • Cytosine found in DNA and RNA
  • It is a pyrimidine derivative
  • It forms three hydrogen bonds with guanine
  • 4-amino-1H-pyrimidine-2-one

11
Thymine
  • Thymine (pyrimidine nucleobase) found only in DNA
  • Thymine is also known as
    5-Methylpyrimidine-2,4(1H,3H)-dione
    (5-methyluracil)
  • Thymine (T) binds to adinine (A) via two hydrogen
    bonds

12
Uracil
  • Uracil (pyrimidine derivative) found only in RNA.
  • uracil (U) binds to adenine (A) via two hydrogen
    bonds.
  • 2,4-dihydroxypyrimidine

13
(No Transcript)
14
Phosphodiester bond
  • A phosphodiester bond is a group of strong
    covalent bonds between a phosphate group and two
    5-carbon ring carbohydrates (pentoses) over two
    ester bonds.

15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
Chargaffs Rules
  • Erwin Chargaff (1947) provides more evidence that
    DNA genetic material
  • Analysis of base composition of DNA compared
    between different organisms
  • Nitrogenous bases
  • Adenine (A)
  • Thymine (T)
  • Guanine (G)
  • Cytosine (C)
  • Conclusions of Chargaff
  • DNA composition is species specific
  • The amounts of A,G,C and T are not the same
    between species
  • Ratios of nitrogenous bases vary between species

19
(No Transcript)
20
Deoxyribonucleic acid
  • DNA contains the genetic instructions used in the
    development and functioning of all known living
    organisms.
  • The main role of DNA molecules is the long-term
    storage of information
  • DNA is often compared to a set of blueprints,
    since it contains the instructions needed to
    construct other components of cells, such as
    proteins and RNA molecules.
  • The DNA segments that carry this genetic
    information are called genes

21
Structure of DNA
  • DNA consists of two long polymer of simple units
    called nucleotides, with backbones made of sugars
    and phosphate groups joined by ester bonds.
  • These two strands run in opposite directions to
    each other and are therefore anti-parallel.
  • Attached to each sugar is one of four types of
    molecules called nucleobases
  • It is the sequence of these four nucleobases
    along the backbone that encodes information.

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
DNA Double Helix
  • The easiest way to visualize DNA is as an
    immensely long rope ladder, twisted into a
    cork-screw shape.
  • The sides of the ladder are alternating
    sequences of deoxyribose and phosphate (backbone)
    while the rungs of the ladder (bases) are made in
    two parts with each part firmly attached to the
    side of the ladder.
  • Although most DNA exists as open ended double
    helices, some bacterial DNA has been found as a
    cyclic helix.

26
Properties
  • DNA is a long polymer made from repeating units
    called nucleotides
  • DNA of all species comprises two helical chains
    each coiled round the same axis, and each with a
    pitch of 34 Å and a radius of 10 Å
  • DNA does not usually exist as a single molecule,
    but instead as a pair of molecules that are held
    tightly together
  • The DNA double helix is stabilized primarily by
    two forces hydrogen bonds between nucleotides
    and base-stacking interactions among the aromatic
    nucleobases

27
Grooves
  • Grooves are spaces between the strands
  • These voids are adjacent to the base pairs and
    may provide a binding site
  • The major groove, is 22 Å wide and the minor
    groove, is 12 Å wide

Major and minor grooves of DNA
28
Alternate DNA structures
  • DNA exists in many possible conformations that
    include A-DNA, B-DNA, and Z-DNA forms

  A, B and Z DNA
29
Form Direction Bases/360o Turn HelixDiameter
A Right 11.0 23A
B Right 10.0 19A
Z Left 12.0 18A
30
(No Transcript)
31
DNA replication
32
Transcription
Initiation Elongation Termination
33
Translation
34
(No Transcript)
35
(No Transcript)
36
RNA
37
Ribonucleic acid
  • RNA is made up of a long chain of components
    called nucleotides.
  • The sequence of nucleotides allows RNA to encode
    genetic information.
  • All cellular organisms use messenger RNA (mRNA)
    to carry the genetic information that directs the
    synthesis of proteins.
  • In addition, some viruses use RNA instead of DNA
    as their genetic material perhaps a reflection
    of the suggested key role of RNA in the
    evolutionary history of life on Earth.

38
(No Transcript)
39
(No Transcript)
40
Synthesis of RNA
  • Synthesis of RNA is usually catalyzed by an
    enzymeRNA polymeraseusing DNA as a template, a
    process known as transcription.
  • The DNA double helix is unwound by the helicase
    activity of the enzyme.
  • The enzyme then progresses along the template
    strand in the 3 to 5 direction, synthesizing a
    complementary RNA molecule with elongation
    occurring in the 5 to 3 direction.
  • The DNA sequence also dictates where termination
    of RNA synthesis will occur

41
Types of RNA
  • Messenger RNA (mRNA)
  • Transfer RNA (tRNA)
  • Ribosomal RNA (rRNA)

42
mRNA
  • Messenger RNA is a molecule of RNA encoding a
    chemical "blueprint" for a protein product.
  • mRNA is transcribed from a DNA template, and
    carries coding information to the sites of
    protein synthesis the ribosomes.
  • In mRNA as in DNA, genetic information is encoded
    in the sequence of nucleotides arranged into
    codons consisting of three bases each.

43
(No Transcript)
44
tRNA
  • Transfer RNA is an adaptor molecule composed of
    RNA, typically 73 to 93 nucleotides in length,
    that is used in biology to bridge the
    three-letter genetic code in messenger RNA with
    the twenty-letter code of amino acids in
    proteins.
  • One end of the tRNA carries the genetic code in a
    three-nucleotide sequence called the anticodon.
    The anticodon forms three base pairs with a codon
    in mRNA during protein biosynthesis.

45
rRNA
  • Ribosomal ribonucleic acid is the RNA component
    of the ribosome.
  • Ribosomal RNA provides a mechanism for decoding
    mRNA into amino acids and interacts with tRNAs
    during translation by providing peptidyl
    transferase activity.

46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
Mutations
In biology, mutations are changes to the base
pair sequence of genetic material (either DNA or
RNA). Mutations can be caused by copying
errors in the genetic material during cell
division and by exposure to ultraviolet
or ionizing radiation, chemical mutagens, or
viruses, or can occur deliberately under cellular
control during processes such as meiosis or
hypermutation
50
The genetic material (DNA) of a cell can become
damaged or changed. This damage produces
mutations (DNA changes) that affect normal cell
growth and division. When this happens, cells do
not die when they should and new cells form when
the body does not need them. The extra cells may
form a mass of tissue called a tumor.
51
Genetic engineering
  • Genetic engineering is a scientific development
    that involves the artificial manipulation of an
    organism's genes by using techniques such as
    molecular cloning and transformation in order to
    alter their nature and structure.
  • Many of these transformations are achieved by
    manipulation of an organism's DNA, which
    effectively is the code inscribed in every cell
    to determine how it will function.

52
(No Transcript)
