CSC 8310 Linguistics of Programming Languages

1
CSC 8310 Linguistics of Programming Languages

• Fall 2009
• Instructor Vijay Gehlot
• Week 2

2
Phases/Components of Compiler
Source
Tokens
AST
1. Scanner (Lexical Analyzer)
2. Parser (Syntax Analyzer)
3. Semantic Analyzer
AnnotatedAST
Intermediate Code
Machine Code
Target
Other Components Symbol Table and Error Handler
1-3
Analysis Phase, 4-7 Synthesis Phase, 1-5 Front
End, 6-7 Back End
3
1. Scanner (Lexical Analyzer)

• Remove white spaces and comments
• Tokenize (group into meaningful pieces)
• Handle lexical errors (this is the first stage in
  compilation from which we get compilation error)
• Tokens may have values
• Token id (identifier)
• Token value e.g. x

4
2. Parser (Syntax Analyzer)

• Checks whether sequence of tokens conforms to the
  (syntactic) rules of the language.
• E.g. ab each token is valid but the sequence is
  not
• Handle syntax errors
• Uses Context Free Grammar (CFG) defined later

5
3. Semantic Analyzer (Type checker)

• Type checking
• Other semantic checking
• Unbound/undeclared variable
• Multiply defined names
• Uninitialized variable

6
4-5. Intermediate Code Generator and Optimizer

• Many forms
• Machine independent optimization
• Algebraic simplification
• Optional component

7
6-7. Code Generator and Optimizer

• Target specific architecture
• Machine dependent optimization
• Specialized instructions
• Optimization optional
• Examples code and optimization (Java/C)

8
Languages

• Any language has
• Syntax
• Described using a formal notationContext Free
  Grammar (CFG)
• Specialized notation called Regular Expressions
  can be used for lexical syntax, i.e., tokens
• Semantics
• Many different ways
• Operational, Axiomatic, Denotational

9
Context Free Grammar (CFG)

• Derivations
• Parse trees
• Abstract syntax trees (ABS)
• Ambiguity (Syntactic)
• BNF (Backus Naur Form), EBNF (Extended Backus
  Naur Form), Syntax diagrams

10
Definition of Context Free Grammar

• Definition A CFG consists of
• A finite set of non-terminal symbols (N)
• A finite set of terminal symbols (tokens) (T)
• A distinguished start symbol S from N
• A finite collection of rules (or productions) of
  the form
• X ? A1 A2,An where
• X is from N,
• Ai is from N or T, n0,
• if n0 then write Ai ? e

11
One Step Derivation

• Definition Given a sequence of symbols
• A1 A2 Ai Ak
• If Ai ? B1 B2 Bj is a production,
• then we can obtain
• A1 A2Ai-1 B1 B2 Bj Ai1 An
• in one step.
• We denote it as
• A1 A2 Ak gt A1 A2Ai-1 B1 B2 Bj Ai1 An

Ai
12
Derivation Sequence

• Definition
• Let S be the start symbol.
• Let t1 t2 ti be sequence of terminal symbols
  (tokens, a program).
• A derivation sequence for t1 t2 ti is a sequence
  of one step derivations that starts with S and
  ends with t1 t2 ti .

13
Definition of Parsing

• Definition A sentence (sequence of terminal
  symbols) is syntactically valid if there is a
  derivation sequence for it.
• Typically choice of nonterminals to be expanded
• Two canonical ways
• Leftmost expand leftmost nonterminal at each
  step
• Rightmost expand rightmost nonterminal at each
  step
• Correspond to Top-down and Bottom-up parsing

14
Types of Parsers

• Top down parser
• Mimics leftmost derivation
• Bottom up parser
• Mimics rightmost derivation in reverse
• Top down parsers cannot handle left recursion.
• These are deterministic parsers.
• General parsing is expensive and not practical

15
Parse Trees

• Definition Parse Tree is a tree such that
• all interior nodes are labeled from (N)
• root labeled with S (start symbol)
• all leaves are labeled from (T)
• if X
• A1 A2 Ai Ak
• where X is a nonterminal and Ais are terminals or
  non terminals, then
• X ? A1 A2 Ai Ak
• must be a production.

16
Parse Trees (cont.)

• Definition t1 t2 tn is valid if there is a
  parse tree whose leaves spell t1 t2 tn when
  read left to write.
• Can be constructed from derivation or directly.

17
Ambiguity

• Definition A CFG is ambiguous if there is at
  least one sentence for which there is more than
  one leftmost (or rightmost) derivations or parse
  trees.
• Should be avoided
• No general algorithm
• Typically has to do with grouping
• Can rewrite or redefine syntax
• Pros/Cons

18
AST

• Definition Abstract Syntax Tree (AST) is a tree
  in which interior nodes are operations and
  children are operands.
• while (condition) body

19
Other Approaches for Describing Syntax

• BNF
• EBNF All are equivalent to
  CFG
• Syntax Diagrams
• Some actual examples
• http//java.sun.com/docs/books/jls/second_edition/
  html/grammars.doc.html44271
• http//www.scheme.com/tspl2d/grammar.htmlg2488
• http//www.schemers.org/Documents/Standards/R5RS/H
  TML/r5rs-Z-H-10.html_chap_7

20
ANTLR Tool

• Parsers can be automatically generated from a CFG
  description
• ANTLR is one such tool that generates a
  (recursive descent) parser (in Java by default)
• Other tools Yacc, Bison, SableCC, JavaCC,
  MLYacc, etc.

ANTLR Tool
Grammar file
Java Code
21
ANTLR Tool

• Allows EBNF.
• Is in LL category and hence cannot handle
  right-recursive grammar rules
• Has a GUI-based grammar development environment
  called ANTLRWorks
• Includes automatic transformation of
  right-recursive rules

22
ANTLR Grammar File Format

• Simplified version
• grammar name
• / Comment Lexical Rules (Tokens).
• Token names must begin with an uppercase
  letter /
• RULE1 ...
• RULE2 ...
• ...
• / Comment Syntax Rules.
• Non-terminals must begin with a lowercase
  letter /
• rule1 ... ... ...
• rule2 ... ... ...
• ...

23
ANTLR Output

• From a grammar named T in file T.g it generates
• TLexer.java
• TParser.java
• T.tokens
• ANTLR generates a method for each rule in a
  grammar.
• The methods are wrapped in a Java class
  definition (Tparser.java).
• ANTLR provides named actions so you can insert
  fields and instance methods into the generated
  class definition. E.g.,
• grammar T
• _at_header import java.util.
• _at_members
• int n
• public void foo() ...

24
ANTLR Output

• Compile the generated files. Make sure the ANTLR
  jar file is on classpath
• To use
• import org.antlr.runtime.
• public class Test
• public static void main(String args) throws
  Exception
• ANTLRInputStream input new ANTLRInputStream(Sys
  tem.in)
• TLexer lexer new TLexer(input)
• CommonTokenStream tokens new
  CommonTokenStream(lexer)
• TParser parser new TParser(tokens)
• parser.rule1() // invoke method associated with
  the start symbol
